SWX-GBEPLUSGigaBeam Plus

Datasheet GBE-Plus 2 of 3 Mechanical Hardware LEDs Software Dimensions Ø155 x 137 mm (Ø6.1 x 5.4") Weight Without Mount: 1kg (2.2 lb) With Mount: _ kg (_ lb) Enclosure Materials UV Resistance Polycarbonate, Stainless Steel Mount Materials Metal Wind Loading 50 N at 200 km/h (11.24 lbf at 125 mph) Processor Quad-Core ARM ® Cortex ® A7 Memory 256 MB DDR3 Networking Interface 10/100/1000 Mbps Ethernet RJ45 Management Interface Ethernet In-Band Bluetooth RF Connections Internal Max. Power Consumption 11W Power Method Passive PoE (Pairs 4, 5+; 7, 8-) Power Supply 24VDC, 0.5A Gigabit PoE Adapter 24V, 1A for using Motor Accessory Supported Voltage Range 22 to 26VDC ESD/EMP Protection Air/Contact: ± 24kV Operating Temperature -40 to 60° C (-40 to 140° F) Operating Humidity 5 - 95% Noncondensing Certications FCC, IC, CE Power Flashing White: Bootup in Progress White: Not Connected to Ubiquiti ® Internet Service Provider (UISP™) Blue: Connected to UISP Ethernet Flashing Blue: Ethernet Trafc Detected 60GHz Blue: Active Connection OS airOS ® Operating Modes PtP a s Access Point and Station Ubiquiti Specic Features Integrated 60 GHz Radio, Discovery Protocol Security WPA2 AES Only GigaBeam Plus GBE-Plus is a 60Ghz Radio capable of supporting 1Gbps rates with low latency. GBE-Plus supports PtP operating modes and is managed through the UISP dashboard. Specifications are subject to change. Ubiquiti products are sold with a limited warranty described at: www.ui.com/support/warranty ©2020 Ubiquiti Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, AirMax, GigBeam, airOS, and UISP are trademarks or registered trademarks of Ubiquiti Inc. in the United States and in other countries. All other trademarks are the property of their respective owners. RF Dashboard Yes Wireless Settings Yes Network Settings Yes System Yes Services UISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery Tools Antenna Alignment Tool, Discovery Utility, Traceroute, Speed Test Software Management Bluetooth Management for Easy Setup Over UISP™ App WEB UI Minimum Software Requirements Any Modern Web Browser/iPhone/Android Operating Frequency* 57,000 - 66,000 MHz * Depends on regulatory region. Max. Conducted TX Power 17 dBi Channel Bandwidth 2160 MHz Management Radio 2400 - 2483.5 MHz Operating Channels 58320, 60480, 62640, 64800 MHz Antenna Gain 35 dBi Beamwidth HPOL: NaN (The Antenna is Only Vertically Polarized) VPOL: 3° Elevation: 3° Electrical Downtilt 0° Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter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…

Text truncated - open the document above for the full version.

685 Third Avenue, New York, New York 10017 USA Date: 2020-08-25 FCC ID: SWX-GBEPLUS To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request 㻌 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description 㻌 The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. 㻌 The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. 㻌 Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected] Declaration letter for label requirement The label is permanent affixed in the battery compartment, and the EUT will be selling to market without the battery installed. The users can see the label during the battery installation process. The battery cover can be opened without any special tools. Sincerely yours,

685 Third Avenue, New York, New York 10017 USA Date: 2020-08 -25 FCC ID: SWX-GBEPLUS To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

685 Third Avenue, New York, New York 10017 USA Date: 2020-08-25 FCC ID: SWX-GBEPLUS To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization) in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

685 Third Avenue, New York, New York 10017 USA Date: 2020-08-25 FCC ID: SWX-GBEPLUS AUTHORIZATION LETTER To Whom It May Concern: Ubiquiti Inc. hereby authorizes Amanda Wu, Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu, Senior Specialist of BV CPS Taoyuan on Ubiquiti Inc.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

Reference No.:200707E04-1 CONSTRUCTION PHOTOS OF EUT Reference No.:200707E04-1 Reference No.:200707E04-1 Reference No.:200707E04-1 Reference No.:200707E04-1

Reference No.:200707E04-2 CONSTRUCTION PHOTOS OF EUT Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2 Reference No.:200707E04-2

Report No.: SA200707E04 Page No. 1 / 6 Report Format Version: 6.1.1 Reference No.: RF Exposure Report Report No.: SA200707E04 FCC ID: SWX-GBEPLUS Test Model: GBE-Plus Received Date: July 07, 2020 Test Date: Aug. 20, 2020 Issued Date: Aug. 27, 2020 Applicant: Ubiquiti Inc. Address: 685 Third Avenue, New York, NY 10017, United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA200707E04 Page No. 2 / 6 Report Format Version: 6.1.1 Reference No.: Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Calculation Result ............................................................................................................................... 6 Report No.: SA200707E04 Page No. 3 / 6 Report Format Version: 6.1.1 Reference No.: Release Control Record Issue No. Description Date Issued SA200707E04 Original release. Aug. 27, 2020 Report No.: SA200707E04 Page No. 4 / 6 Report Format Version: 6.1.1 Reference No.: 1 Certificate of Conformity Product: GigaBeam Plus Brand: UBIQUITI Test Model: GBE-Plus Sample Status: ENGINEERING SAMPLE Applicant: Ubiquiti Inc. Test Date: Aug. 20, 2020 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: Aug. 27, 2020 Joyce Kuo / Specialist Approved by : , Date: Aug. 27, 2020 Clark Lin / Technical Manager Report No.: SA200707E04 Page No. 5 / 6 Report Format Version: 6.1.1 Reference No.: 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 85 cm away from the body of the user. So, this device is classified as Mobile Device. (客戶要求，客戶說他的產品固定在電線桿上) Report No.: SA200707E04 Page No. 6 / 6 Report Format Version: 6.1.1 Reference No.: 2.4 Calculation Result For WLAN and Bluetooth data was copied from the original test report (Report No.: FR073101AC R02 and FR073101AE) The Maximum power was refer to the FCC test reports. (Report No.: ) Operation Mode Evaluation Frequency (MHz) Max. Avg. Power (dBm) Max .Avg. Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WLAN 2.4GHz 2437 20.21 104.954 2 85 0.00183 1 Bluetooth 2480 9.27 8.453 2 85 0.00015 1 Operation Mode Evaluation Frequency (MHz) Max.Avg. EIRP (dBm) Max. EIRP (mW) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 802.11ad 64800 49.11 81470.4284 85 0.89733 1 Conclusion: The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power densit…

Text truncated - open the document above for the full version.

Report No.: RF200707E04 Page No. 1 / 74 Report Format Version: 6.1.1 FCC Test Report Report No.: RF200707E04 FCC ID: SWX-GBEPLUS Test Model: GBE-Plus Received Date: July 07, 2020 Test Date: Aug. 10 to 17, 2020 Issued Date: Aug. 27, 2020 Applicant: Ubiquiti Inc. Address: 685 Third Avenue, New York, NY 10017, United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: RF200707E04 Page No. 2 / 74 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Description of Support Units .............................................................................................................. 11 3.3.1 Configuration of System under Test .................................................................................................. 12 3.4 General Description of Applied Standards ........................................................................................ 13 4 Test Types and Results ...................................................................................................................... 14 4.1 Radiated Emission Measurement ..................................................................................................... 14 4.1.1 Limits of Radiated Emission Measurement ....................................................................................... 14 4.1.2 Test Instruments ................................................................................................................................ 15 4.1.3 Test Procedures ................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 19 4.1.5 Test Setup .......................................................................................................................................... 20 4.1.6 EUT Operating Conditions ................................................................................................................. 21 4.1.7 Test Results ....................................................................................................................................... 22 4.2 Conducted Emission Measurement .................................................................................................. 54 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 54 4.2.2 Test Instruments ................................................................................................................................ 54 4.2.3 Test Procedures ................................................................................................................................. 55 4.2.4 Deviation from Test Standard ............................................................................................................ 55 4.2.5 Test Setup .......................................................................................................................................... 5…

Text truncated - open the document above for the full version.

Reference No.: 200707E04 Page No. 1 / 5 Report No.: PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Reference No.: 200707E04 Page No. 2 / 5 Report No.: RADIATED EMISSION TEST (Below 1GHz) Reference No.: 200707E04 Page No. 3 / 5 Report No.: RADIATED EMISSION TEST (1 ~ 40 GHz) Reference No.: 200707E04 Page No. 4 / 5 Report No.: Reference No.: 200707E04 Page No. 5 / 5 Report No.: RADIATED EMISSION TEST (Above 40GHz)
