SNA-WFC2Wireless Fence Collar

Woodstream Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 23, 2011
Application Purpose: Original Equipment
Date of Application: Jan 23, 2011
Equipment Note: Wireless Fence Collar
Frequency Range: 2441.70000000 - 2441.70000000
Company: Woodstream Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-WFC2 IC: 9458A-WFC2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.25.A Manufacturer: Woodstream Corporation Model: WFC Manual Havahart ® Wireless Woodstream Corporation 69 North Locust Street Lititz, PA 17543 | 1-800-800-1819 www.HavahartWireless.com Instruction Manual Radial-Shape Wireless Dog Fence Model 5134G DO NOT RETURN THIS PRODUCT TO THE STORE FOR ANY REASON. CONTACT HAVAHART ® WIRELESS DIRECTLY! CALL 1-800-800-1819, OPTION 1. Controller F ence R adius 2 Congratulations and thank you for choosing the Radial-Shape Wireless Dog Fence from Havahart ® Wireless - the leading innovator of digital wireless fence solutions. Featuring breakthrough, patent pending wireless technology, the Radial- Shape Wireless Dog Fence is designed to provide maximum freedom and safety for your dog and peace of mind for you with minimal effort, investment and impact on your property. It is the industry’s most-advanced, circular wireless dog containment system. It is the first to offer a Roaming Area that can extend from 40 feet up to 400 feet in all directions with technology housed in a sleek, compact Controller. There are no wires to bury or break, no back pains from digging, and no wasted money on trenching — just a fast & easy setup that creates freedom for your dog to roam! Table of Contents Table of Contents IMPORTANT SAFETY REMINDERS .................................................................................................................................................. SYSTEM COMPONENTS ...................................................................................................................................................................... KEY DEFINITIONS, TECHNOLOGY & HOW IT WORKS ......................................................................................................... - Roaming Area - Trigger Zone - Controller - Havahart ® Collar GETTING STARTED ................................................................................................................................................................................. - Planning Your Wireless Fence Boundary - Quick Checklist INSTALLING THE RADIAL-SHAPE WIRELESS DOG FENCE ................................................................................................... Setting Up the Controller ......................................................................................................................................... - Installing & Activating the Controller Setting Up the Collar ..................................................................................................................................................... - Installing a Battery - Recharging a Battery - Activating a Collar - Adjusting the Correction Level of a Collar - Turning a Collar Off/On - Removing a Collar - Checking Battery Status Setting Up the Fence Boundary/Trigger Zone ........................................................................................ - Establishing the Fence Boundary/Trigger Zone Distance - Placing Training Flags - Turning the Trigger Zone Off/On - Display Options (Viewing Distance to Dog and Battery Status, Turning the Display Off/On, Setting Alarm Options) Fitting a Collar .................................................................................................................................................................... TRAINING YOUR DOG ............................................................................................................................................................................ FACTORS AFFECTING SIGNAL STRENGTH .................................................................................................................................. TROUBLESHOOTING .............................................................................................................................................................................. TERMS OF USE AND LIMITATION OF LIABILITY ....................................................................................................................... WARRANTY INFORMATION .............................................................................................................................................................. 1 2 3 4 Welcome Havahart ® Radial-Shape Wireless Dog Fence www.HavahartWireless.com Havahart ® Radial-Shape Wireless Dog Fence 1-800-800-1819, Option 1 3 4 5 7 8 8 10 13 16 18 25 26 29 30 NOTE: To ensure your complete satisfaction and your dog’s safety, please read and follow all of these instructions carefully. Should you need assistance, our Consumer Care Specialists are ready to help. Call 1-800-800-1819, Option 1. Register Your Havahart ® Wireless Fence at www.HavahartWireless.com/ customerservice/product-registration to ACTIVATE YOUR WARRANTY. Thank you for purchasing the Radial-Shape Wireless Dog Fence from Havahart ® Wireless! ! IMPORTANT MESSAGE Proper training of your dog is the most critical element to ensure the successful operation of your wireless dog fence. Consult the training section of this manual once you have set up your wireless dog fence. AVERAGE SYSTEM SETUP TIME IS 1 HOUR 1 To ensure the safe and effective operation of your Radial-Shape Wireless Dog Fence, please read and follow all safety guidelines and instructions: • The Radial-Shape Wireless Dog Fence is designed for dogs older than 6 months that weigh more than 8 pounds. • The Controller must be installed indoors and should not be exposed to moisture. • The Controller must be plugged into a properly grounded 120V AC outlet. • Changes or modifications to any system component may cause permanent system damage and void manufacturer warranties. • To prevent system damage due to unexpected power surges, it is recommended that you unplug the Controller from…

Text truncated - open the document above for the full version.

Cover Letter(s)

69 N. Locust Street P.O. Box 327 Lititz, PA 17543-0327 (717) 626-2125 C O R P O R A T I O N Fax: (717) 626-5350 www.woodstreamcorp.com January 12, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Agent Letter of Authorization – Advanced Compliance Solutions, Inc. Havahart® Wireless Fence Collar (FCC ID: SNA-WFC2) Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: SNA-WFC2 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Should you have any questions/need any additional information, I can be reached at (717) 626 – 2125 x426 or by email at [email protected] . Sincerely, Chad Mateer Regulatory Affairs Manager Woodstream Corporation

Cover Letter(s)

Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 Phone: (770) 831-8048 Fax: (770) 831-8598 January 20, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Woodstream Corporation respectfully requests confidentiality of certain materials provided with the submission of the WFC under FCC ID: SNA-WFC2 in accordance with FCC Regulations 0.459. The confidentiality request applies to the following exhibits: 11-0003.W06.25.A – Schematics.pdf 11-0003.W06.25.A – System Block Diagram.pdf 11-0003.W06.25.A – Theory of Operation.pdf The WFC has been developed at considerable effort and expense by Woodstream Corporation. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 January 20, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: SNA-WFC2 To Whom It May Concern: The following application is submitted on behalf of our client, Woodstream Corporation, for evaluation of their model WFC for certification under FCC Part 15.247. The WFC was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: SNA-WFC2 IC: 9458A-WFC2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.25.A Manufacturer: Woodstream Corporation Model: WFC Test Begin Date: January 4, 2011 Test End Date: January 6, 2011 Report Issue Date: January 17, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 19 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE.......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION................................................................................................................... 3 1.2.1 General ................................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS................................................................................. 3 2 TEST FACILITIES.............................................................................................................................. 4 2.1 LOCATION....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION.............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION........................................................................... 7 3 APPLICABLE STANDARD REFERENCES.................................................................................... 7 4 LIST OF TEST EQUIPMENT............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ....................................................................... 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.2...................... 10 7.3 RADIATED EMISSIONS – FCC: SECTION 15.109(UNINTENTIONAL RADIATION) IC: RSS-210 2.6.. 10 7.3.1 Measurement Procedure....................................................................................................... 10 7.3.2 Measurement Results ............................................................................................................ 10 TABLE 7.3.2-1: RADIATED EMISSIONS TABULATED DATA....................................................................... 10 7.4 6DB / 99% BANDWIDTH – FCC: SECTION 15.247(A)(2) IC: RSS-210 A8.2(A).............................. 11 7.4.1 Measurement Procedure....................................................................................................... 11 7.4.2 Measurement Results ............................................................................................................ 11 7.5 PEAK OUTPUT POWER REQUIREMENT - FCC SECTION 15.247(B)(3) IC: RSS-210 A8.4(4)........... 13 7.5.1 Measurement Procedure....................................................................................................... 13 7.5.2 Measurement Results ............................................................................................................ 13 7.6 SPURIOUS EMISSIONS - FCC 15.247D IC:RSS-210 2.6, A8.5 ........................................................ 14 7.6.1 RF Conducted Spurious Emissions....................................................................................... 14 7.6.1.1 Measurement Procedure ................................................................................................................... 14 7.6.1.2 Measurement Results ....................................................................................................................... 14 7.6.2 Radiated Spurious Emissions (Restricted Bands) - FCC Sec. 15.205 IC: RSS-210 2.6........ 16 7.6.2.1 Measurement Procedure ................................................................................................................... 16 7.6.2.2 Duty Cycle Correction ..................................................................................................................... 17 7.6.2.3 Measurement Results ....................................................................................................................... 17 7.6.2.4 Sample Calculation: ........................................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: SNA-WFC2 FCC ID: 9458A-WFC2 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0003.W06.25.A Manufacturer: Woodstream Corporation Model: WFC Test Setup Photos Model: WFC FCC ID: SNA-WFC2 IC: 9458A-WFC2 ACS Report: 11-0003.W06.25.A Advanced Compliance Solutions Page 2 Figure 1: Radiated Emissions – X Position Figure 2: Radiated Emissions – X Position Model: WFC FCC ID: SNA-WFC2 IC: 9458A-WFC2 ACS Report: 11-0003.W06.25.A Advanced Compliance Solutions Page 3 Figure 3: Radiated Emissions – Y Position Figure 4: Radiated Emissions – Y Position Model: WFC FCC ID: SNA-WFC2 IC: 9458A-WFC2 ACS Report: 11-0003.W06.25.A Advanced Compliance Solutions Page 4 Figure 5: Radiated Emissions – Z Position Figure 6: Radiated Emissions – Z Position

Contact Information

Applicant

Dwayne Arrighy

[email protected]7177404600Fax: (717) 626-1912

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.44 GHz - 2.44 GHz	117.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
