SELTSM201Single Band CDMA Cellular Phone

“Aspen” Reference Guide This document provides final product specifications. This document contains proprietary information of VIA Telecom, Inc. The information contained herein is not to be used by or disclosed to third parties without the express written permission of an officer of VIA Telecom, Inc. VIA Telecom, Inc. reserves the right to make changes to any product herein at any time without notice. VIA Telecom does not assume any responsibility or liability arising out of the application or use of any product described herein, except as expressly agreed to in writing by VIA Telecom; nor does the purchase or use of a product from VIA Telecom convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of VIA Telecom or third parties. The VIA Telecom logo design and VIA TELECOM are trademarks owned by the company. All other brand and product names may be trademarks of their respective companies. VIA Telecom is certified to the ISO 9001:2000 quality management system international standard. VIA Telecom, Inc. 3390 Carmel Mountain Road San Diego, CA 92121, U.S.A. Tel: 858.350.5560 Internet: www.via-telecom.com Copyright © VIA Telecom, Inc. 2005 All Rights Reserved. Printed in U.S.A.. May 2005 Contents CHAPTER 1 QUICK START.................................................................................................1-1 Installing the Battery...........................................................................................................1-1 Charging the Battery Prior to Use.......................................................................................1-2 Powering the Phone On and Off.........................................................................................1-3 Making, Answering, and Ending a Call...............................................................................1-4 Locking the Keypad............................................................................................................1-4 Parts of the Phone..............................................................................................................1-5 Screen Icons.......................................................................................................................1-7 Navigating Through the Menus...........................................................................................1-8 CHAPTER 2 CONTACTS......................................................................................................2-1 Using the Keypad to Enter Information...............................................................................2-1 Entering and Editing Contacts............................................................................................2-4 Creating and Using the Speed List.....................................................................................2-7 Using the vCard - VCard Exchange....................................................................................2-8 Set Reception Mode.......................................................................................................2-8 Read vCards ..................................................................................................................2-8 Send a vCard...............................................................................................................2-10 Send All of Your Phonebook........................................................................................2-11 Delete vCards..............................................................................................................2-12 CHAPTER 3 MESSAGES.....................................................................................................3-1 Using Short Message.........................................................................................................3-1 Using Ring Tone.................................................................................................................3-3 Browse all rings..................................................................................................................3-3 Manage rings......................................................................................................................3-3 Message Settings...............................................................................................................3-5 Using Voice Mail.................................................................................................................3-7 CHAPTER 4 MAKING CALLS..............................................................................................4-1 Viewing Incoming Call Details............................................................................................4-1 Making an Emergency Call.................................................................................................4-1 Making Calls.......................................................................................................................4-2 Viewing a List of Call Logs..................................................................................................4-6 i Aspen Reference Guide Contents CHAPTER 5 SETTING UP YOUR PHONE...........................................................................5-1 Selecting Ring Tones.........................................................................................................5-1 Editing Profile.....................................................................................................................5-2 Adjusting the Volume.....................................................................................................5-2 Setting Up Alerts.................................................................................................................5-4 Setting up the Display.....................................................................................................…

Text truncated - open the document above for the full version.

Feb. 21, 2005 Vitelcom Mobile Technology Inc. 2480 Irvine Boulevard, #172 Tustin, California 92782 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko USA, 11696 Sorrento Valley Rd. San Diego, USA, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Vitelcom Mobile Technology, Inc. Dated this 21 Day of February 20 05 Agency agreement expiration date: 1 October 2005 Monika Hormaza Engineering Project Manager Vitelcom Mobile Technology, Inc. CDMA Technology Division Tel: (714) 389.1169 Mobile: (714) 865.4608 Email: [email protected]

May 17, 2005 Vitelcom Mobile Technology Inc. 2480 Irvine Boulevard, #172 Tustin, California 92782 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA Re: Request of Confidentiality Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Monika Hormaza Engineering Project Manager Vitelcom Mobile Technology, Inc. CDMA Technology Division Tel: (714) 389.1169 Mobile: (714) 865.4608 Email: [email protected]

LABEL REQUIREMENTS RF IC & FCC Vitelcom Mobile Technology S.A. Model No.: CV210 Serial No. FCC ID: SELTSM201 ESN DEC: En Decimal |||||||||||||||||||||||||||||||||||||||||||||||||| ESN HEX: En Hexadecimal |||||||||||||||||||||||||||||||||||||||||||||||||| * This device complies with Part 15 of the FCC Rules. . Made in SPAIN L Width Preferred Dimension ( < 16 (L) x 32 (W) x 0.5 (H) mm ) Optional Dimension Less than ( < 38 (L) x 32 (W) x 0.5 (H) mm )

© 2005 RF Exposure Lab, LLC 2867 Progress Place, Suite 4D • Escondido, CA 92029 • U.S.A. TEL (760) 737-3131 • FAX (760) 737-9131 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Vitelcom Mobile Technology U.S.A. Dates of Test: May 3, 2005 2480 Irvine Blvd., #172 Test Report Number: SAR.20050502 Tustin, CA 92782 This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1999 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003 and OET Bulletin 65 Supp. C (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President FCC ID: SELTSM201 Model(s): CV210-VTL201 Serial No.: Production Unit Equipment Type: Single Band CDMA Cellular Phone Classification: Part 22 Licensed Portable Transmitter Held to Ear TX Frequency Range: 824.7 – 848.31 MHz (CDMA) RX Frequency Range: 869.7 – 893.31 MHz (CDMA) Maximum RF Output: 24.30 dBm Conducted Signal Modulation: CDMA Antenna Type (Length): Internal – Patch Antenna Application Type: Certification FCC Rule Parts: Part 22H FCC ID: SELTSM201 © 2005 RF Exposure Lab, LLC Page 2 of 78 Table of Contents 1. Introduction ........................................................................................................................... 3 SAR Definition [5]...................................................................................................................... 3 2. SAR Measurement Setup ..................................................................................................... 4 Robotic System ......................................................................................................................... 4 System Hardware ..................................................................................................................... 4 System Description ................................................................................................................... 4 E-Field Probe ALS-E-020 .........................................................................................................5 3. Robot Specifications ............................................................................................................. 7 4. Phantom & Simulating Tissue Specifications........................................................................ 8 SAM Phantom ........................................................................................................................... 8 Brain & Muscle Simulating Mixture Characterization ................................................................ 8 Device Holder ........................................................................................................................... 8 5. Definition of Reference Points...............................................................................................9 Ear Reference Point.................................................................................................................. 9 Device Reference Points .......................................................................................................... 9 6. Test Configuration Positions ............................................................................................... 10 Positioning for Cheek/Touch [5] .............................................................................................. 10 Positioning for Ear / 15 ̊ Tilt [5]................................................................................................ 11 Body Worn Configurations ...................................................................................................... 12 7. ANSI/IEEE C95.1 – 1999 RF Exposure Limits [2]............................................................... 13 Uncontrolled Environment.......................................................................................................13 Controlled Environment .......................................................................................................... 13 8. Measurement Uncertainty ................................................................................................... 14 9. System Validation ............................................................................................................... 15 Tissue Verification................................................................................................................... 15 Test System Verification ......................................................................................................... 15 10. SAR Test Data Summary ................................................................................................ 16 Procedures Used To Establish Test Signal............................................................................. 16 Device Test Condition ............................................................................................................. 16 Tilt Position Test ..................................................................................................................... 16 SAR Data Summary – 835 MHz Brain .................................................................................... 17 SAR Data Summary – 835 MHz Brain .................................................................................... 18 SAR Data Summary – 835 MHz Body ............................................…

Text truncated - open the document above for the full version.

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 TEST REPORT FOR CERTIFICATION Test Report: 2005 050389-FCC FCC ID: Equipment Under Test: CDMA 800 Cellular Phone Model: CV210-VTL201 Applicant: VITELCOM MOBILE TECHNOLOGY U.S.A. 2480 Irvine Boulevard #172 Tustin, California 92782 714.389.1169 In Accordance With: FCC Part 22, Subpart H Tested By: Nemko USA Inc. 11696 Sorrento Valley Road San Diego, CA 92121-1024 Date: May 18, 2005 Total Number of Pages: 32 Nemko USA Inc. FCC Part 22 25-389-VITR1 FCCID#: SELTSM201 EQUIPMENT: CV2101-TSM201 Table of Contents Section 1. Summary of Test Results...................................................................................3 Section 2. General Equipment Specification......................................................................6 Section 3. RF Power Output................................................................................................7 Section 4. Audio Frequency Response...............................................................................14 Section 5. Audio Low-Pass Filter Response.....................................................................15 Section 6. Modulation Limiting.........................................................................................16 Section 7. Occupied Bandwidth.......................................................................................17 Section 8. Spurious Emissions At Antenna Terminals....................................................21 Section 9. Field Strength of Spurious...............................................................................27 Section 10. Frequency Stability...........................................................................................30 Section 11. Test Equipment List.........................................................................................32 Page 2 of 32 Nemko USA Inc. FCC Part 22 25-389-VITR1 FCCID#: SELTSM201 EQUIPMENT: CV2101-TSM201 Section 1. Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22. DOCUMENT HISTORY REVISION DATE COMMENTS - May 18, 2005 Prepared By: A. Laudani - May 18, 2005 Initial Release: C. Fleury NOTE: Nemko USA, Inc. hereby makes the following statements so as to conform to Chapter 10 (Test Reports) Requirements of ANSI C63.4 (1992) “Methods and Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”: o The unit described in this report was received at Nemko USA, Inc.'s facilities on May 11, 2005. Testing was performed on the unit described in this report on May 11, 2005 to May 12, 2005 . o Retest for Revision A occurred for conducted RF power and frequency stability May 3, 2005. o The Test Results reported herein apply only to the Unit actually tested, and to substantially identical Units. o This report does not imply the endorsement of the Federal Communications Commission (FCC), NVLAP or any other government agency. This Report is the property of Nemko USA, Inc., and shall not be reproduced, except in full, without prior written approval of Nemko USA, Inc. However, all ownership rights are hereby returned unconditionally to VITELCOM MOBILE TECHNOLOGY U.S.A., and approval is hereby granted to VITELCOM MOBILE TECHNOLOGY U.S.A. and its employees and agents to reproduce all or part of this report for any legitimate business purpose without further reference to Nemko USA, Inc. Page 3 of 32 Nemko USA Inc. FCC Part 22 25-389-VITR1 FCCID#: SELTSM201 EQUIPMENT: CV2101-TSM201 CERTIFICATION Nemko USA, Inc., an independent Electromagnetic Compatibility (EMC) Test Laboratory, produced this Test Report and performed the Radio Frequency Interference (RFI) testing and data evaluation contained herein. Nemko USA, Inc.’s measurement facility is currently registered with the United States Federal Communications Commission (FCC) in accordance with the provisions of 47 United States Code (CFR) Part 2, Subpart I, Section 2.948(a). A current description of Nemko USA, Inc.’s measurement facility is on file with the FCC. Nemko USA Inc. has additionally satisfied the FCC that it complies with the requirements set forth in 47 CFR Part 2, Subpart I, Section 2.948(d) regarding the accreditation of EMC laboratories. As a result, the FCC has placed Nemko USA Inc. on its list of EMC laboratories approved to perform Declaration of Conformity (DOC) procedure testing. The RFI testing, test data collection and test data evaluation were accomplished in accordance with the ANSI C63.4-1992 Standard, and in accordance with the applicable sections of the FCC rules (47 CFR Parts 2 and 18)." digital devices. The testing was also accomplished in accordance with Industry Canada's ICES-003 standard for unintentional radiating device per EMCAB-3, Issue 3 (May 1998). The administrative summary of this test report provides a description of the test sample I hereby certify that the test data, test data evaluation, and equipment configurations used to compile this test report are a true and accurate representation of the test sample’s radio frequency interference characteristics as of the test date(s), and, for the design of the test sample. Chip Fleury Chip Fleury, Frontline manager Page 4 of 32 Nemko USA Inc. FCC Part 22 25-389-VITR1 FCCID#: SELTSM201 EQUIPMENT: CV2101-TSM201 Summary Of Test Data Name Of Test Para. No. Result RF Power Output 2.1046 Complies Audio Frequency Response 2.1047 NA 1 Audio Low Pass Filter Response 2.1047 NA 1 Modulation Limiting 2.1047 NA 1 Occupied Bandwidth (WB Data ) 2.1049 Complies Spurious Emissions at Antenna Terminals 2.1051 Complies Field Strength of Spurious Emissions 2.1053 Complies Frequency Stability 2.1055 Complies Footnotes For N/A’s: 1 Digital Modulation Page 5 of 32 Nemko USA Inc. FCC Part 22 25-389-VITR1 FCCID#: SELTSM201 EQUIPMENT: CV2101-T…

Text truncated - open the document above for the full version.

Para. No. 2.1051 Spurious Emissions at Antenna Terminals ara. No. 2.1053 - Field Strength of Spurious Radiation EUTAttenuator Radio Communication Monitor Spectrum Analyzer P EUT NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH HEIGHT (1 TO 4 m) TO TEST RECEIVER/SPECTRUM ANALYZER SEARCH ANTENNA 3 METERS Para. No. 2.1055 - Frequency Stability Climate Chamber EUT Variable Power Supply Attenuator Counter Frequency Spectrum Analyzer Substitution
