1/6 Bluetooth Headset #BTH-08A2 User Manual About Bluetooth Headset #BTH-08A2 This versatile ultra slim/light weighted headset is built-in w/D.S.P. solution for Echo Cancellation and Noise Suppression for high quality digital communication. It supports VoIP/Skype (2.0.43/1.4.4.84) calls – relative Skype setting is required. Cord-free comfort and hands-free convenience in a Bluetooth Heads gives you impeccable sound quality you've never experienced. About Bluetooth Technology? Bluetooth wireless technology is set to revolutionize the personal connectivity by providing freedom from wired connections-enabling links and connectivity between mobile computers, mobile phones, portable handheld devices and other Bluetooth enables devices within 10 meters. Utilizing global sound & digital data 2.4G ISM transmission, it makes global communication in the way you've never dreamed of! Getting to Know Your Bluetooth Headset Getting Started The Bluetooth headset comes with a built-in rechargeable battery. Prior to using the headset, it is recommendable to charge the battery fully for the first time. Please follow these simple steps: (a) Charge your headset. Prior to using the headset, it is recommendable to charge the battery fully for the first time. Main unit 1) Charge Port 2) MFB (Multi-Function Button) 3) Volume Increase (V+) 4) Volume Decrease (V-) 5) Left/Right Changeable Ear Hook, Flexible 6) Travel Charger 7) Charge Cradle 7 6 2/6 (b) Connect the charger to an AC wall outlet and the charge plug to the headset’s charging socket. After completion of charge, please remove the chargers from headset and outlet. (c) Place your headset and a Bluetooth-enabled mobile handset no more than 1 meter apart for pairing. (d) Ensure your headset and handset is within 10 meters(max.) - Bluetooth sensing distance. IMPORTANT: (a) Charge time: Normal full charge time is 1.5 hrs. (Approx.). (b) Charge indication: When charge is in process, the LED will flash red. When charge is completed, the LED will flash off. (c) Low voltage indication: The LED will flash red every 3 seconds. You may hear 2 beeps from headset every 30 seconds with LED flashes red. It’s recommended to charge the headset immediately to prolong durability of battery and standby time. Under low voltage, if battery is not charged within certain time – 30 seconds(approx.), the headset will be powered off. (d) Charging indication will be delayed for a few minutes if the headset has not been used for a long time or the battery is drained off. Press and hold the MFB for 3 seconds until you hear a long beep. The LED will flash red for 3 seconds. Turning On/Off the Headset Turning On - Headset under off mode: (a) Press and hold the MFB for 3 seconds until you hear a short beep. The LED will flash blue for 3 seconds. (b) Headset will be under standby mode. The LED will flash blue every 3 seconds. Turning Off - headset under any modes: (a) Press and hold the MFB for 3 seconds until you hear a long beep. The LED will flash red for 3 seconds. (b) Headset will be off. The LED will flash stop. IMPORTANT: Press the MFB again each time you turn on the headset to reactive the paring so that the connection in between the headset and paired mobile handset is resumed. For pairing, please refer to procedures under “Pairing”. Pairing with a Mobile phone Prior to using the speakerphone for the first time, you must pair it with a Bluetooth-enabled mobile handset. The following steps describes pairing instruction for a typical Bluetooth-enabled mobile handset. (a) Place the headset and mobile phone no more than 1 meter apart (b) Ensure the headset is under off mode.. (c) Press and hold the MFB for 6 seconds until the headset LED flashes red and blue alternately. Mean while you can hear a long beep from the headset. It’s now ready for pairing. (d) Activate your mobile handset’s Bluetooth accessing function by referring to your mobile handset user guide for details. Mean while, the handset will search for accessible Bluetooth devices. (e) Select “BTH-08A2” from the list. (f) Enter the pre-programmed passkey “0000” and press “OK” to pair the headset and the handset. When pairing is completed, you may hear a long beep and LED will flash blue for 3 times. Now the headset is under standby mode with LED flashes blue every 3 seconds. (g) Press “Return” to go back to your handset’s main menu. (For most of the mobile handset models, a headset icon will be shown on the screen.) You should now be able to make and receive calls through the headset. Please place the mobile handset to the headset no more than 10 meters. (Obstruction could cause shorter sensing distance.) 3/6 IMPORTANT: Under pairing mode, if pairing procedures are not completed within 2 minutes, the headset will be turned off and emit a long beep. Please repeat step (c) to (g) to pair the headset and mobile handset again. Connection/Link to a Mobile Handset After pairing is completed, headset is always under standby mode. Before you place or answer a call, if the headset ICON is not shown on phone screen, please follow the simple steps to activate the Bluetooth connection/link through your handset or speakerphone until the headset ICON is on the screen. (a) On Handset: Select “BT-08A2” from the paired list on your handset screen. (b) On Speakerphone: Press MFB and select “Accept” on handset screen to accept connection. IMPORTANT: Whenever Bluetooth connection/link is removed and you cannot see the headset ICON on phone screen, for example: Headset or mobile handset is powered off and then turn on, or out of 10 meter sensing distance, please activate connection/link as suggested. Disconnection to the Mobile Handset You may connect your headset with another Bluetooth handset. Please follow the simple steps to disconnect the headset with the pre-paired handset. (a) Power off the headset (b) Select “disconnecting” to remove previous connection from your handset list. IMPORTANT: When Bluetooth connection is removed, the hands…

Text truncated - open the document above for the full version.

910805 1 International Co., Ltd. 3B02&3B03, No.5 Hsin-Yi Rd., Sec. 5, Taipei 110, Taiwan Tel: 886-2-27223333 (Rep.) Fax: 886-2-27225050 _____E-mail: [email protected] web site: www.celltrend.com.tw___ Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize ELECTRONICS TESTING CENTER, TAIWAN, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ELECTRONICS TESTING CENTER, TAIWAN on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ELECTRONICS TESTING CENTER, TAIWAN as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; 910805 2 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, (signature) Meg Wang Sales Manager CellTrend International Co., Ltd. 3B02, NO.5, HSIN-YI ROAD, SEC.5, TAIPEI 110, TAIWAN, R.O.C.

910805 3 International Co., Ltd. 3B02&3B03, No.5 Hsin-Yi Rd., Sec. 5, Taipei 110, Taiwan Tel: 886-2-27223333 (Rep.) Fax: 886-2-27225050 _____E-mail: [email protected] web site: www.celltrend.com.tw___ Federal Communications Commission FCC ID: SPEBTH08A2 Product Name: Bluetooth Headset Model Name: BTH-08A2, BTH-XXXX (X=0~9, A~Z or Blank) Trade Name: CELLTREND Dear Sir: In accordance with 47 C.F.R. Section 0.459, we would like to request confidentiality on some exhibits we submitted for above application for the reason of trade secret. If those exhibits are available for public inspection, any person who once gets the information contained in those exhibits will be able to design and to make the same products very easily. This is a very serious problem and huge loss for us, because we did invest so much on it. Please be not made the Exhibit Types listed below routinely available for public inspection: Block Diagram and Schematics and Operation Description. By: By: Meg Wang (Signature) (Printed) Title : Sales Manager Applicant : CELLTREND INTERNATIONAL CO., LTD. Address : 3B02, NO.5, HSIN-YI ROAD, SEC.5, TAIPEI 110, TAIWAN, R.O.C. Tel : 886-2-27223333 Fax: 886-2-27225050 Date : 2007,Feb.,7

ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Mode: EUT Top View of EUT Rear View of EUT ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Side View of EUT Front View of EUT ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Side View of EUT Rear View of EUT ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Charger Top View of Charger Bottom View of Charger ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Side View of Charger Front View of Charger ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Side View of Charger Rear View of Charger ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Adaptor Side View of Adaptor Side View of Adaptor

1.2CM×0.4 CM Model : BTH-08A2 FCC ID SPEBTH08A2:

ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Internal View of EUT ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Component View of PCB Component View of PCB ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Solder View of PCB ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Internal View of Charger ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Component View of Charger’s PCB Solder View of Charger’s PCB ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 2.1 CONSTRUCTED PHOTOS of EUT Component View of Adaptor’s PCB Solder View of Adaptor’s PCB

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : Bluetooth Headset Model : BTH-08A2 FCC ID : SPEBTH08A2 for APPLICANT : CELLTREND INTERNATIONAL CO., LTD. ADDRESS : 3B02, NO. 5, HSIN-YI ROAD, SEC. 5, TAIPEI, TAIWAN, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO.34, LIN 5, DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail : [email protected] Report Number : 07-02-RBF-064-03 ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : CELLTREND INTERNATIONAL CO., LTD. 3B02, NO. 5, HSIN-YI ROAD, SEC. 5, TAIPEI, TAIWAN, R.O.C. Manufacture : MEGATREND IND. CO., LTD. TONG-FU-YU IND., KU-KENG, GUAN-LAN, BAO-AN DISTRICT, SHENZHEN, CHINA. Description of Device : a) Type of EUT : Bluetooth Headset b) Trade Name : CELLTREND c) Model No. : BTH-08A2 d) Power Supply : Charger: DC 50 to 6V, 400mA, DC & mini USB jack; Battery: DC 3.7V Li-ion 85mAH e) The data also apply to : BTH-XXXX (X=0~9, A~Z or Blank) Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2006) I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. Issued Date : Mar. 26, 2007 Test Engineer : ( Falcon Shi ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 07-02-RBF-064-03 FCC ID.: SPEBTH08A2 Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION ...................................................................................................... 1 1.1 Product Description...................................................................................................................... 1 1.2 Characteristics of Device ............................................................................................................. 1 1.3 Test Methodology ........................................................................................................................ 1 1.4 Test Facility.................................................................................................................................. 1 2 PROVISIONS APPLICABLE ..................................................................................................... 2 2.1 Definition ..................................................................................................................................... 2 2.2 Requirement for Compliance ....................................................................................................... 3 2.3 Restricted Bands of Operation ..................................................................................................... 5 2.4 Labeling Requirement .................................................................................................................. 6 2.5 User Information .......................................................................................................................... 6 3 SYSTEM TEST CONFIGURATION ......................................................................................... 7 3.1 Justification .................................................................................................................................. 7 3.2 Devices for Tested System........................................................................................................... 7 4 RADIATED EMISSION MEASUREMENT.............................................................................. 8 4.1 Applicable Standard ..................................................................................................................... 8 4.2 Measurement Procedure............................................................................................................... 8 4.3 Measuring Instrument ................................................................................................................ 10 4.4 Radiated Emission Data ............................................................................................................. 11 4.4.1 Tx Portion .......................................................................................................................................... 11 4.4.2 Radiated Emissions in Restricted Bands ............................................................................................ 14 4.4.3 Other Emissions ................................................................................................................................. 15 4.5 Field Strength Calculation ......................................................................................................... 15 4.6 Photos of Radiation Measuring Setup........................................................................................ 16 5 CONDUCTED EMISSION MEASUREMENT ....................................................................... 17 5.1 Standard Applicable ................................................................................................................... 17 5.2 Measurement Procedure............................................................................................................. 17 5.3 Conducted Emission Data .......................................................................................................... 18 5.4 Result Data Calculation ............................................................................................................. 20 5.5 Conducted Measurement Equipment ......................................................................................... 20 5.6 Photos of Conduction Measu…
