RWO-RZ150129Wireless SmartBand

0 | For gamers. by gamers™ PACKAGE CONTENTS / SYSTEM REQUIREMENTS CONTENIDO DEL PAQUETE / REQUISITOS DEL SISTEMA PACKAGE CONTENTS • Razer Nabu X (Model: RZ15-0129) • USB charging cable • Important product information guide CONTENIDO DEL PAQUETE • Razer Nabu X • Cable de carga USB • Guía con información importante del producto MINIMUM SYSTEM REQUIREMENTS • iOS 7 / Android 4.3 device • Bluetooth Smart (Bluetooth 4.0 / Bluetooth LE) REQUISITOS MÍNIMOS DEL SISTEMA • Dispositivo iOS 7 / Android 4.3 • Bluetooth Smart (Bluetooth 4.0 / Bluetooth LE) 1 | razer™ REGISTRATION / TECHNICAL SUPPORT REGISTRO / ASISTENCIA TÉCNICA REGISTRATION Sign up now for a Razer ID account to get real-time information on your product’s warranty status. To learn more about Razer ID and all its features, visit www.razerzone.com/razer-id. If you are already a Synapse user, register your product by clicking on your email address at the Synapse application and select Warranty Status from the dropdown list. REGISTRO Regístrate ahora en una cuenta de Razer ID para obtener información en tiempo real sobre el estado de la garantía de tus productos. Para obtener más información sobre Razer ID y todas sus características, visita www.razerzone.com/razer-id. Si ya eres usuario de Synapse, registra tu producto haciendo clic en tu dirección de correo electrónico en la aplicación de Synapse y selecciona Estado de la garantía en la lista desplegable. To register your product online, visit www.razerzone.com/registration. Please note that you will not be able to view your warranty status if you register via the website. Entra en www.razerzone.com/registration para registrar el producto en línea. Ten en cuenta que no podrás ver el estado de tu garantía si la registras a través del sitio web. Your product’s serial number can be found here El número de serie de tu producto se puede encontrar aquí. 2 | For gamers. by gamers™ TECHNICAL SUPPORT What you’ll get: • 1 year limited manufacturer’s warranty. • Free online technical support at www.razersupport.com. ASISTENCIA TÉCNICA Obtendrás: • 1 año de garantía limitada del fabricante. • Asistencia técnica gratuita en línea en www.razersupport.com. 3 | razer™ USING YOUR NABU X USO DE NABU X 1. CHARGE 1. CARGA Status Indicator Indicador de estado Battery Level Nivel de batería Fully Charged Completamente cargada <100% <100% <67% <67% 4 | For gamers. by gamers™ <30% <30% Caution: Do not leave the Nabu X charging overnight. The approximate time to fully charge the Nabu X is 2 hours. Precaución: No dejes el Nabu X cargando toda la noche. El tiempo aproximado para cargar completamente el Nabu X es de 2 horas. 2. PAIR 2. EMPAREJAMIENTO NABU X UTILIDADES Status Indicator Indicador de estado Pairing Status Estado del emparejamiento Paired Emparejado Failed Error NABU X UTILITY APP 5 | razer™ 3. WEAR 3. COMO LLEVARLO For more information, please refer to the Online Master Guide at www.razersupport.com Para obtener más información, consulta la Guía maestra online en www.razersupport.com 6 | For gamers. by gamers™ SAFETY AND MAINTENANCE SEGURIDAD Y MANTENIMIENTO SAFETY GUIDELINES In order to achieve maximum safety while using your Nabu X, we suggest that you adopt the following guidelines: 1. Should you have trouble operating the device properly, unplug and/or remove the device and contact the Razer hotline; or go to www.razersupport.com for assistance. Do not attempt to fix the device yourself. 2. Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads. 3. Charge the Nabu X in accordance with the recommended charging time and do not leave the battery charging overnight. Do not wear the Nabu X while it is charging. 4. Do not expose the Nabu X to liquids while charging. Exposing the Nabu X to these conditions may result in an electric shock. 5. The Nabu X is water resistant however, do not submerge the Nabu X in liquid for more than 30 min at a depth of more than 1 meter. 6. Do not tamper or abuse the Nabu X; including but not limited to dropping, crushing, excessive bending, puncturing, shredding, microwaving, incinerating, or inserting foreign objects into the Nabu X. 7. Do not use abrasive cleaners and/or harsh cleaning agents to clean the Nabu X. 8. Do not expose the Nabu X to extremely high or low temperatures such as leaving the Nabu X in direct sunlight or in snowy weather for extended periods of time. 9. Do not expose the Nabu X to open flames such as stoves, candles, or fireplaces. 7 | razer™ 10. Do not expose the inner band to organic solvents such as alcohol, acetone, and detergent. 11. Dispose the product in accordance with your local environmental laws and guidelines. PAUTAS DE SEGURIDAD Con el fin de tener la máxima seguridad durante el uso del Nabu X, te recomendamos seguir las siguientes directrices: 1. Si tuvieras algún problema para utilizar el dispositivo correctamente, desconéctalo y/o quítatelo y ponte en contacto con la línea de atención al cliente de Razer, o accede a www.razersupport.com para solicitar asistencia. En ningún momento intentes reparar el dispositivo por tu cuenta. 2. No desmontes el dispositivo (esto anulará la garantía) y tampoco intentes utilizarlo si la tensión eléctrica no es la normal. 3. Carga el Nabu X de acuerdo con el tiempo de carga recomendado y no dejes cargando la batería durante toda la noche. No lleves puesto el Nabu X mientras se está cargando. 4. No expongas al Nabu X a líquidos mientras se está cargando. La exposición del Nabu X a estas condiciones puede provocar una descarga eléctrica. 5. Nabu X es resistente al agua; sin embargo, no lo sumerjas en líquido durante más de 30 minutos a una profundidad de más de 1 metro. 6. No manipules ni des un mal uso al Nabu X. Esto incluye, entre otros, caídas, aplastamiento, flexión excesiva, punción, trituración, exposición a microondas, incineración o introducción de objetos extraños en el mismo. 7. No utilices productos de limpieza abrasivos …

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We, Name: Razer Inc. Address: 2035 Corte Del Nogal, Suite 101 City: Carlsbad State: California 92011 Country: United States Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: Wireless SmartBand Type designation: RZ15-0129 (FCC ID: RWO-RZ150129) Trademark: RAZER on our behalf. Date: 2014-11-25 City: Carlsbad Name: Johnsen Tia Signature: ............................... Senior Engineer

Project No.: 1411C110 Page 2 of 10 Project No.: 1411C110 Page 3 of 10

FCC ID: RWO-RZ150129 IC: 8092D-RZ150129 Product Label Label Location: Bottom of Product Product Name: Wireless SmartBand Model: RZ15-0129 Rating:5V, 40mA FCC ID: RWO-RZ150129 IC:8092D-RZ150129

Project No.: 1411C110 Page 4 of 10 Project No.: 1411C110 Page 5 of 10 Project No.: 1411C110 Page 6 of 10 Project No.: 1411C110 Page 7 of 10 Project No.: 1411C110 Page 8 of 10 Project No.: 1411C110 Page 9 of 10 Project No.: 1411C110 Page 10 of 10

FCC RF EXPOSURE REPORT FCC ID: RWO-RZ150129 Equipment : Wireless SmartBand Model : RZ15-0129 Applicant : Razer Inc. Address : 2035 Corte Del Nogal, Suite 101, Carlsbad CA 92011. USA. According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Table for Filed Antenna Ant. Manufacturer Model Name Antenna Type Connector Gain(dBi) 1 N/A ANT016008LCS2442 MA2 Internal N/A 2.50 GENERAL CONCULUSION: Maximum measured transmitter power: OutputPower (dBm) Output Power (mW) Limit (mW) -0.09 1 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 1mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold.

Report No.: BTL-FCCP-1-1411C110 Page 1 of 61 FCC Radio Test Report FCC ID: RWO-RZ150129 This report concerns (check one): Original Grant Class II Change Project No. : 1411C110 Equipment : Wireless SmartBand Model Name : RZ15-0129 Applicant : Razer Inc. Address : 2035 Corte Del Nogal, Suite 101. Carlsbad California 92011. USA Date of Receipt : Nov. 12, 2014 Date of Test : Nov. 12, 2014~ Nov. 21, 2014 Issued Date : Nov. 24, 2014 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1411C110 Page 2 of 61 Declaration BTL represents to the client that testing is done in accordance with st andard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1411C110 Page 3 of 61 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 13 4.1.5 EUT OPERATING CONDITIONS 13 4.1.6 EUT TEST CONDITIONS 13 4.1.7 TEST RESULTS 13 4.2 RADIATED EMISSION MEASUREMENT 14 4.2.1 RADIATED EMISSION LIMITS 14 4.2.2 TEST PROCEDURE 15 4.2.3 DEVIATION FROM TEST STANDARD 15 4.2.4 TEST SETUP 16 4.2.5 EUT OPERATING CONDITIONS 17 4.2.6 EUT TEST CONDITIONS 17 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 17 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 18 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 18 5 . BANDWIDTH TEST 19 5.1 APPLIED PROCEDURES / LIMIT 19 5.1.1 TEST PROCEDURE 19 5.1.2 DEVIATION FROM STANDARD 19 5.1.3 TEST SETUP 19 5.1.4 EUT OPERATION CONDITIONS 19 5.1.5 EUT TEST CONDITIONS 19 5.1.6 TEST RESULTS 19 6 . MAXIMUM OUTPUT POWER TEST 20 6.1 APPLIED PROCEDURES / LIMIT 20 Report No.: BTL-FCCP-1-1411C110 Page 4 of 61 Table of Contents Page 6.1.1 TEST PROCEDURE 20 6.1.2 DEVIATION FROM STANDARD 20 6.1.3 TEST SETUP 20 6.1.4 EUT OPERATION CONDITIONS 20 6.1.5 EUT TEST CONDITIONS 20 6.1.6 TEST RESULTS 20 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 21 7.1 APPLIED PROCEDURES / LIMIT 21 7.1.1 TEST PROCEDURE 21 7.1.2 DEVIATION FROM STANDARD 21 7.1.3 TEST SETUP 21 7.1.4 EUT OPERATION CONDITIONS 21 7.1.5 EUT OPERATION CONDITIONS 21 7.1.6 TEST RESULTS 21 8 . POWER SPECTRAL DENSITY TEST 22 8.1 APPLIED PROCEDURES / LIMIT 22 8.1.1 TEST PROCEDURE 22 8.1.2 DEVIATION FROM STANDARD 22 8.1.3 TEST SETUP 22 8.1.4 EUT OPERATION CONDITIONS 22 8.1.5 EUT TEST CONDITIONS 22 8.1.6 TEST RESULTS 22 9 . MEASUREMENT INSTRUMENTS LIST 23 ATTACHMENT A - CONDUCTED EMISSION 25 ATTACHMENT B - RADIATED EMISSION (9KHZ-30MHZ) 28 ATTACHMENT C - RADIATED EMISSION BETWEEN 30MHZ AND 1000MHZ) 30 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 37 ATTACHMENT E - BANDWIDTH 50 ATTACHMENT F - MAXIMUM OUTPUT POWER TEST 53 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 55 ATTACHMENT H - POWER SPECTRAL DENSITY TEST 59 Report No.: BTL-FCCP-1-1411C110 Page 5 of 61 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1411C110 Original Issue. Nov. 24, 2014 Report No.: BTL-FCCP-1-1411C110 Page 6 of 61 1. CERTIFICATION Equipment : Wireless SmartBand Brand Name : RAZER Model Name : RZ15-0129 Applicant : Razer Inc. Manufacturer : Razer (Asia-Pacific) Pte Ltd Address : 514 Chai Chee Lane #07-01 ~ 06 Singapore 469029 Date of Test : Nov. 12, 2014~ Nov. 21, 2014 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C :2013 (15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1411C110) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-1-1411C110 Page 7 of 61 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emission PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS 15.209/15.205 Transmitter Radiated Emis…

Text truncated - open the document above for the full version.

Project No.: 1411C110 Page 1 of 4 EUT TEST PHOTO Conducted Measurement Photos Project No.: 1411C110 Page 2 of 4 Radiated Measurement Photos 9KHz to 30MHz Project No.: 1411C110 Page 3 of 4 Radiated Measurement Photos 30M to 1000MHz Project No.: 1411C110 Page 4 of 4 Radiated Measurement Photos Above 1000MHz
