SBP-WALLSmart Wall Switch

Paddle Switch (PS01) Features  Familiar rotary design ideal for dimming  Push Paddle for on/off control  Can be set for on/off or dimming control for various fixture compatibility  Backwards compatible with most legacy Insteon-branded devices  Powerful Insteon technology inside, uses an unclogged long range 915MHz radio in concert with powerline communication to create a blanket of coverage to all parts of the home – doesn’t conflict with your Wi-Fi and doesn’t require any network admin skills to deploy Description TBD What’s Included  Paddle Switch  Wire nuts  Quick Start Guide Compatibility  Works with all Vantaa Products o Keypad o Dial Switch o Outlet o IP Bridge  Backwards compatible with legacy Insteon-branded devices* *Not all devices supported. Some features may not be accessible via manual linking or other software/hardware controllers Requirements •Power requirements: 120V-240V AC 60Hz power •Neutral wire required Help... Link to installation video... TBD Professional installation service... TBD Contact us (email, phone)... TBD Installation Step 1. Prepare your setup Take advantage of daylight – you’ll need to disconnect power for installation, so we suggest doing the installation during the day to avoid having to work in the dark. Get your tools ready oScrewdriver Phillips head Flathead oVoltage detector oOptional Wire strippers – in case you encounter wires that need pruning Painters tape – you may wish to mask off the area below your switches so your walls are kept clean Installation requires interacting with high voltage wiring. If this makes you uncomfortable, contact a qualified electrician or call us for a certified installer. Regulatory Statements Caution: not designed for wiring to a switched outlet Certification This device contains license‐exempt transmitter(s)/receiver(s) that complies with Part 15 of the FCC Rules and Innovation, Science and Economic Development Canada’s license‐exempt RSS(s). Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. To maintain the compliance with the FCC's and Canada’s ISED RF exposure guideline, place the unit at least 20 cm (7.9‐ inches) from nearby persons. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause such interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following measures: • Re‐orient or relocate the receiving antenna of the device experiencing the interference • Increase the distance between this device and the receiver • Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver • Consult the dealer or an experienced radio/TV technician. Cet appareil a été testé et s’avère conforme aux restrictions relatives aux équipements numériques de classe B, d’après l’article 15 des règlements du Conseil supérieur de l’audiovisuel américain (FCC). Ces restrictions ont été instaurées pour offrir une protection raisonnable contre les interférences nuisibles au sein d’une installation résidentielle. Cet appareil génère, utilise et peut émettre des fréquences radio et s’il n’est pas installé selon les instructions, peut nuire aux radiocommunications. Toutefois, rien ne garantit que des parasites ne surviendront pas dans une installation particulière. Si cet appareil cause des interférences nuisibles à la réception du téléviseur ou de la radio, ce que vous pouvez déterminer en ouvrant et en fermant votre appareil, nous vous invitons à essayer l’une des mesures correctives suivantes : • Réorientez l’antenne de réception installée sur l’appareil qui manifeste les parasites. • Éloignez l’appareil du composant qui reçoit les ondes. • Branchez l’appareil dans une prise de courant CA différente de celle du composant qui reçoit les ondes. • Au besoin, consultez votre marchand électronique ou un technicien spécialisé dans le service des radios/téléviseurs pour des suggestions supplémentaires. WARNING: Changes or modifications to this device not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. When operating in the dimmer mode, this UL warning applies: CAUTION to reduce the risk of overheating and possible damage to other equipment, do not install to control a receptacle, a motor operated appliance, a fluorescent lighting fixture, or a transformer‐supplied appliance L'AVERTISSEMENT gradateurs commandant une lampe a filament de tungstene– afin de reduire le risque de surchauffe et la possibilite d’endommagement a d’autres materiels, ne pas installer pour commander une prise, un appareil a moteur, une lampe fluorescente ou un appareil alimente par un transformateur Limited Warranty Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date of pur…

Text truncated - open the document above for the full version.

smart ＠ Feb 15, 2020 Federal C ommunications Commission 7 43 5 Oakland Mills Road Columbia, MD 21 046 l· Con=�:::!: lit y J Subject: Application for FCC Certification - Confidentiality Request Applicant: Smartlabs, Inc. FCC ID: SBP-WALL To Whom It May Concern: This letter is to comply with 47 CFR Sections 0.457(d) and 0.459 pertaining to confidential material. These sections authorize a withholding from public inspection materials that would be privileged as a matter of law if retained by the person submitting them and materials which would not customarily be released to the public by that person. Type of Confidentially ReQuested Exhibit ✓ Permanent All Schematics ✓ Permanent All Block Diagrams ✓ Permanent All Operational Descriptions ✓ Short Term External Photographs ✓ Short Term Internal Photographs ..; Short Term Test Setup Photographs ✓ Short Term User Manual The above material contains trade secrets or technical data that is protected by Smartlabs as confidential and that would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. For the Short-Term Confidentially documents, Smartlabs request these be withheld from public viewing for one hundred eighty (180) days after the date the grant of equipment authorization is issued. Those documents reveal technical and design information that has not been publicly disclosed during initial marketing activities and are regarded as trade secrets by Smartlabs. This information may be disclosed to those required to maintain its confidentiality, and is not customarily disclosed publicly prior to the commercial release of the device. If you have any further questions or need additional information, please feel free to give me a call at 949-221-0037 ext. 132 」dhnLocky£r Sr. Product Development Manager, Smartlabs, Inc. smartlabs 也 1621 Alton Parkway, Scute 100 Irvine CA 926061 (949) 221 - 0037 I www smartlabsinc .com iNSTE('.)N UR "' SMAHT CR 0 INSTEC>N smartlabs des1g'1 Smatlhomepto 5 M AR TH O M E"'''

smart ® ：芯二����、 J Feb 15, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21 046 Gentlemen: This is a letter of authorization to accept: MiCOM Labs 5 7 5 Boulder Court Pleasanton, California 94566 United States as an Agent for Smartlabs, Inc., for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Smartlabs, Inc. products: Smart Wall Switch Model: PSOl, DSOl, KPOl 4 FCC ID: SBP-WALL Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Smartlabs, Inc. nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988, 21 U.S.C. 853(a). In addition, Smartlabs, Inc. will notify the Federal Communications Commission if, at any time, the situation changes causing Smartlabs, Inc. to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 949-221-0037 xl 32 Sincerely, John Lockyer Sr. Product Development Manager Smartlabs, Inc. smartlabs 1621 Alto'1 Pa吹k.way, S,11te勺00 Irvine CA 92606 (949) 221-0037 J www smartlabs,nc com NSTE<.'>N INSTEC>N smartlabs riP.<;1(1 Smarfhome p ro SMARTHOME''

January 16, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Declaration of similar models for FCC ID: SBP-WALL To Whom It May Concern, This letter is to inform you that we, Smartlabs, Inc., are requesting radio equipment certification under a sinqular certification, FCC: SBP-WALL for the following products: Model Number Product Marketing Name Equipment Description PS01 Paddle Switch Smart Wall Switch DS01 Dial Switch Smart Wall Switch KP014 Keypad (4-button) Smart Wall Switch be certified as members of the same product family because: All models are the same circuit and RF module, except the model name. Thanks Sincerely, Signature John Lockyer Sr. Regulatory Affairs and Compliance Officer Smartlabs, Inc.

Model: PS01 N20191017V1 Photo 1 Photo 2 Model: PS01 N20191017V1 Photo 3 Photo 4 Model: PS01 N20191017V1 Photo 5 Photo 6

Smart Wall Switch Model: PS01, DS01, KP014 FCC ID: SBP-WALL ISED: 5202A-PS01 Unit Label Location Smart Wall Switch Model: PS01, DS01, KP014 FCC ID: SBP-WALL ISED: 5202A-PS01 Model: PS01Model: DS01Model: KP014 Unit Lab el

Model: PS01 N20191017V1 Photo 1 Photo 2 Model: PS01 N20191017V1 Photo 3 Photo 4 Model: PS01 N20191017V1 Photo 5 Photo 6 Model: PS01 N20191017V1 Photo 7 Photo 8 Model: PS01 N20191017V1 Photo 9 Photo 10 ANT Model: PS01 N20191017V1 Photo 11

Report No.: S19101601506001 ` Version.1.2 Page 1 of 31 RADIO TEST REPORT FCC ID: SBP-WALL Product： Smart Wall Switch Trade Mark： TBD Model Name： PS01 Family Model： DS01, KP014 Report No.： S19101601506001 Prepared for Smartlabs, Inc. 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http//www.ntek.org.cn Report No.: S19101601506001 ` Version.1.2 Page 2 of 31 TEST RESULT CERTIFICATION Applicant’s name ................. : Smartlabs, Inc. Address ................................. : 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Manufacturer's Name .......... : Smartlabs, Inc. Address ................................. : 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Product description Product name ........................... : Smart Wall Switch Model and/or type reference : PS01 Family Model .......................... DS01, KP014 Rating(s) ................................ : 120~240VAC, 60Hz, 9Amps Standards ............................. : FCC Part15.249 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 17 Oct. 2019 ~ 12 Nov. 2019 Date of Issue ........................................... : 12 Nov. 2019 Test Result ............................................... : Pass Testing Engineer : (Mary Hu) Technical Manager : (Jason Chen) Authorized Signatory : (Sam Chen) Report No.: S19101601506001 ` Version.1.2 Page 3 of 31 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . ANTENNA REQUIREMENT 13 3.1 STANDARD REQUIREMENT 13 3.2 EUT ANTENNA 13 3.3 CONDUCTED EMISSION MEASUREMENT 14 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.3.2 TEST PROCEDURE 15 3.3.3 DEVIATION FROM TEST STANDARD 15 3.3.4 TEST SETUP 15 3.2.5 TEST RESULT 16 3.4 RADIATED EMISSION MEASUREMENT 20 3.4.1 RADIATED EMISSION LIMITS 20 3.4.2 TEST PROCEDURE 21 3.4.3 DEVIATION FROM TEST STANDARD 21 3.4.4 TEST RESULTS (BELOW 30MHZ) 23 3.4.5 TEST RESULTS (BELOW 1000 MHZ) 24 3.4.6 TEST RESULTS (ABOVE 1000 MHZ) 26 3.4.7 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 28 4. BANDWIDTH TEST 30 4.1 TEST PROCEDURE 30 4.2DEVIATION FROM STANDARD 30 4.3TEST SETUP 30 4.4TEST RESULTS 31 Report No.: S19101601506001 ` Version.1.2 Page 4 of 31 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.203 Antenna Requirement Pass 15.249 15.209 Radiated Spurious Emission Pass 15.249b(2) Frequency Tolerance N/A 15.249(a) Fundamental Measurement Pass 15.205 Band Edge Emission Pass 15.215 Occupied Bandwidth Pass Note: “N/A” denotes test is not applicable in this Test Report. Report No.: S19101601506001 ` Version.1.2 Page 5 of 31 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. FCC FRN Registration No.:463705; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Report No.: S19101601506001 ` Version.1.2 Page 6 of 31 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Smart Wall Switch Trade Mark TBD Model Name PS01 Family Model DS01, KP014 Model Difference All models are the same circuit and RF module, except the model name. Product Description The EUT is a Smart Wall Switch Operation Frequency: 915MHz Modulation Type: FSK Antenna Designation: PCB Antenna Antenna Gain(Peak) 1dBi Based on the application, features, or specification exhibited in User's Manual. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery N/A Hardware version V2.0 Firmware version 0X60 Software version N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Report No.: S19101601506001 ` Version.1.2 Page 7 of 31 2. Channel Frequency(MHz) 01 915 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna N/A 1 Antenna Note:The device does not support simultaneous transmission Report No.: S19101601506001 ` Version.1.2 Page 8 of 31 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or t…

Text truncated - open the document above for the full version.

FCC ID: SBP-WALL Radiated Measurement Photos FCC ID: SBP-WALL Conducted Measurement Photos
