SNA-5125GPEt Training Electronic Products

5125G Basic Remote Trainer Training Guide & Owner’s Manual OPERATING INSTRUCTIONS INTRODUCTION Congratulations on your purchase. The Havahart® Remote Trainer will help you train your dogs to eliminate nuisance behaviors and to follow basic obedience commands: Sit, Stay, Heel, Wait, Down, Come, among others. The Havahart Remote Trainer can be a useful aid in the training process, but you will be the key factor in its success. If you consistently spend as little as 10 minutes a day training each dog, you’ll be surprised at the positive results – and even amazed at how smart (and trainable) your dogs are! Havahart is committed to the caring control of pets and wildlife, and all of our products are designed to enhance the relationship between animals and people. Through effective use of Havahart training products, our goal is to help strengthen the bond between dogs and their owners. FREQUENTLY ASKED QUESTIONS How does it work? The Havahart Remote Trainer uses state-of-the-art intelligent electronics to help train your dog to follow your directions/commands. This is a proven technique used by many training professionals. It is a safe and highly effective method for both eliminating negative behavior and creating desired positive behavior. When you press the appropriate button, a static stimulus and a tone are sent to the receiver collar and a correction is delivered via the collar receiver probes. As a safety feature, the unit automatically shuts off if a button is pressed for 10 seconds. If you wish to use tone only to control behavior, simply press the Warning button. Your dog will hear an audible tone instead of receiving stimulation and will begin to associate the tone to the misbehavior. The Remote Trainer offers you two training modes – Tone only or Stimulus with Tone. There are 5 levels of static stimulus with tone. The first time your dog receives a correction, normal reactions may be yelping or jumping. These reactions will decrease as he becomes accustomed to the collar. You should notice improvements in your dog’s behavior during the first week of training. When training, always start at the lowest level and check your dog’s response to the static stimulus. You should always use the lowest level necessary to get the desired response. In addition the hand held trainer can operate two collars training two dogs at the same time. This is accomplished by toggling the switch on the hand held control unit between collars. The digital read out panel tells you which collar is in operation. The training collar neck straps are color coded to distinguish them. Your remote trainer comes supplied with a single collar as most owners train only one dog. Additional collars are available as a separate option. Will the Remote Trainer work for my dog? The Havahart® Remote Trainer effectively and safely uses a static stimulus to help train your dog. It’s important to remember that every dog has a unique personality and responds differently to stimuli. While there is no way to know how your dog will react to its introduction of the training collar, Havahart® products have proven effective for use with dogs of virtually every size, every breed and every age, 8 months and older. For the safety and security of you and your dog, initial training should take place in a confined area where you have complete control over the situation. Please be aware that dogs with aggressive behavior could turn on the trainer upon receiving a static stimulus for the first time. If you believe your dog has aggressive behavior or there is a history of such behavior, we suggest you contact a certified animal trainer before using any electronic stimulus products. Is the Havahart Remote Trainer safe? The Havahart Remote Trainer is safe and humane. To protect your dog and yourself, please observe the following precautions: • Never leave the collar on your dog for more than 12 hours at one time. • Only use the Havahart® Remote Trainer on healthy dogs, ages 8 months and older. Consult your veterinarian before using the collar if your dog has health problems. • Check collar fit each time you place collar on your dog– the collar must be fitted properly to work effectively (see “Fitting the Collar”). • Check dogs daily for skin irritation and do not use the collar if the skin is irritated. • Always use the lowest stimulation possible to train your dog. On small dogs (less than 8-10 lbs.) use Level 1. How long will it take to train my dog? We recommend that you spend 10-15 minutes, 2-3 times a day for 4 to 6 weeks to gain the maximum benefit from the Havahart training system. Every dog learns at his/her own pace but in all cases consistency and repetition are the keys to long-term obedience. GETTING STARTED... HAVAHART® BASIC REMOTE TRAINER FEATURES 1. Train Up to 100 Yards 2. 5 Levels of Correction with Tone and Bad Tone only 3. Operate two color coded collars simultaneously if required. The collar supplied with the hand held is black. An extra collar, sold separately, will be gray. 4. LED Indicator Lights Indicate Low Battery, Static Stimulus level and which collar is being signaled. 5. Collar and handheld trainer both have smart technology that conserves battery life when they are inactive. 6. Ergonomically Designed Transmitter with Lanyard 7. Lightweight Waterproof Receiver Collar 8. Heart Shaped Test Light 9. Product Meets FCC Part 15 Regulations* * This device operates under part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any modification to this device not expressly authorized by Woodstream Corporation may void the user’s authority to operate this device. PACKAGE CONTENTS 1. Collar Receiver – Powered by a disposable CR2 lithium battery. This device delivers the stimulation to the dog via the collar probes. The receiver is held in plac…

Text truncated - open the document above for the full version.

5125G VOLTAGE: 3.0V DC FCC ID: SNA – 5125G MADE IN CHINA LABEL scale 21 X 11.5mm Label position at the enclosure

FCC ID: SNA-5125G Report No.: 070623FIA01 1 FCC TEST REPORT REPORT NO.: 070623FIA01 MODEL NO.: 5125G RECEIVED: Jun. 26, 2007 TESTED: Jun. 26 ~ Jul. 11, 2007 ISSUED: Jul. 11, 2007 APPLICANT: Woodstream Corporation ADDRESS: Room 2106-2110, East Qiu Shi Building, Shen Nan Road, Fu Tian, Shen Zhen, G.D, China ISSUED BY: ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No. 1618, Yishan Rd., 201103, Shanghai, China This test report consists of 22 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. This report contains data that were produced under Laboratory ADT (Shanghai) Corporation. ADT (Shanghai) Corporation. V 2.1.0 FCC ID: SNA-5125G Report No.: 070623FIA01 2 Table of Contents 1 CERTIFICATION .......................................................................................... 3 2 SUMMARY OF TEST RESULTS .................................................................. 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION........................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................. 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST.......................................................................................... 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULTS .......................................................................................... 8 4.2 RADIATED EMISSION MEASUREMENT.................................................... 9 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ................................. 9 4.2.2 TEST INSTRUMENTS............................................................................... 10 4.2.3 TEST PROCEDURE.................................................................................. 11 4.2.4 DEVIATION FROM TEST STANDARD...................................................... 11 4.2.5 TEST SETUP............................................................................................. 12 4.2.6 EUT OPERATING CONDITIONS .............................................................. 12 4.2.7 TEST RESULTS ........................................................................................ 13 4.3 BAND EDGES MEASUREMENT .............................................................. 17 4.3.1 LIMITS OF BAND EDGES MEASUREMENT ............................................ 17 4.3.2 TEST INSTRUMENTS............................................................................... 17 4.3.3 TEST PROCEDURE.................................................................................. 17 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 17 4.3.5 EUT OPERATING CONDITION................................................................. 17 4.3.6 TEST RESULTS ........................................................................................ 17 5 PHOTOGRAPHS OF THE TEST CONFIGURATION................................. 18 6 PHOTOGRAPHS OF THE EUT ................................................................. 19 7 APPENDIX A- INFORMATION ON THE TESTING LABORATORY ........... 20 8 APPENDIX B – UNCERTAINTY IN EMC MEASUREMENT ...................... 21 FCC ID: SNA-5125G Report No.: 070623FIA01 3 1 CERTIFICATION PRODUCT: Pet Training Electronic Products MODEL NO.: 5125G APPLICANT: Woodstream Corporation TESTED: Jun. 26 ~ Jul. 11, 2007 TEST ITEM: Engineering Sample STANDARDS: FCC Part 15:2007, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment has been tested by ADT (Shanghai) Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. TECHNICAL ACCEPTANCE : , DATE:Jul. 11, 2007 Vivian Hsu Engineering Supervisor APPROVED BY : , DATE:Jul. 11, 2007 Wallace Pan Director of Operations FCC ID: SNA-5125G Report No.: 070623FIA01 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type ResultRemark 15.207 Conducted Emission Test N/A Refer to 4.1.2 15.249 Radiated Emission Test PASS Minimum passing margin is –3.95 dB at 2440.50 MHz 15.249 (d) Band Edge Measurement PASSMeet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. MEASUREMENT FREQUENCY UNCERTAINTY Conducted emissions 9kHz ~ 30MHz 3.04 dB 30MHz ~ 200MHz (Horizontal) 4.42 dB 30MHz ~ 200MHz (Vertical) 4.62 dB 200MHz ~ 1000MHz (Horizontal) 4.06 dB Radiated emissions 200MHz ~ 1000MHz (Vertical) 4.16 dB Note: The measurement uncertainty is factored into the compliance determination. The additional information is listed on APPENDIX B of this report. FCC ID: SNA-5125G Report No.: 070623FIA01 5 3 GENERAL INFORMATION 3.1 GENERAL D…

Text truncated - open the document above for the full version.

RE
