S3CDB6M33SADB6M Dual Band Repeater DB6M33-700UC+AWS

. Page All Rights Reserved Shyam Telecom Limited 1/43 Next Generation Signal Enhancement RF / DB6M Series O O P P E E R R A A T T I I O O N N & & I I N N S S T T A A L L L L A A T T I I O O N N M M A A N N U U A A L L 5920 0030 200 September 2010 D D B B 6 6 M M ( (Dual Band) 6 Sub-Band Repeater for Outdoor Applications (FCC ID: S3CDB6M33SA and IC:5751A-DB6M33SA for AWS and 700 LTE Upper C Sub-Bands only) PROPRIETARY INFORMATION The information contained herein is proprietary to Shyam Telecom Limited. Unauthorized access, copy and replication are prohibited. This document must not be copied in whole or part by any means or it shall not be disclosed or divulged to any third Party without the prior written consent of Shyam Telecom Limited. . Page All Rights Reserved Shyam Telecom Limited 2/43 Next Generation Signal Enhancement CONTENTS 1. Document History......................................................................................... 4 2. Disclaimer...................................................................................................... 5 3. Safety Instructions and Warnings............................................................... 6 3.1. Personnel Safety....................................................................................6 3.2. Equipment Safety...................................................................................6 3.3. Electrostatic Sensitivity ..........................................................................6 4. Introduction................................................................................................... 7 4.1. Purpose .................................................................................................7 4.2. Scope.....................................................................................................7 4.3. Definitions ..............................................................................................7 4.4. References ............................................................................................8 4.5. General ..................................................................................................9 5. Functional Description of DB6M Dual Band Repeater............................... 9 5.1. General Description ...............................................................................9 6. To Get started-Basic Software Control Of the system............................. 11 6.1. General ................................................................................................11 6.2. Terminal Set-up ...................................................................................12 6.3. Block Schematic Description ...............................................................26 7. DB6M Repeater Specifications.................................................................. 28 7.1. Electrical Specifications-RF ...................................................................1 7.2. Electrical Specification Power Requirement ..........................................1 7.3. External Electrical Interface .................................................................29 7.4. Mechanical Specification .....................................................................29 7.5. Environmental Specification.................................................................29 7.6 Contents of Delivery............................................................................30 8. Installation................................................................................................... 31 8.1. Preparation Sheet- Pre Installation ......................................................31 8.2. Engineering Consideration...................................................................32 8.3. Installation Tools ..................................................................................34 8.4. Installation Procedure ..........................................................................34 8.5. Repeater Gain Settings........................................................................35 8.6. Commissioning ....................................................................................35 8.7. Dos & Don’t Dos ..................................................................................36 . Page All Rights Reserved Shyam Telecom Limited 3/43 Next Generation Signal Enhancement 8.8. Checklist – Post Installation .................................................................37 9. Trouble Shooting........................................................................................ 40 10. System Maintenance................................................................................. 41 10.1. General ..............................................................................................41 10.2. Preventive Maintenance ....................................................................41 11. Shut Down Mechanisms............................................................42 . Page All Rights Reserved Shyam Telecom Limited 4/43 Next Generation Signal Enhancement 1. Document History Document Number Document Name Date Compiled by Approved by Revision 5920 0030 200 DB6M Dual Band Repeater September 2010 Inderjit Ramvir Singh Revision Revised Section Date . Page All Rights Reserved Shyam Telecom Limited 5/43 Next Generation Signal Enhancement Intentionally Left Blank 2. Disclaimer Every attempt has been made to make this material complete, accurate, and up-to-date. Users are cautioned, however, that Shyam Telecom Limited reserves the right to make changes without notice and shall not be responsible for any damages including consequential, caused by reliance of the contents presented, including, but not limited to, typographical, arithmetical, or listing errors. Product name(s) referenced in this document may be trademarks or registered trademarks of their respective companies, and are hereby acknowledged. In areas with unstable power…

Text truncated - open the document above for the full version.

1 Next Generation Signal Enhancement Shyam Telecom Inc. 6 Kilmer Road, Suite D, Edison, NJ 08902 T 732 985 1324 F 732 907 1023 www.shyamtelecom.com December 10, 2010 FCC ID: S3CDB6M33SA IC: 5751A-DB6M33SA FCC and IC Confidentiality Request In accordance with 0.459 & 0.457 of CFR 47, please, accept this letter as an official request to have the schematics, block diagram, operational description, tune-up procedure and parts list of BTS Link treated as confidential. The information contained within is a result of extensive investment and development effort by Shyam Telecom, inc. and its disclosure will compromise Shyam Telecom’s Intellectual Property and competitive edge. We thus ask the FCC and IC NOT to publish the enclosed information including Schematics, Block diagram and operational description in order to protect Shyam Telecom Inc.’s Intellectual Property. Sincerely, B.S.Yadav Vice President Shyam Telecom Inc.

EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 45 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Section 13. EUT Photos external Front View EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 46 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Bottom/Side View

EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 41 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Section 10. FCC ID Labeling FCC ID Label Location of Label on the back/side of EUT FCC LABEL FCC ID: S3CDB6M33SA This device complies with Part 2 & Part 27 of the FCC Rules. Operation is subject to the following two condit ions: (1) this device may not cause harmful interference. and (2) this device must accept any interference received, including interference that may cause undesired operation.

EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 47 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 internal Open View EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 48 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Converter & PA View EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 49 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Duplexer & PS View EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 50 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 PA Module View

(3) Converter AWS DL (4) Converter AWS UL

(7) LNA AWS DL (10) LNA AWS UL

(11) Quadplexer 700MHz & AWS Band (2 Qty @ DL & UL) (12) Mother Board (13) Supervisory Board

(1)Power Amplifier AWS DL (2) Power Amplifier AWS UL

(3) Power Amplifier 700MHz DL (4) Power Amplifier 700MHz UL

Electromagnetic Emission Compliance Test Report Equipment Under Test (EUT) DB6M Dual Band Repeater Applicant Shyam Telecom Inc. In Accordance With FCC Part 27 & Part 2 Test by Advanced Compliance Laboratory, Inc. 6 Randolph Way Hillsborough, New Jersey 08844 Authorized by Wei Li Lab Manager Signature Date December 10, 2010 AC Lab Report Number 0048-101122-01 The test result in this report is supported and covered by the NVLAP accreditation. Lab Code:200101-0 Advanced Compliance 6 Randolph Way Hillsborough, NJ 08844 Tel: (908) 927 9288 Fax: (908) 927 0728 EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 2 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Index Section 1. Summary of Test Results.....................................................................3 Section 2. General Equipment Specification.......................................................5 Section 3. RF Output Power....................................................................................7 Section 4. Occupied Bandwidth........................................................................... 14 Section 5. Spurious Emissions at Antenna Terminals.................................... 24 Section 6. Field Strength of Spurious................................................................. 48 Section 7. Frequency Stability.............................................................................. 54 Section 8. Out of Band Rejection......................................................................... 56 Section 9. Test Equipment List............................................................................. 61 Section 10. FCC ID Labeling.................................................................................. 62 Section 11. Maximum Permissible Exposure.................................................... 63 Section 12. Setup Photos...................................................................................... 64 Section 13. EUT Photos......................................................................................... 65 EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 3 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Section 1. Summary of Test Results Manufacturer: Shyam Telecom Inc. Product Name: DB6M Dual Band Repeater Model No.: DB6M33-700UC+AWS Sample No.: D6M30GFJ01 General: All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 27& Part 2. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. “See Summary of Test Data” NVLAP LAB CODE: 200101-0 Advance Compliance Laboratory, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Advance Compliance Laboratory, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 4 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Summary of Test Data RF Power Output 27.50& 2.1046 1000W/MHz ERP Complies Occupied Bandwidth (Digital) 2.1049(i) Mask Complies Spurious Emissions at Antenna Terminals for SMR700 Band 27.53&2.1051 27.53(c)(f) Complies Spurious Emissions at Antenna Terminals for AWS2100 Band 27.53&2.1051 27.53(h) Complies Field Strength of Spurious Emissions 2.1053 -13 dBm E.I.R.P. Complies RF Safety 27.52 1.1307(b) 2.1091 2.1093 Complies Frequency Stability 27.54 2.1055 Complies* * These items are NOT applied to the EUT. The estimated uncertainty of the test result is given as following. The method of uncertainty calculation is provided in Advanced Compliance Lab. Doc. No. 0048-01-01. Prob. Dist. Uncertainty(dB) Uncertainty(dB) Uncertainty(dB) 30-1000MHz 1-6.5GHz Conducted Combined Std. Uncertainty u c norm. ±2.36 ±2.99 ±1.83 Wei Li Date: December 10, 2010 Lab Manager Advanced Compliance Lab EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 5 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Section 2. General Equipment Specification Supply Voltage 100-240VAC, 50-60Hz DL/ 746-756MHz SMR 700MHz Upper C UL/ 777-787MHz DL/ 2145-2155MHz Frequency Range AWS 2100MHz UL/ 1745-1755MHz Modulation LTE CDMA GSM EDGE TDMA Type of Emissions F9W F9W GXW G7W DXW Rated Power DL: +30.0dBm & UL:+27dBm for each Sub-band Rated Gain 85.0 +/-2dB for each Sub-band Output Impedance /Nominal OCBW 50ohm / 9MHz F1-F1 F1-F2 N/A Frequency Translation Software Duplexer Change Full Band Coverage DC voltages and DC currents per 2.1033(c)(8) The input supply to the transmitter was set at 27Volts DC. The RF power output was measured with the indicated voltage and current applied into the final RF amplifying device(s). SMR 700UC Band RF Output, DC Current and RF Input Power are all average values. Rated RF DL output : +30dBm w/ V=27V & I=2.25A Rated RF UL output : +27Bm w/ V=27V & I=2.25A AWS 2100 Band RF Output, DC Current and RF Input Power are all average values. RF Output, DC Current and RF Input Power are all average values. Rated RF DL output : +30dBm w/ V=27V & I=2.75A Rated RF UL output : +27Bm w/ V=27V & I=2.75A EUT: DB6M Dual Band Repe…

Text truncated - open the document above for the full version.

EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 43 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Section 12. Setup Photos Conducted Power/OC/Spurious Test EUT: DB6M Dual Band Repeater FCC ID: S3CDB6M33SA Model: DB6M33-700UC+AWS Report Number: 0048-101122-01 Page 44 Advanced Compliance Laboratory, Inc. 6 Randolph Way, Hillsborough, NJ 08844, Tel: (908) 927 9288 Field Strength of Spurious
