SJ2HJZ0095Bluetooth module

1 Users Manual Model No. : HJZ0095 and HJZ0093 FCC ID : SJ2HJZ0095 IC ID : 5427A HJZ0095 Xanavi Informatics Corporation 2 List of content 1. General information - Name of product - Model Name - Descriptions 2. Procedure to build in 2.1 Procedure for HJZ0095 2.2 Procedure for HJZ0093 3. Pin Description of Connector 4. Label Information 4.1 HJZ0095 4.2 HJZ0093 5. Caution 6. Regulatory information 7. Product information 3 1. General information - Name of product Bluetooth Module - Model Name Manufacture name Xanavi Informatics Corporation Sony Corporation Difference of product HJZ0093 (*1) CXN1041-3AAC - Output PCM clock signals included Synch clock as master mode from the module - 921.6kbps in UART Baud rate HJZ0095 (*2) CXN1041-3ABC - Input PCM clock signals included Synch clock as slave mode to the module - 115.2kbps in UART Baud rate (*1) Based on HJZ0093, fully compatible with the CXN1041-3AAC from SONY (*2) Based on HJZ0095, fully compatible with the CXN1041-3ABC from SONY Note 1 : There is no hardware change between above two models. Note 2 : The IC,CXD 3264, used these Module has its own power supply regulator. - Descriptions The HJZ0093 and HJZ0095 are a fully integrated Class 2 Radio and baseband module conforming to ver.1.2 of the Bluetooth Core specification. 4 2. Procedure to build in: 2.1 Procedure for HJZ0095 A mounting position of the Bluetooth module Vo l u m e k n o b s 1) Pulling out volume knobs Two screws Four screws Two screws 2) Removing two types and eight screws 5 Two screws Two screws FPC cables with connectors FPC cables with connectors 3) Removing four screws and pulling out FPC cable from the connectors Three screws Three screws 4) Removing six screws 6 2. Bluetooth SW printed wiring board R SW printed wiring board L SW printed wiring board R 5) Removing the Bluetooth module from SW pwb R 7 2.2 Procedure for HJZ0093 A mounting position of the Bluetooth module Navigation Unit Two screws A screw Front cover 1) Removing three screws and pulling out FPC cable from the connectors 8 A screw A screw Bluetooth module CF bracket CF Bluetooth cover CF & HDD pwb CF ejector Bottom is contact side CF shield cover Clinches FPC-15pin FPC-35pin 2) Removing four screws and pulling out FPC cable from the connectors 9 3. Pin Description of Connector 10 4. Label Information 4.1 HJZ0095 11 4.2 HJZ0093 12 5. Caution - The following sentence has to be displayed on the outside of the device in which the module is installed: "Contains Transmitter Module FCC ID: SJ2HJZ0095", or "Contains FCC ID: SJ2HJZ0095". - Please note that this users manual should not be provided to end-users. - In the User manual or Label of the device (end-set), which install HJZ0095 or HJZ0093, following Regulatory information should be mentioned. 6. Regulatory information FCC Regulatory information - CAUTION: To maintain compliance with FCC’s RF exposure guidelines, use only the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. - Operation is subject to the following two conditions: 1) this device may not cause interference and 2) this device must accept any interference, including interference that may cause undesired operation of the device IC Regulatory information - Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. L'utilisation de ce dispositif est autorisee seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l'utilisateur du dispositif doit etre pret a accepter tout brouillage radioelectrique recu, meme si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. - This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. 13 7. Product information 7.1. ..................................................................................................................................14 7.1. ...............................................................................................................................14 7.2. ...........................................................................................................................16 7.3. F IRMWARE............................................................................................................................18 1 12 14 7.1. 7.1. CXN1041Bluetooth Specification Ver.1.2 Class2BluetoothRF/ 7.1.1. UART,PCM CODEC,PIO 12252.55 [mm] FLASH MEMORY8M Bit CXD3264GLCSRBlueCore4-EXT 17 Bluetooth CXN1041-3AACCXN1041-3ABC IFUART(BCSP BAUD RATE 921.6kbaud)PCMPIO 2.73.6 [V] 12252.55 [mm] 7.1.2. CXD3264GL 15 7.1.3. 16 7.2. 7.2.1. 7.2.2. 7.2.3. (Ta:-40+85) CXN1041CXD3264GL 17 7.2.4. 18 7.2.5. 100mA 7.3. Firmware Software Stack CSR HCI Stack (Ver.19.2) 19 1

Block diagram of Bluetooth module HJZ0093/HJZ0095 Reset Inverter Flash Memory CXD3264 26MHz X’tal Bulun BPF Chip Antenna 1.8V Connector /w Switch VDD:3.3V GND UART PCM SPI PIO TX RX 26MHz BT Frequency range:2402-2480 MH

Modular Approval Request (per DA 00-1407) FCC ID: SJ2HJZ0095 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. This module has RF shielding with metal case. Refer to external photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Using IC has buffered circuit. 3. The modular transmitter must have its own power supply regulation. The IC,CXD 3264, used in this Module has regulator. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. Yes, this module use ceramic chip antenna attached with solder. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes, this testing is performed by stand-alone configuration. Please refer to test set up photo. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The label of this module with its own FCC ID is put on PCB. Exterior label instruction to installer of this module is provided in user manual. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. Instruction for operational requirements is provided in user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. This module complies with RF exposure requirements and instruction for users is provided in the user manual. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA).

Request for confidentiality. DOC Date: 16 May 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Attn: Reviewing Engineer RE : Bluetooth Module for Navigation System / FCC ID : SJ2HJZ0095 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the schematic diagrams and parts list required to be submitted with this application be withheld from public review. The documents are company proprietary information that could never get into the possession of our competition. Please contact me if there is any information you may need. Sincerely, Koichi Fujimoto Manager of Circuit Design Group Dept. of Hardware Design

HCI Class2 Bluetooth module HJZ0095_External Photo 1) Top View 2) Bottom View Xanavi Informatics Corporation

HCI Class2 Bluetooth module HJZ0093_External Photo 1) Top View 2) Bottom View Xanavi Informatics Corporation

Manufacturer QR code TELEC qualification number FCC and IC No. Serial number 1) Top View (Front) Product Name TELEC log mark 2) Bottom View (Rear) A label indicated FCC ID and IC ID is put the case of navigation unit, following: XXXXX-XXXXX XXXXXXXXX

HCI Class2 Bluetooth module HJZ0095_Internal Photo 1) Top View 2) Bottom View Xanavi Informatics Corporation

HCI Class2 Bluetooth module HJZ0093_Internal Photo 1) Top View 2) Bottom View Xanavi Informatics Corporation

HJZ0093/HJZ0095 (Bluetooth Module for Navigation System) 1. Features 1) Model Number: HJZ0093/HJZ0095 2) Equipment description: Bluetooth Module for Car Navigation System 3) Bluetooth ® standard Ver 1.2 conformity (Modulation Type: GFSK) 4) Power Class2 (Max 4dBm) Bluetooth Module 5) Designed for Xanavi series Navigation System 6) With Antenna is provided on board (Antenna Gain (MAX) = +0.8 dBi) 7) Internal base band clock oscillator 8) Support functions: Serial Port Emulation (Point-To-Point) 9) Bluetooth wireless connection-to-UART bridge function 10) Interface (to Navigation System) : UART 11) Ground line is connected to the application for equipment via one of pins of connector 2. Technical Description 2.1 Specification Parameter Description Min. Typ. Max. Units Carrier Frequency 2.402 2.480 GHz Supply Voltage 2.7 3.3 3.6 V RF Output Power Measured in 50 Ohm -6 0 4 dBm Rx Sensitivity - -84 -70 dBm Operating Temperature -40 85 Degree C Current Consumption HV1 @ SCO 42 mA 2.2 Hardware Block Diagram Reset Inverter Flash Memory CXD3264 26MHz X’tal Bulun BPF Chip Antenna 1.8V Connector /w Switch VDD:3.3V GND UART PCM SPI PIO TX RX 26MHz BT Frequency range:2402-2480 MH

TEST REPORT Report No. : 6080F Page: 2 of 43 Table of Contents 1 TEST REPORT .........................................................................................................................................................................5 2 GENERAL INFORMATION ......................................................................................................................................................5 2.1 P RODUCT DESCRIPTION.......................................................................................................................................................5 2.2 S UMMARY OF TEST AND INSPECTION RESULT........................................................................................................................6 2.3 T EST METHODOLOGY...........................................................................................................................................................6 2.4 T EST FACILITY.....................................................................................................................................................................6 3 SYSTEM TEST CONFIGURATION ..........................................................................................................................................7 3.1 J USTIFICATION.....................................................................................................................................................................7 3.2 O PERATING MODES..............................................................................................................................................................8 3.3 L IST OF ACCESSORIES..........................................................................................................................................................9 3.4 I NTERFACE CABLES...........................................................................................................................................................10 3.5 S PECIAL TEST CONDITION..................................................................................................................................................11 3.6 E QUIPMENT MODIFICATIONS...............................................................................................................................................11 3.7 C ONFIGURATION OF TESTED SYSTEM.................................................................................................................................12 4 ANTENNA REQUIREMENT ...................................................................................................................................................14 5 DC POWERLINE CONDUCTED EMISSION TEST................................................................................................................15 5.1 T EST SETUP......................................................................................................................................................................15 5.2 T EST INSTRUMENTATION....................................................................................................................................................15 5.3 C ONDUCTED EMISSION CALCULATION.................................................................................................................................16 5.4 T EST RESULTS..................................................................................................................................................................17 6 RADIATED EMISSION TEST .................................................................................................................................................20 6.1 T EST SETUP......................................................................................................................................................................20 6.2 T EST INSTRUMENTATION....................................................................................................................................................21 6.3 R ADIATED EMISSION CALCULATION.....................................................................................................................................21 6.4 T EST RESULTS..................................................................................................................................................................22 7 20DB BANDWIDTH ................................................................................................................................................................25 7.1 T EST SETUP......................................................................................................................................................................25 7.2 T EST INSTRUMENT.............................................................................................................................................................25 7.3 T EST RESULTS..................................................................................................................................................................25 8 CARRIER FREQUENCY SEPARATION................................................................................................................................26 8.1 T EST SETUP......................................................................................................................................................................26 8.2 T EST INSTRUMENT.............................................................................................................................................................26 8.3 T EST RESULTS..................................................................................................................................................................26 9 NUMBER OF HOPPING FREQUENCY ...................................................................................…

Text truncated - open the document above for the full version.

Xanavi Informatics Corporation Bluetooth Module HJZ0095 PHOTOS OF TEST SETUP 1. Photos of Radiated Measurement Axial Direction : XY-Plane Axial Direction : YZ-Plane Axial Direction : ZX-Plane Xanavi Informatics Corporation Bluetooth Module HJZ0095 2. Photos of Conducted Measurement
