SE6E004TEMPERATURE DATA LOGGER LT2

User Guide CUG00028-EN-A01 USER GUIDE Wireless temperature data logger LT2 This device complies with FCC RF radiation exposure limits set forth for general population (uncontrolled exposure). This device must be installed to provide a separation distance of at least 20cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. User Guide CUG00028-EN-A01 IJINUS - 25 ZA de Kervidanou 3, 29300 MELLAC – France : +33 2 98 09 03 30 – Customer Service: +33 2 98 09 03 32 / [email protected] SUMMARY 1 Safety instructions and regulatory compliance .............................................................................................................. 3 1.1 Operating instructions ............................................................................................................................................ 3 1.2 Safety instructions .................................................................................................................................................. 3 1.3 Battery Safety ......................................................................................................................................................... 3 1.4 Warning to users in the United States .................................................................................................................... 4 1.5 Warning to users in Canada / Attention pour les utilisateurs au Canada .............................................................. 4 2 Introduction .................................................................................................................................................................... 6 3 Necessary equipments .................................................................................................................................................... 6 4 Configuration of the logger using the software IJITempLab 4.7 ..................................................................................... 7 4.1 Launch the software IJITempLab 4.7 and connect to the data logger to configure ............................................... 7 4.2 Displaying the measures ......................................................................................................................................... 8 4.3 Data export ............................................................................................................................................................. 9 4.4 Menu options .......................................................................................................................................................... 9 5 Revision of the document ............................................................................................................................................. 11 Temperature data logger LT2 User Guide CUG00028-EN-A01 IJINUS - 25 ZA de Kervidanou 3, 29300 MELLAC – France : +33 2 98 09 03 30 – Customer Service: +33 2 98 09 03 32 / [email protected] 3 1 Safety instructions and regulatory compliance 1.1 Operating instructions • For a battery replacement, check the presence of a desiccant bag after an opening. This bag must be replaced after a contact with ambient air during a period longer than 3 minutes. If the desiccant bag turn green, it means you have to replace it (PN : H0Q00012). • Only the use of Ijinus' accessories and consumable ensures the best and the more safely installation. • Do not mechanically force the housing. 1.2 Safety instructions • Do not shortcut, reload, pierce, warm, put into fire, crush the batteries • Do not shake the devices. • Do not physically modify the devices. • Do not clean the devices with aggressive products like acetone. • Do not use batteries not recommended by Ijinus (PN: A0G00010) • The devices contain elements sensitive to electrostatic discharge. Download your body from electrostatic loads before opening and manipulate the devices by touching a metallic surface linked to the Earth. 1.3 Battery Safety This product contains a lithium battery that must be disposed of properly. Please follow the battery safety items below: • Do not dismantle, open or shred secondary cells or batteries. • Do not expose cells or batteries to heat or fire. Avoid storage in direct sunlight. • Do not short-circuit a cell or a battery. Do not store cells or batteries haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by, other metal objects. • Never try to recharge this non-rechargable batteries. • Do not mix cells of different manufacture, capacity, size or type within a device. • Seek medical advice immediately if a cell or a battery has been swallowed. • Do not subject cells or batteries to mechanical shock. • In the event of a cell leaking, do not allow the liquid to come in contact with the skin or eyes. If contact has been made, wash the affected area with copious amounts of water and seek medical advice. • Keep cells and batteries out of the reach of children. • Keep cells and batteries clean and dry. • Use only the cell or battery in the application for which it was intended. Temperature data logger LT2 User Guide CUG00028-EN-A01 IJINUS - 25 ZA de Kervidanou 3, 29300 MELLAC – France : +33 2 98 09 03 30 – Customer Service: +33 2 98 09 03 32 / [email protected] 4 1.4 Warning to users in the United States Federal Communication Commission Interference Statement 47 CFR Section 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a pa…

Text truncated - open the document above for the full version.

Technical Documentation External Photos FCC ID SE6E004 Publication History Version Date Modification description 01 November 25, 2019 Creation of the document Technical Documentation External Photos Version : 01 Page 2/8 LT2: Front View (Original version: Manufacturer) Technical Documentation External Photos Version : 01 Page 3/8 LT2: Front View (Customer’s version: Biolog) Technical Documentation External Photos Version : 01 Page 4/8 LT2: Rear View Technical Documentation External Photos Version : 01 Page 5/8 LT2: Right side View Technical Documentation External Photos Version : 01 Page 6/8 LT2: Left side View Technical Documentation External Photos Version : 01 Page 7/8 LT2: Top View Technical Documentation External Photos Version : 01 Page 8/8 LT2: Bottom View

Technical Documentation Label Location FCC ID SE6E004 Publication History Version Date Modification description 01 November 22, 2019 Creation of the document Technical Documentation Label Location Version : 01 Page 2/2 FCC Label location for LT2: LT2: Label Location View

Technical Documentation Label FCC ID SE6E004 Publication History Version Date Modification description 01 November 18, 2019 Creation of the document Technical Documentation Label Version : 01 Page 2/2 LT2 – FCC Label size: Size = 51x29 mm Label: Photo of product with label:

Technical Documentation Internal Photos FCC ID SE6E004 Publication History Version Date Modification description 01 November 25, 2019 Creation of the document Technical Documentation Internal Photos Version : 01 Page 2/4 LT2: Device Open View Technical Documentation Internal Photos Version : 01 Page 3/4 LT2: Electronic Card Recto View (1) Technical Documentation Internal Photos Version : 01 Page 4/4 LT2: Electronic Card Verso View (1)

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:0,16(dBm) Maximum peak output power at the antenna terminal:1,037528416(mW) Antenna gain(typical):0(dBi) Maximum antenna gain:1(numeric) Prediction distance:20(cm) Prediction frequency:915(MHz) MPE limit for uncontrolled exposure at prediction frequency:1(mW/cm^2) Power densit y at prediction frequency: 0,000206(mW/cm^2) Maximum allowable antenna gain:36,85269855(dBi) FCC ID: SE6E004 IJINUS Model: LT2 2 4R PG S  

902MHz-928MHz Template: Release July 3 rd , 2019 This document shall not be reproduced, except in full, without the written approval of the LCIE. This document contains results related only to the items tested. It does not imply the conformity of the whole production to the items tested. Unless otherwise specified or rule defined by the test method, the decision of conformity doesn’t take into account the uncertainty of measures.This document doesn’t anticipate any certification decision. TEST REPORT N°: 163634-742939-A Version : 01 Subject Radio spectrum matters tests according to standards: 47 CFR Part 15.247 & RSS-247 Issue 2 & RSS-Gen Issue 5 Issued to IJINUS 25 ZA de Kervidanou 3 29300 - MELLAC FRANCE Apparatus under test  Product Temperature logger with 2 external probes  Trade mark IJINUS  Manufacturer IJINUS  Model under test LT2  Serial number IJT 30 05 0000 0815  FCC ID SE6E004  IC 10983A-E004 Conclusion See Test Program chapter Test date : October 9, 2019 to November 21, 2019 Test location Fontenay Aux Roses Test Site 6230B-1 Composition of document 41 pages Document issued on January 6, 2020 Written by : Approved by : Julien Palard Arnaud FAYETTE Tests operator Technical manager TEST REPORT N° 163634-742939-A Version : 01 Page 2/41 PUBLICATION HISTORY Each new edition of this test report replaces and cancels the previous edition. The control of the old editions of report is under responsibility of client. Version Date Author Modification 01 06/01/2019 J. PALARD Creation of the document Date of receipt of test item 08/10/2019 TEST REPORT N° 163634-742939-A Version : 01 Page 3/41 SUMMARY 1. TEST PROGRAM ............................................................................................................................... 4 2. EQUIPMENT UNDER TEST: CONFIGURATION (DECLARED BY PROVIDER) ................................ 5 3. OCCUPIED BANDWIDTH ................................................................................................................. 10 4. 6DB EMISSION BANDWIDTH .......................................................................................................... 13 5. DUTY CYCLE ................................................................................................................................... 16 6. MAXIMUM CONDUCTED OUTPUT POWER ................................................................................... 19 7. POWER SPECTRAL DENSITY ........................................................................................................ 22 8. UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS AT THE BAND EDGE 25 9. UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS ................................... 28 10. UNWANTED EMISSIONS IN RESTRICTED FREQUENCY BANDS ................................................ 32 11. UNCERTAINTIES CHART ................................................................................................................ 41 TEST REPORT N° 163634-742939-A Version : 01 Page 4/41 1. TEST PROGRAM References  47 CFR Part 15.247  RSS 247 Issue 2  RSS Gen Issue 5  KDB 558074 D01 DTS Meas Guidance v05r02  ANSI C63.10-2013 Radio requirement: Clause (47CFR Part 15.247 & RSS-247 Issue 2 & RSS-Gen Issue 5) Test Description Test result - Comments Occupied Bandwidth   PASS  FAIL  NA  NP(1) 6dB Bandwidth   PASS  FAIL  NA()  NP(1) Duty Cycle   PASS  FAIL  NA  NP(1) Maximum Conducted Output Power   PASS  FAIL  NA  NP(1) Power Spectral Density   PASS  FAIL  NA  NP(1) Conducted Spurious Emission at the Band Edge   PASS  FAIL  NA()  NP(1) Unwanted Emissions into Non-Restricted Frequency Bands   PASS  FAIL  NA()  NP(1) AC Power Line Conducted Emission   PASS  FAIL  NA(2)  NP(1) Unwanted Emissions into Restricted Frequency Bands   PASS  FAIL  NA  NP(1) Receiver Radiated emissions   PASS  FAIL  NA  NP(1) This table is a summary of test report, see conclusion of each clause of this test report for detail. (1): Limited program (2): EUT not directly or indirectly connected to the AC Power Public Network PASS: EUT complies with standard’s requirement FAIL: EUT does not comply with standard’s requirement NA: Not Applicable NP: Test Not Performed TEST REPORT N° 163634-742939-A Version : 01 Page 5/41 2. EQUIPMENT UNDER TEST: CONFIGURATION (DECLARED BY PROVIDER) 2.1. HARDWARE IDENTIFICATION (EUT AND AUXILIARIES): Equipment under test (EUT): IJINUS LT2 Serial Number: IJT 30 05 0000 0815 Equipment Under Test TEST REPORT N° 163634-742939-A Version : 01 Page 6/41 Equipment Under Test Inputs/outputs - Cable: Access Type Length used (m) Declared <3m Shielded Under test Comments - - -    - TEST REPORT N° 163634-742939-A Version : 01 Page 7/41 Equipment information: Type: Frequency band: [902 – 928] MHz Number of Channel: 1 Spacing channel: - Channel bandwidth: 0,6 MHz Antenna Type:  Integral  External  Dedicated Antenna connector:  Yes  No  Temporary for test Transmit chains:  1  2 Receiver chains  1  2 Type of equipment:  Stand-alone  Plug-in  Combined Ad-Hoc mode:  Yes  No Duty cycle:  Continuous duty  Intermittent duty  100% duty Equipment type:  Production model  Pre-production model Operating temperature range: Tmin:  -20°C  0°C  -35°C Tnom: 20°C Tmax:  35°C  55°C  85°C Type of power source:  AC power supply  DC power supply  Battery Operating voltage range: Vnom:  120V/60Hz  3,6 Vdc Antenna Characteristic Antenna assembly Gain (dBi) Frequency Band (MHz) Impedance(Ω) 1 0 902-928 50 CHANNEL PLAN Channel Frequency (MHz) Cnom 915 Modulation Type Worst Case Modulation GFSK  TEST REPORT N° 163634-742939-A Version : 01 Page 8/41 2.2. RUNNING MODE Test mode Description of test mode Test mode 1 Permanent emission with modulation on a fixed channel in the data rate that produced the highest power Test mode 2 Permanent reception Test Running mode Occupied Bandwidth  Test mode 1  Alternative test mode() 6dB Bandwidth  Test mode 1  Alternativ…
