400 Perimeter Park Drive T: 919-379-1951 Suite K F: 919-463-7706 Morrisville, NC 27560 USA www.sensus.com MODULAR APPROVAL REQUEST FORM 10/25/2011 Subject: Modular Approval Requirements for FCC certification for Sensus FLXA2D Product. Reference: FCC ID: SDBFLEXELS Dear Application Examiner, Sensus FLXA2D Product is seeking modular approval for FCC ID: SDBFLEXELS This document is to attest that the radio bearing the FCC ID: SDBFLEXELS meets the requirements for a modular approval as detailed in the FCC public notice DA00-1407. Compliance to each requirement is described below: 1. The SDBFLEXELS modular transmitter has its own RF shielding. 2. The modular transmitter incorporates buffered modulation/data inputs. 3. The SDBFLEXELS is designed with integrated regulated power supplies. 4. The modular device complies with the antenna requirements of Section 15.203 and 15.204(c). (The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). 5. The SDBFLEXELS was tested in a stand-alone configuration, 6. The modular transmitter must is labeled with its own FCC ID number. 7. The modular device complies with all specific rules or operating requirements applicable to the transmitter and the manufacturer has provided adequate instructions along with the module to explain any such requirements. 8. The SDBFLEXELS complies with all applicable RF exposure requirements. Sincerely, Al Servais | Reliability and Compliance Program Manager 400 Perimeter Park Drive | Suite K | Morrisville, NC 27560 USA T: 919-379-1951 | C: 919-208-8983 | [email protected] | www.sensus.com

400 Perimeter Park Drive T: 919-379-1951 Suite K F: 919-463-7706 Morrisville, NC 27560 USA www.sensus.com LETTER OF AUTHORIZATION 10/25/2011 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: Sensus, of 8609 Six Forks Road, Raleigh, NC 27615, hereby appoints Gordon Hurst, or appointee of MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA to act as our agent in the preparation of an application for equipment authorization of the SDBFLEXELS to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name FLXA2D and FCC IDENTIFIER SDBFLEXELS listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. This authorization is valid for FLXA2D ONLY, and shall not be utilized for any other matters on the behalf of Sensus. Sincerely, Al Servais | Reliability and Compliance Program Manager 400 Perimeter Park Drive | Suite K | Raleigh, NC 27560 USA T: 919-379-1951 | C: 919-208-8983 | [email protected] | www.sensus.com

400 Perimeter Park Drive T: 919-379-1951 Suite K F: 919-463-7706 Morrisville, NC 27560 USA www.sensus.com January 12, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: SDBFLEXELS Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Justification Schematic 8525-0212-01 Schematics Rev 2.20.pdf Proprietary Information and Trade Secret Parts List ELSTER A3 XCVR 221BOM_11.pdf Proprietary Information and Trade Secret Theory Of Operation FLEXELS Theory of Operation.pdf Proprietary Information and Trade Secret Tune-Up Procedure Sensus Integrated Transceiver Tune Up.pdf Proprietary Information and Trade Secret The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The product covered by this Confidentiality Request is not sold to any OEM and is only installed in Sensus Products by Sensus Employees or Contractors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Al Servais | Reliability and Compliance Program Manager 400 Perimeter Park Drive | Suite K | Raleigh, NC 27560 USA T: 919-379-1951 | C: 919-208-8983 | [email protected] | www.sensus.com

the wireless lab 12 January 2012 External Photographs Sensus Metering Systems FlexELS MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Page 2 of 2

the wireless lab 12 January 2012 Internal Photographs Sensus Metering Systems FlexELS EUT 1 MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab EUT2 Page 2 of 3 the wireless lab EUT Shield removed Page 3 of 3

1.1.1. Maximum Permissible Exposure FCC, Part 1 Subpart §1.1310 IC RSS-Gen 5.5 Calculations for Maximum Permissible Exposure Levels Power Density = Pd (mW/cm 2 ) = EIRP/(4πd 2 ) EIRP = P * G P = Peak output power (mW) G = Antenna numeric gain (numeric) d = Separation distance (cm) Numeric Gain = 10 ^ (G (dBi)/10) The calculated power density at 20cm is;- Because the EUT belongs to the General Population/Uncontrolled Exposure the limit of power density is f/1500 (where f = 896 MHz) = 0.6 mW/cm 2 Freq. Band (GHz) Antenna Gain (dBi) Numeric Gain (numeric) Max Peak Output Power (dBm) Peak Output Power (mW) Calculated Power Density (mW/cm 2 )@ 20 cm Power Density Limit (mW/cm 2 ) 900 0.0 1.0 +29.99 997.7 0.198 0.6 *Note: for mobile or fixed location transmitters the minimum separation distance is 20cm, even if the calculations indicate the MPE distance to be lower. Specification Maximum Permissible Exposure Limits §1.1310 Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency levels in excess of the Commission’s guidelines. See §1.1307 (b)(1) of this chapter. Limit = 0.6 mW / cm 2 from 1.310 Table 1 Note: for mobile or fixed location transmitters the minimum separation distance is 20cm, even if calculations indicate the MPE distance to be less.

COVER PAGE Test of Sensus FLEXELS To: FCC 47 CFR Part(s) 24, 90, 101 Test Report Serial No.: SNUS10-U1 Rev B TEST REPORT FROM Test of Sensus FLEXELS To FCC 47 CFR Part(s) 24, 90, 101 RSS-134 & RSS-119 Test Report Serial No.: SNUS10-U1 Rev B This report supersedes: SNUS10-U1 Rev A Manufacturer: Sensus Metering Systems 8609 Six Forks Road, 3rd Floor Raleigh, North Carolina 27615 USA Product Function: Integrated AMR FlexNet Solution Copy No: pdf Issue Date: 13th January 2012 This Test Report is Issued Under the Authority o f; MiCOM Labs, Inc. 440 Boulder Cour t, Suite 200 Pleasanton, CA 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com TESTING CERTIFICATE #2381.01 MiCOM Labs is an ISO 17025 Accredited Testing Laboratory Title: Sensus FLEXELS To: Serial #: Issue Date: Page: FCC 47 CFR Part(s) 24, 90, 101 SNUS10- U1 Rev B 13th January 2012 3 of 82 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs Inc, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com This page has been left intentionally blank Title: Sensus FLEXELS To: Serial #: Issue Date: Page: FCC 47 CFR Part(s) 24, 90, 101 SNUS10- U1 Rev B 13th January 2012 4 of 82 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs Inc, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com TABLE OF CONTENTS ACCREDITATION, LISTINGS & RECOGNITION ..........................................................5 TESTING ACCREDITATION ........................................................................................... 5 RECOGNITION................................................................................................................ 6 PRODUCT CERTIFICATION........................................................................................... 7 1. TEST RESULT CERTIFICATE .................................................................................9 2. REFERENCES AND MEASUREMENT UNCERTAINTY ......................................10 2.1. Normative References .......................................................................................... 10 2.2. Test and Uncertainty Procedures ......................................................................... 10 3. PRODUCT DETAILS AND TEST CONFIGURATIONS ........................................11 3.1. Technical Details .................................................................................................. 11 3.2. Scope of Test Program ......................................................................................... 12 3.3. Equipment Model(s) and Serial Number(s) .......................................................... 12 3.4. Antenna Details .................................................................................................... 12 3.5. Cabling and I/O Ports ........................................................................................... 13 3.6. Test Configurations............................................................................................... 13 3.7. Equipment Modifications....................................................................................... 15 3.8. Deviations from the Test Standard ....................................................................... 15 3.9. Subcontracted Testing or Third Party Data .......................................................... 15 4. TEST SUMMARY ....................................................................................................16 5. TEST RESULTS ......................................................................................................18 5.1. Device Characteristics .......................................................................................... 18 5.1.1. Output Power ........................................................................................ 18 5.1.2. Occupied Bandwidth and Spectrum Mask ............................................ 21 5.1.3. Frequency Stability; Temperature Variations, and Voltage Variations .. 42 5.1.4. Spurious Emissions from Antenna Terminals ....................................... 47 5.1.5. Maximum Permissible Exposure ........................................................... 60 5.1.6. Radiated Spurious Emissions ............................................................... 61 5.1.7. AC Wireline Conducted Emissions (0.15 – 30 MHz)............................. 75 6. TEST SET-UP PHOTOGRAPHS............................................................................77 6.1. General Measurement Test Set-Up ...................................................................... 77 6.2. General Measurement – Environmental Chamber ............................................... 78 6.3. Radiated Emissions below 1 GHz ........................................................................ 79 6.4. Radiated Digital Emissions above 1 GHz ............................................................. 80 7. TEST EQUIPMENT DETAILS.................................................................................81 Title: Sensus FLEXELS To: Serial #: Issue Date: Page: FCC 47 CFR Part(s) 24, 90, 101 SNUS10- U1 Rev B 13th January 2012 5 of 82 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs Inc, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com ACCREDITATION, LISTINGS & RECOGNITION TESTING ACCREDITATION MiCOM Labs, Inc. is an accredited Electrical testing laboratory per the international standard EN ISO/I…

Text truncated - open the document above for the full version.

the wireless lab 26 October 2011 Test Setup Photographs Sensus Metering Systems FlexELS General Measurement Test Set-Up MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab General Measurement – Environmental Chamber Page 2 of 4 the wireless lab Radiated Emissions below 1 GHz Page 3 of 4 the wireless lab Radiated Digital Emissions above 1 GHz Page 4 of 4
