RYD-ISB224BBluetooth Boombox with PLL FM radio

Gardez les piles neuves et d’occasion à partir des enfants. Si le compartiment de la batterie ne • pas fermer correctement, cesser d’utiliser le produit et garder loin des enfants. • If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. Si vous pensez que les batteries peuvent avoir été avalé ou placé à l’intérieur d’une partie du corps, consulter immédiatement un médecin. • Do not mix old and new batteries. Ne pas mélanger vieilles et nouvelles batteries. • Completely replace all old batteries with new ones. Remplacer complètement toutes les piles par des neuves. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries. Ne mélangez pas des piles alcalines, standard (carbone-zinc) ou rechargeables (Ni-Cd, Ni-MH, etc) batteries. • Batteries should be recycled or disposed of as per state and local guidelines. Piles doivent être recyclées ou éliminées selon les directives étatiques et locales. FEATURES AND CONTROLS BLUETOOTH WIRELESS SPEAKER User’s Guide for Model No.ISB224 v1065-01 Important Safety Instructions • Read these Instructions. • Keep these Instructions. • Heed all Warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. FCC Warnings Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Additional Warnings and Precautions • CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. • WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain, moisture, dripping, or splashing. AVIS: Pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité. • CAUTION: Use of controls or adjustments or performance of procedures other than those specified may result in hazardous radiation exposure. • WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • WARNING: Do not place this unit directly onto furniture surfaces with any type of soft, porous, or sensitive finish. As with any rubber compound made with oils, the feet could cause marks or staining where the feet reside. We recommend using a protective barrier such as a cloth or a piece of glass between the unit and the surface to reduce the risk of damage and/or staining. • WARNING: Use of this unit near fluorescent lighting may cause interference regarding use of the remote. If the unit is displaying erratic behavior move away from any fluorescent lighting, as it may be the cause. • CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. AVIS: Danger d’explosion si les piles sont remplacées de façon incorrect. Remplacer les piles seulement par le même type de pile ou l’équivalent. • WARNING: There is a danger of explosion if you attempt to charge standard Alkaline batteries in the unit. Only use rechargeable NiMH batteries. • WARNING: The remote control’s button cell battery contains mercury. Do not put in the trash, instead recycle or dispose of as hazardous waste • WARNING: Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled o…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 JETOP INDUSTRIAL LIMITED 2014-07-02 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _JETOP INDUSTRIAL LIMITED_ hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Bluetooth Speaker, ISB224B Sincerely, signature Cathie lian / Manager E-mail: [email protected] Phone: 00852-25153978 Fax: 00852-25583209 Address: Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 JETOP INDUSTRIAL LIMITED 2014-07-02 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _JETOP INDUSTRIAL LIMITED_ hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Bluetooth Speaker, ISB224B We affirm that between SIEMIC, Inc. and JETOP INDUSTRIAL LIMITED_, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, signature Cathie lian / Manager E-mail: [email protected] Phone: 00852-25153978 Fax: 00852-25583209 Address: Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong

Confidentiality Request Letter JETOP INDUSTRIAL LIMITED 2014-07-02 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality Request for FCC ID: RYD-ISB224B We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. signature Cathie lian / Manager E-mail: [email protected] Phone: 00852-25153978 Fax: 00852-25583209 Address: Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong

Label Location Proposed Label Location on EUT

Bluetooth module Antenna

FCC ID: RYD-ISB224B Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculated. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Max Conducted Power (dBm) Result calculation 1-g SAR 2.402 GFSK 4.23 0.8209 3.00 2.441 GFSK 4.37 0.8547 3.00 2.480 GFSK 4.42 0.8715 3.00 2.402 1/4Π-DQPSK 1.34 0.4220 3.00 2.441 1/4Π-DQPSK 1.41 0.4323 3.00 2.480 1/4Π-DQPSK 1.44 0.4388 3.00 2.402 8DPSK 1.33 0.4210 3.00 2.441 8DPSK 1.34 0.4254 3.00 2.480 8DPSK 1.41 0.4358 3.00 Conclusion: For the max result 0.87≤ 3.0 for 1-g SAR extremity SAR, No SAR is required.

TRF No.:FCC 15.247/A Page 1 of 52 Report No.: ES140619183E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPARTC REQUIREMENT OF Bluetooth Speaker MODEL No.: ISB224B FCC ID: RYD-ISB224B Trademark: , , GPX, JT REPORT NO.: ES140619183E ISSUE DATE: July 2, 2014 Prepared for JETOP INDUSTRIAL LIMITED. Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL : 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 52 Report No.: ES140619183E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World VERIFICATION OF COMPLIANCE Applicant: JETOP INDUSTRIAL LIMITED. Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong Manufacturer: JETOP INDUSTRIAL LIMITED. Unit 11, 2/F., Sing Win Factory Building, 15-17 Shing Yip Street, Kwun Tong, Kowloon, Hong Kong Product Description: Bluetooth Speaker Model Number: ISB224B Serial Number: N/A File Number: ES140619183E We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : June 20, 2014 to July 2, 2014 Prepared by : Jack.Li/Editor Reviewer : June xie/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.:FCC 15.247/A Page 3 of 52 Report No.: ES140619183E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World Table of Contents 1 GENERAL INFORMATION ............................................................................................................. 5 1.1 PRODUCT DESCRIPTION ........................................................................................................................ 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 5 1.3 TEST METHODOLOGY ............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES .......................................................................................................................... 5 1.5 EQUIPMENT MODIFICATIONS ................................................................................................................. 5 1.6 TEST FACILITY ........................................................................................................................................ 6 2 SYSTEM TEST CONFIGURATION ..................................................................................... 7 2.1 EUT CONFIGURATION ............................................................................................................................ 7 2.2 EUT EXERCISE ....................................................................................................................................... 7 2.3 TEST PROCEDURE .................................................................................................................................. 7 2.4 LIMITATION .............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM ................................................................................................ 11 2.6 EQUIPMENT USED IN TESTED SYSTEM .................................................................................................... 11 2.7 DESCRIPTION OF TEST MODES ............................................................................................................. 12 3 SUMMARY OF TEST RESULTS ....................................................................................... 13 4 CONDUCTED EMISSIONS TEST ..................................................................................... 14 4.1 MEASUREMENT PROCEDURE: ............................................................................................................. 14 4.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)..................................................................... 14 4.3 MEASUREMENT EQUIPMENT USED: .................................................................................................... 14 4.4 CONDUCTED EMISSION LIMIT ................................................................................................................... 14 4.5 MEASUREMENT RESULT: ..................................................................................................................... 15 5 RADIATED EMISSION TEST ............................................................................................. 17 5.1 MEASUREMENT PROCEDURE ............................................................................................................... 17 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)..................................................................... 17 5.3 MEASUREMENT EQUIPMENT USED: .................................................................................................... 18 5.4 MEASUREMENT RESULT .…

Text truncated - open the document above for the full version.

Radiated Emission Test Conducted Emissions Test
