SNA-5145GFence Free Pet Containment System

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0177 Manufacturer: Woodstream Corporation Model: 5140G Manual Fence Free Pet Containment System OPERATING INSTRUCTIONS ModelModel #5140G#5140G Model #5140G Système d’enclos sans clôture pour animaux ® 2 Congratulations on your purchase. The Havahart® Fence Free Pet Containment System can help you safely and effectively train your dog to stay within the boundaries you set. Havahart is committed to caring control of pets and wildlife. Through effective use of Havahart training products, our goal is to help strengthen the bond between dogs and their owners. Requirements: 1. Use on dogs 6 months and older and weighing over 8lbs. Do not use to contain puppies. Consult your veterinarian before using the system if your dog has health problems. 2. Adequate time to install your inground fence. 3. Train your dog in 15 minute sessions, 3 times a day. Training should last a minimum of 15 consecutive days. Consistency is the key to success. This initial investment in time and energy will result in long-term rewards: security and exercise for your dog and peace of mind for you! Before you begin, it’s very important that you take the time to thoroughly review the instruction manual and field training cards. These materials have been specially prepared in consultation with professional dog trainers to help guide you though the installation and training process. How does the Fence Free System work? The Fence Free System uses state-of-the-art intelligent electronics to help train your dog to stay within the boundaries you set. Through training, your dog will learn to recognize the boundary visually (aided by flags), through an audio tone and a corrective static stimulus transmitted through the collar. When the dog reaches the edge of the boundary signal, you will hear a warning tone that will last as long as the dog remains in the warning zone. If the dog moves away, the tone shuts off. If the dog continues toward the boundary, the initial low-level static stimulus occurs. If the dog still continues toward the boundary the preset full-level static correction will be administered. You can set this level of correction to individually suit your dog’s temperament. The first time your dog receives a correction, normal reactions may be yelping or jumping. These reactions will decrease as he/she becomes accustomed to the collar. You should notice improvements in your dog’s behavior during the first week of training. FREQUENTLY ASKED QUESTIONS Will the Fence Free System work for my dog? It’s important to remember that every dog has a unique personality and responds differently to stimuli. While there is no way to know how your dog will react to the introduction of the training collar, Havahart products have proven effective for use with dogs of virtually every size and breed that is 6 months and older and weigh more than 8lbs. For the safety and security of you and your dog, initial training should take place in a confined area where you have complete control over the situation. Is the Havahart Fence Free System safe? The Havahart Fence Free System is safe and humane. To protect your dog and yourself, please observe the following safety precautions: 3 • Never leave the collar on your dog for more than 12 hours at one time. • Check collar fit each time you place collar on your dog– the collar must be fitted properly to work effectively (see “Fitting the Collar”). • Check dogs daily for skin irritation and do not use the collar if the skin is irritated. • Always use the lowest stimulation possible to train your dog. Contents of Havahart Fence Free System 1. Water Resistant SMART Collar Receiver with black nylon collar. Powered by a disposable CR2450 coin lithium battery. 2. Wall-Mounted SMART Transmitter/ Control Box. 3. AC Adapter 4. (4) Wire Splicers (2) short probes for short-haired dogs (2) long probes for longer or thicker coated dogs. (2) Screws & Anchors 5. Heart-shaped Tester 6. (50) Training Flags 7. 500 ft of Boundary Wire, 20 gauge 8. Field Training Cards Features of Havahart Fence Free System The following built-in features help increase the system’s effectiveness: • Run-Through Protection When your dog runs towards the boundary, first a warning tone is emitted; if your dog continues towards the fence, the collar will emit another warning tone accompanied by a low level warning static stimulus; if your dog continues towards the boundary, he/she will receive the full level static stimulus that you have set. The factory default setting is the lowest level of static correction. • Over Correction Protection If your dog becomes “trapped” or “confused” in the signal field, this feature limits stimulation. It does this by stopping the static stimulus after 10 seconds and not accepting any additional signal from the fence for 30 seconds; therefore correction of your pet is stopped. The collar will automatically revert to normal operation after this 30-second window. • The Collar offers one level of tone only and 5 levels of tone with static stimulus. The collar comes ready to use, preset at Level 2, the lowest level of tone and static stimulus. • LED Loop Indicator Light to signal that the fence loop is complete. • UL Listed Components Included. 1. 2. 3. 4. 5. 6. 7. 8. 4 GETTING STARTED To begin using your Havahart Fence Free System, you’ll need to plan and install the system boundary wire, and make sure that the collar and the fence communicate with one another. While the system has been designed for easy installation, please allow adequate time to complete each essential step as detailed in the following instructions. 1. DESIGN YOUR BOUNDARY • Contact your utility company to mark off utility lines (phone, electric, cable) before you install your boundary wire. Using graph paper, select th…

Text truncated - open the document above for the full version.

69 N. Locust Street P.O. Box 327 Lititz, PA 17543-0327 (717) 626-2125 CORPORAT IONFax: (717) 626-5350 www.woodstreamcorp.com May 18, 2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Agent Letter of Authorization – Advanced Compliance Solutions, Inc. HAVAHART® IN GROUND FENCE (FCC ID: SNA-5145G) Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of the Havahart® In Ground Fence (SNA- 5145G) to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Should you have any questions/need any additional information, I can be reached at (717) 626 – 2125 x426 or by email [email protected]. Sincerely, Chad Mateer Regulatory Affairs Manager Woodstream Corporation

69 N. Locust Street P.O. Box 327 Lititz, PA 17543-0327 (717) 626-2125 CORPORAT IONFax: (717) 626-5350 www.woodstreamcorp.com May 18, 2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:CONFIDENTIALITY REQUEST HAVAHART® IN GROUND FENCE (FCC ID: SNA-5145G) Dear Sir or Madam: Woodstream Corporationrespectfully requests confidentiality of certain materials provided with the submission of the 5140G Havahart® In Ground Fence under FCC ID: SNA-5145G in accordance with 47 CFR 0.457(d) and 47 CFR 0.459. The confidentiality request applies to the schematic diagrams, block diagram (including associated oscillator frequencies, block signal paths and frequencies, tuning ranges and intermediate frequencies), and operational descriptions (including circuit functions, grounding system description, antenna and duty cycle details) contained in this filing and included in the following files: 12-0177 - Schematics.pdf 12-0177 - Block Diagram.pdf 12-0177 - Theory of Operation.pdf The Havahart® In Ground Fencehas been developed at considerable effort and expense by Woodstream Corporation. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Should you have any questions/need any additional information, I can be reached at (717) 626 – 2125 x426 or by email [email protected]. Sincerely, Chad Mateer Regulatory Affairs Manager Woodstream Corporation

5015 B. U. Bowman Dr. Buford, GA 30518 July 19, 2012 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: SNA-5145G To Whom It May Concern: The following application is submitted on behalf of our client, Woodstream Corporation, for evaluation of their model 5140G for certification under FCC Part 15.209. The 5140G is a fence free pet containment system which was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0177 Manufacturer: Woodstream Corporation Model: 5140G External Photos Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 2 Figure 1: External Photo Figure 2: External Photo Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 3 Figure 3: External Photo Figure 4: External Photo Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 4 Figure 5: External Photo Figure 6: External Photo

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0177 Manufacturer: Woodstream Corporation Model: 5140G Label Information 5140G Product Label Requirement for FCC and IC Adhesive Label located on back of device

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0177 Manufacturer: Woodstream Corporation Model: 5140G Internal Photos Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 2 Figure 1: Internal Photo – Top Figure 2: Internal Photo – Bottom

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Report Number: 12-0177.W06.1A Manufacturer: Woodstream Corporation Model: 5140G Test Begin Date: May 11, 2012 Test End Date: May 14, 2012 Report Issue Date: July 19, 2012 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 16 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ......................................................................................................................10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ........................................................................10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: CFR 47 PART 15.207/ IC: RSS-GEN 7.2.4 .............10 7.2.1 Measurement Procedure ........................................................................................................10 7.2.2 Measurement Results .............................................................................................................10 7.3 RADIATED EMISSIONS – FCC CFR 47 PART 15.209 / RSS-210 SECTION 2.5..................................12 7.3.1 Measurement Procedure ........................................................................................................12 7.3.2 Distance Correction for Measurements Below 30 MHz – Part 15.31 ...................................13 7.3.3 Measurement Results .............................................................................................................13 7.3.4 Sample Calculation ................................................................................................................14 7.4 20DB / 99% BANDWIDTH – FCC: SECTION 15.215, IC: RSS-GEN 4.6.1 .........................................15 7.4.1 Measurement Procedure ........................................................................................................15 7.4.2 Measurement Results .............................................................................................................15 8 CONCLUSION ....................................................................................................................................15 Model: 5140G FCC ID: SNA-5145G IC: 9458A-5145G ACS Report: 12-0177.W06.1A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210. 1.2 Product description The 5140G is a fence free pet containment system. Technical Information: Detail Description Frequency Range 10 kHz Number of Channels 1 Modulation Format AM Operating Voltage 12 VDC Antenna Wire Loop AWG#18 Solid (Varying Length) Manufacturer Information: Woodstream Corporation 69 N. Locust Street Lititz, PA 17543 Test Sample Serial Number(s): 9 Test Sample Condition: The test samples were provided in good working order with no visible defects. 1.3 Test Methodology and Considerations The EUT was tested in an orientation of typical installation. The boundary width setting was 5 which produces the maximum field width and highest field strength. A 5m length of solid AWG18 wire was included in the test setup to represent the perimeter boundary. See section 6.0 for additional test setup details. Model: 5140G FCC ID: SNA-5145G IC: 9458A-5145G ACS R…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-5145G IC: 9458A-5145G FCC Rule Part: 15.209 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-0177 Manufacturer: Woodstream Corporation Model: 5140G Test Setup Photos Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 2 Figure 1: Radiated Emissions – Front View Figure 2: Radiated Emissions – Rear View Model: 5140GFCC ID: SNA-5145GIC: 9458A-5145G ACS Project: 12-0177Advanced Compliance SolutionsPage 3 Figure 3: Conducted Emissions – Front View Figure 4: Conducted Emissions – Side View
