Telegesis TG-ETRX35X-LR-PM-011-101 ETRX351-LR AND ETRX357-LR Preliminary Product Manual ©2010 Telegesis (UK) Ltd ETRX35x-LR Preliminary Product Manual ETRX35x-LR ZIGBEE ® MODULES PRODUCT MANUAL ETRX351-LR AND ETRX357-LR ©2010 Telegesis (UK) Ltd - 2 - ETRX35x-LR Preliminary Product Manual Table of Contents 1 INTRODUCTION...................................................................................................................5 1.1 Hardware Description ........................................................................................................ 5 2 PRODUCT APPROVALS ..................................................................................................... 6 2.1 FCC Approvals...................................................................................................................6 2.1.1 FCC Labelling Requirements............................................................................................. 6 2.2 European Certification .......................................................Error! Bookmark not defined. 2.3 Declarations of Conformity.................................................Error! Bookmark not defined. 2.4 IEEE 802.15.4.................................................................................................................... 6 2.5 The ZigBee® Protocol ....................................................................................................... 6 3 MODULE PINOUT ................................................................................................................ 8 4 HARDWARE DESCRIPTION ............................................................................................. 10 4.1 Hardware Interface .......................................................................................................... 10 5 FIRMWARE DESCRIPTION ............................................................................................... 11 5.1 Custom Firmware............................................................................................................. 11 5.2 Software Interface............................................................................................................ 12 6 ABSOLUTE MAXIMUM RATINGS..................................................................................... 13 7 RECOMMENDED OPERATING CONDITIONS ................................................................. 13 8 DC ELECTRICAL CHARACTERISTICS ............................................................................ 14 9 DIGITAL I/O SPECIFICATIONS ......................................................................................... 15 10 A/D CONVERTER CHARACTERISTICS ........................................................................... 16 11 AC ELECTRICAL CHARACTERISTICS ............................................................................ 16 11.1 TX Power Characteristics ................................................................................................ 18 12 PHYSICAL DIMENSIONS .................................................................................................. 19 13 SOLDERING TEMPERATURE TIME PROFILE (FOR REFLOW SOLDERING) .............. 20 13.1 For Leaded Solder ........................................................................................................... 20 13.2 For Lead-free Solder........................................................................................................ 20 14 PRODUCT LABEL DRAWING ........................................................................................... 21 15 RECOMMENDED FOOTPRINT ......................................................................................... 22 15.1 Example carrier board...................................................................................................... 23 16 RELIABILITY TESTS ......................................................................................................... 24 17 APPLICATION NOTES ...................................................................................................... 24 17.1 Safety Precautions........................................................................................................... 24 17.2 Design Engineering Notes ............................................................................................... 24 17.3 Storage Conditions .......................................................................................................... 25 ETRX351-LR AND ETRX357-LR ©2010 Telegesis (UK) Ltd - 3 - ETRX35x-LR Preliminary Product Manual 18 PACKAGING ......................................................................................................................25 18.1 Embossed Tape............................................................................................................... 25 18.2 Component Orientation.................................................................................................... 26 18.3 Reel Dimensions.............................................................................................................. 26 18.4 Packaging ........................................................................................................................ 26 19 ORDERING INFORMATION .............................................................................................. 27 20 TRADEMARKS................................................................................................................... 28 21 DISCLAIMER ......................................................................................................................28 22 ROHS DECLARATION....................................................................................................... 28 23 DATA SHEET STATUS ...................................................................................................... 28 24 LIFE SUPPORT POLICY......................................................…

Text truncated - open the document above for the full version.

Position of the Label on ETRX3 Series Modules The non peel label is attached during production in the position as shown below. The label can withstand reflow soldering.

Position of the Label on ETRX3 Series Modules The non peel label is attached during production in the position as shown below. The label can withstand reflow soldering.

Appendix G:MPE Calculation OET Bulletin No. 65, Supplement C 01-01 47 CFR §§1.1307 and2.1091 2.1091 Radio frequency radiation exposure evaluation: mobile devices. For purposes of these requirements mobile devices are defined by the FCC as transmitters designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimetres is normally maintained between radiating structures and the body of the user or nearby persons. These devices are normally evaluated for exposure potential with relation to the MPE limits. As the 20cmseparation specified under FCC rules may not be achievable under normal operation of the EUT, an RF exposure calculation is needed to show the minimum distance required to be less than 1mW/cm 2 power density limit, as required under FCC rules. Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where: S = power density R = distance to the centre of radiation of the antenna EIRP = EUT Maximum power Note: The EIRP measurement was performed using the peak conducted power measurement in conjunction with the maximum declared antenna gain. Result Prediction Frequency (MHz) Maximum EIRP (mW) Power density limit (S) (mW/cm 2 ) Distance (R) cm required to be less than 1mW/cm 2 (cm) 240519.911.3 4 arranged-re 4 2 S EIRP R R EIRP S

Total number of pages : 111 TRaC Radio Test Report : TTR001087WUS1 Applicant : Telegesis (UK) Ltd Apparatus : ETRX357-LR#2 Radio Module Specification(s) : CFR47 Part 15.247 2008 FCCID : S4GEM35X2 Purpose of Test : Certification Authorised by : : Authorised Signatory 2 nd July 2010 Issue Date :2 Authorised Copy Number : PDF TRaC Radio Test Report: TTR001087WUS1 Contents Section 1: Introduction 3 1.1 General 3 1.2 Tests Requested By 4 1.3 Manufacturer 4 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes Relating To The Assessment 7 1.7 Deviations from Test Standards 7 Section 2: Measurement Uncertainty 8 2.1 Measurement Uncertainty Values 8 Section 3: Modifications 9 3.1 Modifications Performed During Assessment 9 Appendix A: Formal Emission Test Results 10 A1 6 dB Bandwidth 11 A2 Transmitter Peak Output Power 12 A3 Transmitter Power Spectral Density 13 A4 RF Antenna Conducted Spurious Emissions 14 A5 Radiated Electric Field Emissions within the Restricted Bands of 15.205 18 A6 Power Line Conducted Emissions 22 A7 Antenna Gain 25 A8 Unintentional Radiated Electric Field Emissions - 15.109 26 Appendix B: Supporting Graphical Data 29 Appendix C: Additional Test and Sample Details 83 Appendix D: Additional Information 90 Appendix E: Calculation of the duty cycle correction factor 105 Appendix E: Calculation of the duty cycle correction factor 105 Appendix F: Photographs and Figures 106 Appendix G: MPE Calculation 110 2 TRaC Radio Test Report: TTR001087WUS1 Section 1: Introduction 1.1 General This report contains an a ssessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed at: TRaC Telecoms & Radio [ X ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Telecoms & Radio [ ] Moss View Nipe Lane Up Holland West Lancashire, WN8 9PY United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: M E Leach Report author: K J Anderson This report must not be reproduced except in full without prior written permission from TRaC Telecoms & Radio. 3 TRaC Radio Test Report: TTR001087WUS1 1.2 Tests Requested By This testing in this report was requested by : Telegesis (UK) Ltd 3 Abbey Barn Business Centre Abbey Barn Lane High Wycombe Bucks HP10 9QQ 1.3 Manufacturer Ryder Electronics (Shen zhen) Ltd 139 Da Bao Road, District 33 Bao An, Shenzhen 518133 China 4 TRaC Radio Test Report: TTR001087WUS1 1.4 Apparatus Assessed The following apparatus was assessed between: 29/06/10 and 21/07/10 ETRX357-LR#2 Module The ETRX357-LR#2 is a Long-Range (high power) Zigbee module fitted with an integral (Antenova Rufa 2.4GHz SMD) PCB mount antenna. All radiated testing was performed using the integral antenna, the conducted tests were performed using an ETRX357-LR HR module fitted with a Hirose U.FL connector for connection to the appropriate test equipment. Datasheets for the antenna is reproduced in Appendix D of this report The family of products also include an ETRX351 series of modules that have identical RF circuitry to the ETRX357 range but with reduced on-board memory. No testing was performed on these modules. Details of the ETRX351 modules are contained within Appendix D of this report. 5 TRaC Radio Test Report: TTR001087WUS1 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result Radiated spurious emissions (Restricted bands) Title 47 of the CFR: Part 15 Subpart C; 15.247 ANSI C63.10 Pass Conducted spurious emissions (Non-restricted bands) Title 47 of the CFR: Part 15 Subpart C; 15.247 ANSI C63.10 Pass AC Power conducted emissions Title 47 of the CFR: Part 15 Subpart C; 15.207 ANSI C63.10 Pass Occupied Bandwidth Title 47 of the CFR : Part 15 Subpart C; 15.247(a)(2) ANSI C63.10 Pass Conducted Carrier Power Title 47 of the CFR : Part 15 Subpart C; 15.247(b) ANSI C63.10 Pass Power Spectral Density Title 47 of the CFR : Part 15 Subpart C; 15.247(d) ANSI C63.10 Pass Unintentional Radiated Spurious Emissions Title 47 of the CFR: Part 15 Subpart C; 15.109 ANSI C63.10 Pass Digital Modulation Title 47 of the CFR: Part 15 Subpart C; 15.403 - Pass RF Safety Title 47 of the CFR : Part 15 Subpart C; 15.247(b)(5) - Pass Abbreviations used in the above table: Mod : Modification CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions 6 TRaC Radio Test Report: TTR001087WUS1 1.6 Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in th…
