SNA-CFR2Custom Fence Remote

Woodstream Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 23, 2011
Application Purpose: Original Equipment
Date of Application: Jan 23, 2011
Equipment Note: Custom Fence Remote
Frequency Range: 2441.70000000 - 2441.70000000
Company: Woodstream Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-CFR2 IC: 9458A-CFR2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.45.A Manufacturer: Woodstream Corporation Model: 5144R Manual Instruction Manual Havahart ® Wireless Woodstream Corporation 69 North Locust Street Lititz, PA 17543 | 1-800-800-1819 www.HavahartWireless.com DO NOT RETURN THIS PRODUCT TO THE STORE FOR ANY REASON.CONTACT HAVAHART ® WIRELESS DIRECTLY! CALL 1-800-800-1819, OPTION 1. Model 5144G PRIOR TO INSTALLATION Fully Charge the System Controllerand Batteries for 3 hours.AVERAGE SYSTEM SETUP TIME IS 2 HOURS. 2 Congratulations and thank you for choosing the Custom-Shape Wireless Dog Fence from Havahart ® Wireless — the leading innovator of digital wireless fence solutions. Featuring breakthrough, patented, wireless technology, the Custom-Shape Wireless Dog Fence is designed to maximize the freedom and safety of your dog, with minimal effort, investment and impact on your property. It is the industry’s most-advanced, wireless dog containment system.The Custom-Shape Wireless Dog Fence gives you all the advantages of a professionally-installed, underground wire fence system without all the hassles and costs. Our revolutionary technology allows you to shape the wireless fence to the specific configuration of your yard — maximizing the space for your dog to roam. It also allows you to add Custom Exclusion Zones thereby keeping your dog out of your garden or swimming pool. There are no wires to bury or break, no back pains from digging, and no wasted money on trenching — just a fast & easy setup that creates freedom for your dog to roam! Table of Contents Table of Contents Welcome Havahart ® Custom-Shape Wireless Dog Fence www.HavahartWireless.com Havahart ® Custom-Shape Wireless Dog Fence 1-800-800-1819, Option 1 IMPORTANT SAFETY REMINDERS ............................................................................................................................. SYSTEM COMPONENTS ............................................................................................................................... ................ KEY DEFINITIONS, TECHNOLOGY & HOW IT WORKS ........................................................................................... - Roaming Area - Trigger Zone - Exclusion Zone - Controller - Bases - Havahart ® Wireless Collar - The Technology Behind the System - How it Works GETTING STARTED ............................................................................................................................... ........................................ - Quick Checklist - Planning Your Fence Boundary & Exclusion Zones INSTALLING THE CUSTOM-SHAPE WIRELESS DOG FENCE .......................................................................................... Setting Up the Bases ............................................................................................................................... .............. - Installing the Bases - Accessing the Wireless Fence Tracker - Activating the Bases Setting Up the Fence Boundary/Trigger Zone ................................................................................... - Placing Fence Boundary Training Flags - Recording the Fence Boundary/Trigger Zone - Removing the Fence Boundary/Trigger Zone - Removing/Resetting System Bases - Advanced Base Setup - Manual Distance Entry Setting Up the Exclusion Zones (Optional) ............................................................................................ - What are Exclusion Zones (ExZones)? - Placing Exclusion Zone Training Flags - Recording an Exclusion Zone - Naming an Exclusion Zone - Removing an Exclusion Zone - Deactivating /Reactivating an Exclusion Zone Setting Up the Collar(s) ............................................................................................................................... ........ - Installing a Battery - Activating a Collar - Naming a Collar - Adjusting the Correction Level of a Collar - Testing the Trigger Zone - Removing a Collar - Recharging a Battery - System Monitoring / Checking Battery Status - Fitting a Collar Wireless Fence Tracker Examples .......................................................................................................... 27 TRAINING YOUR DOG ............................................................................................................................... ................................... FACTORS AFFECTING SIGNAL STRENGTH ........................................................................................................................... TERMS OF USE AND LIMITATION OF LIABILITY ................................................................................................................ WARRANTY INFORMATION ............................................................................................................................... ...................... 345788131621 29363940 12 345 IMPORTANT MESSAGE ! NOTE: To ensure your complete satisfaction and your dog’s safety, please read and follow all of these instructions carefully. Should you need assistance, our Consumer Care Specialists are ready to help. Call 1-800-800-1819, and press “1”. Register Your Havahart ® Wireless Fence at www.HavahartWireless.com/ customerservice/product-registration to ACTIVATE YOUR WARRANTY. Thank you for purchasing the Custom-Shape Wireless Dog Fence from Havahart ® Wireless! 1 Proper training of your dog is the most critical element in ensuring the success of your wireless dog fence. Consult the training section of this manual once you have set up your wireless dog fence. Controller USB Cable USB AC Adapter Master Base 3 Bases 4 AC Adapter Power Cords For Bases Removable Wall-Mount Adhesive Strips 4 Screws and 4 Wall Anchors Collar 2 RCR123 Batteries For Collar Battery Charger Extra Set Of Collar Probes For Short…

Text truncated - open the document above for the full version.

Cover Letter(s)

69 N. Locust Street P.O. Box 327 Lititz, PA 17543-0327 (717) 626-2125 C O R P O R A T I O N Fax: (717) 626-5350 www.woodstreamcorp.com January 12, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Agent Letter of Authorization – Advanced Compliance Solutions, Inc. Havahart® Wireless Custom Fence Remote (FCC ID: SNA-CFR2) Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: SNA-CFR2 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Should you have any questions/need any additional information, I can be reached at (717) 626 – 2125 x426 or by email at [email protected] . Sincerely, Chad Mateer Regulatory Affairs Manager Woodstream Corporation

Cover Letter(s)

Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 Phone: (770) 831-8048 Fax: (770) 831-8598 January 19, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Woodstream Corporation respectfully requests confidentiality of certain materials provided with the submission of the 5144R under FCC ID: SNA-CFR2 in accordance with FCC Regulations 0.459. The confidentiality request applies to the following exhibits: 11-0003.W06.45.A – Schematics.pdf 11-0003.W06.45.A – System Block Diagram.pdf 11-0003.W06.45.A – Theory of Operation.pdf The 5144R has been developed at considerable effort and expense by Woodstream Corporation. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 January 19, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: SNA-CFR2 To Whom It May Concern: The following application is submitted on behalf of our client, Woodstream Corporation, for evaluation of their model 5144R for certification under FCC Part 15.247. The Havahart® Custom Fence Remote model 5144R was tested in full to the requirements of the aforementioned rules and was found to be in compliance. The 5144R can be configured as a PC peripheral therefore the Declaration of Conformity (DoC) equipment authorization procedure was also applied and the 5144R labeled accordingly. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-CFR2 IC: 9458-CFR2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.45.A Manufacturer: Woodstream Corporation Model: 5144R RF Exposure Model: 5144R FCC ID: SNA-CFR2 IC: 9458A-CFR2 ACS Report: 11-0003.W06.45.A Advanced Compliance Solutions Page 2 General Information: Applicant: Woodstream Corporation ACS Project: 11-0003.W06.45.A Device Category: Mobile / Portable Environment: General Population/Uncontrolled Exposure Operating Configuration: PC Peripheral / Handheld Technical Information: Antenna Type: Skywave dipole antenna part number 81-3000-A Antenna Gain: 3dBi Maximum Transmitter Conducted Power: 19.43dBm, 87.70mW Maximum System EIRP: 22.43dBm, 174.98mW RF Exposure Compliance Justification: For portable applications model 5144R operates in a handheld configuration only. There are no provisions or accessories for body-worn applications. Per KDB 447 498 D01 V04 4(c)(iii), hand SAR is required for hand-held and hand-operated devices with output power > 1000·[f(GHz)]^(-0.5)mW that are designed with the hand operating closer than 5 cm from the antenna during normal use. Model 5144R is exempt from SAR based on the output power (higher of conducted or EIRP) being < 1000*[f(GHz)]^(-0.5)mW. SAR threshold and maximum equipment EIRP calculations are provided below. MPE calculations are also provided for satisfying mobile RF exposure conditions. SAR Threshold = 1000*[2.4417]^(-0.5)mW = 639.96mW Maximum Equipment EIRP = 174.98mW MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Calculator for Mobile Equipment Limits for General Population/Uncontrolled Exposure* 2441.719.431.0087.7031.995 200.035 Power Densit y (mW/cm^2) Distance (cm) Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Installation Guidelines The installation manual should contain text similar to the following advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: RF Exposure In accordance with FCC requirements of human exposure to radio frequency fields, the radiating element shall be installed such that a minimum separation distance of 20 centimeters will be maintained. Conclusion This device complies with the MPE requirements by providing adequate separation between the device, any radiating structure and the general population.

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: SNA-CFR2 IC: 9458A-CFR2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.45.A Manufacturer: Woodstream Corporation Model: 5144R Test Begin Date: January 4, 2011 Test End Date: January 6, 2011 Report Issue Date: January 17, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 21 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE.......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION................................................................................................................... 3 1.2.1 General ................................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS................................................................................. 3 2 TEST FACILITIES.............................................................................................................................. 4 2.1 LOCATION....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION.............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION........................................................................... 7 3 APPLICABLE STANDARD REFERENCES.................................................................................... 7 4 LIST OF TEST EQUIPMENT............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ....................................................................... 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.2...................... 10 7.2.1 Measurement Procedure....................................................................................................... 10 7.2.2 Measurement Results ............................................................................................................ 10 7.3 RADIATED EMISSIONS – FCC: SECTION 15.109(UNINTENTIONAL RADIATION) IC: RSS-210 2.6.. 12 7.3.1 Measurement Procedure....................................................................................................... 12 7.3.2 Measurement Results ............................................................................................................ 12 TABLE 7.3.2-1: RADIATED EMISSIONS TABULATED DATA....................................................................... 12 7.4 6DB / 99% BANDWIDTH – FCC: SECTION 15.247(A)(2) IC: RSS-210 A8.2(A).............................. 13 7.4.1 Measurement Procedure....................................................................................................... 13 7.4.2 Measurement Results ............................................................................................................ 13 7.5 PEAK OUTPUT POWER REQUIREMENT - FCC SECTION 15.247(B)(3) IC: RSS-210 A8.4(4)........... 15 7.5.1 Measurement Procedure....................................................................................................... 15 7.5.2 Measurement Results ............................................................................................................ 15 7.6 SPURIOUS EMISSIONS - FCC 15.247D IC:RSS-210 2.6, A8.5 ........................................................ 15 7.6.1 RF Conducted Spurious Emissions....................................................................................... 15 7.6.1.1 Measurement Procedure ................................................................................................................... 15 7.6.1.2 Measurement Results ....................................................................................................................... 15 7.6.2 Radiated Spurious Emissions (Restricted Bands) - FCC Sec. 15.205 IC: RSS-210 2.6........ 18 7.6.2.1 Measurement Procedure ................................................................................................................... 18 7.6.2.2 Duty Cycle Correction ..................................................................................................................... 18 7.6.2.3 Measurement Resul…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Dwayne Arrighy

[email protected]7177404600Fax: (717) 626-1912

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.44 GHz - 2.44 GHz	88.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approved for hand-held configuration only; there are no provisions or accessories for body-worn applications. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
