TRANSPARENT TECHNOLOGIES R2 Utility Mobile Transceiver Operations Manual Transparent Technologies, Inc 5665 Airport Blvd Boulder, CO 80301 720-406-1294 Disclaimer In no event shall Transparent Technologies be liable for any incidental, indirect, or consequential damages or other damages including without limitation loss of profits, loss of revenue, loss of data, loss of use of the product or any associated equipment, downtime, and user’s time associated with the use of this product, the resale hardware or its software. Use of Hardware In no event shall Transparent Technologies be liable for damages resulting from the use of its hardware or the malfunction of that hardware. Specifications for the hardware are subject to change at any time without notice. Copyrights /Trademarks Transparent Technologies reserves the names T2, M2 and UDA. Version R2 Version RevGc November 2007 R2 Utility Mobile Transceiver Operations Manual OVERVIEW 1 INSTALLATION & CABLING 2 ANTENNA 3 OPERATION 4 APPENDIX 5 1 1 R2 Utility Radio Transmitter The R2 Utility Mobile Transceiver is a compact, powerful transceiver used within the G2 AMR System. The R2 unit provides the ability for high-performance meter reading of the M2 endpoint radios. The R2 unit also provides the two- way capability for remote mobile configuration and datalogging of the M2 endpoint radios. Basic Specifications Transmission: Spread Spectrum Regulatory: FCC 15.247 Temperature: -40°F to 158°F (-40°C to +70°C) Submersion: Splash-proof OVERVIEW Housing: Anodized Aluminum Interface: USB 2.0 port Power: Std Vehicle 12Vdc Antenna: Omni-directional Magnetic-mount 2 1 2 1 1 2 Installation R2 Installation The R2 is designed to be temporarily or permanently mounted within a utility vehicle for the meter reading and customer service functions. The unit is small (roughly 6”x3”) and can be installed easily in a utility vehicle. Recommended placement for the R2 is in the vehicle console or on protected location on floorboard. Note: Avoid installing the R2 unit on the dashboard or other position of direct sunlight. Excessive heat from direct sunlight can cause decreased performance. Power Cable The R2 unit will have connection for the vehicle power supply. This connection is a DC power plug that is designed for a vehicle lighter outlet or DC outlet. The power cable is fused with a 1A slow-blow fuse. The cable is coiled allowing for extension up to 3 feet. INSTALLATION & CABLING USB Cable to Laptop The R2 connects to the G2 laptop via a standard USB cable (type A connector at the laptop, type B at the R2). The laptop will require the correct USB serial driver installed before operation. Check with T2 Customer Service for assistance. Antenna Installation The R2’s antenna is a omni-directional whip antenna with a magnetic mount base. The antenna connects to the base via a standard N-type connector. The base connects to the R2 via an RP-TNC (threaded) connector. The antenna’s cable and connection is critical to the performance of the system. The user should always take care to ensure the cable is not crimped, bent or damaged at the point of exit from the vehicle. Also, the user should take care in threading the antenna onto the base and the base into the R2 unit. 2 2 Connection Diagram 1 3 Antenna The antenna supplied by Transparent Technologies is an FCC-approved model. The user should always utilize this authorized antenna with the R2 Utility Mobile Transceiver. The connections between the antenna and the base (N-type connector) and the base and the R2 unit (RP-TNC connector) must be clean and fully seated for optimum performance. The coax cable from the base to the R2 unit must also be maintained in good condition. The user should refrain from kinking this cable in the vehicle door or window. Contact T2 immediately if the antenna or base is damaged to arrange a replacement. T2 can also provide permanent- mount antenna bases. ANTENNA Antenna Magnetic Antenna Base With RP-TNC connector 1 4 The R2 does not require any user interaction to operate. Applying power to the R2 unit will initiate its operations. Basic Indicators The R2 unit has two basic physical indicators which are LEDs on the front panel of the R2 unit. Power Indicator This LED should be a constant GREEN when power is supplied to the R2 unit. The first step in any troubleshooting of the R2 should be to check this indicator. RF Traffic This amber LED should flicker on/off when the R2 is in proximity to any M2 endpoint radios. This LED shows the RF traffic and will indicate if there is a problem with the antenna/base or if there is a frequency configuration problem. Manual Reset Button The R2 unit has a manual reset button which cycles power and resets the R2 microcontroller. This is not a normal operation and should only be performed when directed by T2 Customer Service. OPERATIONS 2 4 G2 Laptop Interaction The R2 is linked to the G2 laptop system with the USB cable. This connection provides the path for the serial data coming from the R2 into the G2 software. Transceiver Status In addition to the data, the R2 also provides a “heartbeat” (a consistent data indicator) to the G2 software. This heartbeat notifies the G2 software that the R2 is operational. The G2 software indicates this status on the Activity Window. GREEN indicates the R2 is operational, while RED indicates a data or power problem Software Reset If the R2 status indicator shows RED, the user should first check the power and USB cables. The user can also place the windows cursor directly over the indicator to see a more detailed status. If the user clicks on the indicator, a command box will appear allowing the user to Restart the serial port or to view the active communication. When performing these commands, the user should be aware that the restart could take a few minutes to complete and that this could cause the Windows OS to lock up if there is a physical or driver problem with the USB port. 1 A FCC Information Information to user. …
