  1. Home/
  2. Innovative Wireless Technologies, Inc./
  3. SP8-FAP5015-050

SP8-FAP5015-050903-927MHz Transmit Becon for Tracking System

Innovative Wireless Technologies, Inc.
903-927MHz Transmit Becon for Tracking System - FCC ID SP8-FAP5015-050 - Innovative Wireless Technologies, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 22, 2011
Application Purpose
Original Equipment
Date of Application
Dec 21, 2011
Equipment Note
903-927MHz Transmit Becon for Tracking System
Frequency Range
903.00000000 - 927.00000000
Company
Innovative Wireless Technologies, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 32 of 36 Appendix L: Manual Please refer to the following pages. Page 1 of 10 Issuer: IWT, Inc. Doc. Num.: 6650-11-0040 Rev: A Revised: Dec 15, 2011 Approval: INSTALLATION AND USER’S GUIDE FOR SENTINEL BEACON FAP5015-050 Innovative Wireless Technologies, Inc. 1047 Vista Park Drive, Suite A Forest, VA 24551 Phone: (434)316-5230 Fax: (434)316-5232 www.iwtwireless.com Page 2 of 10 Issuer: IWT, Inc. Doc. Num.: 6650-11-0040 Rev: A Revised: Dec 15, 2011 Approval: Contents 1. PRODUCT OVERVIEW.................................................................................................... 3 2. SAFETY INFORMATION ................................................................................................ 3 2.1 Requirements for FCC Compliance .................................................................................... 3 2.2 Requirements for MSHA Compliance ................................................................................ 4 3. SPECIFICATIONS FOR FAP5010-001 ............................................................................ 5 4. DESCRIPTION................................................................................................................... 6 4.1 Outputs ................................................................................................................................ 6 4.2 Components Necessary for Installation .............................................................................. 6 5. PRIOR TO INSTALLATION ............................................................................................ 7 5.1 Site Survey .......................................................................................................................... 7 5.2 Visually inspect each Sentinel Beacon to ensure that: ........................................................ 7 6. INSTALLATION INSTRUCTIONS.................................................................................. 7 6.1 Installations Below Ground ................................................................................................ 7 6.1.1 Antenna Placement ............................................................................................................. 7 6.1.2 Applying Power to the Sentinel Beacon ............................................................................. 8 6.1.3 Sentinel Beacon Enclosure Placement ................................................................................ 9 6.2 Installations Above Ground ................................................................................................ 9 6.2.1 Sentinel Beacon Installation Instructions ............................................................................ 9 7. OPERATING AND MAINTENANCE INSTRUCTIONS .............................................. 10 Page 3 of 10 Issuer: IWT, Inc. Doc. Num.: 6650-11-0040 Rev: A Revised: Dec 15, 2011 Approval: 1. PRODUCT OVERVIEW Innovative Wireless Technologies’ Sentinel Beacon is a transmitter intended primarily for use in industrial mining applications. The FAP5015-050 Sentinel Beacon design provides enhanced tracking for miners and equipment in high-traffic areas of a coal mine. 2. SAFETY INFORMATION IMPORTANT INFORMATION ON SAFE OPERATION. READ THIS INFORMATION BEFORE INSTALLING AND OPERATING THE SENTINEL BEACON. 2.1 Requirements for FCC Compliance Changes or modifications to this unit not expressly approved by Innovative Wireless Technologies (IWT) may void the user’s authority to operate this equipment. FCC ID: SP8-FAP5015-050 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The Sentinel Beacon must be installed 20cm or more from any personnel in order to comply with FCC exposure requirements. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These designed limits provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no Page 4 of 10 Issuer: IWT, Inc. Doc. Num.: 6650-11-0040 Rev: A Revised: Dec 15, 2011 Approval: guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. 2.2 Requirements for MSHA Compliance This device has been evaluated by the Mine Safety…

Text truncated - open the document above for the full version.

Attestation Statements

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 22 of 36 Appendix B: Part 15.247 Unlicensed Digital Modulation Letter Please refer to the following page. IWT Confidential Page 1 of 1 6650-11-0046 R1 October 01, 2011 Federal Communications Commission To Whom It May Concern: Please be advised that Innovative Wireless Technologies, Inc. is requesting Part 15.247 Unlicensed Digital Modulation approval for its Sentinel Beacon, IWT P/N: FAP5015-050 to have FCC ID: SP8-FAP5015-050. The below statements outline Innovative Wireless Technologies’ responses to part 15.247 concerning Digital Modulation compliance. 1. The Sentinel Beacon is designed specifically for and marketed for mine safety applications. 2. The Sentinel Beacon uses an Edge Slot Antenna that complies with FCC EIRP limits and has less then 3dBi of gain. 3. The Sentinel Beacon is limited to 10dBm output power. 4. The Sentinel Beacon has been tested by Rheintech Test Labs for Part 15 emissions compliance. The EUT was tested as a battery powered intentional radiator complying with §15.247. 5. The Sentinel Beacon will have the FCC ID label with ID number and warnings located on the bottom of the Sentinel Beacon. 6. The user manual for the Sentinel Beacon outlines the proper usage of the EUT and will be submitted with the application for equipment authorization. 7. The Sentinel Beacon will not be operated in a manner, as described by Table 1 of §1.1307(b)(1), that would expose the public to energy levels in excess of the Commission’s guidelines. Innovative Wireless Technologies, Inc. certifies that the above statements are true to the best of our knowledge. Thank you for your attention to this matter. Sincerely, Gary Raulerson NPI Manager Innovative Wireless Technologies, Inc.

Cover Letter(s)

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 23 of 36 Appendix C: FCC Agency Authorization Letter Please refer to the following page . IWT Confidential Page 1 of 1 6650-11-0011 R2 March 29, 2011 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Innovative Wireless Technologies, Inc. authorizes Rheintech Laboratories to act on our behalf, until otherwise notified, for applications submitted to the Federal Communications Commission and/or American Certification Body, Inc. We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party to the application, as defined in 47 CFR 1.2002(b), is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Sincerely, Gary Raulerson NPI Manager Innovative Wireless Technologies, Inc.

Cover Letter(s)

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 24 of 36 Appendix D: FCC Confidentiality Request Letter Please refer to the following page . IWT Confidential Page 1 of 1 6650-11-0012 R2 March 29, 2011 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.459 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and is proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Technical Product Description • Block Diagram Thank you for your attention to this matter. Sincerely, Gary Raulerson NPI Manager Innovative Wireless Technologies, Inc.

External Photos

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 35 of 36 Appendix N: External Photographs IWT Confidential Page 1 of 6 6650-11-0048 R1 Sentinel Beacon FAP5015-050 External Pictures 2011 DEC 01 Picture1: Antenna Side View IWT Confidential Page 2 of 6 6650-11-0048 R1 Picture2: Lid Side View IWT Confidential Page 3 of 6 6650-11-0048 R1 Picture3: Side Side View IWT Confidential Page 4 of 6 6650-11-0048 R1 Picture4: Other Side Side View IWT Confidential Page 5 of 6 6650-11-0048 R1 Picture5: End Side View IWT Confidential Page 6 of 6 6650-11-0048 R1 Picture6: Other End Side View

Internal Photos

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 36 of 36 Appendix O: Internal Photographs Board Top Side Board Bottom Side RF Shield Removed Assembled Box

RF Exposure Info

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 21 of 36 Appendix A: FCC Part 1.1307, 1.1310, 2.1091, 2.1093; IC RSS-Gen: RF Exposure Using FCC 1.1310 Table 1B as guidance, the maximum permissible RF exposure for an uncontrolled environment is 0.6 mW/cm 2 for the frequencies used in this device (903.0 to 927.0 MHz). The worst case power is used for the calculation below. The actual power density for the EUT calculated as shown below. )4/()( 2 dGPS×××=π where: S = power density P = transmitter conducted power in (W) G = antenna numeric gain d = distance to radiation center (m) Frequency (MHz) Antenna Gain (dBi) Conducted Power (W) Calculated Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) 903.0 3 0.010 0.004 0.6 Notice: Radiation Exposure Statement The calculated power density is well below the limit. Nonetheless, the minimum separation distance for this equipment, which is a mobile/fixed device, is 20 cm.

Test Report

Engineering Solutions & Electromagnetic Compatibility Services 360 Herndon Pkwy | Suite 1400 | Herndon | Virginia 20170 Phone: 703.689.0368 | Fax: 703.689.2056 | www.rheintech.com FCC Part 15.247 & IC RSS-210 Certification Report Test Lab: Rhein Tech Laboratories, Inc. Phone: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 www.rheintech.com Herndon, VA 20170 E-Mail: [email protected] Applicant: Innovative Wireless Technologies, Inc. (IWT) 1047 Vista Park Dr., Suite A Tel: 434-316-5230 x14 Forest, VA 24551 Fax: 434-316-5232 Contact: Gary Raulerson, Jr. FCC ID: IC: SP8-FAP5015-050 9568A-FAP5015050 Test Report Date: December 22, 2011 Platform: N/A RTL Work Order Number: 2011183 Model #: FAP5015-050 RTL Quote Number: QRTL11-249 American National Standard Institute: ANSI C63.4-2003: Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz American National Standard Institute: ANSI C63.10-2009: American National Standard for Testing Unlicensed Wireless Devices FCC Classification: DTS – Part 15 Digital Transmission System FCC Rule Part(s): FCC Rules Part 15.247: Operation within the bands 920-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Direct Sequence System (10-01-10) IC Rule Part(s) RSS-210 Issue 8: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment Frequency Range (MHz) Output Power (W) Frequency Tolerance Emission Designator 903.0 – 927.0 0.011 N/A 526KF1D I, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described in this test report. No modifications were made to the equipment during testing in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to, or exclusions from, the applicable parts of FCC Part 2, FCC Part 15, ANSI C63.4. Signature: Date: December 22, 2011 Typed/Printed Name: Desmond A. Fraser Position: President This report may not be reproduced, except in full, without the written approval of Rhein Tech Laboratories, Inc. and Innovative Wireless Technologies, Inc. (IWT). The test results relate only to the item(s) tested. Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 2 of 39 Table of Contents 1 General Information ............................................................................................................................... 6 1.1 Scope ................................................................................................................................................ 6 1.2 Description of EUT ............................................................................................................................ 6 1.3 Test Facility ....................................................................................................................................... 6 1.4 Related Submittal(s)/Grant(s) ........................................................................................................... 6 1.5 Modifications ..................................................................................................................................... 6 2 Test Information ..................................................................................................................................... 7 2.1 Description of Test Modes ................................................................................................................ 7 2.2 Exercising the EUT ........................................................................................................................... 7 2.3 Test Result Summary ........................................................................................................................ 7 2.4 Test System Details .......................................................................................................................... 8 2.5 Configuration of Tested System ........................................................................................................ 8 3 Peak Output Power – FCC 15.247(b)(3); IC RSS-Gen ......................................................................... 9 3.1 Power Output Test Procedure........................................................................................................... 9 3.2 Power Output Test Data .................................................................................................................... 9 4 Band Edge Compliance of RF Conducted Emissions – FCC 15.247(d); IC RSS-Gen ....................... 10 4.1 Band Edge Test Procedure ............................................................................................................. 10 4.2 Test Results .................................................................................................................................... 11 5 Antenna Conducted Spurious Emissions – FCC 15.247(d); IC RSS-Gen .......................................... 13 5.1 Antenna Conducted Spurious Emissions Test Procedures ............................................................ 13 5.2 Antenna Conducted Spurious Emissions Test Results .................................................................. 13 6 6 dB Bandwidth – FCC 15.247(a)(2); IC RSS-210 A8.2(a) ................................................................. 14 6.1 6 dB Bandwidth Test Procedure – Minimum 6 dB Bandwidth ........................................................ 14 6.2 6 dB Bandwidth Test Results .......................................................................................................... 14 7 Power Spectral Density – FCC 15.247(e); IC RSS-210 A8.2(b) ......................................................... 17 7.1 Power Spectral Density Test Procedure .......................…

Text truncated - open the document above for the full version.

Test Setup Photos

Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 33 of 36 Appendix M: Test Photographs Photograph 1: Radiated Testing – Front View Rhein Tech Laboratories, Inc. Client: IWT 360 Herndon Parkway Model #: FAP5015-050 Suite 1400 Standards: FCC 15.247/RSS-210 Herndon, VA 20170 FCC ID: SP8-FAP5015-050 http://www.rheintech.com Report #: 2011183 Page 34 of 36 Photograph 2: Radiated Testing – Back View

Contact Information

Applicant

Gary L Raulerson, Jr.(New Products Introduction Manager)
[email protected]4343165230Fax: 4343165232

Technical Contact

Rhein Tech LabsRick McMurray
[email protected]703-689-0459

360 Herndon Parkway · Herndon, Virginia · United States

Test Firm

Rhein Tech Laboratories, Inc.Richard McMurray
[email protected]703-689-0368Fax: 703-689-2056

Technical Specifications

#Rule PartsFrequency RangePower Output
115C903 MHz - 927 MHz11.00 mW
Confidentiality
Long Term
Grant Notes
Power out is conducted at the antenna terminal. The antenna(s) used for this transmitter must be installed to provide a minimum separation distance of 20cm from all persons as specified in the filing and must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
