SOY-HAW2R1Hi-Gain Wireless-N Dual Radio Smart Repeater Pro

website www.hawkingtech.com e-mail [email protected] © COPYRIGHT 2010 HAWKING TECHNOLOGIES,INC. ALL RIGHTS RESERVED. USER’S MANUAL  HI-GAIN TM WIRELESS-300N SMART REPEATER PRO HAW2R1 COPYRIGHT Copyright ©2010 by Hawking Technologies, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company LIMITED WARRANTY Hawking Technology guarantees that every HAW2R1 Hi-Gain™ Wireless-300N Smart Repeater Pro is free from physical defects in material and workmanship under normal use for one (1) year from the date of purchase. If the product proves defective during this one-year warranty period, call Hawking Customer Service in order to obtain a Return Authorization number. Warranty is for repair or replacement only. Hawking Technology does not issue any refunds. BE SURE TO HAVE YOUR PROOF OF PURCHASE. RETURN REQUESTS CAN NOT BE PROCESSED WITHOUT PROOF OF PURCHASE. When returning a product, mark the Return Authorization number clearly on the outside of the package and include your original proof of purchase. IN NO EVENT SHALL HAWKING TECHNOLOGY’S LIABILTY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING SOFTWARE OR ITS DOCUMENTATION. Hawking Technology makes no warranty or representation, expressed, implied or statutory, with respect to its products or the contents or use of this documentation and all accompanying software, and specifically disclaims its quality, performance, merchantability, or fitness for any particular purpose. Hawking Technology reserves the right to revise or updates its products, software, or documentation without obligation to notify any individual or entity. Please direct all inquiries to: [email protected] Federal Communication Commission Interference Statement FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio technician for help. FCC Caution This equipment must be installed and operated in accordance with provided instructions and a minimum 20 cm spacing must be provided between computer mounted antenna and person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. Safety This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment. EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. Contents Chapter I: Product Information ........................................................................................... 1 1-1 Introduction and safety information ......................................................................... 1 1-2 Safety Information .................................................................................................... 3 1-3 System Requirements .........................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 1 Rev 2.0 SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw 1/27/2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SPORTON International Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Hi-Gain Wireless-N Dual Radio Smart Repeater Pro Model Number: HAW2R1 We affirm that between SIEMIC and SPORTON International Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Name / title: Wayne Hsu / Vice Manager Contact information / address: No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. / Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw

Confidentiality Request Letter Date: 2011/1/6 Federal Communications Commission Authorization and Evaluation Division FCC ID：SOY-HAW2R1 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Hawking Technologies, Inc. Applicant’s company address : 35 Hammond, Suite 150, Irvine California 92618 United States Signature : ________________________________ Job Title and Dept. : Amy Tang / Product Manager E-mail : [email protected] Te l . : 949-206-6900

Date: January 6, 2011 Subject: Ad Hoc Mode Function Declaration FCC ID: SOY-HAW2R1 To Whom it may concern, We, Hawking Technologies, Inc., declare that the device (FCC ID: SOY-HAW2R1) 1. is acting as slave and operating on 2.4GHz band. 2. Ad Hoc function is available. 3. does not work in non-US/Canada frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Applicant : Hawking Technologies, Inc. Address : 35 Hammond, Suite 150, Irvine California 92618 United States Signature : _________________________________ Name and Job Title. : Amy Tang / Product Manager E-mail [email protected] Te l . 949-206-6900

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 2106 Date: 6 January 2011 Subject: FCC Application for FCC ID: SOY-HAW2R1 To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Applicant :Hawking Technologies, Inc. Address :35 Hammond, Suite 150, Irvine California 92618 United States Signature : _________________________________ Name and Job Title. :Amy Tang / Product Manager E-mail :[email protected] Te l . :949-206-6900

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C30 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 External Dipole antenna FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C32 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255

FCC ID: SOY-HAW2R1 Power: 12VDC, 1A HAW2R1 Hi-Gain ™ Wireless-N Dual Radio Smart Repeater Pro

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C8 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C9 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C10 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C11 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C12 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C13 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C14 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C15 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C16 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C17 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C18 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C19 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C20 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C21 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C23 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C24 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C25 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C26 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C27 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C28 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C29 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255 Internal Patch antenna FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C30 OF C32 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 25, 2011 FAX : 886-2-2696-2255

FCC TEST REPORT Report No.: FR052802 Page No. : A1 of A3 FCC ID : SOY-HAW2R1 Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR052802 Page No. : A2 of A3 FCC ID : SOY-HAW2R1 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR052802 Page No. : A3 of A3 FCC ID : SOY-HAW2R1 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11b/g : 24.18 dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 24.18 261.8183 0.1040 Max Conducted Power for IEEE 802.11n port A: 17.16 dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 1.995262 17.16 51.9996 0.0207 Max Conducted Power for IEEE 802.11n port B: 18.41 dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 3 3.981072 18.41 69.3426 0.0275 IEEE 802.11n port A + port B Power Density = 0.0207 + 0.0275 = 0.0482 (mW/cm2) Antenna Type : Patch Antenna Max Conducted Power for IEEE 802.11b/g : 23.96dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 11 12.58925 23.96 248.8857 0.6237 Max Conducted Power for IEEE 802.11n : 22.14dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 11 1.995262 22.14 163.6817 0.4102 Co-location Patch Antenna worst power density + Dipole Antenna worst power density: Power Density = 0.6237 + 0.1040 = 0.7277 (mW/cm2)

FCC TEST REPORT Report No.: FR052802AI SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : Hi-Gain Wireless-N Dual Radio Smart Repeater Pro Model No. : HAW2R1 Brand Name : HAWKING Filing Type : New Application Applicant : Hawking Technologies, Inc. 35 Hammond, Suite 150, Irvine, CA 92618, USA FCC ID : SOY-HAW2R1 Manufacturer : Hawking Technologies, Inc. 35 Hammond, Suite 150, Irvine, CA 92618, USA Received Date : Dec. 25, 2010 Final Test Date : Jan. 06, 2011 Statement Test result included is only for the patch antenna 802.11n of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR052802AI SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC ID : SOY-HAW2R1 Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION ..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Table for Filed Antenna ........................................................................................................................................................................... 3 2.3 Table for Carrier Frequencies ................................................................................................................................................................. 4 2.4 Table for Test Modes .............................................................................................................................................................................. 4 2.5 Table for Testing Locations ..................................................................................................................................................................... 4 2.6 Table for Supporting Units ....................................................................................................................................................................... 5 2.7 Table for Parameters of Test Software Setting ....................................................................................................................................... 5 2.8 EUT Operation during Test ..................................................................................................................................................................... 5 2.9 Test Configuration ................................................................................................................................................................................... 6 3 TEST RESULT ........................................................................................................................................................ 8 3.1 AC Power Line Conducted Emissions Measurement .............................................................................................................................. 8 3.2 Maximum Conducted Output Power Measurement .............................................................................................................................. 12 3.3 Power Spectral Density Measurement .................................................................................................................................................. 14 3.4 6dB Spectrum Bandwidth Measurement ............................................................................................................................................... 20 3.5 Radiated Emissions Measurement ........................................................................................................................................................ 26 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 44 3.7 Antenna Requirements .......................................................................................................................................................................... 49 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 50 5 TEST LOCATION .................................................................................................................................................. 52 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 53 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT ..................................................................................................... C1 ~ C32 FCC TEST REPORT Report No.: FR052802AI SPORTON International Inc. Page No. : ii of ii TEL : 886-2-2696-…

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR052802AC SPORTON International Inc. Report Format Version: a FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : Hi-Gain Wireless-N Dual Radio Smart Repeater Pro Model No. : HAW2R1 Brand Name : HAWKING Filing Type : New Application Applicant : Hawking Technologies, Inc. 35 Hammond, Suite 150, Irvine, CA 92618, USA FCC ID : SOY-HAW2R1 Manufacturer : Hawking Technologies, Inc. 35 Hammond, Suite 150, Irvine, CA 92618, USA Received Date : Dec. 25, 2010 Final Test Date : Jan. 06, 2011 Statement Test result included is only for the patch antenna 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. FCC TEST REPORT Report No.: FR052802AC SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 25, 2011 FAX : 886-2-2696-2255 FCC ID : SOY-HAW2R1 Table of Contents 1 SUMMARY OF THE TEST RESULT ...................................................................................................................... 2 2 GENERAL INFORMATION ..................................................................................................................................... 3 2.1 Product Details ........................................................................................................................................................................................ 3 2.2 Accessories ............................................................................................................................................................................................. 3 2.3 Table for Filed Antenna ........................................................................................................................................................................... 3 2.4 Table for Carrier Frequencies ................................................................................................................................................................. 3 2.5 Table for Test Modes .............................................................................................................................................................................. 4 2.6 Table for Testing Locations ..................................................................................................................................................................... 4 2.7 Table for Supporting Units ....................................................................................................................................................................... 4 2.8 Table for Parameters of Test Software Setting ....................................................................................................................................... 5 2.9 EUT Operation during Test ..................................................................................................................................................................... 5 2.10 Test Configuration ................................................................................................................................................................................... 6 3 TEST RESULT ........................................................................................................................................................ 8 3.1 AC Power Line Conducted Emissions Measurement .............................................................................................................................. 8 3.2 Peak Output Power Measurement ........................................................................................................................................................ 12 3.3 Power Spectral Density Measurement .................................................................................................................................................. 14 3.4 6dB Spectrum Bandwidth Measurement ............................................................................................................................................... 20 3.5 Radiated Emissions Measurement ........................................................................................................................................................ 26 3.6 Band Edge and Fundamental Emissions Measurement ....................................................................................................................... 44 3.7 Antenna Requirements .......................................................................................................................................................................... 49 4 LIST OF MEASURING EQUIPMENTS ................................................................................................................. 50 5 TEST LOCATION .................................................................................................................................................. 52 6 TAF CERTIFICATE OF ACCREDITATION .......................................................................................................... 53 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOT…

Text truncated - open the document above for the full version.

FCC TEST REPORT Report No.: FR052802 Page No. : 1 of 11 FCC ID : SOY-HAW2R1 Co-location Report FCC TEST REPORT Report No.: FR052802 Page No. : 2 of 11 FCC ID : SOY-HAW2R1 1 TEST RESULT 1.1 Radiated Emissions Measurement 1.1.1 Limit 20dBc in any 100 kHz bandwidth outside the operating frequency band. In case the emission fall within the restricted band specified on 15.205(a), then the 15.209(a) limit in the table below has to be followed. Frequencies (MHz) Field Strength (mico…
