About Your SM-2402 Series Radio Maxon's SM-2402 series mobile radio are Compatible. Conventional radio system operation. the SM-2402 is capable of up to 208 channels 13 Groups per system in conventional operation. The operation and functions for the SM-2402 Series radios are described in this manual. We urge you to thoroughly read this manual before operating the radio. Application of some functions described in this manual is determined by the system you use. Your Maxon Dealer will program your radio so that you have the greatest number of functions possible relative to your needs. Should you have questions regarding the operation of the radio, please consult your Maxon Dealer. About Maxon Maxon is a world-respected name in professional FM two-way radio equipment operating in the UHF, VHF and 800 MHz frequencies; personal two-way communication devices, including the popular FRS (Family Radio Service) and GMRS radios; and a variety of wireless communication products (two-way voice messaging handsets, Wireless Local Loop terminals, etc.). Safety Information The Federal Communications Commission (FCC), with its action in General Docket 93-62, November 7, 1997, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Maxon subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act and Federal Communications Commission limits. WARNING - The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 60 cm from all persons and must not be co-located or operation in conjunction with any other antenna or transmitter. Safety Information, Continued WARNING - This radio has been tested and complies with the FCC RF exposure limits for βOccupational Use Only.β In addition, your FM radio complies with the following standards and guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans : - FCC OET Bulletin 65 Edition 97-01 supplement C, Evaluating compliance with FCC guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. - American National Standards Institute (C95.1-1992), IEEE standard for Safety levels with respect to human exposure to radio frequency electromagnetic fields, 3 kHz to 300 GHz. - American National Standards Institute (C95.3-1992), IEEE recommended practice for the measurement of potentially hazardous electromagnetic fields β RF and Microwave. - DO not operate the radio without a proper antenna attached, as this may damage the radio and may also cause you to exceed FCC RF exposure limits. A proper antenna is the antenna supplied with this radio by the manufacturer or an antenna specifically authorized by the manufacturer for use with this radio. - ALWAYS use Maxon authorized accessories. Use of unauthorized accessories can cause the FCC RF exposure compliance requirements to be exceeded. - DO not transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to assure that this radio operates within the FCC RF exposure limits. During transmissions, your Radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. WARNING - It is mandatory that radio installations in vehicles fueled by liquefied petroleum gas conform to the following standard: National Fire Protection Association standard NFPA 58 applies to radio installations in vehicles fueled by liquefied petroleum (LP) gas with LP gas container in the trunk or other sealed-off space within the interior of the vehicle. This standard requires that: 1 Any space containing radio equipment shall be isolated by a seal from the space in which the LP gas container and its fittings are located. 2 Remote (outside) filling connections shall be vented to the outside. WARNING - DO not operate the transmitter of a mobile radio when someone outside the vehicle is within two feet (0.6 meter) of the antenna. WARNING - DO not allow children to operate transmitter - equipped radio equipment. CAUTION - DO not operate the radio near electrical blasting caps or in an explosive atmosphere. CAUTION - DO not operate the transmitter of any radio unless all RF connectors are secure and any open connectors are properly terminated. All equipment must be properly grounded for safe operation. All equipment should be serviced by a qualified technician. NOTE: This radio operates in FCC regulated frequency bands. All radios must be licensed by the FCC before use. Because this radio contains a transmitter, Federal law prohibits unauthorized use or adjustments of this radio.
FCC ID : RXUSM2402 Report File No. : STROS-07-003 Page : 1 of 9 SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-041 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com MPE TEST REPORT Equipment Under Test : Private Land Mobile Radio for Vehicle(UHF) Model No. : SM-2402 Applicant : MAXON CIC Corp. Address of Applicant : Chongho Bldg, #7-61, Yangjae-Dong, Seocho-Gu, Seoul, Korea Date of Test(s) : 2006-12-21 Date of Issue : 2007-01-12 Standards : FCC 47CFR 2.1091(b) In the configuration tested, the EUT complied with the standards specified above. Remarks: Tested by : Feel Jeong 2007-01-12 Approved by : Albert Lim 2007-01-12 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Testing Korea Co., Ltd. or testing done by SGS Testing Korea Co., Ltd. in connection with distribution or use of the product described in this report must be approved by SGS Testing Korea Co., Ltd. in writing. FCC ID : RXUSM2402 Report File No. : STROS-07-003 Page : 2 of 9 SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-041 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com TABLE OF CONTENTS Page 1. Description---------------------------------------------------- 3 2. Antenna Information---------------------------------------- 3 3. Test site-------------------------------------------------------- 3 4. Measurement System---------------------------------------- 3 5. Measurement Uncertainty---------------------------------- 4 6. Method of measurement------------------------------------ 4 7. Test result----------------------------------------------------- 6 8. Conclusion---------------------------------------------------- 9 FCC ID : RXUSM2402 Report File No. : STROS-07-003 Page : 3 of 9 SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-041 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 1. Description Maxon's SM-2402 series mobile radio are Compatible. Conventional radio system operation. the SM-2402 is capable of up to 208 channels 13 Groups per system in conventional operation. The operation and functions for the SM-2402 Series radios are described in this manual. SM-2402 has a compact size with a various features in range of 440~470 MHz. SM-2402 has a various features shown as below. - Conventional radio operation, 9 character display with icons - Wideband frequency separation, Programmable output power -Programmable 12.5 / 25 kHz channel spacing, Multiple-function five button keypad - Programmable On / Off hook function, Talk Around - Scanning. Priority Scanning - Look Back, Scan list editing - CTCSS / CDDCS (Conventional operation), Busy channel lockout - Time-out timer 2. Antenna Information Whip Antenna for vehicle : 435 ~ 450 MHz, 1/4 wave 3 dBi Whip Antenna for vehicle : 450 ~ 470 MHz, 1/4 wave 3 dBi 3. Test site SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-city, Gyeonggi-do, Korea 4. Measurement System - Automobile: KIA Pride(2000) - E-Field Survey Meter & Probe - NARDA Model EMC 20 (100 kHz~3 GHz) Calibration due date: 2007-10-16 - Antennas - (1/4 wave 3 dBi) FCC ID : RXUSM2402 Report File No. : STROS-07-003 Page : 4 of 9 SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-041 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 5. Measurement Uncertainty The information below presents an estimate of the possible errors that are associated with the measurement system. Description Error NARDA Survey Meter Β± 3% Repeatability Accuracy Β± 7% 6. Method of measurement 6.1 EME measurements made on trunk mounted antennas 6.1.1 External vehicle EME measurement (Antenna mounted in trunk center) With the survey meter and probe, take ten (10) measurements, at the standard test distance of 60 cm to the antenna, from the back of the vehicle in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters. 6.1.2 Internal vehicle EME measurement (Antenna mounted in trunk center) While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each location. After the highest level is found, scan vertically making two (2) additional measurements within an area approximately 40 cm wide (representing the width of a person) so as to have a total of three (3) measured points as indicated below that will be averaged. a) Head area b) Chest area c) Lower Trunk area 6.2 EME measurements made on center roof mounted antennas 6.2.1 External vehicle EME measurement With the survey meter and probe, take ten (10) measurements, at the standard test distance of 110 cm from the vehicle-mounted antenna, in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters; this would be representative of a person standing next to a vehicle during a mobile radio transmission. FCC ID : RXUSM2402 Report File No. : STROS-07-003 Page : 5 of 9 SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-041 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 6.2.2 Internal vehicle EME measurement Whiβ¦
Text truncated - open the document above for the full version.
FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 1 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com TEST REPORT OF FCC Part 90, Part 2 FCC ID : RXUSM2402 Equipment Under Test : Private Land Mobile Radio for Vehicle(UHF) Model No. : SM-2402 Serial No. : N/A Applicant : MAXON CIC Corp. Manufacturer : MAXON CIC Corp. Date of Test(s) : 2006-09-20 ~ 2006-10-20 Date of Issue : 2007-01-12 In the configuration tested, the EUT complied with the standards specified above. Te s t e d B y : Date 2007-01-12 Feel Jeong Approved By Date 2007-01-12 Albert Lim FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 2 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com INDEX TABLE OF CONTENTS Page 1. General Information ------------------------------------------------------------------------------ 3 2. Output Power Conducted------------------------------------------------------------------------- 6 3. Radiated Spurious Emissions-------------------------------------------------------------------- 8 4. Conducted Spurious Emissions------------------------------------------------------------------ 15 5. Audio Frequency Response----------------------------------------------------------------------- 28 6. Audio Low Pass Filter Frequency Response-------------------------------------------------- 30 7. Modulation Limited-------------------------------------------------------------------------------- 32 8. Occupied Bandwidth------------------------------------------------------------------------------- 34 9. Frequency Stability--------------------------------------------------------------------------------- 37 10. Transient Frequency Behaviours of the Transmitter -------------------------------------- 39 Appendix A. Photo of Radiated Spurious Emissions Test Appendix B. Photos of the EUT FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 3 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 1. General Information 1-1. Testing Laboratory SGS Testing Korea Co., Ltd. Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-Si, Gyeonggi-do, Korea 435-040 www.electrolab.kr.sgs.com Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 1-2. Details of Applicant Applicant : MAXON CIC Corp. Address : Chongho Bldg, #7-61, Yangjae-Dong, Seocho-Gu, Seoul, Korea Contact Person : Won Dae-Hee Phone No. : 82-2-3498-3053 Fax No. : 82-2-3498-3115 1-3 Description of EUT Kind of Product Private Land Mobile Radio for Vehicle(UHF) Model Name SM-2402 Serial Number N/A Power Supply DC 13.8 V Frequency Range 440 MHz ~ 470 MHz Transmit Power 2W(Low), 25 W(High) Modulation Technique FM Number of Channels 208 Channels Operating Conditions -30 ~ 60 deg C Antenna Type External Antenna 1-4 Details of modification FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 4 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 1-5. Test Equipment List EQUIPMENT MANUFACTURER MODEL CAL DUE. Signal Generator Agilent E4438C May 2007 Spectrum Analyzer Agilent E4440A May 2007 Audio Analyzer H.P. 8903B Dec.2007 Modulation Analyzer H.P. 8901B Dec.2007 DC Power Supply Agilent 6674A May 2007 Tem/Hum Chamber Han-Gil HGTP-4050 Oct.2007 Power Sensor Agilent E9327A May 2007 Power Meter Agilent 4416A May 2007 Attenuator Weincshel AZ3096 Dec.2007 Preamplifier Agilent 8449B May 2007 Preamplifier Agilent 8447F Jun.2007 Log-periodic Rohde & Schwarz UHALP9107 Jan.2007 Biconical Antenna Schwarzbeck VHA9103 Mar.2007 Horn Antenna Rohde & Schwarz HF906 Mar.2007 Test Receiver R&S ESIB 26 Apr.2007 Signal Generator R&S SMR 20 Dec.2007 Horn Antenna R&S HF906 Aug.2007 Ultra Broadband Antenna R&S HL562 Sep.2007 Biconical Antenna Schwarzbeck ME VUSA 9117 Nov.2007 Turn Table INN-CO CT 0800 N.C.R Antenna Mast INN-CO MA 2000 N.C.R Turn Device INN-CO FSM 230-M N.C.R Controller INN-CO CO 2000 N.C.R Fully Anechoic Chamber SY Corporation 10m 5m 5m Feb. 2007 FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 5 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 1.6 Summary of Test Results Description of Test FCC Rule Result Output Power Conducted 2.1046(a), 90.205 Complies Radiated Spurious Emissions 2.1053(a), 90.210 Complies Conducted Spurious Emissions 2.1051, 90.210 Complies Audio Frequency Response 2.1047(a) Complies Audio Low Pass Filter Frequency Response 2.1047(a) Complies Modulation Limiting 2.1047(b) Complies Occupied Bandwidth 2.1049, 90.210 Complies Frequency Stability 90.213, 2.1055 Complies Transient Frequency Behaviour of the Transmitter 90.214 Complies FCC ID : RXUSM2402 Report File No. : STROR-07-008 Page : 6 of 52 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.electrolab.kr.sgs.com 2. Output Power Conducted : FCC 2.1046(a), FCC90.205 2.1. Limit Accordingβ¦
