SDP650 PORTABLE RADIO USER MANUAL TNM-U-E-0115, Issue – 1.1B July 2013 Field House, Uttoxeter Old Road Derby DE1 1NH Tel: +44 (0) 1332 375500 FAX: +44 (0) 1332 375501 http://www.simocogroup.com 1270 Ferntree Gully Road, Scoresby Victoria, 3179 Australia Tel: +61 (0)3 9730 3999 FAX: +61 (0)3 9730 3988 http://www.simocogroup.com ©Simoco 2013 SDP650 – USER MANUAL TNM-U-E-0115 Jul 13 (Iss. 1.1) Page 2 PREFACE PREFACE D ECLARATION This User Manual covers the Digital Mobile Radio (DMR) Operating Instructions for the SDP650 Portable Radio Transceiver. Any performance figures quoted are subject to normal manufacturing and service tolerances. The right is reserved to alter the equipment described in this manual in the light of future technical development. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. COPYRIGHT All information contained in this document is the property of Simoco. All rights are reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine@readable form, without prior written permission from Simoco. C OMPUTER S OFTWARE C OPYRIGHTS The AMBE+2 TM voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to extract, remove, decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human@readable form. U.S. Patent Nos. #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. DISCLAIMER There are no warranties extended or granted by this document. Simoco accepts no responsibility for damage arising from use of the information contained in the document or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions. E QUIPMENT AND M ANUAL U PDATES In the interests of improving the performance, reliability or servicing of the equipment, Simoco reserves the right to update the equipment or this document or both without prior notice. SDP650 – USER MANUAL TNM-U-E-0115 Jul 13 (Iss. 1.1) Page 3 PREFACE E RRORS AND O MISSIONS The usefulness of this publication depends upon the accuracy and completeness of the information contained within it. Whilst every endeavour has been made to eliminate any errors, some may still exist. It is requested that any errors or omissions noted should be reported to either of the following who are part of the Simoco group: Field House Uttoxeter Old Road, Derby. DE1 1NH. UK 1270 Ferntree Gully Road, Scoresby Victoria. 3179 Australia Tel: +44 (0) 871 741 1050 Tel: +61 (0)3 9730 3999 E@mail: [email protected] E@mail: [email protected] D OCUMENT H ISTORY Issue Date Comments 1.0 January 2013 Initial Issue. 1.1 July 2013 Additional General Precaution added, plus changes to Support page email addresses. R ELATED D OCUMENTS 1. TNM-M-E-0033. SDP600 Series DMR Portable Radio Transceivers – Service Manual, Issue 1.0. 2. TNM-U-E-0117. SDP650 Portable Radio – Brief User Guide, Issue 1.1, dated July 2013. 3. TNM-U-E-0118. PAR-600CRG1 Single Rapid Charger – SDP650/660 Instruction Manual, Issue 1.0, dated January 2013. To order printed copies of this or any of the above publications, please contact Simoco. See the Support page for contact information. A comprehensive list of documentation is available for download on the Simoco website http://www.simocogroup.com via the Partner Portal. SDP650 – USER MANUAL TNM-U-E-0115 Jul 13 (Iss. 1.1) Page 4 CONTENTS TABLE OF CONTENTS Page Title Page ......................................................................................................................................1 Preface ..........................................................................................................................................2 Table of Contents (This List) .......................................................................................................4 List of Figures ..............................................................................................................................6 List of Tables ................................................................................................................................6 Personal Safety ............................................................................................................................7 Warnings .......................................................................................................................................7 Compliance with RF Energy Exposure Guidelines (United States and Canada)......................9 General Notes .............................................................................................................................12 Support – Contact Information ..................................................................................................13 Abbreviations .............................................................................................................................14 Glossary ......................................................................................................................................15 1 INTRODUCTION..................................................................................................................16 1.1 OVERVIEW....................................................................................................…

Text truncated - open the document above for the full version.

SDP660 PORTABLE RADIO USER MANUAL TNM-U-E-0114, Issue 1.1B July 2013 Field House, Uttoxeter Old Road Derby DE1 1NH Tel: +44 (0) 1332 375500 FAX: +44 (0) 1332 375501 http://www.simocogroup.com 1270 Ferntree Gully Road, Scoresby Victoria, 3179 Australia Tel: +61 (0)3 9730 3999 FAX: +61 (0)3 9730 3988 http://www.simocogroup.com ©Simoco 2013 SDP660 – USER MANUAL TNM-U-E-0114 Jul 13 (Iss 1.1) Page 2 PREFACE PREFACE D ECLARATION This User Manual covers the Digital Mobile Radio (DMR) Operating Instructions for the SDP660 Portable Radio Transceiver. Any performance figures quoted are subject to normal manufacturing and service tolerances. The right is reserved to alter the equipment described in this manual in the light of future technical development. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. COPYRIGHT All information contained in this document is the property of Simoco. All rights are reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine@readable form, without prior written permission from Simoco. C OMPUTER S OFTWARE C OPYRIGHTS The AMBE+2 TM voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to extract, remove, decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human@readable form. U.S. Patent Nos. #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. DISCLAIMER There are no warranties extended or granted by this document. Simoco accepts no responsibility for damage arising from use of the information contained in the document or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions. E QUIPMENT AND M ANUAL U PDATES In the interests of improving the performance, reliability or servicing of the equipment, Simoco reserves the right to update the equipment or this document or both without prior notice. SDP660 – USER MANUAL TNM-U-E-0114 Jul 13 (Iss 1.1) Page 3 PREFACE E RRORS AND O MISSIONS The usefulness of this publication depends upon the accuracy and completeness of the information contained within it. Whilst every endeavour has been made to eliminate any errors, some may still exist. It is requested that any errors or omissions noted should be reported to either of the following who are part of the Simoco group: Field House Uttoxeter Old Road, Derby. DE1 1NH. UK 1270 Ferntree Gully Road, Scoresby Victoria. 3179 Australia Tel: +44 (0) 871 741 1050 Tel: +61 (0)3 9730 3999 E@mail: [email protected] E@mail: [email protected] D OCUMENT H ISTORY Issue Date Comments 1.0 January 2013 Initial Issue. 1.1 July 2013 Additional General Precaution added, plus changes to Support page email addresses. R ELATED D OCUMENTS 1. TNM-M-E-0033. SDP600 Series DMR Portable Radio Transceivers – Service Manual, Issue 1.0. 2. TNM-U-E-0116. SDP660 Portable Radio – Brief User Guide, Issue 1.1, dated July 2013. 3. TNM-U-E-0118. PAR-600CRG1 Single Rapid Charger – SDP650/660 Instruction Manual, Issue 1.0, dated January 2013. To order printed copies of this or any of the above publications, please contact Simoco. See the Support page for contact information. A comprehensive list of documentation is available for download on the Simoco website http://www.simocogroup.com via the Partner Portal. SDP660 – USER MANUAL TNM-U-E-0114 Jul 13 (Iss 1.1) Page 4 CONTENTS TABLE OF CONTENTS Page Title Page ......................................................................................................................................1 Preface ..........................................................................................................................................2 Table of Contents (This List) .......................................................................................................4 List of Figures ..............................................................................................................................6 List of Tables ................................................................................................................................7 Personal Safety ............................................................................................................................8 Warnings .......................................................................................................................................8 Compliance with RF Energy Exposure Guidelines (United States and Canada)....................10 General Notes .............................................................................................................................13 Support – Contact Information ..................................................................................................14 Abbreviations .............................................................................................................................15 Glossary ......................................................................................................................................16 1 INTRODUCTION..................................................................................................................17 1.1 OVERVIEW..........................................................................................................…

Text truncated - open the document above for the full version.

Re: STZSDP600TU: Letter of Agency To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yours faithfully, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 24/06/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

Re: FCC Declaration of Similarity: FCC ID: STZSDP600TU To Whom It May Concern: Please be advised that the models SDP650TU and SDP660TU are electronically identical, all RF measurements and test results are exactly the same. The difference between the two models is that the SDP660TU radio has a full alpha numeric keypad and graphic liquid crystal display whereas the SDP650TU has no alpha numeric keypad and a simpler 12 character liquid crystal display. Thank you for your attention to these matters. Yours sincerely, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 24/06/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

Re: Extended Frequency Justification: FCC ID: STZSDP600TU To Whom It May Concern: Simoco Australasia Pty Ltd would like to submit the following justification to show the frequency range as 406.1 – 480 MHz on the Grant of Equipment Authorization for STZSDP600TU equipment. This frequency range is applicable to FCC Part 90 radiocommunication systems that would include federal and public agencies, emergency services, commercial, business and industrial services etc. These services account for the majority of users on this band (refer to the list below). Frequency: Application: 406.1 – 420 Federal Government 420 – 480 Federal Government and Part 90 Also the frequency of operation of the STZSDP600TU portable radio cannot be programmed by the operator to transmit on frequencies other than those programmed by service or maintenance personnel. From the FCC KDB634187 guide, it is noted that FCC rules would be violated if the STZSDP600TU equipment were programmed and operated on unauthorized frequencies. Thank you for your attention to these matters. Yours sincerely, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 06/08/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

Re: STZSDP600TU Certification: FCC Request for Confidentiality in Accordance with FCC Rule 0.459 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.459 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and is proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Operational Description • Block Diagram • Parts List Yours sincerely, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 24/06/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

Re: Spectrum Efficiency: FCC ID: STZSDP600TU To Whom It May Concern: This is to certify that the requirements of 47 CFR Part 90.203(j)(4) and (5) spectrum efficiency standard of one voice channel per 12.5kHz of channel bandwidth are met by the STZSDP600TU portable radio as demonstrated by the tests conducted on the sample radio provided (11k0F3E emission). Additionally in this sample, the 4FSK data rate is in accordance with ETSI TS 102 361-1 that is 9600 bits per second in a 12.5kHz channel bandwidth using TDMA, therefore the STZSDP600TU transmitted data satisfies the requirement of 4800 bits per second per 6.25kHz of channel bandwidth (7K60FXE and 7K60FXD emissions). Thank you for your attention to these matters. Yours sincerely, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 06/08/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

Re: Frequency Programming: FCC ID: STZSDP600TU To Whom It May Concern: The frequency of operation of the STZSDP600TU portable radio cannot be programmed by the operator to transmit on frequencies other than those programmed by service or maintenance personnel. The STZSDP600TU portable radio requires the operating frequencies to be programmed through the use of an external device only available to service or maintenance personnel. Thank you for your attention to these matters. Yours sincerely, Simoco Australasia Pty Ltd Robert Stowell Senior Engineer Date: 06/08/2013 TraC Global Ltd 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK

The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. SAR_Report_Simoco_60320_6140297_FCC_Plots_SDP650_Body Page 1 of 9 Appendix for the Report Dosimetric Assessment of the SDP650 FM Analogue PMR and Digital DMR (TDMA) Two-Way Radio from Simoco (FCC ID: STZSDP600TU) (IC: 7068A-SDP600TU) According to the FCC Requirements SAR Distribution Plots September 11, 2014 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Simoco Australasia Pty Ltd 1270 Ferntree Gully Road Scoresby, VIC 3179 Australia The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo SAR_Report_Simoco_60320_6140297_FCC_Plots_SDP650_Body Page 2 of 9 1 SAR Distribution Plots, Body Worn Test Laboratory: IMST GmbH, DASY Blue (I); File Name: SDP650_055B_b4h_40HW_1_clip_lms.da4 DUT: Simoco; Type: SDP650; Serial: 56NTU1412055B Program Name: 400.125MHz Communication System: CW; Frequency: 400.125 MHz;Duty Cycle: 1:1 Medium parameters used: f = 400.125 MHz; σ = 0.93 mho/m; ε r = 56.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(7.58, 7.58, 7.58); Calibrated: 28.01.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 23.01.2014 - Phantom: ELI 4; Type: ELI 4; Serial: 1004 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (9x22x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.02 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.6 V/m; Power Drift = -0.129 dB Peak SAR (extrapolated) = 9.15 W/kg SAR(1 g) = 6.46 mW/g; SAR(10 g) = 4.72 mW/g Maximum value of SAR (measured) = 6.81 mW/g Fig. 1: SAR distribution for Simoco SDP650, low channel PMR mode, 400.125 MHz, body worn configuration, belt clip and remote speaker attached (August 20, 2014). SAR_Report_Simoco_60320_6140297_FCC_Plots_SDP650_Body Page 3 of 9 Test Laboratory: IMST GmbH, DASY Blue (I); File Name: SDP650_055B_b4h_40HW_1_clip_lms.da4 DUT: Simoco; Type: SDP650; Serial: 56NTU1412055B Program Name: 400.125MHz Communication System: CW; Frequency: 400.125 MHz;Duty Cycle: 1:1 Medium parameters used: f = 400.125 MHz; σ = 0.93 mho/m; ε r = 56.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(7.58, 7.58, 7.58); Calibrated: 28.01.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 23.01.2014 - Phantom: ELI 4; Type: ELI 4; Serial: 1004 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (9x22x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.02 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.6 V/m; Power Drift = -0.129 dB Peak SAR (extrapolated) = 9.15 W/kg SAR(1 g) = 6.46 mW/g; SAR(10 g) = 4.72 mW/g Maximum value of SAR (measured) = 6.81 mW/g Fig. 2: SAR distribution for Simoco SDP650, low channel PMR mode, 412.950 MHz, body worn configuration, belt clip and remote speaker attached (August 20, 2014). SAR_Report_Simoco_60320_6140297_FCC_Plots_SDP650_Body Page 4 of 9 Test Laboratory: IMST GmbH, DASY Blue (I); File Name: SDP650_055B_b4h_40HW_1_clip_lms.da4 DUT: Simoco; Type: SDP650; Serial: 56NTU1412055B Program Name: 400.125MHz Communication System: CW; Frequency: 400.125 MHz;Duty Cycle: 1:1 Medium parameters used: f = 400.125 MHz; σ = 0.93 mho/m; ε r = 56.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(7.58, 7.58, 7.58); Calibrated: 28.01.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 23.01.2014 - Phantom: ELI 4; Type: ELI 4; Serial: 1004 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (9x22x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.02 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.6 V/m; Power Drift = -0.129 dB Peak SAR (extrapolated) = 9.15 W/kg SAR(1 g) = 6.46 mW/g; SAR(10 g) = 4.72 mW/g Maximum value of SAR (measured) = 6.81 mW/g Fig. 3: SAR distribution for Simoco SDP650, low channel PMR mode, 459.075 MHz, body worn configuration, belt clip and remote speaker attached (August 20, 2014). SAR_Report_Simoco_60320_6140297_FCC_Plots_SDP650_Body Page 5 of 9 Test Laboratory: IMST GmbH, DASY Blue (I); File Name: SDP650_055B_b4h_40HW_1_clip_lms.da4 DUT: Simoco; Type: SDP650; Serial: 56NTU1412055B Program Name: 400.125MHz Communication System: CW; Frequency: 400.125 MHz;Duty Cycle: 1:1 Medium parameters used: f = 400.125 MHz; σ = 0.93 mho/m; ε r = 56.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ET3DV6R - SN1579; ConvF(7.58, 7.58, 7.58); Calibrated: 28.01.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 23.01.2014 - Phantom: ELI 4; Type: ELI 4; Serial: 1004 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (9x22x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 7.02 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.6 V/m; Power Drift = -0.129 dB Peak SAR (extrapolated) = 9.15 W/kg SAR(1 g) = 6.46 mW/g; SAR(10 g) = 4.72 mW/g Maximum value of SAR (measured) = 6.81 mW/g Fig. 4: SAR distribution for Simoco SDP650, low channel PMR mode, 479.925 MHz, body worn configuration, belt clip and remote speaker attached (August 20, 2014…

Text truncated - open the document above for the full version.

The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. SAR_Report_Simoco_60320_6140297_FCC_SDP650_Body Page 1 of 31 SAR Test Report Dosimetric Assessment of the SDP650TU FM Analogue PMR and Digital DMR (TDMA) Two-Way Radio from Simoco (FCC ID: STZSDP600TU) (IC: 7068A-SDP600TU) According to the FCC Requirements September 04, 2014 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Simoco Australasia Pty Ltd 1270 Ferntree Gully Road Scoresby, VIC 3179 AUSTRALIA The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo SAR_Report_Simoco_60320_6140297_FCC_SDP650_Body Page 2 of 31 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Executive Summary The device SDP650TU is a multiple mode FM Analogue PMR and Digital DMR (TDMA) two way portable radio from Simoco operating in the 400 MHz – 480 MHz frequency range. The device has a whip antenna. The objective of the measurements done by IMST was the dosimetric assessment of one test device in the 400 MHz – 480 MHz frequency range in FM Analogue PMR mode in body worn and PTT configuration. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the 47 CFR § 2.1093 [47CFR] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions and IEEE 1528-2003 [IEEE1528-2003]. Additional information and guidelines given by the following FCC documents were used:  SAR Measurement Requirements for 100 MHz to 6 GHz [KDB 865664]  Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies [KDB 447498]  SAR Test Reduction Considerations for Occupational PTT Radios [KDB 643646] All measurements have been performed in accordance to the recommendations given by SPEAG. SAR_Report_Simoco_60320_6140297_FCC_SDP650_Body Page 3 of 31 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Compliance Statement The device SDP650TU from Simoco (FCC ID: STZSDP600TU, IC: 7068A-SDP600TU) is in compliance with the following standards for controlled exposure:  47 CFR § 2.1093 [47CFR]  IEEE Std. C95.1 - 1999 [C95.1-1999],  IEEE Std. C95.3 - 2002 [C95.3-2002],  IEEE 1528-2003 [IEEE 1528-2003],  The latest version of all relevant FCC OET KDB Procedures The maximum results of SAR for the SDP650TU are as follows: WORST CASE SAR RESULTS Test Position Frequency [MHz] CH ModeFig No. Calculated SAR 1g [W/kg] Reported SAR 1g [W/kg] SAR Limit [W/kg] Body Worn 400.125 40HW PMR 13 3.327 (DF 50%)3.327 8.0 PASS PTT 400.125 40HW PMR 13 3.783 (DF 50%)3.783 8.0 PASS prepared by: .............................................. reviewed by: .............................................. Alexander Rahn André van den Bosch test engineer quality assurance engineer SAR_Report_Simoco_60320_6140297_FCC_SDP650_Body Page 4 of 31 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Table of Contents 1 SUBJECT OF INVESTIGATION ..........................................................................................................5 2 FCC EXPOSURE CRITERIA................................................................................................................5 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES ...........6 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS ....................................6 3 THE FCC MEASUREMENT PROCEDURE .........................................................................................7 3.1 GENERAL REQUIREMENTS ..............................................................................................................7 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR ................................................................................7 3.2.1 PHANTOM REQUIREMENTS ..........................................................................................................7 4 BODY-WORN CONFIGURATIONS .....................................................................................................7 4.1 POC (PTT) POSITION .....................................................................................................................8 4.2 PHANTOM REQUIREMENTS ..............................................................................................................8 4.3 TEST TO BE PERFORMED ................................................................................................................8 5 THE MEASUREMENT SYSTEM ..........................................................................................................9 5.1 PHANTOMS ...................................................................................................................................11 5.2 E-FIELD PROBES ..........................................................................................................................12 5.3 MEASUREMENT PROCEDURE .........................................................................................................13 5.4 UNCERTAINTY ASSESSMENT .........................................................................................................14 6 OUTPUT POWER VALUES AND TUNE-UP INFORMATION ..........................................................15 7 SAR TEST RESULTS ........................................................................................................................15 7.1 STANDALONE SAR TEST EXCLUSION ............................................................................................16 8 APPENDIX ..................…

Text truncated - open the document above for the full version.

The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. SAR_Report_TRaC_60320_6130147_FCC_CalData_SDP660_V2 Appendix for the Report Dosimetric Assessment of the SDP660TU FM Analogue PMR and Digital DMR (TDMA) Two-Way Radio from Simoco (FCC ID: STZSDP600TU) (IC: 7068A-SDP600TU) According to the FCC Requirements Calibration Data May 24, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer TRaC Global Ltd Unit 1, Pendle Place, Skelmersdale, West Lancs, WN8 9PN, UK Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo DAT-P-152/98-01 Cal_D450V2_SN1014_0212 Page 1 of 7 _ Calibration_Certificate_Dipole_V1.0/01.08.2009/ABo Calibration Certificate Certificate No: Cal_D450V2_SN1014_0212 0 Object: D450V2 SN: 1014 Date of Calibration: February 13, 2012 Next Calibration: February 2014 Object Condition: In Tolerance Calibration Equipment used: Test Equipment Serial Number Last calibration Calibrated by Next calibration Powermeter E4416A GB41050414 Dec 10 Agilent Techn. (ISO/IEC 17025, 1-1784162174-1) Dec 12 Power Sensor E9301H US40010212 Dec 10 Agilent Techn.…
