SELTSM301Single Band CDMA Cellular Phone

Artemis Phone User Manual Introduction Congratulations on your purchase of the advanced and compact Artemis cellular phone, designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system such as greatly enhanced voice clarity this phone offers: ● Large, easy-to-read, 8-line backlight color LCD with status line. ● Paging, messaging, voice mail, and caller ID. ● 24-key keypad. ● Long battery stand-by and talk time. ● Menu-driven interface with prompts for easy operation and configuration. Any key answer, auto answer, auto retry, one-touch and speed dialing with 200 memory locations. ● Support multiple languages (English, Spanish and Portuguese). INFORMATION TO USER You must sign up with a wireless service provider and subscribe to the service of your choice. Your service provider will describe its services and instructions for using them. This device is an automated self tuning and power adjusting radio that interacts with the service provider base station operating in the CDMA frequency band and does not require user intervention to operate the tuning or the power adjustment Important information This user’s manual provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications void your warranty. Getting Started Phone Components The following shows key components of your mobile phone. VX600 0 Earpiece LCD screen Right Soft Key END/POWER Key Navigation Keys Left Soft Key Side keys Send key Alphanumeric keys Microphone Bottom Connector Using the Battery Pack Note: It is important to charge the battery fully before the initial use of the phone. The phone comes with a rechargeable battery. Keep the battery charged while not in use in order to maximize talk and standby time when using the phone. This phone will only operate with the battery provided with the phone, or from a authorized retailer. Installing the Battery To install the battery, insert the bottom of the battery into the opening on the back of the phone. Then push the battery down until the latch clicks. Removing the Battery Turn the power off. Lift the release latch to detach the battery Battery Charge Level The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in three ways: sounding an audible tone, blinking the battery icon, and displaying LOW BATTERY WARNING! If the battery charge level becomes exceedingly low, the phone automatically switches off and any function in progress is not saved. Battery Information and Care 1. Never use an unapproved battery since this could damage the phone and / or battery and could cause the battery to explode. 2. The battery does not need to be fully discharged before recharging. 3. Use only VITELCOM approved chargers specific to your phone model since they are designed to maximize battery life. 4. Do not disassemble or short-circuit the battery. 5. Keep the battery’s metal contacts clean. 6. Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement. 7. Recharge the battery after long periods of nonuse to maximize battery life. 8. Do not expose the battery charger to direct sunlight or use it in areas of high humidity such as a bathroom. 9. Battery life will decrease if exposed to extreme hot or cold temperatures. 10. Battery life will vary due to usage patterns and environmental conditions. 11. The use of extended backlighting, MiniBrowser, and data connectivity kits affect battery life and talk/standby times. Accessories There are a variety of accessories available for your mobile phone. You can select these options according to your personal communication requirements. Consult your local dealer for availability. Your phone will come with one Travel Charger and one battery. Optional Accessories: Hands-free headset, data cable. Screen Icons RSSI Displays the strength of the signal received by the phone and current signal strength Online In use. A call is in progress. No Service No service. The phone is not receiving a system signal. Roaming Roaming The phone is outside of the home service area. Normal Outdoor In Car Meeting Silent Profiles and environment setting Alarm Alarm Clock is on SMS Text message. Voice mail Smart message Battery Charge level: Indicates battery charge level. Basic Functions Phone Overview 1. Earpiece 2. Flip Design: Flip open to answer an incoming call (when Answer Call is set to “Flip Open”) and close the flip to end the call. 3. Message Key: Shortcut to retrieve or send voice and text messages. 4. SEND Key: Use to place or answer calls. 5. Side Keys: Use to adjust the key beep volume in standby mode and the earpiece volume during a call. 6. Navigation Key Use for quick access to phone functions ●Up Key: Change the idle screen wallpaper ●Down Key: Enter the contact menu ●Left Key: Set the profiles ●Right Key: Enter the messages menu 7. Soft Keys Left Soft Key: Use to select an action within a menu. Right Soft Key: Use to exit from the current menu or as a CLR key to erase text input. 8. END/PWR Use to turn the power on/off and to end a call. Pressing “PWR” key, you can return to the main menu display screen. 9. Alphanumeric Keypad Use to enter numbers and characters and choose menu items. 10. LCD Screen Displays messages and indicator functions. 11. Microphone 12. Bottom Connector : To connect to charger, hands-free headset or data cable. Side Keys Up, Down side key 1.Adjust the key volume during idle state 2.Adjust the speaker volume during a call Record key 1.Start/stop the record function when in conversation 2.Press the key to enter the voice memo menu when in idle. 3.Hold the key to begin to reco…

Text truncated - open the document above for the full version.

February 28, 2005 Vitelcom Mobile Technology Inc. 2480 Irvine Boulevard, #172 Tustin, California 92782 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko, USA, 11696 Sorrento Valley Rd, San Diego, USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko USA, still resides with Vitelcom Mobile Technology, Inc Dated this 28 Day of February 20 05 Agency agreement expiration date: July 1, 2005 Sincerely, Monika Hormaza Engineering Project Manager Vitelcom Mobile Technology, Inc. CDMA Technology Division Tel: (714) 389.1169 Mobile: (714) 865.4608 Email: [email protected]

February 17, 2005 Vitelcom Mobile Technology Inc. 2480 Irvine Boulevard, #172 Tustin, California 92782 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA Re: Request of Confidentiality - FCC ID: SELTSM301 Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Monika Hormaza Engineering Project Manager Vitelcom Mobile Technology, Inc. CDMA Technology Division Tel: (714) 389.1169 Mobile: (714) 865.4608 Email: [email protected]

LABEL REQUIREMENTS RF IC & FCC Vitelcom Mobile Technology S.A. Marca: TSM Model No.: TSMCV330 Serial No. FCC ID: SELTSM301 ESN DEC: En Decimal |||||||||||||||||||||||||||||||||||||||||||||||||| ESN HEX: En Hexadecimal |||||||||||||||||||||||||||||||||||||||||||||||||| * This device complies with Part 15 of the FCC Rules. . Made in SPAIN Width Preferred Dimension ( < 16 (L) x 32 (W) x 0.5 (H) mm ) Optional Dimension Less than ( < 38 (L) x 32 (W) x 0.5 (H) mm ) L

© 2004 RF Exposure Lab, LLC 2867 Progress Place, Suite 4D • Escondido, CA 92029 • U.S.A. TEL (760) 737-3131 • FAX (760) 737-9131 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Vitelcom Mobile Technology U.S.A. Dates of Test: February 10, 2005 2480 Irvine Blvd., #172 Test Report Number: SAR.20050202 Tustin, CA 92782 This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003 and OET Bulletin 65 Supp. C (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President FCC ID: SELTSM301 Model(s): TSM CV330-VTL301 Serial No.: Production Unit Equipment Type: Single Band CDMA Cellular Phone Classification: Part 22 Licensed Portable Transmitter Held to Ear TX Frequency Range: 824.7 – 848.31 MHz (CDMA) RX Frequency Range: 869.7 – 893.31 MHz (CDMA) Maximum RF Output: 24.30 dBm Conducted Signal Modulation: CDMA Antenna Type (Length): Stubby – 21 mm(L) x 8 mm(Dia.) Application Type: Certification FCC Rule Parts: Part 22H FCC ID: SELTSM301 © 2004 RF Exposure Lab, LLC Page 2 of 70 Table of Contents 1. Introduction.............................................................................................................. 3 SAR Definition [5]........................................................................................................ 3 2. SAR Measurement Setup ........................................................................................ 4 Robotic System............................................................................................................ 4 System Hardware........................................................................................................ 4 System Description...................................................................................................... 4 E-Field Probe ALS-E-020 ............................................................................................ 5 3. Robot Specifications ................................................................................................ 7 4. Phantom & Simulating Tissue Specifications ........................................................... 8 SAM Phantom ............................................................................................................. 8 Brain & Muscle Simulating Mixture Characterization ................................................... 8 Device Holder .............................................................................................................. 8 5. Definition of Reference Points.................................................................................. 9 Ear Reference Point .................................................................................................... 9 Device Reference Points ............................................................................................. 9 6. Test Configuration Positions.................................................................................. 10 Positioning for Cheek/Touch [5]................................................................................. 10 Positioning for Ear / 15 ̊ Tilt [5] .................................................................................. 11 Body Worn Configurations ......................................................................................... 12 7. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] .................................................. 13 Uncontrolled Environment ......................................................................................... 13 Controlled Environment ............................................................................................. 13 8. Measurement Uncertainty ...................................................................................... 14 9. System Validation .................................................................................................. 15 Tissue Verification..................................................................................................... 15 Test System Verification ............................................................................................ 15 10. SAR Test Data Summary ................................................................................... 16 Procedures Used To Establish Test Signal............................................................... 16 Device Test Condition................................................................................................ 16 Tilt Position Test ........................................................................................................ 16 SAR Data Summary – 835 MHz Brain....................................................................... 17 SAR Data Summary – 835 MHz Brain....................................................................... 18 SAR Data Summary – 835 MHz Body....................................................................... 19 11. Test Equipment List............................................................................................ 20 12. Conclusion.......................................................................................................... 21 13. References......................................................................................................... 22 Appendix A –…

Text truncated - open the document above for the full version.

Para. No. 2.1046 - R.F. Pow er Output Para. N o . 2.1049 - O c cupi ed Bandw idth Para. No. 2.1051 - Spurious Emissions at Antenna Terminals EUT Attenuator Radio Communication Monitor Spectrum Analyzer Para. N o . 2.1053 - Fi el d Str e ngt h of Spur ious Radi ati o n 3 METERS EUT NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH HEIGHT (1 TO 4 m) TO TEST RECEIVER/SPECTRUMANALYZER SEARCH ANTENNA Para. N o . 2.1055 - Fr equenc y St abi lit y Climate Chamber EUT Variable Power Supply Frequency Counter Attenuator W i reless Communication Test Set

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 TEST REPORT FOR CERTIFICATION Test Report: 2005 020092-FCC FCC ID: Equipment Under Test: CDMA 800 Cellular Phone Model: CV330 Applicant: VITELCOM MOBILE TECHNOLOGY U.S.A. 2480 Irvine Boulevard #172 Tustin, California 92782 714.389.1169 In Accordance With: FCC Part 22, Subpart H Tested By: Nemko USA Inc. 11696 Sorrento Valley Road San Diego, CA 92121-1024 Date: February 25, 2005 Total Number of Pages: 39 Nemko USA Inc. FCC Part 22 25-093-VIT EQUIPMENT: SELTSM301 800MHz CDMA Cellular Table of Contents Section 1. Summary of Test Results...................................................................................3 Section 2. General Equipment Specification......................................................................6 Section 3. RF Power Output................................................................................................7 Section 5. Audio Low-Pass Filter Response.....................................................................14 Section 6. Modulation Limiting.........................................................................................15 Section 7. Occupied Bandwidth (WB Data).....................................................................16 Section 8. Spurious Emissions At Antenna Terminals....................................................19 Section 9. Field Strength of Spurious...............................................................................30 Section 10. Block Diagrams.................................................................................................36 Section 11. Conductive Emissions ...................................................................25 Section 12. Test Equipment List..........................................................................................27 Page 2 of 39 Nemko USA Inc. FCC Part 22 25-093-VIT EQUIPMENT: SELTSM301 800MHz CDMA Cellular Section 1. Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22, Subpart H. DOCUMENT HISTORY REVISION DATE COMMENTS - February 25, 2005 Prepared By: A. Laudani - February 25, 2005 Initial Release: R. L. Hill NOTE: Nemko USA, Inc. hereby makes the following statements so as to conform to Chapter 10 (Test Reports) Requirements of ANSI C63.4 (1992) “Methods and Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”: o The unit described in this report was received at Nemko USA, Inc.'s facilities on February 18, 2005. Testing was performed on the unit described in this report on February 18, 2005. o The Test Results reported herein apply only to the Unit actually tested, and to substantially identical Units. o This report does not imply the endorsement of the Federal Communications Commission (FCC), NVLAP or any other government agency. This Report is the property of Nemko USA, Inc., and shall not be reproduced, except in full, without prior written approval of Nemko USA, Inc. However, all ownership rights are hereby returned unconditionally to VITELCOM MOBILE TECHNOLOGY U.S.A., and approval is hereby granted to VITELCOM MOBILE TECHNOLOGY U.S.A. and its employees and agents to reproduce all or part of this report for any legitimate business purpose without further reference to Nemko USA, Inc. Page 3 of 39 Nemko USA Inc. FCC Part 22 25-093-VIT EQUIPMENT: SELTSM301 800MHz CDMA Cellular CERTIFICATION Nemko USA, Inc., an independent Electromagnetic Compatibility (EMC) Test Laboratory, produced this Test Report and performed the Radio Frequency Interference (RFI) testing and data evaluation contained herein. Nemko USA, Inc.’s measurement facility is currently registered with the United States Federal Communications Commission (FCC) in accordance with the provisions of 47 United States Code (CFR) Part 2, Subpart I, Section 2.948(a). A current description of Nemko USA, Inc.’s measurement facility is on file with the FCC. Nemko USA Inc. has additionally satisfied the FCC that it complies with the requirements set forth in 47 CFR Part 2, Subpart I, Section 2.948(d) regarding the accreditation of EMC laboratories. As a result, the FCC has placed Nemko USA Inc. on its list of EMC laboratories approved to perform Declaration of Conformity (DOC) procedure testing. The RFI testing, test data collection and test data evaluation were accomplished in accordance with the ANSI C63.4-1992 Standard, and in accordance with the applicable sections of the FCC rules (47 CFR Parts 2 and 18), digital devices. The administrative summary of this test report provides a description of the test sample I hereby certify that the test data, test data evaluation, and equipment configurations used to compile this test report are a true and accurate representation of the test sample’s radio frequency interference characteristics as of the test date(s), and, for the design of the test sample. ________________________________ Ricky L. Hill, Senior EMC Engineer Page 4 of 39 Nemko USA Inc. FCC Part 22 25-093-VIT EQUIPMENT: SELTSM301 800MHz CDMA Cellular Summary Of Test Data Name Of Test Para. No. Result RF Power Output 2.1046 Complies Audio Frequency Response 2.1047 NA 1 Audio Low Pass Filter Response 2.1047 NA 1 Modulation Limiting 2.1047 NA 1 Occupied Bandwidth 2.1049 Complies Spurious Emissions at Antenna Terminals 2.1051 Complies Field Strength of Spurious Emissions 2.1053 Complies Frequency Stability 2.1055 Complies Footnotes For N/A’s: 1 Digital Modulation 2.1033(c) (8) 800 MHz Digital CDMA The input supply to the transmitter was set at 3.6 Volts. The RF power output was measured with the indicated voltage and current applied into the final RF amplifying device(s). RF Output, DC Current and RF Input Power are all average values. Measured Maximum RF output: 24dBm (0.25W) Measured DC voltage: 3.6V…

Text truncated - open the document above for the full version.
