iControl System Starter Kit Beta User Manual - DRAFT This document provides more detailed information on how to use your iControl System. More specifically: . •how to read your iControl Summary page . •adding, changing, and managing your iControl box and devices, and . •frequently asked questions You should consult your Quick Start Guide or Getting Started Guide for information on how to install your system. Your Starter kit or device box will provide a list of what’s included with the kit or device. © 2004-2007 iControl Networks, Inc. All rights reserved. No reproduction in whole or in part without prior written approval. iControl Networks, iControl and I logo design are pending trademarks of iControl Networks. All other trademarks are the property of their respective owners. Information contained herein is subject to change without notice. The only warranties for iControl products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. iControl shall not be liable for technical or editorial errors or omissions contained herein. Printed in USA. Version 2.0 January 2007 Table of Contents Chapter 1 Chapter 2 Chapter 3 Chapter 4 Chapter 5 Chapter 6 Chapter 7 Chapter 8 Chapter 9 Chapter 10 Chapter 11 Appendix A Check pages Getting Started 3 About your iControl box 9 Using your System 11 Using your Wired Camera 19 Using your Door/Window Sensor 32 Using your Keychain Remote Control 33 Using your Lamp Module 36 Using your Motion Sensor 37 Adding Additional Devices 38 Frequently Asked Questions 42 Terms and Conditions, Warranty Information, and More 44 Battery Maintenance 45 Getting Started Your iControl Summary page is where you begin using your iControl System; the iControl Summary page is your portal to your iControl System. To begin, log on First, go to a web browser and enter www.icontrol.com. In the customer login area, type the user name and password provided to you via email when you purchased your iControl product. You will be presented with your Summary page. This web page provides a fast, simple view into the status of your iControl box and devices. It also is the starting point from which you can monitor your system’s status, change your devices’ setup, add devices, set and change notifications, and set and modify automations. Here is an example of the Summary page where you can access the many functions of your iControl System. Read your Summary page This section provides a definition of the many terms found on your Summary page and serves as a good background to the iControl System. Tabs Your iControl Summary page has five major tabs. Summary tab When you log onto your iControl System from www.icontrol.com, your landing page is the Summary page. This is where you begin using your System. The Summary page consists of the following series of windows. Status window The top portion of this window indicates the overall status of the system and the current mode the system is in. The status light can have three possible colors as described below: Green – No alarm conditions. System operating normally Yellow – One or mode device alarm conditions (e.g. motion detected) Red – System problem (e.g. iControl box communication problem). The Status window also shows the current mode for your iControl System. Here, the System is in ‘Away Mode’. The rest of the Status window is a list showing the current state of all the devices in the system. In the screen shown earlier, three devices appear: a door/window sensor called ‘Back door’; a Thermostat showing the current temperature at 74 degree and its Heat Setpoint to of 69 degrees and Cooling Setpoint of 61 degrees; and a door/window sensor labeled ‘front door’. Your house may have many more devices than three and to view these you place your cursor over the up or down arrow to scroll to see additional devices or on the small box inside the scroll bar. Current states Current states refer to the status of all of your devices. If a device has a yellow triangle next to it, the triangle indicates that the device has recognized a change that creates an alarm. The following table shows the possible states and the alarm conditions of Starter Kit devices. Device Possible state Example Alarm Condition Door/Window Open, Closed Open indicates the Open Sensor door or window is open Motion Occupied, Empty Occupied means a Occupied Sensor person is in the monitored area Additional optional devices, such as freeze, water, smoke and heat sensors have their own associated states as well but are not described here since they are not part of the iControl Starter Kit. Pictures window Here you will see thumbnails of pictures or video from each of your iControl cameras. In the Summary page shown earlier, three thumbnails are shown, as three cameras are active. If your hover the cursor over a thumbnail, the name of the associated camera is displayed. You can also click on the thumbnail and it will expand. From there you can take a new picture, view past pictures, watch live video and delete pictures. Alarm History This window shows the record of the alarms recognized by the devices installed in your iControl System. An alarm occurs whenever a device detects a change, such as a door/window sensor detecting a door open or a motion sensor detects movement. (These are the only two types alarms available from the devices in the Starter Kit. Other optional devices provide alarms for freezing, water leakage, etc. and these devices will be offered in the future). For each change, it shows the time of the alarm. Each item in the alarm history has a yellow triangle next to it, indicating that it is an alarm. You can click on any change to learn more about the device. Use the scroll bar on the right to scroll down the events. The Alarm History only saves the last 7 days of alarms. Pending Updates window This window shows the changes that you made to your IContol …

Text truncated - open the document above for the full version.

January 2, 2007 American TCB 6731 Whittier Avenue, Suite C110 McLean, VA. 22101 Gentlemen: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Subpart C of Part 15 of FCC Rules (CFR 47) regarding intentional radiators and RSS-210 and RSP-100 regarding low power, license-exempt radio communications devices. Data within this report demonstrates that the equipment tested complies with the FCC limits for intentional radiators. Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, David W. Bare Chief Technical Officer DWB/dmg Enclosures: Agent Authorization Letter Application Form Application Fee Emissions Test Report with Exhibits
