S23-IHUB3001BHome Monitoring Gateway

Copyright © 2010 ADT Security Service, Inc. All rights reserved. ISSUE 2.0 11/2010 iHUB-3001B iHUB-3001B-ADT Installation Guide Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 2 Copyright © 2010 ADT Security Service, Inc. All rights reserved. About This Guide This document does not cover the physical installation and special configurations that may be required for the security system components. Refer to the manufacturer's documentation for each device for those specifics. Overview of the Installation Process The installation utilizes a streamlined process for setting up the system. All components are individually activated and tested before being physically installed in their final locations, whenever possible. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 3 Upgrading the iHub Software Prior to activating the service, the software in the iHub may need to be upgraded to the latest version. This process takes approximately 30 minutes to complete and should be performed early in the install process so it can be done parallel with the site’s installation activities. To upgrade the software: 1. On a computer connected to the Internet, open a web browser, and go to the activation URL portal.adtpulse.com/activation. 2. Enter your Installer username and password, and click Sign In. The activation wizard displays the Welcome screen. 3. After reading the information on the screen, click Continue. The Select Hardware screen appears. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 4 4. Select the type of security system panel you are installing, and click Continue. The Enter Activation Key screen appears. 5. The iHub’s current firmware will be displayed, along with the Latest firmware version required. Select “upgrade now” to begin the firmware upgrade. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 5 6. The firmware upgrade process will take about 30 minutes to complete. During this time, other installation activities may be done. 7. When the upgrade is complete, the iHub will reboot and the LEDs will return to the “green / dark / dark / green” state. 8. The installer may sign out of the Activation wizard at this point. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 6 Activating the Service with Security Panel Before continuing the activation process, you must make the hardware connections. Since each security panel is different, follow the instructions in the next section, "Connecting the Hardware ", for the specific security panel you are installing. Then please follow the instructions in "Activating the Service" on page 7 for all security panels. Connecting the Hardware Follow the procedure in this section that applies to the security panel you are installing. Note: Do not connect the iHub gateway's power supply to an electrical outlet until you are instructed to do so by the activation wizard. If you power on the gateway before it is connected to the Internet, it cannot retrieve the information it requires on power up. If you have already done this, simply unplug it and continue with the following instructions. If you are installing a Touch Screen, do not connect it to a power source until you are instructed to do so by the activation wizard. To connect the gateway to the security panel RS422 interface: 1. Wire the RS422 interface unit (Automation Module or xSPIM) per manufacturer’s instructions. The RS422 module will connect to the Control Panel’s Keypad bus.) 2. The iHub connectors are labeled Tx+, Tx-, Rx+, and Rx-. The RS422 interface Module connectors are labeled the same but might include a/b instead of +/-. Using a standard 4-wire security cable, connect the ports on the gateway's RS422 bus to the RS422 interface Module as follows: iHUB Gateway RS422 interface module Tx+ Rx+ or RxD(+) Tx- Rx- or RxD(-) Rx+ Tx+ or TxD(+) Rx- Tx- or TxD(-) Locating the iHUB Internal Antenna units: 1. If the iHUB has no external antenna, the unit must be located on a horizontal surface (desk top). Try to place it at least 6 inches from other communication or heat generating devices. Do not place any electronics/communications devices on top of the iHUB. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 7 External Antenna units: 1. If the iHUB has an external antenna, the unit can be located on a wall or on a horizontal surface (desk top). Try to place it at least 6 inches from other communication or heat generating devices. 2. After mounting ensure the antenna is positioned vertically for best performance. Antenna Position Desk top iHUB Wall mounted iHUB Activating the Service To activate the service: 1. On a computer connected to the Internet, open a web browser, and go to the activation URL portal.adtpulse.com/activation. 2. Enter your Installer username and password, and click Sign In. The activation wizard displays the Welcome screen. 3. After reading the information on the screen, click Continue. The Select Hardware screen appears. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 8 4. Select the type of hardware you are installing, and click Continue. The Enter Activation Key screen appears. 5. Enter the activation key, and click Continue. Note: The activation key contains numbers from 0-9 and letters from A-F. There are no letters O or I. The activation process begins, and then the Select Service Options screen appears. Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 9 6. Select the appropriate options for the installation based on the information on the Installer Reference Sheet, and click Continue. The Physical Setup screen appears. The exact wording on this screen varies based on the security panel you are installing and the service options you selected on the previous screen. 7. Follow the instructions on the screen, and then click Continue. A message displays a progress bar, which indicates approximately how much longer the activation will take. If an upgrade is required, the activation application performs the upgr…

Text truncated - open the document above for the full version.

iControl Networks Inc. Date：March 27, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: S23-IHUB3001B Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, iControl Networks Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Your Sincerely, _____________________ Mike Ergo / VP of Service Operations iControl Networks Inc. TEL:650.739.5838 FAX:650.592.2244 E-Mail:[email protected] iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States

iControl Networks Inc. Date: June 7, 2012 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, Due to the business consideration, we hereby declare that our product of Home Monitoring Gateway Model: iHUB-3001B ; iHUB-3001B-ADT have as following difference The model number iHUB-3001B for Brand Name iControl The model number iHUB-3001B-ADT for Brand Name ADT Are identical just for market purpose only. Any questions regarding this declaration, please don’t hesitate to contact us. iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States

iControl Networks Inc. Date：June 7, 2012 Subject:DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: S23-IHUB3001B, would like to declare that the composite Portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Brand Name & Model Name of the specified radio equipment: iControl ; ADT / iHUB-3001B ; iHUB-3001B-ADT FCC ID: S23-IHUB3001B Product Name: Home Monitoring Gateway Regards, iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States

iControl Networks Inc. Date：March 27, 2012 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, iControl Networks Inc. hereby authorize Compliance Certification Services Inc./ Jason Lin to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2012/09/27 Your Sincerely, Mike Ergo / VP of Service Operations iControl Networks Inc. TEL:650.739.5838 FAX:650.592.2244 E-Mail:[email protected] iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States

Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 1 Total Page: 13 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 2 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 3 Adapter for MU12-G120100-A1 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 4 Adapter for YS1381-1212-W2 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 5 Dipole Antenna

Label Sample & Location

Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 6 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 7 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 8 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 9 Z-WAVE Module Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 10 Z-WAVE Antenna Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 11 WLAN Module Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 12 Compliance Certification Services Inc. Report No.: T120327D06 Date of Issue: May 2, 2012 A1 - 13 PIFA Antenna

Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 26 FCC 47 CFR PART 15 Subpart C TEST REPORT For Home Monitoring Gateway Model Number: iHUB-3001B, iHUB-3001B-ADT Trade Name: iControl, ADT Issued to iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: May 2, 2012 Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 May 2, 2012 Initial Issue ALL Eunice Shem Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION................................................................................................. 4 2. EUT DESCRIPTION....................................................................................................................... 5 3. TEST METHODOLOGY................................................................................................................ 6 3.1 EUT CONFIGURATION................................................................................................................. 6 3.2 EUT EXERCISE............................................................................................................................. 6 3.3 GENERAL TEST PROCEDURES...................................................................................................... 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.................................................. 7 3.5 DESCRIPTION OF TEST MODES.................................................................................................... 7 4. INSTRUMENT CALIBRATION.................................................................................................... 8 4.1 MEASURING INSTRUMENT CALIBRATION............................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .................................................................................. 8 4.3 MEASUREMENT UNCERTAINTY ........................................................................................ 9 5. FACILITIES AND ACCREDITATIONS ..................................................................................... 10 5.1 FACILITIES ................................................................................................................................ 10 5.2 EQUIPMENT...............................................................................................................................10 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.............................................................................. 11 6. SETUP OF EQUIPMENT UNDER TEST.................................................................................... 12 6.1 SETUP CONFIGURATION OF EUT................................................................................................ 12 6.2 SUPPORT EQUIPMENT ........................................................................................................ 12 7. FCC PART 15.249 REQUIREMENTS ......................................................................................... 13 7.1 20 DB BANDWIDTH.............................................................................................................. 13 7.2 SPURIOUS EMISSION .......................................................................................................... 15 7.3 POWERLINE CONDUCTED EMISSIONS ........................................................................... 21 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................ 24 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 4 1. TEST RESULT CERTIFICATION Applicant: iControl Networks Inc. 555 Twin Dolphin Drive Suite 280, Redwood City, California 94065, United States Equipment Under Test: Home Monitoring Gateway Tr a d e N a m e : iControl, ADT Model Number: iHUB-3001B, iHUB-3001B-ADT Date of Test: March 29 ~ April 26, 2012 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements emission limits of FCC Rules Part 15.107, 15.109,15.207, 15.209 and 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jason Lin Gina Lo Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 5 2. EUT DESCRIPTION Product Home Monitoring Gateway Trade Name iControl, ADT Model Number iHUB-3001B, iHUB-3001B-ADT Model Discrepancy All the specification and layout are identical except they come with different model numbers for marketing purposes. Received Date March 27, 2012 Power Adapter 1. Brand: Sunny / Model: SYS1381-1212-W2 I/P: 100-240V, 50-60Hz, 0.5A MAX O/P: 12V, 1.0A 2. Brand: LEADER / Model: MU12-G120100-A1 I/P: 100-240V, 50-60Hz, 0.5A O/P: 12…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 24 APPENDIX I PHOTOGRAPHS OF TEST SETUP Conducted Emission Set Up Photo Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 25 Radiated Emission Set up Photos Compliance Certification Services Inc. FCC ID: S23-IHUB3001B Report No.: T120327D06-RP2 Page 26 Powerline Conducted Emissions Setup Photos
