SU3RM6800ModRAE LoRa

Install Example to install LoRa module Diagram Step1: 1. Remove the Clip Step2 2. Install the Clip, LoRa module, and long screws onto the original Clip position of the Helix according to the diagram. Step3 3. install LoRa Module ready Active Preparation Centra Hub The lora module uses private protocol, so you need a host (centra Hub) to receive device’s data. Remeter the configuration of centra hub, which will be used same at device side. SSRT You need to get SSRT account from Honeywell and add the centra Hub to your account, so after device connects with centra hub, you can see the real time data at SSRT. Module Install Check Enter reading UI, check whether show “LoRa” icon. Configuration ⚫ Press power and R key at same time for 5 seconds ⚫ Enter password ⚫ Enter setting menu ⚫ Enter Wireless menu ⚫ Enter Lora menu ⚫ Check PANID and channel whether same with centra hub. ⚫ If it is not same with centra Hub, change it to same and save configuration, then back to main menu. Real time data ⚫ Wait a few seconds, check the color of Lora icon whether change ⚫ Check the real time data at SSRT. Warnings: FCC compliance statement: This device complies with Part 15 of the FCC Rules / Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC (ISED) compliance statement: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.

092723-17 rev 10 Certification Application Attestation Statements D ate: June 10, 2026 A merican Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 T o Whom It May Concern: S tatement for 47 CFR section 2.911(d)(5)(i) RAE Systems, Inc certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. I f the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> S tatement for 47 CFR section 2.911(d)(5)(ii) RAE Systems, Inc (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is /  - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. T he applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. T hank you, By : __________________________ Saxinger Bonnie ___________ (Signature 2 ) (Print name) T itle: Sr Advanced Regulatory Engineer C ompany: RAE System, Inc Telephone: +18479554040 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

U.S. Agent Designation for Service of Process (Applicant is Both Grantee and U.S. Agent) TO : American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to co nfirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to i nform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: RAE Systems, Inc FRN #: 0012436135 Grantee Code: SU3 Contact Name: Bonnie Saxinger Street Address: 12220 Rojas Drive City/Province/Zip: EI Paso, Texas, 79936. United states Telephone No: +18479554040 Email: [email protected] Applicant Signature 1 : Date: June 11, 2026 Signed by (Printed Name/Title): Bonnie Saxinger 1 - Letters must be placed on appropriate letterhead.

050222-17 Authority to Act as Agent Date : June 10, 2026 Ame rican Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Int ertek Testing Services (Shanghai FTZ) Co., Ltd. is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: _____06/07/2027 By: __________________________ Saxinger Bonnie (Signature 1 ) (Print name) Title: ____ Sr. Advanced Regulatory Engineer__ On behalf of: RAE Systems Inc. (Company Name) Telephone: +18479554040 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

050222-17 R equest for Confidentiality D ate: June 10, 2026 Subject: Confidentiality Request for: FCC ID: SU3RM6800/ IC: 20969-RM6800 P ursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐Short Term☒PermanentBlock Diagrams ☐Short Term--------------------------- External Photos ☐Short Term☐Permanent * 1 Internal Photos ☐Short Term☒PermanentOperation Description/Theory of Operation ☐Short Term☐PermanentParts List & Placement/BOM ☐Short Term☐PermanentTune-Up Procedure ☐Short Term☒PermanentSchematics ☐Short Term--------------------------- Test Setup Photos ☐Short Term☐Permanent * 1 User’s Manual RAE Systems, Inc has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. P ermanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Sho rt -Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . S incerely, B y: __________________________ ________________________ (Signature/Title 3 ) Sr Advanced Regulatory Engineer (Print name): Saxinger Bonnie 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on approriate letterhead.

FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800

Label content： Size: 32mm X 16mm Label location: Laser printed on one side of the enclosure (below Figure 1 shows).

FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800

RAE Systems, Inc MPE ASSESSMENT REPORT Report Type: FCC MPE assessment report Model: RM6800 REPORT NUMBER: 2604B0422SHA-002 ISSUE DATE: June 11, 2026 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-01_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCMPE-01_V1© 2018 Intertek Page 2 of 10 Report no.: 2604B0422SHA-002 Applicant: RAE Systems, Inc 12220 Rojas Drive, EI Paso, Texas, 79936. United states Manufacturer: RAE Systems, Inc 12220 Rojas Drive, EI Paso, Texas, 79936. United states Factory: Honeywell Sensing and Control (China) Co Ltd. No. 1668 Tianyin Road Nanjing Science Park Jiangning District Nanjing 211100 China Product Name (PMN): ModRAE LoRa Type/Model (HVIN): RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D01 General RF Exposure Guidance v06 FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Project Engineer Alexander Li Reviewer Wakeyou Wang Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 3 of 10 Revision History Report No. Version Description Issued Date 2604B0422SHA-002 Rev. 01 Initial issue of report June 11, 2026 Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 4 of 10 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: ModRAE LoRa Type/Model: RM6800 Brand Name: Honeywell Description of EUT: The product covered by this report is ModRAE LoRa, which is equipped with LoRa module and GNSS module. Rating: DC3.3V Category of EUT: Class A EUT type: Table top Floor standing Software Version: / Hardware Version: / Sample identification number: A269523-24-001 Sample received date: May 23, 2026 Date of test: May 23, 2026 to June 11, 2026 1.2 Technical Specification Frequency Range: 906MHz ~ 924MHz Support Standards: LoRa Type of Modulation: BPSK Channel Number: 10 Channel Separation: 2MHz Antenna Information: PIFA Antenna, 0.89dBi Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 5 of 10 1.3 Description of Test Facility Name: Intertek Testing Services (Shanghai FTZ) Co., Ltd Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L21189 FCC Accredited Lab Designation Number: CN0175 IC Registration Lab CAB identifier.: CN0014 VCCI Registration Lab Registration No.: R-14243, G-10845, C-14723, T-12252 A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 6 of 10 2 MPE Assessment Test result: Pass 2.1 MPE Assessment Limit 100 MHz – 6 GHz and ≤ 50 mm Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 7 of 10 100 MHz – 6 GHz and > 50 mm < 100 MHz and < 200 mm Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 8 of 10 2.2 Assessment Results Seen from the test report 2604B0422SHA-001: The Max. EIPR=18.08dBm=64.27mW. Duty Cycle calculation from appendix I. The time-averaged radiated power = 64.27mW * 10.37% = 6.66mW < 15.83mW (Test Exclusion Thresholds of 926MHz at 5mm) Therefore, the SAR requirement is deemed to be satisfied without test. Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 9 of 10 Appendix I: Duty Cycle calculation The device is Source-based controlled, the duty factor is locked at the hardware/firmware source level and autonomously controlled by the device itself, unaffected by user operation, usage scenarios, duration of use, or any human intervention. Regardless of how the user operates the device, the transmit duty factor cannot be increased or modified; the factory- default duty factor remains unchanged, and no external means can alter this parameter. Report No.: 2604B0422SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 10 of 10 Duty Cycle (the worst case)=10.37/100*100%=10.37%. ******************************************* END ************************************

Antenna DataSheet 1 规格/spec 1.1 产品图片/product images 此天线为LORA 高频天线,型号M06-2042-001，支架尺寸40.8mm+33.8mm 天线主频860MHz-930MHz. This is a high-frequency LoRa antenna,with Model: M06-2042-001, with a bracket size of 40.8mm x 33.8mm and a main frequency of 860MHz-930MHz. (a) LDS 样图片/LDS image (b)装配图片/assembly image 40.8mm 33.8mm Antenna DataSheet 2 天线参数 S11 VSWR /Antenna parameters Antenna DataSheet Efficiency Gain 800MHz 810MHz 820MHz 830MHz 840MHz850 MHz 860MHz 870MHz 880MHz 890MHz -1.23dbi-0.63dbi-0.21dbi0.07dbi 0.26dbi 0.59dbi 0.81dbi 0.89dbi 0.84dbi 0.84dbi 900MHz 910MHz 920MHz 930MHz 940MHz 950MHz 960MHz 970MHz 980MHz 990MHz 0.75dbi 0.52dbi -0.08dbi-0.78dbi-1.36dbi-1.77dbi-1.42dbi-0.87dbi-0.51dbi-0.45dbi 1000MHz 0 5 10 15 20 25 30 35 40 45 Effiency（%) -2 -1.5 -1 -0.5 0 0.5 1 1.5 Gain(dbi) Antenna DataSheet -0.62dbi Gain对应值 3 辐射方向图/Radiation pattern LORA 高频天线位于侧面 antenna is located on the side 方位角 Theta 对应角度 The angle for azimuth Theta /Gain value VS Frequency Antenna DataSheet 俯仰角 Phi-0 面对应角度 The angle corresponding to the elevation Phi = 0 plane 俯仰角 Phi-90 面对应角度 The angle corresponding to the elevation Phi = 90 plane 860MHz XOY面 XOZ面 YOZ面 890MHz XOY面XOZ面YOZ面 Antenna DataSheet 930MHz XOY面XOZ面YOZ面

FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict LORA Ant1 906.0 0.740 905.260 906.740 0.5 PASS 916.0 0.730 915.270 916.730 0.5 PASS 924.0 0.746 923.254 924.746 0.5 PASS FCC ID: SU3RM6800 IC: 20969-RM6800 Test Graphs Low Channel (906.0MHz) Middel Channel (916.0MHz) High Channel (926.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict LORA Ant1 906.0 0.6149 905.3851 906.6149 --- --- 916.0 0.5874 915.4126 916.5874 --- --- 924.0 0.6110 923.3890 924.6110 --- --- FCC ID: SU3RM6800 IC: 20969-RM6800 Test Graphs Low Channel (906.0MHz) Middel Channel (916.0MHz) High Channel (926.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix C: Maximum conducted output power Test Result Peak TestMode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] EIRP[dBm] EIRP Limit[dBm] Verdict LORA Ant1 906.0 16.56 ≤30 17.45 ≤36 PASS 916.0 16.89 ≤30 17.78 ≤36 PASS 924.0 17.19 ≤30 18.08 ≤36 PASS Test Graphs Peak Low Channel (906.0MHz) Middel Channel (916.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 High Channel (926.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict LORA Ant1 906.0 3.04 ≤8.00 PASS 916.0 3.63 ≤8.00 PASS 924.0 1.43 ≤8.00 PASS FCC ID: SU3RM6800 IC: 20969-RM6800 Test Graphs Low Channel (906.0MHz) Middel Channel (916.0MHz) High Channel (926.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix E: Band edge measurements Test Result TestMod e Antenn a ChNam e Frequency[MHz ] RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t LORA Ant1 Low 906.0 16.46 -53.07 ≤-3.54 PASS High 926.0 16.57 -51.69 ≤-3.43 PASS FCC ID: SU3RM6800 IC: 20969-RM6800 Test Graphs Low Channel (906.0MHz) High Channel (926.0MHz) FCC ID: SU3RM6800 IC: 20969-RM6800 Appendix F: Conducted Spurious Emission Test Result TestMod e Antenn a Frequency[MHz ] FreqRange [MHz] RefLeve l [dBm] Result[dBm ] Limit[dBm ] Verdic t LORA Ant1 906 Reference 16.51 16.51 --- PASS 30~1000 16.51 -58.04 ≤-3.49 PASS 1000~2650 0 16.51 -37.27 ≤-3.49 PASS 916 Reference 16.84 16.84 --- PASS 30~1000 16.84 -58.37 ≤-3.16 PASS 1000~2650 0 16.84 -38.43 ≤-3.16 PASS 924 Reference 17.10 17.10 --- PASS 30~1000 17.10 -61.46 ≤-2.90 PASS 1000~2650 0 17.10 -38.76 ≤-2.90 PASS FCC ID: SU3RM6800 IC: 20969-RM6800 Test Graphs Low Channel (906.0MHz)_0~Reference Low Channel (906.0MHz)_30~1000 Low Channel (906.0MHz)_1000~26500 FCC ID: SU3RM6800 IC: 20969-RM6800 Middel Channel (916.0MHz)_0~Reference Middel Channel (916.0MHz)_30~1000 Middel Channel (916.0MHz)_1000~26500 FCC ID: SU3RM6800 IC: 20969-RM6800 High Channel (926.0MHz)_0~Reference High Channel (926.0MHz)_30~1000 High Channel (926.0MHz)_1000~26500

RAE Systems, Inc RF TEST REPORT Report Type: FCC Part 15.247 & ISED RSS-247 RF report Model: RM6800 REPORT NUMBER: 2604B0422SHA-001 ISSUE DATE: June 11, 2026 DOCUMENT CONTROL NUMBER: TTRF15.247-02_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-02_V1 © 2018 Intertek Page 2 of 31 Report no.: 2604B0422SHA-001 Applicant: RAE Systems, Inc 12220 Rojas Drive, EI Paso, Texas, 79936. United states Manufacturer: RAE Systems, Inc 12220 Rojas Drive, EI Paso, Texas, 79936. United states Manufacturing site: Honeywell Sensing and Control (China) Co Ltd. No. 1668 Tianyin Road Nanjing Science Park Jiangning District Nanjing 211100 China Product Name (PMN): ModRAE LoRa Type/Model (HVIN): RM6800 FCC ID: SU3RM6800 IC: 20969-RM6800 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2024): Radio Frequency Devices (Subpart C) ANSI C63.10 (2020) +Cor.1(2023) +C63.10a (2024) +Errata to C63.10a(2024): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices RSS-247 Issue 4 (July 2025): Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence- Exempt Local Area Network (LE-LAN) Devices RSS-Gen Issue 5 (February 2021) Amendment 2: General Requirements for Compliance of Radio Apparatus PREPARED BY: REVIEWED BY: Project Engineer Alexander Li Reviewer Wakeyou Wang Report No.: 2604B0422SHA-001 TEST REPORT TTRF15.247-02_V1 © 2018 Intertek Page 3 of 31 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................................ 7 1.2 TECHNICAL SPECIFICATION ................................................................................................................................ 7 1.3 DESCRIPTION OF TEST FACILITY .......................................................................................................................... 8 2 TEST SPECIFICATIONS ................................................................................................................................... 9 2.1 STANDARDS OR SPECIFICATION .......................................................................................................................... 9 2.2 MODE OF OPERATION DURING THE TEST .............................................................................................................. 9 2.3 TEST SOFTWARE LIST ..................................................................................................................................... 10 2.4 TEST PERIPHERALS LIST................................................................................................................................... 10 2.5 TEST ENVIRONMENT CONDITION: ..................................................................................................................... 10 2.6 INSTRUMENT LIST ......................................................................................................................................... 11 2.7 MEASUREMENT UNCERTAINTY ......................................................................................................................... 12 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 13 3.1 LIMIT ......................................................................................................................................................... 13 3.2 MEASUREMENT PROCEDURE .......................................................................................................................... 13 3.3 TEST CONFIGURATION ................................................................................................................................... 13 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ................................................................................................... 13 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 14 4.1 LIMIT ......................................................................................................................................................... 14 4.2 MEASUREMENT PROCEDURE .......................................................................................................................... 14 4.3 TEST CONFIGURATION ...............…

Text truncated - open the document above for the full version.

FCC ID: SU3RM6800 IC: 20969-RM6800 Conducted Emission test Radiated emission test below 1GHz FCC ID: SU3RM6800 IC: 20969-RM6800 Radiated emission test above 1GHz RF conducted test
