Date: 28 Sep 2020 Product Manual for Gaming Headset Model: RZ04-0347 . FOR GAMERS. BY GAMERS. ™ 1 WHAT’S INSIDE / WHAT’S NEEDED WHAT’S INSIDE  Gaming Headset (Model: RZ04-0347) A. EQ / Xbox Pairing button B. Game / Chat balance wheel C. Bluetooth / Multi-function button D. Adjustable padded headband E. Breathable memory foam ear cushions F. Earcups powered by Razer Chroma TM G. Mic mute switch H. Volume wheel I. Status indicator J. Power button K. Charging port L. Microphone jack M. Mic diaphragm  Charging cable  Removable Razer™ HyperClear Supercardioid Mic  Important Product Information Guide WHAT’S NEEDED PRODUCT REQUIREMENTS  Xbox One TM / Xbox One TM S / Xbox One TM X / Xbox Series TM X LEFT RIGHT FOR GAMERS. BY GAMERS. ™ 2 OR  PC (Windows® 10 64-bit or higher) with a free USB port* OR  Devices with Bluetooth 5.0 connectivity RAZER HEADSET SETUP FOR XBOX APP REQUIREMENTS  PC or Xbox console  Internet connection for app installation RAZER AUDIO COMPANION APP REQUIREMENTS  iOS or Android device with Bluetooth connectivity  Internet connection for app installation *May require the Xbox Wireless Adapter for Windows 10 (not included). SAFETY STATEMENT IMPORTANT! Before using your Xbox console with this product, read its instruction manual for safety, health, and other information regarding the use of your Xbox console. LET’S GET YOU COVERED You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com FOR GAMERS. BY GAMERS. ™ 1 Got a question? Ask the Razer Support Team at support.razer.com Your product’s serial number can be found here. [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 2 GETTING STARTED CHARGING YOUR HEADSET Connect your Gaming Headset (Model: RZ04-0347) to a powered USB port using the charging cable. For best results, please fully charge your headset before using it for the first time. A depleted headset will fully charge in about (x) hours. Once fully charged, your Gaming Headset (Model: RZ04-0347) will briefly show its battery level on the status indicator. Indicator Battery level Charging Fully charged [IMAGE PLACEHOLDER] [IMAGE PLACEHOLDER] Type C FOR GAMERS. BY GAMERS. ™ 3 PAIRING YOUR HEADSET A. TO YOUR XBOX CONSOLE 1. Press the Connect button on your console. 2. Press and hold the power button until the status indicator is briefly lit or until you hear a tone to power on the headset. 3. Press and hold the EQ / Xbox Pairing button until the status indicator is blinking green to activate Xbox pairing mode. The status indicator will then turn static green to indicate that the headset is now paired to the Xbox console. [IMAGE PLACEHOLDER] Indicator Status Pairing Connected [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 4 B. TO YOUR PC VIA XBOX WIRELESS ADAPTER FOR WINDOWS 10* Make sure that your Xbox Wireless Adapter for Windows 10 is up-to-date. Some systems have Xbox Wireless built in which allows you to pair your headset by using Add a device in Settings. 1. Plug in your Xbox Wireless Adapter for Windows 10* to your PC and then press its Connect button. 2. While powered on, press and hold the EQ / Xbox Pairing button until the status indicator is blinking green to activate Xbox pairing mode. The status indicator will then turn static green to indicate that the headset is now paired to the wireless adapter. Indicator Status Pairing Connected [IMAGE PLACEHOLDER] [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 5 C. TO YOUR MOBILE DEVICES VIA BLUETOOTH While powered on, press the Bluetooth / Multi-function button until the status indicator is lit or until you hear a tone to activate Bluetooth pairing mode. Follow your device’s instructions to pair it with your headset. Once the headset is paired, the status indicator will briefly change to static blue. [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 6 USING YOUR GAMING HEADSET (MODEL: RZ04-0347) POWER BUTTON Power ON / OFF Power on or off your headset by holding the power button until the status indicator is on; and holding the button again to turn off. Two distinct tones will help notify you that the headset is powered on or off. Changing Earcup Lighting When powered on, the power button can also be used to cycle between the lighting presets on the headset. Simply press the power button to change the current lighting effect on the earcups. [IMAGE PLACEHOLDER] The headset’s lighting effect can also be configured from the Razer Audio Companion app (on iOS and Android) and the Razer Headset Setup For Xbox app (on PC and Xbox console). [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 7 BATTERY LEVEL When unplugged and powered on, the status indicator will briefly show the connection and battery status. While in use, there will be a tone notification when the headset needs to be recharged; during such time, the indicator will continue showing the battery status until you charge the headset. EQ / XBOX PAIRING BUTTON Pairing Mode When pairing the headset to a different Xbox console or wireless adapter, use the EQ / Xbox Pairing button to activate Xbox pairing mode. Simply press and hold the EQ / Xbox Pairing button until the status indicator blinks in green or until you hear a tone, indicating that the headset can now be paired to a different Xbox console or wireless adapter. EQ Presets Press the EQ / Xbox Pairing button to switch between the equalizer presets available on the headset. Indicator Battery Level Critical Low Tone Warning tone Warning tone [IMAGE PLACEHOLDER] Press and hold for 6 seconds [IMAGE PLACEHOLDER] FOR GAMERS. BY GAMERS. ™ 8 [image placeholder] Preset Description Default All-around balance of audio clarity and bass Bass Boost Immerse more on solid, realistic bass FPS Hear the most subtle of footsteps sneaking from behind Custom* Your own custom balance of audio clarity *This preset will only be available when you customize a preset on the Razer Headset Setup for Xbox app or Razer Au…
