S4RBST22030Dual Band Bi-directional Booster

For use with: 2G, 3G & 4G Cellular Devices The BST220-15 Dual Band RX/TX 800/1900Mhz Signal Booster with Smoothtalker proprietary " Stealthtech Signal Technology " Increases your Cellular and PCS Band Signals, expands your service coverage area, enhances voice call quality and significantly increases Data speeds The Intelligent CPU monitors the environment in which the amplifier is operating and continuously adjusts itself to prevent Oscillation and also automatically prevents any RX/TX overload to both the Cell Phone and Cellular Tower while giving you maximum signal improvement. It is easy and simple to install and you can be up and running in minutes Series: BST220-15 User Manual & Instructions This is a CONSUMER device BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider. WARNING. E911 locator information may not be provided or may be inaccurate for calls served by using this device. LED Light Indicators on Panel Label: Initial Setup Assembly & Installation 1-First make sure that no power is connected to the booster. Connect the inside antenna or cell phone holder, the outside antenna and power supply to the booster. Please make sure to connect each item in to the correct ports as indicated on the booster. 2-Place the antenna on the outside of the vehicle and keep it separated as far as possible from the inside antenna or cell phone holder. 3-Turn the power switch to ON position and the single Green LED on the side of the unit will become Green constant ON to indicate that pwr is reaching the unit and that the unit is turned on. Operation: PLEASE NOTE: It is normal for the booster to be quite warm during cell phone "in use" state. LED Light Indicators on Panel Label: There two orange LED lights, one for the 800MHz cellular band and one for the 1900MHz PCS band. LED ON state indicates that the RX (Receive Signal) function of the band is functioning normally. LED Off state indicates that the band is shut down. There two Green LED lights, one for the 800MHz cellular band and one for the 1900MHz PCS band. Solid ON state indicates that the TX (Transmit Signal) function of the indicated band is on and is at maximum gain. Flashing Green LED in either 800MHz or 1900MHz indicates gain reduction in that band Each flash equals 3db reduction in gain. One flash represents a 3dB reduction, two flashes represents a 6dB reduction etc. until the total gain of the booster has been suppressed. Causes of Flashing Green LED Lights: 1-If the outside antenna is located too close to the inside antenna or phone holder the booster will reduce gain in order to suppress any oscillation (feedback loop) and the Green LED will flash. To achieve higher gain or max gain further separation of the inside and outside antennas is required. 2-If the booster is close to a cellular tower (Strong cell tower signal ) it will automatically reduce its gain to protect the network. This condition will change as the booster approaches or leaves a cellular tower. This is normal and cannot be defeated or altered by the user. Green LED Lights (TX): Orange LED Lights (RX): Car Installation (shown with CLA type power supply) Pg. 2 Typical Installations Fig1Fig2 Home Installation (shown with AC/DC type power supply) All parts shown may or may not be included depending on the Smothtalker Booster Kit part number configuration DCH6i: DC 6V Power Supply; Install type Signal Booster Outside Antenna DCH6Csw: DC 6V Power Cigar Socket type Adapter Pg. 3 Phone/Device Antenna Connection cable To comply with FCC rules, this booster must only be operated with cables, antennas and coupling devices that have been approved for use with this equipment Authorized Co-ax Cables ACX100 extension cable ACX900 extension cable AC series antenna connection cable to specific phone/device For specifications of any of the Smoothalker FCC approved part numbers listed below visit smoothtalker.com Authorized Magnetic base Antennas SEM244MMF SEM2MX, SEM2MF SEM11MX, SEM11MF SEM15MX, SEM15MF SEM2MaX, SEM2MaF SEM11MaX, SEM11MaF SEM15MaX, SEM15MaF SEM2MaXL, SEM2MaFL SEM11MaXL, SEM11MaFL SEM15MaXL, SEM15MaFL SEM2LGMX, SEM2LGMF SEM11LGMX, SEM11LGMF SEM15LGMX, SEM15LGMF SEM26LGMX, SEM26LGMF SEM2LGMXL, SEM2LGMFL SEM11LGMXL, SEM11LGMFL SEM15LGMXL, SEM15LGMFL SEM26LGMXL, SEM26LGMFL Authorized thru-hole Antennas SEM2THX, SEM2THF SEM11THX, SEM11THF SEM15THX, SEM15THF SEM26THX, SEM26THF SEM2THXL, SEM2THFL SEM11THXL, SEM11THFL SEM15THXL, SEM15THFL SEM26THXL, SEM26THFL Authorized directional Antennas SEMD1XL, SEMD1FL SEMDA2XL, SEMDA2FL DCH6HV: AC/DC Wall 6V Power supply Warranty: 2 Year on manufacturing defects. Does not include misuse or customer damage. Original Bill of Sale is required for all Warranty Claims Contact us at: smoothtalker.com Important: 1-Use only the power supply included with the booster. Connecting any other power supply at any time will result in damage to the booster and will void the warranty. 2-Do not turn on the power switch until ALL cables have been screwed or plugged into the booster or you can cause damage to the booster. 3-It is the user's/operator's responsibility to maintain a minimum distance of 8 inches separation from the antennas to any person. Pg. 4 Notes: 1-This booster is not user configurable. User changes are a violation under FCC rules and will void the user's authority to operate the equipment. 2-User changes changes or modifications will void warranty.

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Phone:(905)726-3444 Fax:(905)726-4233 October 11, 2013 Federal Communications Commission Office of Engineering and Technology 445 12th Street, S.W. Washington, D.C. 20554 Device: Wideband Consumer Coupling Booster FCC ID: S4RBST22030 Subject: KDB 935210 SIGNAL BOOSTERS CERTIFICATION REQUIREMENTS 3 Consumer Signal Booster Specifics Section: (c) Attestation non-confidential (1) Does not apply to wideband consumer booster (2) NPS and other compliance/safeguard features have been implemented (3) NPS and other compliance/safeguard features are defaulted to be “On” (in operation) (4) NPS and other compliance/safeguard features can not be field reconfigured, disabled or removed (5) Consumer booster is not user programmable, does not need fine tuning or adjustment, does not require professional installation (6) Future software upgrade will not cause non-compliance Sincerely Tom Vagenas Director

Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 QA-FR-170-A FCC Authorization January 24, 2014 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We Mobile Communications Inc., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Sincerely, Tom Vagenas Director ASO Per: Mobile Communications Inc. 230 Earl Stewart Dr. Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 QA-FR-170-A L4G 6V8 Aurora, Ontario Canada

QA-FR-172-A Mobile Communications Inc. 230 Earl Stewart Drive Aurora, Ont. Canada L4G 6V8 Tel: (905)726-3444 Fax:(905)726-4233 FCC Confidential Authorization Oct. 11, 2013 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: S4RBST22030 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Mobile Communications Inc., hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operational Description  Parts List/Tune up Procedure As well as short-term confidential treatment of information accompanying this application as outlined below:  Internal Photos  User’s Manual  External Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Tom Vagenas, Director ASO Per: Mobile Communications Inc. 230 Earl Stewart Dr. L4G 6V8 Aurora, Ontario Canada

Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 19 of 22 FCC Part 22H/24E Test Report 7 Exhibit C- EUT Photographs 7.1 EUT Top View 7.2 EUT - Bottom View Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 20 of 22 FCC Part 22H/24E Test Report 7.3 EUT - Front View 7.4 EUT - Rear View 7.5 EUT – Side View (1) 7.6 EUT – Side View (2)

Mobile Communications Inc. FCC ID: S4RBST22030 DUT label Report Number: BST22023Page 1 of 2FCC Part 20.21 Mobile Communications Inc. FCC ID: S4RBST22030 Warning label: Label location: Report Number: BST22023Page 2 of 2FCC Part 20.21

Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 21 of 22 FCC Part 22H/24E Test Report 7.7 EUT – PCB Top View 7.8 EUT – PCB Bottom View

Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 9 of 22 FCC Part 22H/24E Test Report 4 FCC §1.1310 & §2.1091 - RF Exposure Information 4.1 Applicable Standards According to §1.1310 and §2.1091 (Mobile Devices) RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Cellular Band Uplink: Maximum peak output power at antenna input terminal (dBm): 20.92 Maximum peak output power at antenna input terminal (mW): 123.6 Prediction distance (cm): 20 Prediction frequency (MHz): 837 Maximum Antenna Net Gain (dBi): 7.14 Maximum Antenna Net Gain (numeric): 5.176 Power density at predication frequency and distance (mW/cm 2 ): 0.127 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 0.558 Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 10 of 22 FCC Part 22H/24E Test Report PCS Band Uplink: Maximum peak output power at antenna input terminal (dBm): 20.29 Maximum peak output power at antenna input terminal (mW): 106.91 Prediction distance (cm): 20 Prediction frequency (MHz): 1865.4 Maximum Antenna Net Gain (dBi): 7.14 Maximum Antenna Net Gain (numeric): 5.176 Power density at predication frequency and distance (mW/cm 2 ): 0.110 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ): 1.0 4.3 Test Result The device complies with the MPE requirements by providing a safe separation distance of 20 cm between the antenna, including any radiating structure, and any persons when normally operated based on the maximum antenna gain of 7.14. The proposed RF exposure safety information has been included in the User’s Manual.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.3) FCC PART 22H & 24E TEST AND MEASUREMENT REPORT For Mobile Communications, Inc. 230 Earl Steward Drive, Aurora, Ontario L4G 6V8, Canada FCC ID: S4RBST22030 Report Type: Original Report Product Type: Dual-Band Bi-Directional Coupling Booster (BST220-23) Dual-Band Bi-Directional Direct Connect Booster (BST220-15) Prepared By: Chen Ge Report Number: R1310236-2224 Report Date: 2014-01-27 Reviewed By: Bo Li Test Engineer Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 2 of 22 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION ............................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................... 4 1.2 MECHANICAL DESCRIPTION .............................................................................................................................. 4 1.3 OBJECTIVE ......................................................................................................................................................... 4 1.4 RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................... 4 1.5 TEST METHODOLOGY ........................................................................................................................................ 5 1.6 MEASUREMENT UNCERTAINTY .......................................................................................................................... 5 1.7 TEST FACILITY ................................................................................................................................................... 5 2 SYSTEM TEST CONFIGURATION .................................................................................................................. 7 2.1 JUSTIFICATION ................................................................................................................................................... 7 2.2 EUT EXERCISE SOFTWARE ................................................................................................................................ 7 2.3 EQUIPMENT MODIFICATIONS ............................................................................................................................. 7 2.4 EUT INTERNAL CONFIGURATION ...................................................................................................................... 7 2.5 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS .............................................................................................. 7 2.6 POWER SUPPLY AND LINE FILTERS .................................................................................................................... 7 2.7 INTERFACE PORTS AND CABLING ...................................................................................................................... 7 3 SUMMARY OF TEST RESULTS ........................................................................................................................ 8 4 FCC §1.1310 & §2.1091 - RF EXPOSURE INFORMATION ............................................................................ 9 4.1 APPLICABLE STANDARDS .................................................................................................................................. 9 4.2 MPE PREDICTION .............................................................................................................................................. 9 4.3 TEST RESULT ................................................................................................................................................... 10 FCC §2.1053, §22.917 & §24.2383 - RADIATED SPURIOUS EMISSIONS ......................................................... 11 4.4 APPLICABLE STANDARD .................................................................................................................................. 11 4.5 TEST PROCEDURE ............................................................................................................................................ 11 4.6 TEST SETUP BLOCK DIAGRAM ......................................................................................................................... 12 4.7 TEST EQUIPMENT LIST AND DETAILS .............................................................................................................. 13 4.8 TEST ENVIRONMENTAL CONDITIONS ............................................................................................................... 13 4.9 TEST RESULTS ................................................................................................................................................. 13 5 EXHIBIT A - FCC ID LABELING REQUIREMENTS .................................................................................. 15 5.1 FCC ID LABEL REQUIREMENTS ....................................................................................................................... 15 5.2 FCC ID LABEL CONTENTS AND LOCATION ..................................................................................................... 16 6 EXHIBIT B - TEST SETUP PHOTOGRAPHS ................................................................…

Text truncated - open the document above for the full version.

Mobile Communications Inc. FCC ID: S4RBST22030 FCC TEST REPORT FCC Rules & Regulations Part 20.21 For: Mobile Communications, Inc 230 Earl Stewart Dr., Aurora, ON, Canada L4G6V8 FCC ID: S4RBST22030 Report Type: Original Report Product Type: Consumer wide-band bi-directional coupling and direct connect booster Test Engineer:Roman Gurvich Report Number:BST22023 Report Date:Oct. 11, 2013 Test Procedure:As specified in KDB publication 935210 D03 with FCC permission dated 9/30/2013 to PBA inquiry 942758 Prepared By: Roman Gurvich Report Number: BST22023Page 1 of 68FCC Part 20.21 Mobile Communications Inc. FCC ID: S4RBST22030 Table of Content 1 GENERAL INFORMATION 3 1.1 Product Description Equipment Under Test (EUT) 3 1.2 Mechanical Description 4 1.3 Objective 4 1.4 Test Methodology 4 1.5 Measurement Uncertainty 4 1.6 Test Facility 5 1.7 Test Equipment 5 2 SUMMARY OF TEST RESULTS 6 2.1 Rules Applied 6 2.2 Notes 6 3 TEST REPORT 7 3.1 Part 20.21 § (e)(8)(i)(A) Noise Limits 7 3.1.1 Noise power test procedure in the presence of a downlink signal 7 3.1.2Test results for noise power in presence of downlink signal 9 3.1.3Maximum noise power test procedure 10 3.1.4Maximum noise power test results 10 3.1.5Variable uplink noise timing test procedure 14 3.2 Part 20.21 § (e)(8)(i)(B) Bidirectional Capability 15 3.2.1Bi-directional capability test procedure 15 3.2.2Bi-directional capability test results 16 3.3Part 20.21 § (e)(8)(i)(C) Booster Gain Limits. 18 3.3.1Variable booster gain test procedure 18 3.3.2Variable booster gain test results 19 3.3.3Maximum gain calculation procedure 20 3.3.4Maximum gain test results 20 3.3.5Variable uplink gain timing test procedure 21 3.3.6Variable uplink gain timing test results 21 3.4 Part 20.21 § (e)(8)(i)(D) Power Limits 23 3.4.1Channel power test procedure 23 3.4.2Channel power test results 24 3.4.3 Maximum EIRP for each band of operation 26 ......................................................................................................................................................................................................................... Report Number: BST22023Page 2 of 68FCC Part 20.21 Mobile Communications Inc. FCC ID: S4RBST22030 3.5 Part 20.21 § (e)(8)(i)(E) Out of Band Emission Limits 27 3.5.1Out of band emissions test procedure 27 3.5.2Out of band emissions test results 28 3.5.3Conducted spurious emissions test procedure 41 3.5.4Conducted spurious emissions test results 41 3.6 Part 20.21 § (e)(8)(i)(F) Intermodulation Limits 46 3.6.1Intermodulation product test procedure 46 3.6.2Intermodulation product test results 47 3.7 Part 20.21 § (e)(8)(i)(G) Booster Antenna Kitting 50 3.8 Part 20.21 § (e)(8)(i)(H) Transmit Power Off Mode 52 3.9 Part 20.21 § (e)(8)(i)(I) Uplink Inactivity 52 3.10 Part 20.21 § (e)(8)(ii)(A) Anti-Oscillation 52 3.10.1Anti-Oscillation test procedure 52 3.10.2Test results 54 3.11 Part 20.21 § (e)(8)(ii)(B) Gain Control 57 3.12 Part 2.1049 Occupied Bandwidth 57 3.12.1Occupied bandwidth test procedure 57 3.12.2Occupied bandwidth Test Results 58 3.13 Part 2.1053 Radiated Spurious Emissions 67 3.13.1Radiated spurious emissions test procedure 67 3.13.2Radiated spurious emissions Test Results 67 4 MSCL CALCULATIONS & MEASUREMENTS 68 1GENERAL INFORMATION 1.1Product Description Equipment Under Test (EUT) This test and measurement report has been compiled by Mobile Communications, Inc. for product model number: BST220-23 FCC ID: S4RBST22030, which will be henceforth in this report to as the EUT (Equipment Under Test). The EUT is a Cellular/PCS Consumer wide-band bi-directional coupling booster. EUT Description Dual band, Bi-Directional Coupling Booster Model BST220-23 Dual band, Bi-Directional Direct connect Booster Model BST220-15 FCC IDS4RBST22030 Operation Frequency Cellular band: 824-849 MHz, 869-894 MHz PCS band: 1850-1910 MHz, 1930-1990 MHz Report Number: BST22023Page 3 of 68FCC Part 20.21 Mobile Communications Inc. FCC ID: S4RBST22030 ModulationsCDMA, WCDMA, LTE, HSPA, GSM, GPRS, EDGE Type of EquipmentConsumer wide-band bi-directional coupling booster 1.2Mechanical Description The EUT measures approximately 190 mm (L) x 90 mm (W) x 25 mm (H), and weighs approximately 350 grams. 1.3Objective This type approval report is prepared on behalf of Mobile Communications, Inc. in accordance with Part 20.21 of the Federal Communication Commissions rules. The objective is to determine compliance FCC rules. 1.4Test Methodology All tests and measurements indicated in this document were performed at Mobile Communications, Inc in accordance with the Code of Federal Regulations Title 20.21. The “Wideband Consumer Signal Booster Measurement Guidance” draft, KDB publication # 935210 D03, was used in test procedure to test EUT. 1.5Measurement Uncertainty All measurements involve certain level of uncertainties, especially in the field of EMC. The factors contributing to uncertainties are spectrum analyzer, cable loss, antenna factor calibration and antenna directivity, antenna factor variation with height, antenna phase centre variation, antenna factor frequency interpolation, measurement distance variation, site imperfections, mismatch (average), and system repeatability. Based on NIS81, The Treatment of Uncertainty in EMC Measurements, the values ranging from + 2.0 dB for Conducted Emissions tests and + 4.0 dB for Radiated Emissions tests are the most accurate estimates pertaining to uncertainty of EMC measurements at Mobile Communications, Inc. 1.6Test Facility Report Number: BST22023Page 4 of 68FCC Part 20.21 Mobile Communications Inc. FCC ID: S4RBST22030 The test conducted at Mobile Communications Inc. located at 230 Earl Stewart Drive, Aurora, Ontario, Canada, L4G6V8. 1.7Test Equipment #DescriptionManufacturerModel NoSerial NoCalibration Date 1Spectrum AnalyzerAgilentE4440AMY461865647/16/2013 2Signal Generator #1AgilentE4438CUS414614777/12/2013 3Signal Generator #2AgilentE4438CUS414613896/25/2013 4Communication TesterRohde SchwarzCMU-200105…

Text truncated - open the document above for the full version.

Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 17 of 22 FCC Part 22H/24E Test Report 6 Exhibit B - Test Setup Photographs 6.1 Radiated Emissions – Above 1 GHz Rear View 6.2 Radiated Emissions – Above 1 GHz Front View Mobile Communications, Inc. FCC ID: S4RBST22030 Report Number: R1310236-2224 Page 18 of 22 FCC Part 22H/24E Test Report 6.3 Radiated Emissions – Below 1 GHz Rear View
