MOXA Inc. FCC ID.: SLE-WFS001 FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN.Tel : +886-2-8919- Federal Communications Commission July 29, 2014 Authorization and Evaluation Division ATTESTATION FCC ID: SLE-WFS001 Product: Industrial 900MHz Access Point Confirmed Model: AWK-3191-xx-yy-z (x=0-9,A-Z,blank; y=0-9,A-Z,blank or dash;z can be T or blank; for marketing purpose and no impact safety related critical components and constructions) We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, ------------------------------------------ Lea-Ming Tseng / Manager MOXA Inc.

MOXA Inc. FCC ID.: SLE-WFS001 FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN Tel : +886-2-8919- MOXA Inc. FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN Tel : +886-2-8919-1230 Fax: +886-2-8919-1231 Federal Communications Commission July 29, 2014 Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics: (AWK-3191-xx-yy-z) Schem Block Diagram: (AWK-3191-xx-yy-z) BlkDia Operational Description : (AWK-3191-xx-yy-z) OPDes The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, -------------------------------------------- Lea-Ming Tseng / Manager MOXA Inc.

MOXA Inc. FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN TEL No: 886-2-8919-1230 FAX No: 886-2-8919-1231 Attestation for FCC Declaration of Conformity FCC ID: SLE-WFS001 Data: July 29, 2014 Please be notified that we, the undersigned, MOXA Inc., declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 1460553R-ITUSP01V00. Testing in regards to this report was done by QuieTek Corporation, located at 2F, No.345, Xinhu 2nd Rd., Neihu District,Taipei City 114,Taiwan,R.O.C. which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Sincerely, ------------------------------------------------------------------------ Lea-Ming Tseng / Manager MOXA Inc. Tel: 886-2-8919-1230 Fax: 886-2-8919-1231 Email: [email protected]

RF_160, Issue 03 MOXA Inc. Declaration of Authorization We Name: MOXA Inc. Address: FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN City: NEW TAIPEI CITY  . Country: TAIWAN  . Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Industrial 900MHz Access Point Confirmed FCC ID: SLE-WFS001 Trademark: MOXA on our behalf. Date:  2014/07/29  .. City:  TAIWAN  .. Name:  Lea-Ming Tseng  .. (2) Function: ...............Manager............ Signature:  . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Report No.: 1460553R-RFUSP25V00 Page : 1 of 6 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 1460553R-RFUSP25V00 Page : 2 of 6 (3) EUT Photo (4) EUT Photo

MOXA Inc. FCC ID.: SLE-WFS001 FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN.Tel : +886-2-8919- FCC ID Label

MOXA Inc. FCC ID.: SLE-WFS001 FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN.Tel : +886-2-8919- The FCC ID Label will be placed on the equipment as shown in the photograph below.

Report No.: 1460553R-RFUSP25V00 Page : 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 1460553R-RFUSP25V00 Page : 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 1460553R-RFUSP25V00 Page : 5 of 6 (9) EUT Photo (10) EUT Photo Report No.: 1460553R-RFUSP25V00 Page : 6 of 6 (11) EUT Photo (12) EUT Photo

Report No. 1460553R-RFUSP25V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name Industrial 900MHz Access Point Confirmed Model No. AWK-3191-xx-yy-z (x=0-9,A-Z,blank; y=0-9,A-Z,blank or dash;z can be T or blank; for marketing purpose and no impact safety related critical components and constructions) FCC ID SLE-WFS001 Applicant MOXA Inc. Address FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN Date of Receipt June 23, 2014 Date of Declaration July 16, 2014 Report No. 1460553R-RFUSP25V00 The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF any agency of the U.S. Government Report No. 1460553R-RFUSP25V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 1460553R-RFUSP25V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Industrial 900MHz Access Point Confirmed Test Item : RF Exposure Evaluation Test Site : No.3 OATS Operation Frequency Range 905.25 -924.75 MHz Maximum Output Power 29.11dBm Maximum Antenna gain 2.37dBi Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 814.7043 0.279725 Power density is lower than the limit (1 mW/cm 2 ).

Report No. 1460553R-RFUSP25V00 Page : 1 of 74 FCC Test Report Product Name Industrial 900MHz Access Point Confirmed Model No AWK-3191-xx-yy-z (x=0-9,A-Z,blank; y=0-9,A-Z,blank or dash;z can be T or blank; for marketing purpose and no impact safety related critical components and constructions) FCC ID. SLE-WFS001 Applicant MOXA Inc. Address FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TAIPEI CITY, TAIWAN Date of Receipt June 23, 2014 Issue Date July 15, 2014 Report No. 1460553R-RFUSP25V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No. 1460553R-RFUSP25V00 Page : 2 of 74 Test Report Issue Date: July 15, 2014 Report No.: 1460553R-RFUSP25V00 Product Name Industrial 900MHz Access Point Confirmed Applicant MOXA Inc. Address FL.4, NO. 135. LANE 235, BAOQIAO RD. XINDIAN DIST.,NEW TA I P E I C I T Y, TA I WA N Manufacturer MOXA Inc. Model No. AWK-3191-xx-yy-z (x=0-9,A-Z,blank; y=0-9,A-Z,blank or dash;z can be T or blank; for marketing purpose and no impact safety related critical components and constructions) FCC ID. SLE-WFS001 EUT Rated Voltage DC 3.3V EUT Test Voltage AC 120V/60Hz Trade Name MOXA Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2014 ANSI C63.10: 2009, KDB 558074 Test Result Complied Documented By : ( Senior Adm. Specialist / Genie Chang ) Tested By : ( Engineer / Vincent Chu ) Approved By : ( Manager / Vincent Lin ) Report No. 1460553R-RFUSP25V00 Page : 3 of 74 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................14 3.1. Test Equipment............................................................................................................................14 3.2. Test Setup ....................................................................................................................................14 3.3. Limits ..........................................................................................................................................14 3.4. Test Procedure .............................................................................................................................14 3.5. Uncertainty ..................................................................................................................................14 3.6. Test Result of Peak Power Output...............................................................................................15 4. Radiated Emission .....................................................................................................................19 4.1. Test Equipment............................................................................................................................19 4.2. Test Setup ....................................................................................................................................19 4.3. Limits ..........................................................................................................................................20 4.4. Test Procedure .............................................................................................................................21 4.5. Uncertainty ..................................................................................................................................21 4.6. Test Result of Radiated Emission................................................................................................22 5. RF antenna conducted test............................................................…

Text truncated - open the document above for the full version.

Report No.: 1460553R-RFUSP25V00 Page : 1 of 4 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 1460553R-RFUSP25V00 Page : 2 of 4 Front View of Radiated Test Back View of Radiated Test Report No.: 1460553R-RFUSP25V00 Page : 3 of 4 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn) Report No.: 1460553R-RFUSP25V00 Page : 4 of 4 Test Fixture
