SBP-WR01Smart Outlet

Insteon Technologies, LLC
Smart Outlet - FCC ID SBP-WR01 - Insteon Technologies, LLC
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Mar 21, 2020
Application Purpose
Original Equipment
Date of Application
Mar 21, 2020
Equipment Note
Smart Outlet
Frequency Range
915.00000000 - 915.00000000
Company
Insteon Technologies, LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Vantaa Outlet (WR01) Features  Two independently controlled outlets  Control plug-in lights and appliances up to 15 Amps  Local control buttons that can be disabled via software  Tamper-resistant outlets for safety  Powerful Insteon technology inside, uses an unclogged long range 915MHz radio in concert with powerline communication to create a blanket of coverage to all parts of the home – doesn’t conflict with your Wi-Fi and doesn’t require any network admin skills to deploy Description TBD What’s Included  Outlet  Wire nuts  Quick Start Guide Compatibility  Works with all Vantaa Products o Keypad o Dial Switch o Paddle Switch o IP Bridge  Backwards compatible with legacy Insteon-branded devices* *Not all devices supported. Some features may not be accessible via manual linking or other software/hardware controllers Requirements  Power requirements: 125VAC 60Hz power Help... Link to installation video... TBD Professional installation service... TBD Contact us (email, phone)... TBD Installation Step 1. Prepare your setup  Take advantage of daylight – you’ll need to disconnect power for installation, so we suggest doing the installation during the day to avoid having to work in the dark.  Get your tools ready o Screwdriver  Phillips head  Flathead o Voltage detector o Optional  Wire strippers – in case you encounter wires that need pruning  Painters tape – you may wish to mask off the area below your switches so your walls are kept clean Installation requires interacting with high voltage wiring. If this makes you uncomfortable, contact a qualified electrician or call us for a certified installer. Regulatory Statements Certification This device contains license‐exempt transmitter(s)/receiver(s) that complies with Part 15 of the FCC Rules and Innovation, Science and Economic Development Canada’s license‐exempt RSS(s). Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. To maintain the compliance with the FCC's and Canada’s ISED RF exposure guideline, place the unit at least 20 cm (7.9‐ inches) from nearby persons. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause such interference, which can be verified by turning the device off and on, the user is encouraged to eliminate the interference by one or more of the following measures: • Re‐orient or relocate the receiving antenna of the device experiencing the interference • Increase the distance between this device and the receiver • Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver • Consult the dealer or an experienced radio/TV technician. Cet appareil a été testé et s’avère conforme aux restrictions relatives aux équipements numériques de classe B, d’après l’article 15 des règlements du Conseil supérieur de l’audiovisuel américain (FCC). Ces restrictions ont été instaurées pour offrir une protection raisonnable contre les interférences nuisibles au sein d’une installation résidentielle. Cet appareil génère, utilise et peut émettre des fréquences radio et s’il n’est pas installé selon les instructions, peut nuire aux radiocommunications. Toutefois, rien ne garantit que des parasites ne surviendront pas dans une installation particulière. Si cet appareil cause des interférences nuisibles à la réception du téléviseur ou de la radio, ce que vous pouvez déterminer en ouvrant et en fermant votre appareil, nous vous invitons à essayer l’une des mesures correctives suivantes : • Réorientez l’antenne de réception installée sur l’appareil qui manifeste les parasites. • Éloignez l’appareil du composant qui reçoit les ondes. • Branchez l’appareil dans une prise de courant CA différente de celle du composant qui reçoit les ondes. • Au besoin, consultez votre marchand électronique ou un technicien spécialisé dans le service des radios/téléviseurs pour des suggestions supplémentaires. WARNING: Changes or modifications to this device not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Limited Warranty Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will perform in substantial conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or errors caused by misuse or neglect. If the product is found to be defective in material or workmanship, or if the product does not perform as warranted above during the warranty period, Seller will either repair it, replace it, or refund the purchase price, at its option, upon receipt of the product at the address below, postage prepaid, with proof of the date of purchase and an explanation of the defect or error. The repair, replacement, or refund that is pr…

Text truncated - open the document above for the full version.

Cover Letter(s)

smart ® Feb 15, 2020 Federal Communications Commission 7435 Oakland Mills Road Co lumbia, MD 21 046 � Con:::::!� lit y J Sub」ect: Application for FCC Certification - Confidentiality Request Applicant: Smartlabs, Inc. FCC ID: SBP-WROl To Whom It May Concern: This letter is to comply with 47 CFR Sections 0.457(d) and 0.459 pertaining to confidential material. These sections authorize a withholding from public inspection materials that would be privileged as a matter of law if retained by the person submitting them and materials which would not customarily be released to the public by that person. Type of Confidentially ReQuested Exhibit ✓ Permanent All Schematics ✓ Permanent All Block Diagrams ✓ Permanent All Operational Descriptions ✓ Short Term External Photographs ✓ Short Term Internal Photographs ✓ Short Term Test Setup Photographs .J Short Term User Manual The above material contains trade secrets or technical data that is protected by Smartlabs as confidential and that would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. For the Short-Term Confidentially documents, Smartlabs request these be withheld from public viewing for one hundred eighty (l 80) days after the date the grant of equipment authorization is issued. Those documents reveal technical and design information that has not been publicly disclosed during initial marketing activities and are regarded as trade secrets by Smartlabs. This information may be disclosed to those required to maintain its confidentiality, and is not customarily disclosed publicly prior to the commercial release of the device. If you have any further questions or need additional information, please feel free to give me a call at 949-221-0037 ext. 132 」o.hnLock�r Sr. Product Development Manager, Smartlabs, Inc. smartlabs 艾 1621 A!ton Pa「kwaySuite 100 Irvine, CA 926061 (949) 221-00371 www.sm artlabsinc.co m INSTE(!)N ,。S THf , .... RT GRID INSTE0N smartlabs design Smatlhome p to' SMARTHOME T

Cover Letter(s)

smart @ [芯;二; �: J Feb 15, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This is a letter of authorization to accept: MiCOM Labs 5 7 5 Boulder Court Pleasanton, California 94566 United States as an Agent for Smartlabs, Inc., for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Smartlabs, Inc. products: Smart Outlet Model: WROl FCC ID: SBP-WROl Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Smartlabs, Inc. nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988, 21 U.S.C. 85 3(a). In addition, Smartlabs, Inc. will notify the Federal Communications Commission if, at any time, the situation changes causing Smartlabs, Inc. to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 949-221-0037 xl 32 Sincerely, John Lockyer Sr. Product Development Manager Smartlabs, Inc. smartlabs 162" Alto'l Pa「kwaySuite 100 I rvine. CA 926061 (949) 221-00371 www.smartlabsinc com INSTEC>N !NSTE(:)N smartlabs f1P�ll"ln Smarlhome p ro 了入1 5M/.\RTHOME'"

External Photos

Model: WR01 N20191017V1 Photo 1 Photo 2 Model: WR01 N20191017V1 Photo 3 Photo 4 Model: WR01 N20191017V1 Photo 5 Photo 6

ID Label/Location Info

Smart Outlet Model: WR01 FCC ID: SBP-WR01 ISED: 5202A-WR01 Unit Label Location FCC ID: SBP-WR01 ISED: 5202A-WR01 Unit Lab e l

Internal Photos

Model: WR01 N20191017V1 Photo 1 Photo 2 Model: WR01 N20191017V1 Photo 3 Photo 4 Model: WR01 N20191017V1 Photo 5 Photo 6 Model: WR01 N20191017V1 Photo 7 Photo 8 Model: WR01 N20191017V1 Photo 9 Photo 10 Model: WR01 N20191017V1 Photo 11 Photo 12 Model: WR01 N20191017V1 Photo 13 Photo 14 ANT Model: WR01 N20191017V1 Photo 15 Photo 16

Test Report

Report No.: S19101601503001 ` Version.1.2 Page 1 of 29 RADIO TEST REPORT FCC ID: SBP-WR01 Product: Smart Outlet Trade Mark: TBD Model Name: WR01 Family Model: N/A Report No.: S19101601503001 Prepared for Smartlabs, Inc. 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http//www.ntek.org.cn Report No.: S19101601503001 ` Version.1.2 Page 2 of 29 TEST RESULT CERTIFICATION Applicant’s name ................. : Smartlabs, Inc. Address ................................. : 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Manufacturer's Name .......... : Smartlabs, Inc. Address ................................. : 1621 Alton Parkway, Suite 100, Irvine, CA 92606, United States Product description Product name ........................... : Smart Outlet Model and/or type reference : WR01 Family Model .......................... N/A Rating(s) ................................ : AC 120V, 60Hz, 15Amps Standards ............................. : FCC Part15.249 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 17 Oct. 2019 ~ 12 Nov. 2019 Date of Issue ........................................... : 12 Nov. 2019 Test Result ............................................... : Pass Testing Engineer : (Mary Hu) Technical Manager : (Jason Chen) Authorized Signatory : (Sam Chen) Report No.: S19101601503001 ` Version.1.2 Page 3 of 29 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . ANTENNA REQUIREMENT 13 3.1 STANDARD REQUIREMENT 13 3.2 EUT ANTENNA 13 3.3 CONDUCTED EMISSION MEASUREMENT 14 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.3.2 TEST PROCEDURE 15 3.3.3 DEVIATION FROM TEST STANDARD 15 3.3.4 TEST SETUP 15 3.2.5 TEST RESULT 16 3.4 RADIATED EMISSION MEASUREMENT 18 3.4.1 RADIATED EMISSION LIMITS 18 3.4.2 TEST PROCEDURE 19 3.4.3 DEVIATION FROM TEST STANDARD 19 3.4.4 TEST RESULTS (BELOW 30MHZ) 21 3.4.5 TEST RESULTS (BELOW 1000 MHZ) 22 3.4.6 TEST RESULTS (ABOVE 1000 MHZ) 24 3.4.7 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 26 4. BANDWIDTH TEST 28 4.1 TEST PROCEDURE 28 4.2 DEVIATION FROM STANDARD 28 4.3 TEST SETUP 28 4.4. TEST RESULTS 29 Report No.: S19101601503001 ` Version.1.2 Page 4 of 29 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission Pass 15.203 Antenna Requirement Pass 15.249 15.209 Radiated Spurious Emission Pass 15.249b(2) Frequency Tolerance N/A 15.249(a) Fundamental Measurement Pass 15.205 Band Edge Emission Pass 15.215 Occupied Bandwidth Pass Note: “N/A” denotes test is not applicable in this Test Report. Report No.: S19101601503001 ` Version.1.2 Page 5 of 29 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. FCC FRN Registration No.:463705; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Report No.: S19101601503001 ` Version.1.2 Page 6 of 29 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Smart Outlet Trade Mark TBD Model Name WR01 Family Model N/A Model Difference N/A Product Description The EUT is a Smart Outlet Operation Frequency: 915MHz Modulation Type: FSK Antenna Designation: PCB Antenna Antenna Gain(Peak) 1dBi Based on the application, features, or specification exhibited in User's Manual. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery N/A Hardware version V1.6 Firmware version 0x60 Software version N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Report No.: S19101601503001 ` Version.1.2 Page 7 of 29 2. Channel Frequency(MHz) 01 915 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna N/A 1 Antenna Note:The device does not support simultaneous transmission Report No.: S19101601503001 ` Version.1.2 Page 8 of 29 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 CH01 M…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: SBP-WR01 Radiated Measurement Photos FCC ID: SBP-WR01 Conducted Measurement Photos

Contact Information

Applicant

John Lockyer(Suite 105-665)
[email protected]949-396-2114Fax: 949-396-2114

Technical Contact

SmartLabs, Inc.
[email protected]

United States

Test Firm

Shenzhen NTEK Testing Technology Co., Ltd.Alex Li
[email protected]+86-755-6115-9384

Technical Specifications

#Rule PartsFrequency RangePower Output
115C915 MHz - 915 MHz-
