RYD-ISB2006BDUAL PORTABLE WIRELESS SPEAKERS

Features & Controls Dual P ortable Wireless speak ers User’ s Guide for Model No. ISB2006 v1409-01 Fea tures • Supports Bluetooth • Automatic device rec onnect • Bluetooth Wir eless range: 33 ft to main speaker/15 ft betw een speakers • Aux In 3.5 mm audio input • Built in rechar geable lithium ion batt ery • Battery life: appro x. 3 hrs I ncludes • AC/DC pow er adapter • Micro-USB to USB cable rear Vie w Po wer/ lights switch Slide to power OFF, ON, or ON with Light effects Micro- usB Power Input Carry Handle Power/Connect speaker Indicator Connect speakers Pair Bluetooth Function Mode Indicator aux In 3.5mm audio Input Important Safety Instructions • Read these Instructions. • Keep these Instructions. • Heed all Warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’ s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. FCC Warnings Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at: www.iliveelectronics.com Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la sec ción de apoyo en: www.ilivee lec tronics.com Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions fr équemment posées, consultez la rubrique d’assistance sur: www.ilivee lec tronics.com For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iliveelectronics.com Customer s er vice: 1-888-999-4215 | email support: [email protected] | email Parts: [email protected] Copyright © 2016 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their r espective owners. Specifications are subject to change without notice. InternatIonal suPPort PoWer & CHargIng BluetootH aux In using aux In Requires a 3.5mm audio cable (not included). 1. Connect a 3.5mm audio cable to the aux In Input on the unit and the audio output on an audio device. The Pairing/Aux In Indicator will display a solid green light. 2. Use the controls on the connected device to select, play, and adjust the v olume of your audio tracks. Pairing to a Bluetooth Device Make sure you have first followed the instructions for Pairing the Speakers. When pair ing, the device should remain within 3 feet of the speakers. 1. Press the Pair button on onl Y one of the speakers (this will be the left speaker channel). The pair indicator will begin flashing quickly. 2. Using the controls on your Bluetooth device, select IsB2006 in your Bluetooth settings. 3. If your device requests a password, enter the default password 0 0 0 0 . 4. Refer to the user’s manual for your specific device for instructions on pairing and connecting Bluetooth devices. 5. When successfully paired, the pairing indicator will stop flashing and will r emain solid. 6. After initial pairing, the unit will stay paired unless unpaired manually by the user or erased due to a r…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 JETOP INDUSTRIAL LIMITED. 2015-10-19 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, JETOP INDUSTRIAL LIMITED. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product name: DUAL PORTABLE WIRELESS SPEAKERS Model Number: ISB2006B FCC ID: RYD-ISB2006B Sincerely, signature Cathie Lian / Manager E-mail: [email protected] Phone: 00852-25153978 Fax: 00852-25583209 Address: Unit 11,2/F.,Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 JETOP INDUSTRIAL LIMITED. 2015-10-19 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: RYD-ISB2006B We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name & title : Cathie Lian Contact information / address : Unit 11,2/F.,Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong

Label Location Proposed Label Location on EUT

FCC ID : RYD-ISB2006B RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the followi ng table shall be used to evaluat e the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission form ula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Channel Freq. (GHz) modulation conducted power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2.402 GFSK 2.51 2 ± 1 3 1 0.00040 1 2.441 GFSK 2.21 2 ± 1 3 1 0.00040 1 2.480 GFSK 1.82 2 ± 1 3 1 0.00040 1 2.402 π /4-DQPSK 2.50 2 ± 1 3 1 0.00040 1 2.441 π /4-DQPSK 2.21 2 ± 1 3 1 0.00040 1 2.480 π /4-DQPSK 1.82 2 ± 1 3 1 0.00040 1 2.402 8-DPS K 2.50 2 ± 1 3 1 0.00040 1 2.441 8-DPSK 2.22 2 ± 1 3 1 0.00040 1 2.480 8-DPSK 1.83 2 ± 1 3 1 0.00040 1

TRF No.:FCC 15.247/APage 1 of 63 Report No.: ES150819002E Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT Fo r DUAL PORTABLE WIRELESS SPEAKERS MODEL No.: ISB2006B FCC ID: RYD-ISB2006B REPORT NO.: ES150819002E ISSUE DATE: October 10 , 2015 Pr epared for JETOP INDUSTRIAL LIMITED. Unit 11,2/F.,Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Hong Kong P repared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 63 Report No.: ES150819002E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION ............................................................................................................ 4 3 SUMMARY OF TEST RESULT ................................................................................................................ 5 4 TEST METHODOLOGY ........................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ................................................................................................ 7 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 FACILITIES .................................................................................................................................... 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 8 6 TEST SYSTEM UNCERTAINTY .............................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 10 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 10 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................... 11 7.4 SUPPORT EQUIPMENT ............................................................................................................. 12 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ......................................................................... 13 8.1 STANDARD APPLICABLE ........................................................................................................... 13 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................... 13 8.3 EQUAL HOPPING FREQUENCY USE ....................................................................................... 14 8.4 FREQUENCY HOPPING SYSTEM ............................................................................................. 14 9 TEST REQUIREMENTS ......................................................................................................................... 15 9.1 20DB BANDWIDTH ..................................................................................................................... 15 9.2 CARRIER FREQUENCY SEPARATION ..................................................................................... 21 9.3 NUMBER OF HOPPING FREQUENCIES ................................................................................... 27 9.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) ................................................................... 29 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER .................................................................. 32 9.6 CONDUCTED SUPRIOUS EMISSION ....................................................................................... 38 9.7 RADIATED SPURIOUS EMISSION ............................................................................................ 45 9.8 CONDUCTED EMISSION TEST ................................................................................................. 58 9.9 ANTENNA APPLICATION ............................................................................................................ 63 TRF No.:FCC 15.247/A Page 3 of 63 Report No.: ES150819002E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: JETOP INDUSTRIAL LIMITED. Unit 11,2/F.,Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Hong Kong Manufacturer: SHENZHEN SHANGMEI ELECTRIC APPLIANCECO.,LTD NO.9&11,LangHui Road,TangXia Yong Zone,Song'gang Town,Bao'an District,ShenZhen,China Product Description: DUAL PORTABLE WIRELESS SPEAKERS Trade Mark: Model Number: ISB2006B File Number: ES150819002E Date of Test: August 20, 2015 to October 10, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test : August 20, 2015 to October 10, 2015 Test by :  King kong /Tester Prepared by : Andy Wei/Editor Approve & Authorized Signer : Lisa Wang/Manager TRF No.:FCC 15.247/A Page 4 of 63 Report No.: ES15081…

Text truncated - open the document above for the full version.

Conducted Measurement Photo Radiated Emission Test
