S4RBRBUZ81975Consumer Wide-band Bi-directional Booster

® Stealth Series Dual Band Booster Amplifiers BRB Stealth Z1 User Manual COTTAGES BUILDINGS HOMES Increases your Cellular and PCS Band Signals, expands your service coverage area, enhances voice call quality and significantly increases Data speeds. Table of Contents Pg. 2 Kit Type Configurations..............................................................................3 Optional parts................................................................................................3 Antenna and Booster Installation..........................................................4 Installation Illustrations...............................................................................5 Control panel ................................................................................................6 LED lights - Outside signal level/RX power..........................................6 Frequently asked questions......................................................................7 Troubleshooting guide.............................................................................7 Inside Antennas ............................................................................................8 Outside Antennas ........................................................................................8 Splitters/Power Dividers.............................................................................8 Extention Cables ..........................................................................................9 Specifications..............................................................................................11 Glossary of terms.......................................................................................12 FCC Information..........................................................................................12 Warranty.....................................................................................................12 This is a CONSUMER device BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 locator information may not be provided or may be inaccurate forcalls served by using this device. To comply with FCC rules the use of this device in any building is for personal use only. Package Contents Typical Configuration Pg. 3 AC/DC Power Supply Indoor Antenna Outdoor Antenna Main Booster Unit Optional Parts Co-Ax Cables RF Splitter/Power Divider Co-Ax Adapters 2”11”14”26” Avaliable Antennas Antenna Pole Mount Kit BRBZ Series (Individual Kit Configuration Parts Included Vary By Model) NOTE : Your model may ship with different antennas. Antenna and Booster Installation a) Location: There are three choices. fig. 2, 3, 4. The choice of donor antenna location depends on the signal strength at the donor antenna location. Use your phone to determine if signal at your chosen location is adequate. Better signal level at the donor antenna location equals larger indoor coverage area. b) Directional Donor Antenna: if using an optional directional donor antenna, point the antenna toward the desired tower. If the location of the desired tower is not known, initiate a phone call and use the signal indicator on your phone after the booster is operational, while turning the donor antenna, to determine optimum donor antenna direction for maximum signal strength. c) Omni-directional Donor Antenna: if using an omni-directional donor antenna, it is recommended that it is placed as far as possible from the inside antenna, usually, ‘outside pole mount’ is recommended (Fig. 4). Use of omni-directional antennas will require more separation distance compared to directional antennas. Fig. 1 Donor Antenna: (outdoor signal antenna) Distribution Antenna: (indoor signal antenna) Connection and Start Procedure: Amplifier/Booster Location: Install the repeater in a location that has proper ventilation, away from excessive heat and moisture. a) Location: There are three choices. fig. 2, 3, 4. The choice of donor antenna location depends on the area to be covered. b) Directional Distribution Antenna: it is recommended that directional antennas are oriented in a fashion that is back to back of each other Fig. 1 c) Omni-directional Distribution Antenna: it is important that omni-directional antennas are separated as far apart as possible from each other. Use of omni-directional antennas will require more separation distance compared to directional antennas d) Splitting Indoor Signal: it is possible to use more than one indoor antenna to cover areas that are separated by walls or floors by using antenna splitters or power dividers, however splitters have a level of signal loss (3dB) and the added cable run will also have signal loss, therefore the coverage area will be diminished. As a general rule, if outside signal is good, splitting signal to more than one distribution antenna results in reasonable coverage. If outside signal is poor or marginal, splitting signal to more than one distribution antenna results in decreased coverage for both distribution antennas. Use only genuine SmoothTalker splitters. Contact your dealer or www.smoothtalker.com WARNING: Make sure all cables have a good connection and are connected to the corresponding antenna port on the Booster. DO NOT APPLY POWER or turn on the power switch on the Amplifier/Booster before all cables and antennas are connected. Antenna connections must be snug and hand tight, ‘Do Not Use Pliers or Wrench’. Connect the cable from outdoor antenna to RF port (a…

Text truncated - open the document above for the full version.

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Phone:(905)726-3444 Fax:(905)726-4233 May 22, 2014 Federal Communications Commission Office of Engineering and Technology 445 12th Street, S.W. Washington, D.C. 20554 Device: Wideband Consumer Wireless Booster FCC ID: S4RBRBUZ81975 Subject: KDB 935210 SIGNAL BOOSTERS CERTIFICATION REQUIREMENTS 3 Consumer Signal Booster Specifics Section: (c) Attestation non-confidential (1) Does not apply to wideband consumer booster (2) NPS and other compliance/safeguard features have been implemented (3) NPS and other compliance/safeguard features are defaulted to be “On” (in operation) (4) NPS and other compliance/safeguard features can not be field reconfigured, disabled or removed (5) Consumer booster is not user programmable, does not need fine tuning or adjustment, does not require professional installation (6) Future software upgrade will not cause non-compliance Sincerely Tom Vagenas Director

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 FCC Authorization May 22, 2014 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for the following project: FCC ID: S4RBRUZB81975 Product Description: Consumer wide-band bi-directional fixed booster To whom it may concern: We Mobile Communications Inc., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Tom Vagenas Director ASO QA-FR-170-A

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 FCC Confidential Authorization May 22, 2014 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: S4RBRBUZ81975 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Mobile Communications Inc., hereby requests long-term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics •Operational Description As well as short-term confidential treatment of information accompanying this application as outlined below: •Internal Photos •User’s Manual •External Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Tom Vagenas, Director ASO QA-FR-172-A

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 DECLARATION OF SIMILARITY May 22, 2014 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Ave. Sunnyvale, CA 94089 Phone: 408-732-9162, Fax: 408-732-9164 http://www.baclcorp.com Dear Sir or Madam: We, Mobile Communications Inc., hereby declare that product: Consumer wide-band bi-directional fixed booster, models listed below meet the requirements of the NPS, are electrically identical with identical hardware components and have the same electromagnetic emissions and electromagnetic compatibility characteristics as tested and reported in the S4RBRBUZ81975 conducted and radiated test reports. The model that was tested was the highest gain of all models listed. The models that are declared as similar differ only in reduced conducted gain which is set by software controlled variable attenuators residing on the EUT circuit board. Descriptions of the differences between the tested model and those that are declared similar are as follows: Tested Model: BRBUZ1-72: maximum gain of 72.0 db 1900Mhz and 64.9 db 800MHz Similar Model: BRBUZ1-70: maximum gain of 70.0 db 1900Mhz and 64.9 db 800MHz Similar Model: BRBUZ1-68: maximum gain of 68.0 db 1900Mhz and 64.9 db 800MHz Similar Model: BRBUZ1-65: maximum gain of 65.0 db 1900Mhz and 64.9 db 800MHz Similar Model: BRBUZ1-62: maximum gain of 65.0 db 1900Mhz and 62.0 db 800MHz Similar Model: BRBUZ1-60: maximum gain of 63.0 db 1900Mhz and 60.0 db 800MHz Similar Model: BRBUZ1-58: maximum gain of 60.0 db 1900Mhz and 58.0 db 800MHz Similar Model: BRBUZ1-55: maximum gain of 60.0 db 1900Mhz and 55.0 db 800MHz Please contact me should there be need for any additional clarification or information. Sincerely, Tom Vagenas Director ASO BACL-NF0028-A

Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 18 of 21 FCC Part 22H/24E Test Report 8 Exhibit C- EUT Photographs 8.1 EUT Top View 8.2 EUT - Bottom View Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 19 of 21 FCC Part 22H/24E Test Report 8.3 EUT - Side View 1 8.4 EUT - Side View 1

Mobile Communications Inc. FCC ID: S4RBRBUZ81975 DUT label Warning label Label location: Page 1 of 1FCC Part 20.21 This is a CONSUMER device BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 locator information may not be provided or may be inaccurate for calls served by using this device.

Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 20 of 21 FCC Part 22H/24E Test Report 8.5 EUT – Open Chassis View 8.6 EUT – PCB Top View Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 21 of 21 FCC Part 22H/24E Test Report 8.7 EUT – PCB Bottom View 8.8 EUT – AC/DC Adapter --- END OF REPORT ---

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 May 22, 2013 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 Subject: Tune-up procedure Reference: S4RBRBUZ81975 Dear Sir/Madam, This devise does not require any tune-up procedure. Sincerely, Tom Vagenas Director ASO

Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 9 of 21 FCC Part 22H/24E Test Report 4 FCC §1.1310 & §2.1091 - RF Exposure Information 4.1 Applicable Standards According to §1.1310 and §2.1091 (Mobile Devices) RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Cellular Band Uplink: Maximum output power at antenna input terminal (dBm): 26.8 Maximum output power at antenna input terminal (mW): 478.63 Prediction distance (cm): 20 Prediction frequency (MHz): 836 Maximum Antenna Net Gain (dBi): 6.26 Maximum Antenna Net Gain (numeric): 4.23 Power density at predication frequency and distance (mW/cm 2 ): 0.403 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 0.557 Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 10 of 21 FCC Part 22H/24E Test Report Downlink: Maximum output power at antenna input terminal (dBm): 6.1 Maximum output power at antenna input terminal (mW): 4.07 Prediction distance (cm): 20 Prediction frequency (MHz): 881 Maximum Antenna Net Gain (dBi): 6.34 Maximum Antenna Net Gain (numeric): 4.31 Power density at predication frequency and distance (mW/cm 2 ): 0.003 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 0.587 PCS Band Uplink: Maximum output power at antenna input terminal (dBm): 28.4 Maximum output power at antenna input terminal (mW): 691.83 Prediction distance (cm): 20 Prediction frequency (MHz): 1880 Maximum Antenna Net Gain (dBi): 1.94 Maximum Antenna Net Gain (numeric): 1.56 Power density at predication frequency and distance (mW/cm 2 ): 0.215 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 1.0 Downlink: Maximum output power at antenna input terminal (dBm): 1.84 Maximum output power at antenna input terminal (mW): 1.53 Prediction distance (cm): 20 Prediction frequency (MHz): 1960 Maximum Antenna Net Gain (dBi): 6.34 Maximum Antenna Net Gain (numeric): 4.31 Power density at predication frequency and distance (mW/cm 2 ): 0.001 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 1.0 4.3 MPE Result The device complies with the MPE requirements by providing a safe separation distance of 20 cm between the antennas, including any radiating structure. The proposed RF exposure safety information has been included in the User’s Manual.

Mobile Communications Inc. FCC ID: S4RBRBUZ81975 Report Number: BRBUZ81975 Page 1 of 81 FCC Part 20.21 FCC TEST REPORT FCC Rules Part 20.21 For: Mobile Communications, Inc 230 Earl Stewart Dr., Aurora, ON, Canada L4G6V8 FCC ID: S4RBRBUZ81975 Report Type: Original Report Product Type: Consumer wide-band bi-directional fixed booster Test Engineer: Roman Gurvich Report Number: BRBUZ81975 Report Date: May 22, 2014 Prepared By: Roman Gurvich Mobile Communications Inc. FCC ID: S4RBRBUZ81975 Report Number: BRBUZ81975 Page 2 of 81 FCC Part 20.21 Table of Contents 1 GENERAL INFORMATION ..................................................................................... 4 1.1 Product Description Equipment Under Test (EUT) ............................................. 4 1.2 Mechanical Description........................................................................................ 4 1.3 Objective .............................................................................................................. 4 1.4 Test Methodology ................................................................................................ 4 1.5 Measurement Uncertainty .................................................................................... 5 1.6 Test Facility .......................................................................................................... 5 1.7 Test Equipment .................................................................................................... 5 2 Summary of Test Results ............................................................................................ 6 2.1 Rules Applied ....................................................................................................... 6 2.2 Notes..................................................................................................................... 6 3 Test Report .................................................................................................................. 7 3.1 Authorized Frequency Band Verification Test .................................................... 7 3.1.1 Authorized frequency band test procedure .................................................... 7 3.1.2 Authorized frequency band test results .......................................................... 8 3.2 Maximum Power Measurement Test ................................................................. 11 3.2.1 Maximum power measurement test procedure ............................................ 11 3.2.2 Maximum power test results ........................................................................ 12 3.3 Maximum Booster Gain Computation ............................................................... 13 3.3.1 Maximum gain calculation procedure ......................................................... 13 3.3.2 Maximum gain test results ........................................................................... 13 3.4 Intermodulation Product Test ............................................................................. 14 3.4.1 Intermodulation product test procedure ....................................................... 14 3.4.2 Intermodulation product test results............................................................. 15 3.5 Out-Of-Band Emissions Test ............................................................................. 17 3.5.1 Out of band emissions test procedure .......................................................... 17 3.5.2 Out of band emissions test results ................................................................ 19 3.6 Conducted Spurious Emissions Test .................................................................. 35 3.6.1 Conducted spurious emissions test procedure ............................................. 35 3.6.2 Conducted spurious emissions test results ................................................... 37 3.7 Noise Limits Test ............................................................................................... 41 3.7.1 Noise power in the presence of a downlink signal test procedure ............... 41 3.7.2 Test results for noise power in presence of downlink signal ....................... 42 3.7.3 Maximum noise power test procedure ......................................................... 43 3.7.4 Maximum noise power test results .............................................................. 44 3.7.5 Uplink noise power timing test procedure. .................................................. 46 3.7.6 Uplink noise power timing test results......................................................... 46 3.8 Uplink Inactivity Test......................................................................................... 48 3.8.1 Uplink inactivity test procedure ................................................................... 48 3.8.2 Uplink inactivity test results ........................................................................ 48 3.9 Variable Booster Gain Test ................................................................................ 51 3.9.1 Variable booster gain test procedure............................................................ 51 3.9.2 Variable booster gain test results ................................................................. 52 Mobile Communications Inc. FCC ID: S4RBRBUZ81975 Report Number: BRBUZ81975 Page 3 of 81 FCC Part 20.21 3.9.3 Variable uplink gain timing test procedure .................................................. 52 3.9.4 Variable uplink gain timing test results ....................................................... 52 3.10 Occupied Bandwidth Test .............................................................................. 55 3.10.1 Occupied bandwidth test procedure ............................................................. 55 3.10.2 Occupied bandwidth Test Results. ............................................................... 56 3.11 Oscillation Detection Test .........................................…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.3) FCC PART 22H & 24E TEST AND MEASUREMENT REPORT For Mobile Communications, Inc. 230 Earl Stewart Drive, Aurora, Ontario L4G 6V8, Canada FCC ID: S4RBRBUZ81975 Report Type: Original Report Product Type: Dual Band Wireless Booster Prepared By: Chen Ge Test Engineer Report Number: R1408087-2224 Report Date: 2014-08-28 Reviewed By: Ivan Cao RF Lead Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 2 of 21 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION ............................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................... 4 1.2 MECHANICAL DESCRIPTION .............................................................................................................................. 4 1.3 OBJECTIVE ......................................................................................................................................................... 4 1.4 RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 4 1.5 TEST METHODOLOGY ........................................................................................................................................ 4 1.6 MEASUREMENT UNCERTAINTY .......................................................................................................................... 5 1.7 TEST FACILITY ................................................................................................................................................... 5 2 SYSTEM TEST CONFIGURATION .................................................................................................................. 7 2.1 JUSTIFICATION ................................................................................................................................................... 7 2.2 EUT EXERCISE SOFTWARE ................................................................................................................................ 7 2.3 EQUIPMENT MODIFICATIONS ............................................................................................................................. 7 2.4 EUT INTERNAL CONFIGURATION ...................................................................................................................... 7 2.5 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS .............................................................................................. 7 2.6 POWER SUPPLY AND LINE FILTERS .................................................................................................................... 7 2.7 INTERFACE PORTS AND CABLING ...................................................................................................................... 7 3 SUMMARY OF TEST RESULTS ........................................................................................................................ 8 4 FCC §1.1310 & §2.1091 - RF EXPOSURE INFORMATION ............................................................................ 9 4.1 APPLICABLE STANDARDS .................................................................................................................................. 9 4.2 MPE PREDICTION .............................................................................................................................................. 9 4.3 TEST RESULT ................................................................................................................................................... 10 5 FCC §2.1053, §22.917 & §24.238 - RADIATED SPURIOUS EMISSIONS .................................................... 11 5.1 APPLICABLE STANDARD .................................................................................................................................. 11 5.2 TEST PROCEDURE ............................................................................................................................................ 11 5.3 TEST SETUP BLOCK DIAGRAM ......................................................................................................................... 11 5.4 TEST EQUIPMENT LIST AND DETAILS .............................................................................................................. 12 5.5 TEST ENVIRONMENTAL CONDITIONS ............................................................................................................... 12 5.6 TEST RESULTS ................................................................................................................................................. 12 6 EXHIBIT A - FCC ID LABELING REQUIREMENTS .................................................................................. 14 6.1 FCC ID LABEL REQUIREMENT ........................................................................................................................ 14 6.2 FCC ID LABEL CONTENTS AND LOCATION ..................................................................................................... 15 7 EXHIBIT B - TEST SETUP PHOTOGRAPHS ................................................................................................ 16 7.1 RADIATED EMISSIONS – ABOVE 1 GHZ FRO…

Text truncated - open the document above for the full version.

Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 16 of 21 FCC Part 22H/24E Test Report 7 Exhibit B - Test Setup Photographs 7.1 Radiated Emissions – Above 1 GHz Front View 7.2 Radiated Emissions – Above 1 GHz Rear View Mobile Communications, Inc. FCC ID: S4RBRBUZ81975 Report Number: R1408087-2224 Page 17 of 21 FCC Part 22H/24E Test Report 7.3 Radiated Emissions – Below 1 GHz Front View 7.4 Radiated Emissions – Below 1 GHz Rear View
