SO4YX545-PCS-CEL2Cellular Signal Booster

zBoost YX545 SOHO User Guide 30 day money back guarantee when you buy directly from Wi-Ex®. If product is purchased from a reseller or third party, you must use their return policy. 1 Year Manufacturer Warranty. Register your zBoost® product at www.Wi-Ex.com v.042512 zBOOST® YX545 SOHO USER GUIDE zBOOST ® YX545 SOHO USER GUIDE i About zBoost ® from Wi-Ex ® Wi-Ex, the leader in cell phone signal boosters manufactures zBoost, the award-winning line of cell phone signal boosters that enhance the performance of your cell phone, smartphone and wireless data card. Compatibility – Dual Band zBoosts are compatible with 800MHz and 1900MHz regardless of technology- including CDMA and GSM. Patented technologies protect the carrier network. 1-year manufacturer warranty – register your product at www.Wi-Ex.com. zBoost products have more awards, more sales and more locations than all other signal boosters...COMBINED. FCC Information FCC ID: SO4YX545-PCS-CEL2 Warning: Changes or modifications to this device not expressly approved by Wi-Ex® could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. In accordance with FCC requirements of human exposure to radiofrequency fields, the radiating element (antenna) shall be installed such that a minimum separation distance of 20cm (8in) is maintained from all persons. Industry Canada Regulations IC ID: 5544A-YX545PCSCL2 This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. RF Exposure: The manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially where the output is re-radiated and can cause interference to zBOOST ® YX545 SOHO USER GUIDE ii zBOOST ® YX545 SOHO USER GUIDE iii Package Contents: zBoost YX545 SOHO ⑦ ② ③ ④ ⑤ ⑥ Before you begin, make sure all of the following parts came with your zBoost YX545. Literature Contents: ① Set-up overview for zBoost® YX545 SOHO (User Guide online only) Product Contents: ② zBoost Base Unit ③ Base Unit Antenna ④ Power Supply ⑤ RG-59 (mini) Coax Cable 50 ft. ⑥ Signal Antenna ⑦ Signal Antenna Mounting Hardware adjacent band users. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Cet appareillage numérique de la classe [B] répond à toutes les exigences de l’interférence canadienne causant des règlements d’équipement. L’opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l’interférence nocive, et (2) ce dispositif doit accepter n’importe quelle interférence reçue, y compris l’interférence qui peut causer l’opération peu désirée. Le fabricant nominale de la puissance de sortie de ce matériel est simple transporteur. Pour les situations lorsque plusieurs signauxporteurs sont présents, l’évaluation devrait être réduite de 3.5 dB, en particulier lorsque le signal de sortie est ré-émise et peut provoquer des interférences adjacentes à la bande utilisateurs. Ce pouvoir est de la réduction par le biais de la sortie d’alimentation ou la réduction de gain et non par un atténuateur à la sortie du dispositif. Please note: This unit has been approved for use in Canada under RSS 131, however, consent for the use of this device to improve cellular or PCS coverage, must be obtained through your cellular or PCS provider, prior to placing the unit in operation. Please refer to the Industry Canada document CPC 2-1-05, Section 6.1 available or viewable at: http://www.ic.gc.ca/epic/site/smt-gst.nsf/en/sf08942e.html Copyright Notice This manual is copyrighted. All rights reserved. This manual, whole or in part, may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form for distribution. This manual whole or in part, may not be modified without prior consent, in writing, from Wireless Extenders. Copyright © 2012 by Wireless Extenders, Inc. Trademarks Wireless Extenders, Wi-Ex, the Wi-Ex logo, zBoost, the zBoost logo and Extending Cell Zones are registered trademarks of Wireless Extenders, Inc. Safety Guidelines In accordance with FCC requirements of human exposure to radiofrequency fields, the radiating element (antenna) shall be positioned such that a minimum separation distance of 8 i…

Text truncated - open the document above for the full version.

Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 44 of 50 FCC Part 22H/24E Test Report 10 Exhibit A - FCC ID Labeling Requirements 10.1 FCC ID Label Requirements FCC §2.925 Identification of equipment (a) Each equipment covered in an application for equipment authorization shall bear a nameplate or label listing the following: (1) FCC Identifier consisting of the two elements in the exact order specified in §2.926. The FCC Identifier shall be preceded by the term FCC ID in capital letters on a single line, and shall be of a type size large enough to be legible without the aid of magnification. Example: FCC ID: XXX123 Where: XXX—Grantee Code, 123—Equipment Product Code. 10.2 FCC ID Label Contents 10.3 FCC ID Label Location Label here

Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 49 of 50 FCC Part 22H/24E Test Report 12.5 EUT – Main Board Top View 12.6 EUT – Main Board Bottom View Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 50 of 50 FCC Part 22H/24E Test Report 12.7 EUT – Main Board without Shielding 12.8 AC/DC Power Adapter --- End of Report ---

Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 42 of 50 FCC Part 22H/24E Test Report 9 FCC §1.1307(b)(1) & §2.1091 – RF Exposure Information 9.1 Applicable Standard According to FCC §1.1310 and §2.1091 (Mobile Devices) RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density 9.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4πR² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Cellular Band Uplink Maximum peak output power at antenna input terminal (dBm):20.84 Maximum peak output power at antenna input terminal (mW): 121.3389 Prediction distance (cm): 20 Prediction frequency (MHz): 836.52 Antenna Gain, typical (dBi): 3.0 Antenna Gain, typical (numeric): 2.0 Power density at predication frequency and distance (mW/cm 2 ):0.0482 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):0.5577 Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 43 of 50 FCC Part 22H/24E Test Report Cellular Band Downlink Maximum peak output power at antenna input terminal (dBm):13.78 Maximum peak output power at antenna input terminal (mW): 23.87811 Prediction distance (cm): 20 Prediction frequency (MHz): 891.6 Antenna Gain, typical (dBi): 3.0 Antenna Gain, typical (numeric): 2.0 Power density at predication frequency and distance (mW/cm 2 ):0.0095 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):0.5944 PCS Band Uplink Maximum peak output power at antenna input terminal (dBm):20.98 Maximum peak output power at antenna input terminal (mW): 125.3141 Prediction distance (cm): 20 Prediction frequency (MHz): 1880.0 Antenna Gain, typical (dBi): 5.0 Antenna Gain, typical (numeric): 3.2 Power density at predication frequency and distance (mW/cm 2 ):0.0798 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):1.0 PCS Band Downlink Maximum peak output power at antenna input terminal (dBm):13.98 Maximum peak output power at antenna input terminal (mW): 25.00345 Prediction distance (cm): 20 Prediction frequency (MHz): 1989.8 Antenna Gain, typical (dBi): 5.0 Antenna Gain, typical (numeric): 3.2 Power density at predication frequency and distance (mW/cm 2 ):0.0159 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):1.0 Results For uplink and downlink, the highest power density levels at 20 cm are below the MPE uncontrolled exposure limit.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 22H, 24E TEST AND MEASUREMENT REPORT For Wireless Extenders, Inc. One Meca Way, Norcross, GA 30093 USA FCC ID: SO4YX545-PCS-CEL2 Report Type: Original Report Product Type: Cellular and PCS band Amplifier Test Engineer: Ning Ma Report Number: R1203211-2224 Report Date: 2012-05-18 Reviewed By: Victor Zhang EMC/RF Lead Prepared By: (SP) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Ave., Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 2 of 50 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL DESCRIPTION ................................................................................................................................. 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................... 5 1.2 MECHANICAL DESCRIPTION.............................................................................................................................. 5 1.3 OBJECTIVE......................................................................................................................................................... 5 1.4 RELATED SUBMITTAL(S)/GRANT(S)................................................................................................................... 5 1.5 TEST METHODOLOGY........................................................................................................................................ 5 1.6 MEASUREMENT UNCERTAINTY.......................................................................................................................... 6 1.7 TEST FACILITY................................................................................................................................................... 6 2 EUT TEST CONFIGURATION........................................................................................................................... 7 2.1 JUSTIFICATION................................................................................................................................................... 7 2.2 EUT EXERCISE SOFTWARE................................................................................................................................7 2.3 EQUIPMENT MODIFICATIONS............................................................................................................................. 7 2.4 SPECIAL EQUIPMENT......................................................................................................................................... 7 2.5 POWER SUPPLY LIST AND DETAILS.................................................................................................................... 7 2.6 EXTERNAL I/O CABLING LIST AND AC CORD.................................................................................................... 7 2.7 EUT INTERNAL CONFIGURATIONS..................................................................................................................... 7 3 SUMMARY OF TEST RESULTS........................................................................................................................ 8 4 FCC §2.1046, §22.913(A) & §24.232 – RF OUTPUT POWER .......................................................................... 9 4.1 APPLICABLE STANDARD.................................................................................................................................... 9 4.2 TEST SETUP BLOCK DIAGRAM AND PROCEDURE............................................................................................... 9 4.3 TEST EQUIPMENT LIST AND DETAILS................................................................................................................ 9 4.4 TEST ENVIRONMENTAL CONDITIONS............................................................................................................... 10 4.5 TEST RESULTS................................................................................................................................................. 10 5 FCC §2.1049, §22.917 & §24.238 – OCCUPIED BANDWIDTH ..................................................................... 12 5.1 APPLICABLE STANDARD.................................................................................................................................. 12 5.2 TEST BLOCK DIAGRAM AND PROCEDURE........................................................................................................ 12 5.3 TEST EQUIPMENT LIST AND DETAILS.............................................................................................................. 12 5.4 TEST ENVIRONMENTAL CONDITIONS............................................................................................................... 12 5.5 TEST RESULTS................................................................................................................................................. 13 6 FCC §2.1053, §22.917 & §24.238 - SPURIOUS RADIATED EMISSIONS.................................................... 22 6.1 APPLICABLE STANDARD.................................................................................................................................. 22 6.2 TEST PROCEDURE............................................................................................................................................ 22 6.3 TEST EQUIPMENT LIST AND DETAILS...............…

Text truncated - open the document above for the full version.

Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 45 of 50 FCC Part 22H/24E Test Report 11 Exhibit B - Test Setup Photographs 11.1 Radiated Emissions - Front View 11.2 Radiated Emissions - Rear View (Below 1 GHz) Wireless Extenders, Inc. FCC ID: SO4YX545-PCS-CEL2 Report Number: R1203211-2224 Page 46 of 50 FCC Part 22H/24E Test Report 11.3 Radiated Emissions - Rear View (Above 1 GHz)
