Version 2.2 March 2005iControl Confidentialpage 1 iControl System Starter Kit Beta User Manual This document provides more detailed information on how to use your iControl System. More specifically: • how to read your iControl Summary page • adding, changing, and managing your iControl box and devices, and • frequently asked questions You should consult your Quick Start Guide or Getting Started Guide for information on how to install your system. Your Starter kit or device box will provide a list of what’s included with the kit or device. © 2004-2005 iControl Networks, Inc. All rights reserved. No reproduction in whole or in part without prior written approval. iControl Networks, iControl and I logo design are pending trademarks of iControl Networks. All other trademarks are the property of their respective owners. Information contained herein is subject to change without notice. The only warranties for iControl products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. iControl shall not be liable for technical or editorial errors or omissions contained herein. Printed in USA. Version 2.2 March 2005 Version 2.2 March 2005iControl Confidentialpage 2 Table of Contents Chapter 1 Getting Started3 Chapter 2About your iControl box9 Chapter 3Using your System11 Chapter 4Using your Wired Camera 19 Chapter 5Using your Door/Window Sensor32 Chapter 6 Using your Keychain Remote Control 33 Chapter 7Using your Lamp Module36 Chapter 8Using your Motion Sensor37 Chapter 9Adding Additional Devices38 Chapter 10Frequently Asked Questions42 Chapter 11Terms and Conditions, Warranty Information, and More44 Appendix A Battery Maintenance45 Check pages Version 2.2 March 2005iControl Confidentialpage 3 1 Getting Started Your iControl Summary page is where you begin using your iControl System; the iControl Summary page is your portal to your iControl System. To begin, log on First, go to a web browser and enter www.icontrol.com. In the customer login area, type the user name and password provided to you via email when you purchased your iControl product. You will be presented with your Summary page. This web page provides a fast, simple view into the status of your iControl box and devices. It also is the starting point from which you can monitor your system’s status, change your devices’ setup, add devices, set and change notifications, and set and modify automations. Here is an example of the Summary page where you can access the many functions of your iControl System. Version 2.2 March 2005iControl Confidentialpage 4 Read your Summary page This section provides a definition of the many terms found on your Summary page and serves as a good background to the iControl System. Tabs Your iControl Summary page has five major tabs. Summary tab When you log onto your iControl System from www.icontrol.com, your landing page is the Summary page. This is where you begin using your System. The Summary page consists of the following series of windows. Status window The top portion of this window indicates the overall status of the system and the current mode the system is in. The status light can have three possible colors as described below: Green – No alarm conditions. System operating normally Yellow – One or mode device alarm conditions (e.g. motion detected) Red – System problem (e.g. iControl box communication problem). The Status window also shows the current mode for your iControl System. Here, the System is in ‘Away Mode’. The rest of the Status window is a list showing the current state of all the devices in the system. In the screen shown earlier, three devices appear: a door/window sensor called ‘Back door’; a Thermostat showing the current temperature at 74 degree and its Heat Setpoint to of 69 degrees and Cooling Setpoint of 61 degrees; and a door/window sensor labeled ‘front door’. Your house may have many more devices than three and to view these you place your cursor over the up or down arrow to scroll to see additional devices or on the small box inside the scroll bar. Click here Click here Version 2.2 March 2005iControl Confidentialpage 5 Current states Current states refer to the status of all of your devices. If a device has a yellow triangle next to it, the triangle indicates that the device has recognized a change that creates an alarm. The following table shows the possible states and the alarm conditions of Starter Kit devices. DevicePossible stateExampleAlarm Condition Door/Window Sensor Open, ClosedOpen indicates the door or window is open Open Motion Sensor Occupied, EmptyOccupied means a person is in the monitored area Occupied Additional optional devices, such as freeze, water, smoke and heat sensors have their own associated states as well but are not described here since they are not part of the iControl Starter Kit. Pictures window Here you will see thumbnails of pictures or video from each of your iControl cameras. In the Summary page shown earlier, three thumbnails are shown, as three cameras are active. If your hover the cursor over a thumbnail, the name of the associated camera is displayed. You can also click on the thumbnail and it will expand. From there you can take a new picture, view past pictures, watch live video and delete pictures. Alarm History This window shows the record of the alarms recognized by the devices installed in your iControl System. An alarm occurs whenever a device detects a change, such as a door/window sensor detecting a door open or a motion sensor detects movement. (These are the only two types alarms available from the devices in the Starter Kit. Other optional devices provide alarms for freezing, water leakage, etc. and these devices will be offered in the future). For each change, it shows the time of the alarm. Each item in the alarm history has a yellow triangle next to it, indicating that it is an alarm. You can click on any …

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 17, 2005 RE: FCC ID: S23-GATEWAY1_ATCB002226 Attention: Mark Briggs I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that while the operational description details the 26ms transmitted packet, it does not show that the transmitter actually shuts off within 5 seconds of activation of transmission. Please provide evidence that the device meets the 5 second transmission restriction requirements of 15.231(a(1) and/or 15.231(a)(2). 2. Please note that 2.1033 of the rules require that the clock and crystal information be provided for transmitters. Please note that there appears to be a 106.5MHz crystal in the transmitter circuitry for this device. The schematics appear to show that the third harmonic (319.5MHz) of this clock is then ‘tuned’ in the transmitter circuitry to obtain the transmit frequency. Please explain why this information was not provided in the block diagram for the rf portion of the device. Please provide a block diagram that meets the requirements of 2.1033(b)(5) of the FCC rules. 3. 15.231 states that data can only be sent with a control signal. A control signal indicates that it commands a device to perform a function. The operational description is not clear on the data and addressing features. It states, “The RF transceiver is only used for the purposes of communicating with alarm devices and safety and security sensors. The control information transmitted between the iControl gateway and the devices includes addressing as well as device data.” Please confirm that this is to mean that data is only sent in conjunction with a control signal and is never sent alone. 4. Page 31 of the manual states a live video capability. The report indicates that this is done via IP communications, however, neither the manual nor the operational description are clear on this issue. Can the device use rf cameras? If so, this would indicate continuous transmission to the device from a remote camera. Please note that this is not allowed under 15.231. Pease verify that this live video capability is not a function of any 15.231 transmitter device. 5. Please note that the manual mentions a keychain remote. This keychain is not an evident part of this application. Does it have its own FCC ID number? Please explain. 6. Page 10 of the report references a version of ANSI C63.4 that has not bee acceptable for a number of years. Please note that 15.31(a)(3) institutes the immediate use of the newest 2003 version of ANSI C63.4. Please note that this 2003 version has significant differences and variations from the referenced version in the report. Since 15.37 (the transition section) has no transition time frame for the use of ANSI C63.4 2003, please provide evidence that the report is in accordance with the acceptable ANSI C63.4 2003 test methods and procedures. 7. Please note that the plot of run4 (page 29) and the table of results (page 30) of the test report shows conducted emissions on the “line” lead from 450kHz to 30MHz. Please note that 15.107 an d15.207 conducted limits are from 150kHz to 30MHz. Please explain. 8. FYI – no action needed as the device is still compliant. Please note that the spurious emissions limits for 15.231 devices above 470MHz is an average limit of 61.9dBuV/m (20log[1250uv/m] not 55.9dBuV, and the peak would be 81.9dBuV/m not 75.9dBuV/m. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. z Page 2 March 17, 2005 Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 of 4 Date: March 17, 2005 Attention: Dennis Ward In response to your comments dated March 17, 2005 regarding the application for FCC ID: S23-GATEWAY1, please find our responses below: 1. Please note that while the operational description details the 26ms transmitted packet, it does not show that the transmitter actually shuts off within 5 seconds of activation of transmission. Please provide evidence that the device meets the 5 second transmission restriction requirements of 15.231(a(1) and/or 15.231(a)(2). The plot shows the single transmission burst in a 100ms window. Each individual transmission consists of one packet and, therefore, complies with the 5 second requirement. Note that the same timing plots were provided to the FCC for the transceiver module approval under FCC ID B4Z-723-TCVR and no additional plots were requested. 2. Please note that 2.1033 of the rules require that the clock and crystal information be provided for transmitters. Please note that there appears to be a 106.5MHz crystal in the transmitter circuitry for this device. The schematics appear to show that the third harmonic (319.5MHz) of this clock is then ‘tuned’ in the transmitter circuitry to obtain the transmit frequency. Please explain why this information was not provided in the block diagram for the rf portion of the device. Please provide a block diagram that meets the requirements of 2.1033(b)(5) of the FCC rules. The block diagram and schematics were provided by the transceiver vendor and were the exact same exhibits were provided to the FCC for the transceiver module approval under FCC ID B4Z-723-TCVR. We contacted the transceiver vendor and they have provided an updated block diagram. Page 2 of 4 3. 15.231 states that data can only be sent with a control signal. A control signal indicates that it commands a device to perform a function. The operational description is not clear on the data and addressing features. It states, “The RF transceiver is only used for the purposes of communicating with alarm devices and safety and security sensors. The control information transmitted between the iControl gateway and the devices includes addressing as well as device data.” Please confirm that this is to mean that data is only sent in conjunction with a control signal and is never sent alone. The gateway sends control command that include addressing information. All of these signals are control signals that contain addressing information. No data- only signals are transmitted. In addition it sends supervisory polling commands, as permitted under 15.231(a), to certain sensor types. 4. Page 31 of the manual states a live video capability. The report indicates that this is done via IP communications, however, neither the manual nor the operational description are clear on this issue. Can the device use rf cameras? If so, this would indicate continuous transmission to the device from a remote camera. Please note that this is not allowed under 15.231. Pease verify that this live video capability is not a function of any 15.231 transmitter device. The cameras are all ethernet interface devices and are not a part of the 15.231 transmitter/receiver functions. Control of these cameras is via the wired ethernet connection on the gateway. 5. Please note that the manual mentions a keychain remote. This keychain is not an evident part of this application. Does it have its own FCC ID number? Please explain. The keychain is not a part of this application and is for remotely controlling the gateway. It will be sold under a separate FCC ID, as yet to be determined. Page 3 of 4 6. Page 10 of the report references a version of ANSI C63.4 that has not bee acceptable for a number of years. Please note that 15.31(a)(3) institutes the immediate use of the newest 2003 version of ANSI C63.4. Please note that this 2003 version has significant differences and variations from the referenced version in the report. Since 15.37 (the transition section) has no transition time frame for the use of ANSI C63.4 2003, please provide evidence that the report is in accordance with the acceptable ANSI C63.4 2003 test methods and procedures. The report references are outdated. All testing was performed in accordance with the 2003 version of ANSI C63.4. Evidence of this is demonstrated by the fact that the AC adapter was located on the test table and not connected directly into the AC outlet. The report has been updated. 7. Please note that the plot of run4 (page 29) and the table of results (page 30) of the test report shows conducted emissions on the “line” lead from 450kHz to 30MHz. Please note that 15.107 and 15.207 conducted limits are from 150kHz to 30MHz. Please explain. Correct, these tests were run against the requirements of RSS 210, which use the 450kHz – 30MHz frequency range. FCC test data is given on pages 27 and 28 of the test report and cover the appropriate frequency range and appropriate limits. For the RSS 210 test the carrier current device within the system had to be decoupled to demonstrate compliance with the RSS 210 limits. The carrier current device and transmitter were operational during the FCC tests as the combined emissions were still below the 15.107/15.207 limits. 8. FYI – no action needed as the device is still compliant. Please note that the spurious emissions limits for 15.231 devices above 470MHz is an average limit of 61.9dBuV/m (20log[1250uv/m] not 55.9dBuV, and the peak would be 81.9dBuV/m not 75.9dBuV/m. It is my understanding that the limit of the spurious emission is based on the frequency of the fundamental signal and not on the frequency of the spurious emission (15.231(b) states that maximum permitted unwanted emission level is 20 dB below the maximum permitted fundamental level). Based on this interpretation the limit for the spurious emissions is 55.9dBuV/m, except in restricted bands where the limit is the 15.209 limit. Page 4 of 4 The following documents have been uploaded to the ATCB website to s…

Text truncated - open the document above for the full version.

External Photographs

Premises Gateway Model: ICPGW-01 Serial #: 704B0000001 ID #: 006035019f54 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. This device complies with IC: ICES - 006 / ICES - 003 B; en conformité avec IC: NMB - 006 / NMB - 003 B FCC ID: S23-GATEWAY1 IC: 5747A-GATEWAY1 iControl Gateway Size = 4” x 3”, affixed to rear of device using permanent adhesive. Label material: 3M thermal transfer polyester label material Palo Alto, California

Internal Photographs Assembly View Digital Board top and bottom (no rf circuitry on this board) RF Board Bottom and Top

File: R58878 Page 1 of 19 2016-01 Electromagnetic Emissions Test Report In Accordance With Industry Canada Radio Standards Specification 210 And FCC Part 15 Sections 15.209, 15.231 on the iControl Networks Transmitter Model: iControl Gateway UPN: 5747A-GATEWAY1 FCC ID: S23-GATEWAY1 GRANTEE: iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 TEST SITE: Elliott Laboratories, Inc. 684 W. Maude Ave Sunnyvale, CA 94086 REPORT DATE: March 2, 2005 FINAL TEST DATE: February 16 and February 17, 2005 AUTHORIZED SIGNATORY: ______________________________ Mark Briggs Principal Engineer Elliott Laboratories, Inc. is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories, Inc. Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: March 2, 2005 File: R58878 Page 2 of 19 pages Equipment Name and Model: Transceiver , iControl Gateway Manufacturer: iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 Tested to applicable standard: RSS210, Issue 5, February 1996 Low Power License-Exempt Radio Communication Devices Test Report Prepared For: Wes Worth iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 Measurement Facility Description Filed With Department of Industry: Departmental Acknowledgement Number: IC4549 3, Dated July 3, 1997 Declaration of Compliance I declare that the testing was performed or supervised by me; that the test measurements were made in accordance with the above mentioned departmental standards (through the use of ANSI C63.4 as detailed in section 5.3 of RSS-210, Issue 5); and that the equipment performed in accordance with the data submitted in this report. Signature ______________________________ Name Mark Briggs Title Principal Engineer Elliott Laboratories Inc. Address 684 W. Maude Ave Sunnyvale, CA 94086 USA Date: March 2, 2005 Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: March 2, 2005 File: R58878 Page 3 of 19 pages TABLE OF CONTENTS COVER PAGE...................................................................................................................................................................................1 TABLE OF CONTENTS..............................................................................................................................................................3 SCOPE............................................................................................................................................................................................5 OBJECTIVE...................................................................................................................................................................................5 STATEMENT OF COMPLIANCE..............................................................................................................................................6 TEST RESULTS SUMMARY......................................................................................................................................................6 15.231 / RSS 210 SECTION 6.1.................................................................................................................................................6 MEASUREMENT UNCERTAINTIES.........................................................................................................................................7 EQUIPMENT UNDER TEST (EUT) DETAILS..........................................................................................................................8 GENERAL...................................................................................................................................................................................8 OTHER EUT DETAILS.............................................................................................................................................................8 ENCLOSURE..............................................................................................................................................................................8 MODIFICATIONS.....................................................................................................................................................................8 SUPPORT EQUIPMENT...........................................................................................................................................................9 EUT INTERFACE PORTS........................................................................................................................................................9 EUT OPERATION.....................................................................................................................................................................9 ANTENNA SYSTEM................................................................................................................................................................9 TEST SITE....................................................................................................................................................................................10 GENERAL INFORMATION...................................................................................................................................................10 CONDUCTED EMISSIONS CONSIDERATIONS...............................................................................................................10 RADIATED EMISSIONS CONSIDERATIONS..................................................................................................................10 MEASUREMENT INSTRUMENTATION................................................................................................................................11 RECEIVER SYSTEM........................................…

Text truncated - open the document above for the full version.

File: R58878 Page 1 of 19 2016-01 Electromagnetic Emissions Test Report In Accordance With Industry Canada Radio Standards Specification 210 And FCC Part 15 Sections 15.209, 15.231 on the iControl Networks Transmitter Model: iControl Gateway UPN: 5747A-GATEWAY1 FCC ID: S23-GATEWAY1 GRANTEE: iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 TEST SITE: Elliott Laboratories, Inc. 684 W. Maude Ave Sunnyvale, CA 94086 REPORT DATE: March 2, 2005 FINAL TEST DATE: February 16 and February 17, 2005 AUTHORIZED SIGNATORY: ______________________________ Mark Briggs Principal Engineer Elliott Laboratories, Inc. is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories, Inc. Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: March 2, 2005 File: R58878 Page 2 of 19 pages Equipment Name and Model: Transceiver , iControl Gateway Manufacturer: iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 Tested to applicable standard: RSS210, Issue 5, February 1996 Low Power License-Exempt Radio Communication Devices Test Report Prepared For: Wes Worth iControl Networks 502 Waverly St. Suite 302 Palo Alto, CA 94301 Measurement Facility Description Filed With Department of Industry: Departmental Acknowledgement Number: IC4549 3, Dated July 3, 1997 Declaration of Compliance I declare that the testing was performed or supervised by me; that the test measurements were made in accordance with the above mentioned departmental standards (through the use of ANSI C63.4 as detailed in section 5.3 of RSS-210, Issue 5); and that the equipment performed in accordance with the data submitted in this report. Signature ______________________________ Name Mark Briggs Title Principal Engineer Elliott Laboratories Inc. Address 684 W. Maude Ave Sunnyvale, CA 94086 USA Date: March 2, 2005 Elliott Laboratories, Inc. -- EMC Department Test Report Report Date: March 2, 2005 File: R58878 Page 3 of 19 pages TABLE OF CONTENTS COVER PAGE...................................................................................................................................................................................1 TABLE OF CONTENTS..............................................................................................................................................................3 SCOPE............................................................................................................................................................................................5 OBJECTIVE...................................................................................................................................................................................5 STATEMENT OF COMPLIANCE..............................................................................................................................................6 TEST RESULTS SUMMARY......................................................................................................................................................6 15.231 / RSS 210 SECTION 6.1.................................................................................................................................................6 MEASUREMENT UNCERTAINTIES.........................................................................................................................................7 EQUIPMENT UNDER TEST (EUT) DETAILS..........................................................................................................................8 GENERAL...................................................................................................................................................................................8 OTHER EUT DETAILS.............................................................................................................................................................8 ENCLOSURE..............................................................................................................................................................................8 MODIFICATIONS.....................................................................................................................................................................8 SUPPORT EQUIPMENT...........................................................................................................................................................9 EUT INTERFACE PORTS........................................................................................................................................................9 EUT OPERATION.....................................................................................................................................................................9 ANTENNA SYSTEM................................................................................................................................................................9 TEST SITE....................................................................................................................................................................................10 GENERAL INFORMATION...................................................................................................................................................10 CONDUCTED EMISSIONS CONSIDERATIONS...............................................................................................................10 RADIATED EMISSIONS CONSIDERATIONS..................................................................................................................10 MEASUREMENT INSTRUMENTATION................................................................................................................................11 RECEIVER SYSTEM........................................…

Text truncated - open the document above for the full version.

Figure 1: AC Conducted Emissions Figure 2: Radiated Emissions - Front View Figure 3: Radiated Emissions - Rear View
