Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 44 of 59 APPENDIX J: USER’S MANUAL Please refer to the Operator’s Manual. 1 SP-200 series Synthesized Scanning Radio FCC RF EXPOSURE COMPLIANCE REQUIREMENTS FOR OCCUPATIONAL USE ONLY The Federal Communications Commission (FCC), with its action in General Docket 93-62, November 7, 1997, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Maxon subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act (OSHA) and Federal Communications Commission limits. DO NOT transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. This radio is NOT approved for use by the general population in an uncontrolled environment. This radio is restricted to occupational use, work related operations only where radio operator must have the knowledge to control the user’s exposure conditions for satisfying the higher exposure limit allowed for occupational use. When transmitting, hold the radio in a vertical position with its microphone 2 inches (5 cm) away from your mouth. The radio is transmitting when the red LED on the front of the radio is illuminated. You can cause the radio to transmit by pressing the PTT bar on the radio. These are required operating configurations for meeting FCC RF exposure compliance. Failure to observe these restrictions mean violation. Operating Instructions About Your SP-200 series Radio Maxon's SP-200 series radio feature up to 13 groups and up to 16 channel operation per group for a total channel capacity of 199 channels of superior performance and reliability. Operation and functions for Maxon's SP-200 series radios are described in this manual. We urge you to thoroughly read this manual before operating the radio. Application of some of the functions described in this manual is determined by the system you use. Your Maxon Dealer will program your radio so that you have the greatest number of functions possible relative to your needs. Should you have questions regarding the operation of the radio please consult your Maxon Dealer. About Maxon America, Inc. Maxon America, Inc. designs and manufactures professional FM two-way radio equipment to serve a wide variety of communication needs. Maxon produces equipment for the Land Mobile Radio and Specialized Mobile Radio markets (business, industrial, government, and public safety). 2 Table of Contents Safety Information.................................................................. Unpacking Information.......................................................... SP-200 Series Features.................................................... Description of Radio Components......................................... Antenna Installation............................................................... Installing and Removing the Battery Pack............................... Attaching and Removing the Belt Clip.................................... Battery Charging and Care..................................................... SP-200 Series Operation................................................. Power On-Volume.................................................. Channel Select Transmit.................................................................. Receive................................................................... Power Off.............................................................. Status Indicators and Audible Alert Tones............................. Scan Modes......................................................................... Normal Channel Scan............................................ Priority Channel Scan............................................. Other Scanning Features....................................................... Look Back.............................................................. Scan Channel Delete.............................................. CTCSS/DCS Scanning............................................ Normal Scan TX..................................................... Priority Scan TX..................................................... Priority Only TX..................................................... Receive Only Scan................................................. Scan List Edit ........................................................................ Licensing and Service Information........................................ Recycling/Disposal of Batteries............................................ Software Copyrights............................................................. Maintenance........................................................................ Warranty Statement................................................................. 1 3 Safety Information The Federal Communications Commission (FCC), with its action in General Docket 79-144, March 13, 1985, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Maxon subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act and Federal Communications Commission limits. WARNING - DO NOT hold the radio in such a manner that the antenna is next to, or touching, exposed parts of the body, especially the face or eyes, while transmitting. WARNING - DO NOT allow children to operate transmitter - equipped radio equipment. CAUTION - DO NOT operate the radio near unshielded electrical blasting caps or in an explosive…
Text truncated - open the document above for the full version.
1 SP-210 FCC RF EXPOSURE COMPLIANCE REQUIREMENTS FOR OCCUPATIONAL USE ONLY The Federal Communications Commission (FCC), with its action in General Docket 93-62, November 7, 1997, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Maxon subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act (OSHA) and Federal Communications Commission limits. DO NOT transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. This radio is NOT approved for use by the general population in an uncontrolled environment. This radio is restricted to occupational use, work related operations only where radio operator must have the knowledge to control the user’s exposure conditions for satisfying the higher exposure limit allowed for occupational use. When transmitting, hold the radio in a vertical position with its microphone 1 inches (2.5 cm) away from your mouth. The radio is transmitting when the red LED on the front of the radio is illuminated. You can cause the radio to transmit by pressing the PTT bar on the radio. These are required operating configurations for meeting FCC RF exposure compliance. Failure to observe these restrictions mean violation. RF EXPOSURE COMPLIANEC AND CONTROL GUIDELINES AND OPERATING INSTRUCTIONS To control your exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere to the following procedures. Guidelines: • Do not remove the RF Exposure Label from the device. Operating Instructions: • Hold the radio in a vertical position in front of face with the microphone (and the other parts of the radio, including the antenna) at least one inch (2.5 cm) away from the nose. Keeping the radio at the proper distance is important because RF exposures decrease with distance from the antenna. The antenna should be kept away from eyes. • When worn on the body, always place the radio in a Maxon Telecom approved clip, holder, holster, case, or body harness for this product. Using approved body-worn accessories is important because the use of Maxon Telecom or other manufacturer’s non-approved accessories may result in exposure levels which exceed the FCC’s occupational/controlled environment RF exposure limits. • Use only Maxon Telecom approved supplied or replacement antennas, batteries, and accessories. Use of non-Maxon Telecom approved antennas, batteries, and accessories may exceed the FCC RF exposure guidelines. 2 About Your SP-210 Radio Maxon's SP-210 Radio feature up to 13 groups and up to 16 channel operation per group for a total channel capacity of 199 channels of superior performance and reliability. Operation and functions for Maxon's SP-210 Radios are described in this manual. We urge you to thoroughly read this manual before operating the radio. Application of some of the functions described in this manual is determined by the system you use. Your Maxon Dealer will program your radio so that you have the greatest number of functions possible relative to your needs. Should you have questions regarding the operation of the radio please consult your Maxon Dealer. About Maxon America, Inc. Maxon America, Inc. designs and manufactures professional FM two-way radio equipment to serve a wide variety of communication needs. Maxon produces equipment for the Land Mobile Radio and Specialized Mobile Radio markets (business, industrial, government and public safety). Table of Contents Safety Information.................................................................. Unpacking Information.......................................................... SP-210 Features................................................................. Description of Radio Components......................................... Antenna Installation............................................................... Installing and Removing the Battery Pack............................... Attaching and Removing the Belt Clip.................................... Battery Charging and Care..................................................... SP-210 Operation.............................................................. Power On-Volume.................................................. Channel Select.......................................... Transmit.................................................................. Receive................................................................... Power Off.............................................................. Status Indicators and Audible Alert Tones............................. Scan Modes........................................................................... Normal Channel Scan............................................ Priority Channel Scan............................................. Other Scanning Features....................................................... . Look Back.......................................................................... Scan Channel Delete.............................................. CTCSS/DCS Scanning............................................ Normal Scan TX..................................................... Priority Scan TX..................................................... Priority Only TX..................................................... Receive Only Scan................................................. Scan List Edit ........................................................................ Licensing and Service Information........................................ Recycling/Disposal of Batteries............................................ Software Copyrights............................................................. Maintenance..........................................................…
Text truncated - open the document above for the full version.
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 36 of 59 APPENDIX B: AGENCY AUTHORIZATION LETTER Please see the following page.
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 37 of 59 APPENDIX C: CONFIDENTIALITY REQUEST LETTER Please see the following page.
To: Desmond Fraser, Rhein Tech Laboratories From: Diane Poole [email protected] FCC Application Processing Branch Re: FCC ID RXUSP210U2 Applicant: Maxontelecom Co., Ltd. Correspondence Reference Number: 28493 AND 28494 731 Confirmation Number: EA470120 Please Note : Rhein Tech Labs received two correspondences, reference #’s 28493 and 28494, which contained the same comments. This response is intended to address both. If this is not acceptable, please advise. RF exposure instructions related to the body worn accessory could not be located. Please provide. RF exposure instructions do not appear to make the user aware of their exposure or what exposure is. Please revise accordingly. Response : Please refer to the revised user manual exhibit uploaded with this response. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal pursuant to Section 2.917 (c) and forfeiture of the filing fee pursuant to section 1.1108. DO NOT reply to this e-mail by using the Reply button. In order for your response to be processed expeditiously, you must upload your response via the Internet at www.fcc.gov , Electronic Filing, OET Equipment Authorization Electronic Filing. If the response is submitted through Add Attachments, in order to expedite processing, a message which informs the processing staff that a new exhibit has been submitted must also be submitted via Submit Correspondence. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.
Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 April 15, 2005 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Acting as agent for purposes of this application on behalf of the applicant Maxon Telecom, we respectfully request the following information be held confidential pursuant of 47 CFR Part §0.459 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and is proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Technical Product Description • Block Diagram • Parts List & Alignment Procedure Sincerely, Kathy Grzovic EMC Regulatory Assistant Rhein Tech Laboratories
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 49 of 59 APPENDIX L: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 6: TOP VIEW OF EUT Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 50 of 59 PHOTOGRAPH 7: END VIEW OF EUT Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 51 of 59 PHOTOGRAPH 8: FRONT VIEW OF EUT Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 52 of 59 PHOTOGRAPH 9: LEFT SIDE OF EUT Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 53 of 59 PHOTOGRAPH 10: RIGHT SIDE OF EUT
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 40 of 59 APPENDIX F: LABEL AND LABEL LOCATION PHOTOGRAPH 1: FCC ID & RF LABEL LOCATIONS Please see the following pages for FCC ID and RF label samples. FCC ID LABEL HERE RF LABEL HERE
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 54 of 59 APPENDIX M: INTERNAL PHOTOGRAPHS PHOTOGRAPH 11: INSIDE BACK COVER Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 55 of 59 PHOTOGRAPH 12: DIGITAL PCB BACK VIEW
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 56 of 59 PHOTOGRAPH 13: DIGITAL PCB TOP VIEW Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 57 of 59 PHOTOGRAPH 14: RF BACK
Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 58 of 59 PHOTOGRAPH 15: RF UPPER 1 Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 59 of 59 PHOTOGRAPH 16: RF UPPER 1 WITHOUT SHIELDS
© 2004 Celltech Labs Inc. 1 of 20 Test Report S/N: 110804RXU-T588-S90U Test Date(s): November 16 & 22, 2004 Test Type: FCC/IC SAR Evaluation Performed By: Spencer Watson Compliance Technologist Celltech Labs Inc. Reviewed By: Russell W. Pipe Senior Compliance Technologist Celltech Labs Inc. Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01) and Industry Canada RSS-102 Issue 1 (Provisional) for the Occupational / Controlled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information MAXON TELECOM CO., LTD. 12F., Sewon Venture Town Bldg., 705-18, Yeoksam-Dong Seoul, Korea FCC IDENTIFIER: RXUSP210U2 IC IDENTIFIER: 153-SP210U2 Model(s): SP210 U2 Rule Part(s): FCC 47 CFR §2.1093; IC RSS-102 Issue 1 (Provisional) Test Procedure(s): FCC OET Bulletin 65, Supplement C (Edition 01-01) Device Classification: Licensed Non-Broadcast Transmitter Held to Face (TNF) Device Description: Portable FM UHF PTT Radio Transceiver Modulation Type: FM (UHF) Tx Frequency Range: 440 - 470 MHz Max. RF Output Power Tested: 37.46 dBm Conducted (455.075 MHz) Antenna Type(s) Tested: Detachable Stubby (P/N: ACC-100) Battery Type(s) Tested: NiMH 7.5 V, 1350 mAh (P/N: BTM100-01) Body-Worn Accessories Tested: Plastic Swivel Belt-Clip with Metal Spring Earbud with Lapel-Microphone Max. SAR Levels Evaluated: 3.74 W/kg - Face-held (50% Duty Cycle) 2.00 W/kg - Body-worn (50% Duty Cycle) © 2004 Celltech Labs Inc. 2 of 20 Test Report S/N: 110804RXU-T588-S90U Test Date(s): November 16 & 22, 2004 Test Type: FCC/IC SAR Evaluation TABLE OF CONTENTS 1.0INTRODUCTION.....................................................................3 2.0DESCRIPTION OF DUT............................................................ 3 3.0SAR MEASUREMENT SYSTEM................................................ 4 4.0MEASUREMENT SUMMARY..................................................... 5 5.0DETAILS OF SAR EVALUATION............................................... 6 6.0EVALUATION PROCEDURES................................................... 6 7.0SYSTEM PERFORMANCE CHECK............................................. 7 8.0SIMULATED EQUIVALENT TISSUES.......................................... 8 9.0SAR SAFETY LIMITS............................................................... 8 10.0ROBOT SYSTEM SPECIFICATIONS........................................... 9 11.0PROBE SPECIFICATION.......................................................... 10 12.0PLANAR PHANTOM................................................................. 10 13.0VALIDATION PHANTOM........................................................... 10 14.0DEVICE HOLDER.................................................................... 10 15.0TEST EQUIPMENT LIST............................................................ 11 16.0MEASUREMENT UNCERTAINTIES............................................. 12-13 17.0REFERENCES.........................................................................14 APPENDIX A - SAR MEASUREMENT DATA............................................... 15 APPENDIX B - SYSTEM PERFORMANCE CHECK DATA............................ 16 APPENDIX C - SYSTEM VALIDATION PROCEDURES................................. 17 APPENDIX D - PROBE CALIBRATION...................................................... 18 APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS................... 19 APPENDIX F - SAR TEST SETUP & DUT PHOTOGRAPHS.......................... 20 Applicant: Maxon Telecom Co., Ltd. FCC ID: RXUSP210U2IC ID: 153-SP210U2 Model:SP210 U2 Portable FM UHF PTT Radio Transceiver 440 - 470 MHz 2004 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the written permission of Celltech Labs Inc. 3 of 20 Test Report S/N: 110804RXU-T588-S90U Test Date(s): November 16 & 22, 2004 Test Type: FCC/IC SAR Evaluation This measurement report demonstrates that the Maxon Telecom Co., Ltd. Model: SP210 U2 Portable FM UHF PTT Radio Transceiver FCC ID: RXUSP210U2 complies with the SAR (Specific Absorption Rate) RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]), and Health Canada’s Safety Code 6 (see reference [2]) for the Occupational / Controlled Exposure environment. The measurement procedures described in FCC OET Bulletin 65, Supplement C (Edition 01-01) (see reference [3]) and IC RSS-102 Issue 1 (Provisional) (see reference [4]), were employed. A description of the product, operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. FCC Rule Part(s) 47 CFR §2.1093 IC Rule Part(s) RSS-102 Issue 1 (Provisional) Test Procedure(s) FCC OET Bulletin 65, Supplement C (01-01) Device Type Portable FM UHF PTT Radio Transceiver FCC IDENTIFER RXUSP210U2 IC ID…
Text truncated - open the document above for the full version.
Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368 Fax: 703-689-2056 CERTIFICATION APPLICATION REPORT FCC PART 90 & INDUSTRY CANADA RSS-119 Test Lab: Rhein Tech Laboratories, Inc. Phone: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 Web: www.rheintech.com Herndon, VA 20170 Contact: [email protected] Applicant: Maxon Telecom Co., Ltd. 12F Sewon Venture Town Bldg., 705-18, Yeoksam-Dong, Seoul Kangnam-Ku, 135-080 South Korea Phone: 82-2-2008-1603 Fax: 82-2-2008-1600 Email: [email protected] Contact: JH Kim FCC ID: RXUSP210U2 FRN NUMBER: 0010534170 MODEL: SP210 U2 RTL WO NUMBER: 2004186 EQUIPMENT TYPE: PTT UHF-H RTL QUOTE NUMBER: QRTL04-347 DATE OF TEST REPORT: December 13, 2004 FCC Classification: TNF – Licensed Non-Broadcast Transmitter Held to Face FCC Rule Part(s): Part 90: Private Land Mobile Radio Services Industry Canada Standard: RSS-119: Land Mobile and Fixed Radio Transmitters and Receivers, 27.41 MHz to 960 MHz Frequency Range (MHz) Output Power (W) Frequency Tolerance (PPM, %, or Hz) Emission Designator 440-470 6.2 1.5 16K0F3E 440-470 6.2 1.5 11K0F3E We, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described in this test report. No modifications were made to the equipment during testing in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to or exclusions from the FCC Part 2, FCC Part 90, Industry Canada RSS-119, ANSI C63.2, ANSI/TIA-603-B-2002 and ANSI/TIA/EIA 603-1. Signature: Date: December 13, 2004 Typed/Printed Name: Desmond A. Fraser Position: President Signature: Date: December 13, 2004 Typed/Printed Name: Daniel Baltzell Position: Test Engineer Rhein Tech Laboratories, Inc. Client: Maxon Telecom Co., Ltd. 360 Herndon Parkway FCC ID: RXUSP210U2 Suite 1400 Model: SP210 U2 Herndon, VA 20170 Standards: FCC Part 90/IC RSS-119 http://www.rheintech.com Date: December 13, 2004 . Page 2 of 59 TABLE OF CONTENTS 1 GENERAL INFORMATION ...................................................................................................................................5 1.1 SCOPE .........................................................................................................................................................5 1.2 TEST FACILITY............................................................................................................................................5 1.3 RELATED SUBMITTAL(S)/GRANT(S) .........................................................................................................5 2 EQUIPMENT INFORMATION................................................................................................................................6 2.1 TEST SYSTEM DETAILS.............................................................................................................................6 2.2 WORST CASE CONFIGURATION OF TESTED SYSTEM..........................................................................7 3 FCC PART 2.1033(C)(8); DC VOLTAGES AND CURRENTS ..............................................................................7 4 RF POWER OUTPUT - §2.1046, RSS-119 §6.2....................................................................................................8 4.1 ANSI/TIA/EIA-603-2002, SECTION 2.2.1 TEST PROCEDURE ...................................................................8 4.2 RF POWER OUTPUT TEST EQUIPMENT ..................................................................................................8 4.3 RF POWER OUTPUT TEST DATA ..............................................................................................................9 5 MODULATION CHARACTERISTICS - §2.1047 TEST PROCEDURE, RSS-119 §6.6 .........................................9 5.1 MODULATION CHARACTERISTICS TEST EQUIPMENT...........................................................................9 6 MODULATION CHARACTERISTICS - AUDIO FREQUENCY RESPONSE - FCC PART 2 §2.1047 (A)...........10 6.1 TEST PROCEDURE...................................................................................................................................10 6.2 TEST DATA ................................................................................................................................................10 7 MODULATION CHARACTERISTICS - AUDIO LOW PASS FILTER RESPONSE - FCC PART 2 §2.1047 (A) 11 7.1 TEST PROCEDURE...................................................................................................................................11 7.2 TEST DATA ................................................................................................................................................11 8 MODULATION CHARACTERISTICS - MODULATION LIMITING - FCC PART 2 §2.1047 (B)..........................12 8.1 TEST PROCEDURE...................................................................................................................................12 8.2 TEST DATA ..................…
