SWX-NBE5M19Access Point

High-Performance 19 dBi airMAX ® CPE Model: NBE-M5-19 Introduction Thank you for purchasing the Ubiquiti Networks® NanoBeam®. This Quick Start Guide is designed to guide you through installation and also includes warranty terms. Package Contents NanoBeamM5Ball Joint Mount Lock Ring High-Performance 19 dBi airMAX ® CPE Model: NBE-M5-19 Metal StrapPoE Adapter (24V, 0.5A) Power Cord Quick Start Guide TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Installation Requirements The NanoBeam can be mounted on a pole or to a wall. A Metal Strap (included) is used for pole-mounting. For wall-mounting, a suitable fastener such as a screw or bolt (not included) is required. • 7 mm socket wrench or screwdriver (for pole-mounting) • Wall fastener (for wall-mounting) • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable, TOUGHCable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Hardware Overview LEDs Reset ButtonEthernet Port (10/100 Mbps) Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the NanoBeam is already powered on. Alternatively, the NanoBeam may be reset remotely via a Reset button located on the bottom of the PoE Adapter. Ethernet Port The Ethernet port is a PoE port used for data and power. It should be connected to the LAN and DHCP server. Power can be provided by any of the following: • PoE Adapter (included) • Ubiquiti Networks EdgeSwitch ™ • Ubiquiti Networks EdgeRouter ™ PoE LEDs Power The Power LED will light blue when the device is connected to a power source. Ethernet The Ethernet LED will light steady blue when an active Ethernet connection is made and flash when there is activity. Signal In airOS, you can modify the wireless signal strength threshold values for each LED on the Advanced tab under Signal LED Thresholds. The default values are shown below: LED will light blue when the wireless signal strength is above -94 dBm. LED will light blue when the wireless signal strength is above -80 dBm. LED will light blue when the wireless signal strength is above -73 dBm. LED will light blue when the wireless signal strength is above -65 dBm. Hardware Installation The NanoBeam can be mounted on a pole or to a wall. Perform the steps for the appropriate installation: Pole-Mount 1. Insert the Ball Joint Mount into the Lock Ring with the threads of the Lock Ring facing the ball joint. 2. Open the Metal Strap and feed it through the base of the Ball Joint Mount. *640-00098-03* 640-00098-03 3. Wrap the Metal Strap around the pole. Use a 7 mm socket wrench or screw driver to turn the screw clockwise and securely fasten the strap to the pole. 4. Attach the NanoBeam to the Ball Joint Mount and turn the Lock Ring to secure it. Keep the Lock Ring loose enough to allow the NanoBeam to pivot for aiming. Wall-Mount The NanoBeam must be mounted directly to a wood stud or other structurally stable surface to avoid damage to the mounting hole when you adjust the aim. Optional Accessory To enhance stability, you can use the NanoBeam Wall Mount Kit, model NBE-WMK (sold separately). Note: Center screw included. Two optional screws (not included) provide additional stability. Installation Instructions 1. Mark the desired location of the mounting point. 2. If needed, drill a pilot hole for the fastener. 3. Insert the Ball Joint Mount into the Lock Ring with the threads of the Lock Ring facing the ball joint. 4. If you are using the optional NanoBeam Wall Mount Kit, skip to step b. a. To attach the Ball Joint Mount to the wall, insert a fastener (not included) through the center of the ball joint, and into the wall. Securely tighten the fastener. Proceed to step 5. b. To attach the Ball Joint Mount to the wall, insert the Wall Mount Kit screw through the center of the ball joint, through the Wall Mount Kit plate, and into the wall. Securely tighten the screw. 5. Attach the NanoBeam to the Ball Joint Mount and turn the Lock Ring to secure it. Keep the Lock Ring loose enough to allow the NanoBeam to pivot for aiming. Aiming 1. Ensure the opening of the Ethernet cable is pointed towards the ground. 2. Aim the front of the NanoBeam towards the other end of the wireless link. 3. Hand-tighten the Lock Ring to lock the aim. Note: Do not use a tool to tighten the Lock Ring. Tighten the Lock Ring by hand only. Connecting to the PoE Adapter 1. Remove the port cover by pressing down the center of the cover and sliding the cover out. 2. Connect an Ethernet cable to the Ethernet port. 3. Replace the port cover. 4. Connect the other end of the Ethernet cable from the NanoBeam to the Ethernet port labeled POE on the PoE Adapter. 5. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the PoE Adapter. 6. Connect the Power Cord to the power port on the PoE Adapter. Connect the other end of the Power Cord to a power outlet. Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host machine is connected via Ethernet to the NanoBeam. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to th…

Text truncated - open the document above for the full version.

f¡ I UBIOUITI" NETWORKS December 22,2014 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ852A4 RE: LETTER OF AGENT AUTHORIZATION To Whom lt May Concern: We, the undersigned, hereby authorize Compliance Testing LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, MichaelTaylor Compliance Manager 2580 Orchard Parkway San Jose, CA 9513'l USA 408-942-3085 x442 [email protected]

July 5, 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: CONFIDENTIALITY REQUEST FOR NanoBeam 5M – 19, NBE-M5-19, FCC ID: SWX- NBE5M19 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the following documents required to be submitted with this application be permanently withheld from public review.  Block Diagram  Schematics  Theory of Operation  Parts List/BOM  U-NII Security Exhibit These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Michael Taylor Compliance Manager 2580 Orchard Parkway San Jose, CA 95131, USA 408-942-3085 [email protected]

July 5, 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: Short Term Confidentiality Request For NanoBeam 5M - 19, NBE-5M-19, ( FCC ID: SWX- NBE5M19) To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, Ubiquiti Networks, Inc. requests short- term Confidentiality of following sections of this application for a period of 45 days after grant is issued. 1. Test setup photos 2. External photos 3. Internal photos 4. User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Grantee will not market or distribute product during the period requested. Once product is available for marketing, Grantee will notify FCC or TCB. Please contact me if there is any information you may need. Sincerely, Michael Taylor Compliance Manager 2580 Orchard Parkway San Jose, CA 95131, USA 408-942-3085 [email protected]

Form: CB-7.2.1 Issued by: QM Issue Date: 9/22/2011 Page 1 of 1 Revised by: QM-JS Revised Date: 6/23/2014 L:\Project\2014\p14a0029-Ubiquiti\TCB Folder\RT's\CB-7.2.1 - Technical Review RT Form.docx CB-7.2.1 – Technical Review RT Form FCC ID: SWX-NBE5M19 IC ID: CT Project: P14a0029 From: Shawn McMillen Date: 07-07-2015 1--The UNI security exhibit and the bill of materials are missing from this application. DW: Security exhibit included. BOM in folder. 2--The operating frequency in the user’s manual is not correct this this device at present will only be approved for UNI-1 and UNI-3 bands. Client: UNII-1/UNII-3 manual provided. 3--The separation distance in the user’s manual is not consistent with the calculated separation distance necessary. Client: UNII-1/UNII-3 manual provided. CT - Response by: Submitted by: Date:

COVER VIEW NanoBeam M5-19 Silkscreen Artwork 4.867 mm 13.3 mm 29.47 mm 3.4 mm 3.4 mm 88 mm 101 mm 15 mm File Name: Date: Revision: Designer: NBE-M5-19 Artwork v03 11/21/14 v03 - Changed FCC and IC IDs Vivian Liu ME: PM: Arena Number: Addison Su Letitia Chiu 388-00010 Colors: PANTONE Cool Gray 9 C PMS Cool Gray 9C PMS Cool Gray 9C PMS Cool Gray 9C PMS Cool Gray 9C This device complies with Part 15 of FCC rules. Operation is subject to the following 2 conditions: 1) this device may not cause harmful interference and, 2) this device must accept any interference received, including interference that may cause undesired operation. M/N: NBE-M5-19 24V 0.5A POE FCC ID: SWX- NBE5M19 IC: 6545A-NBE5M19 This device complies with Part 15 of FCC rules. Operation is subject to the following 2 conditions: 1) this device may not cause harmful interference and, 2) this device must accept any interference received, including interference that may cause undesired operation. M/N: NBE-M5-19 24V 0.5A POE FCC ID: SWX- NBE5M19 IC: 6545A-NBE5M19

p14a0029_FCC_Part 1.1310_Rev 1.0 Page 1 of 5 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-19 Description: NanoBeam M5-19 FCC ID: SWX-NBE5M19 Serial Number: N/A To FCC Part 1.1310 Date of Issue: June 30, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0029 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p14a0029_FCC_Part 1.1310_Rev 1.0 Page 2 of 5 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 16, 2015 Alex Macon Original Document p14a0029_FCC_Part 1.1310_Rev 1.0 Page 3 of 5 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: NBE-M5-19 Description: NanoBeam M5-19 Firmware: N/A Software: N/A S/N: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0029_FCC_Part 1.1310_Rev 1.0 Page 4 of 5 MPE Limit Calculations Exposure Limit 1mW/cm 2 Source Based Time Averaged Power Calculation Average Power Calculations Average Power = Peak Power * duty-cycle% Tuned Frequency (MHz) Conducted Peak Output Power (mW) Duty Cycle (%) Average Power (mW) 5200 389 100 389 p14a0029_FCC_Part 1.1310_Rev 1.0 Page 5 of 5 MPE Evaluation This is a fixed/mobile device used in uncontrolled /general population exposure environment. Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz Limit [mW/cm²] = 100 1.34-30 MHz Limit [mW/cm²] = (180/f²) 30-300 MHz Limit [mW/cm²] = 0.2 300-1500 MHz Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data Test Frequency, MHz 5200 Power, Conducted, mW (P) 389 Antenna Gain Isotropic 19 Antenna Gain Numeric (G) 79.43 Antenna Type Dish Distance (R) 20 푆= 푃∗퐺 4휋푟 2 Power Density (S) mw/cm 2 Power mW (P) Numeric Gain (G) Distance (r 2 ) cm 6.1471968009 389 79.43 20 Power Density (S) = 6.15 Limit =(from above table) = 1.0 The Power Density of 6.15 mw/cm 2 is over the limit of 1.0 mw/cm 2 for the uncontrolled /general population exposure environment so Minimum Safe Distance was calculated. R=√(PG/4πL) Distance (R) cm Power mW (P) Numeric Gain (G) Limit (L) 49.6 389 79.43 1.0 The minimum safe distance is 49.6 cm. END OF TEST REPORT

p14a0029_FCC_Part 1.1310_Rev 1.0 Page 1 of 5 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-19 Description: NanoBeam M5-19 Serial Number: N/A FCC ID: SWX-NBE5M19 To FCC Part 1.1310 Date of Issue: June 30, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0029 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p14a0029_FCC_Part 1.1310_Rev 1.0 Page 2 of 5 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 15, 2015 Alex Macon Original Document p14a0029_FCC_Part 1.1310_Rev 1.0 Page 3 of 5 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: NBE-M5-19 Description: NanoBeam M5-19 Firmware: N/A Software: N/A S/N: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0029_FCC_Part 1.1310_Rev 1.0 Page 4 of 5 MPE Limit Calculations Exposure Limit 1mW/cm 2 Source Based Time Averaged Power Calculation Average Power Calculations Average Power = Peak Power * duty-cycle% Tuned Frequency (MHz) Conducted Peak Output Power (mW) Duty Cycle (%) Average Power (mW) 5800 302 100 302 p14a0029_FCC_Part 1.1310_Rev 1.0 Page 5 of 5 MPE Evaluation This is a fixed/mobile device used in uncontrolled /general population exposure environment. Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz Limit [mW/cm²] = 100 1.34-30 MHz Limit [mW/cm²] = (180/f²) 30-300 MHz Limit [mW/cm²] = 0.2 300-1500 MHz Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data Test Frequency, MHz 5800 Power, Conducted, mW (P) 302 Antenna Gain Isotropic 19 Antenna Gain Numeric (G) 79.43 Antenna Type Point to Point Distance (R) 20 푆= 푃∗퐺 4휋푟 2 Power Density (S) mw/cm 2 Power mW (P) Numeric Gain (G) Distance (r 2 ) cm 4.7723 302 79.43 20 Power Density (S) = 4.772 Limit =(from above table) = 1.0 The Power Density of 4.772 mw/cm 2 is over the limit of 1.0 mw/cm 2 for the uncontrolled /general population exposure environment so Minimum Safe Distance was calculated. R=√(PG/4πL) Distance (R) cm Power mW (P) Numeric Gain (G) Limit (L) 43.7 302 79.43 1.0 The minimum safe distance is 43.7 cm. END OF TEST REPORT

p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 1 of 22 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-19 Description: NanoBeam M5-19 Serial Number: N/A FCC ID: SWX-NBE5M19 To FCC Part 15.407 Date of Issue: June 30, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0029 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 2 of 22 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 15, 2015 Alex Macon Original Document p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 3 of 22 Table of Contents Description Page Standard Test Conditions Engineering Practices 6 Test Results Summary 8 Peak Output Power 9 Transmitter Power Spectral Density 11 Undesirable Emissions Conducted 13 Undesirable Emissions Radiated 15 Occupied Bandwidth 17 Frequency Stability 18 RF Exposure 19 A/C Powerline Conducted Emission 21 Test Equipment Utilized 22 p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 4 of 22 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to the joint ISO-ILAC-IAF Communiqué dated January 2009). The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 5 of 22 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment marked to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 6 of 22 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.10-2013 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specified testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature (ºC) Humidity (%) Pressure (mbar) 24.2 – 25.3 33.7 – 44.9 965.5 – 967.7 EUT Operation during Tests The EUT was configured to run in a continuous data stream using ART software through a POE adaptor and Ethernet connection. EUT Description Model: NBE-M5-19 Description: NanoBeam M5-19 Firmware: N/A Software: N/A Serial Number: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 7 of 22 EUT Specifications Equipment Code NII Model(s)Tested NBE-M5-19 Model(s) covered NBE-M5-19 Maximum Output Power 25.9 dBm Frequency Range 5150- 5250 Bandwidths 10/20/30/40 MHz Data Rates 6, 9, 12, 18, 24, 36, 48, 54, MCS0, MCS1, MCS2, MCS3, MCS4, MCS5, MCS6, MCS7, MCS8, MCS9 Modulations BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM Antenna List No. Manufacturer Part # Antenna Type Peak Gain 1 Ubiquiti NBE-M5-19 Dish 19 dBi 15.203: Antenna Requirement: The antenna is permanently attached to the EUT The antenna uses a unique coupling X The EUT must be professionally installed The antenna requirement does not apply Accessories: None Cables: None Modifications: None p14a0029_FCC_15.407_U-NII-1_Rev 1.0 Page 8 of 22 Test Results Summary Specification Test Name Pass, Fail, N/A Comments §15.203 Antenna Requirements Pass §15.207 §15.407(b)(6) Line Conducted Emissions Pass §15.407(a)(1) Conducted Output Power Pass §15.407(a)(1),(5) Power Spectral Density Pass §15.403(i) 15.407(a)(5) 26dB Occupied Bandwidth Pass 99% Occupi…

Text truncated - open the document above for the full version.

p14a0029_Annex A_UNII-1_Rev 1.0 Page 1 of 25 Annex A Undesirable Conducted Emissions p14a0029_Annex A_UNII-1_Rev 1.0 Page 2 of 25 10MHz high ch 1 - 40 GHz_J1 10MHz high ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 3 of 25 10MHz high ch 30MHz-1000MHz_J1 10MHz high ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 4 of 25 10MHz low ch 1 - 40 GHz_J1 10MHz low ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 5 of 25 10MHz low ch 30MHz-1000MHz_J1 10MHz low ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 6 of 25 10MHz mid ch 1 - 40 GHz_J1 10MHz mid ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 7 of 25 10MHz mid ch 30MHz-1000MHz_J1 10MHz mid ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 8 of 25 20MHz high ch 1 - 40 GHz_J1 20MHz high ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 9 of 25 20MHz high ch 30MHz-1000MHz_J1 20MHz high ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 10 of 25 20MHz low ch 1 - 40 GHz_J1 20MHz low ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 11 of 25 20MHz low ch 30MHz-1000MHz_J1 20MHz low ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 12 of 25 20MHz mid ch 1 - 40 GHz_J1 20MHz mid ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 13 of 25 20MHz mid ch 30MHz-1000MHz_J1 20MHz mid ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 14 of 25 30MHz high ch 1 - 40 GHz_J1 30MHz high ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 15 of 25 30MHz high ch 30MHz-1000MHz_J1 30MHz high ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 16 of 25 30MHz low ch 1 - 40 GHz_J1 30MHz low ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 17 of 25 30MHz low ch 30MHz-1000MHz_J1 30MHz low ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 18 of 25 30MHz mid ch 1 - 40 GHz_J1 30MHz mid ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 19 of 25 30MHz mid ch 30MHz-1000MHz_J1 30MHz mid ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 20 of 25 40MHz high ch 1 - 40 GHz_J1 40MHz high ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 21 of 25 40MHz high ch 30MHz-1000MHz_J1 40MHz high ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 22 of 25 40MHz low ch 1 - 40 GHz_J1 40MHz low ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 23 of 25 40MHz low ch 30MHz-1000MHz_J1 40MHz low ch 30MHz-1000MHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 24 of 25 40MHz mid ch 1 - 40 GHz_J1 40MHz mid ch 1 - 40 GHz_J3 p14a0029_Annex A_UNII-1_Rev 1.0 Page 25 of 25 40MHz mid ch 30MHz-1000MHz_J1 40MHz mid ch 30MHz-1000MHz_J3

p14a0029_Annex B_UNII-1_Rev 1.0 Page 1 of 16 Annex C Undesireable Emissions Radiated Annex C Notes: 1. The emissions that are over the limit in the 30 – 1000 MHz plots are from digital circuitry and not the transmitter, therefor these emissions only need to meet the -27 dBM/MHz general emission requirements. 2. Throughout Annex C, for all plots above 1 GHz, other than the fundamental transmitter frequency, for any peak emission over the restricted band average limit was examined with an average detector and additional plots were supplied. p14a0029_Annex B_UNII-1_Rev 1.0 Page 2 of 16 10 MHz mid ch 18 - 40 GHz 10MHz mid 1-18GHz p14a0029_Annex B_UNII-1_Rev 1.0 Page 3 of 16 10MHz mid 2nd harmonic 10MHz mid 3rd harmonic p14a0029_Annex B_UNII-1_Rev 1.0 Page 4 of 16 10MHz mid 5.35GHz-5.46GHz 10MHz mid ch 30-1GHz peak below average p14a0029_Annex B_UNII-1_Rev 1.0 Page 5 of 16 20 MHz mid ch 18 - 40 GHz 20MHz mid 1-18GHz p14a0029_Annex B_UNII-1_Rev 1.0 Page 6 of 16 20MHz mid 2nd harmonic 20MHz mid 3rd harmonic p14a0029_Annex B_UNII-1_Rev 1.0 Page 7 of 16 20MHz mid 5.35GHz-5.46GHz 20MHz mid ch 30-1GHz peak below average p14a0029_Annex B_UNII-1_Rev 1.0 Page 8 of 16 30 MHz mid ch 18 - 40 GHz 30MHz mid 1-18GHz p14a0029_Annex B_UNII-1_Rev 1.0 Page 9 of 16 30MHz mid 2nd harmonic 30MHz mid 3rd harmonic p14a0029_Annex B_UNII-1_Rev 1.0 Page 10 of 16 30MHz mid 5.35GHz-5.46GHz 30MHz mid ch 30-1GHz peak below average p14a0029_Annex B_UNII-1_Rev 1.0 Page 11 of 16 40 MHz mid ch 18 - 40 GHz 40MHz mid 1-18GHz p14a0029_Annex B_UNII-1_Rev 1.0 Page 12 of 16 40MHz mid 2nd harmonic 40MHz mid 3rd harmonic p14a0029_Annex B_UNII-1_Rev 1.0 Page 13 of 16 40MHz mid 5.35GHz-5.46GHz 40MHz mid ch 30-1GHz peak below average p14a0029_Annex B_UNII-1_Rev 1.0 Page 14 of 16 Band Edge Data 10 MHz low side 20MHz Low Side p14a0029_Annex B_UNII-1_Rev 1.0 Page 15 of 16 30 MHz Low Side 40 MHz Low Side p14a0029_Annex B_UNII-1_Rev 1.0 Page 16 of 16 Band Edge integrated over 1 MHZ Bandwidth Frequency Data Rate TP Measured Level Limit Margin MHz MHz dBm dBm/MHz dB 10 5160 6 20 -30.5 -27 -3.5 20 5165 6 16 -33.7 -27 -6.7 20 5170 6 20 -41.1 -27 -14.1 30 5170 6 12 -34.3 -27 -7.3 30 5175 6 17 -36.9 -27 -9.9 30 5180 6 20 -41.3 -27 -14.3 40 5175 f0 11 -37.1 -27 -10.1 40 5180 f0 13 -41.1 -27 -14.1 40 5195 f0 18 -37.7 -27 -10.7

p14a0029_Annex C_UNII-1_Rev 1.0 Page 1 of 13 Annex C Occupied Bandwidth p14a0029_Annex C_UNII-1_Rev 1.0 Page 2 of 13 10MHz high ch J1 10MHz high ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 3 of 13 10MHz low ch J1 10MHz low ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 4 of 13 10MHz mid ch J1 10MHz mid ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 5 of 13 20MHz high ch J1 20MHz high ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 6 of 13 20MHz low ch J1 20MHz low ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 7 of 13 20MHz mid ch J1 20MHz mid ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 8 of 13 30MHz high ch J1 30MHz high ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 9 of 13 30MHz low ch J1 30MHz low ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 10 of 13 30MHz mid ch J1 30MHz mid ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 11 of 13 40MHz high ch J1 40MHz high ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 12 of 13 40MHz low ch J1 40MHz low ch J3 p14a0029_Annex C_UNII-1_Rev 1.0 Page 13 of 13 40MHz mid ch J1 40MHz mid ch J3

p14a0029_Annex D_UNII-1_Rev 1.0 Page 1 of 3 Annex D Frequency Stability p14a0029_Annex D_UNII-1_Rev 1.0 Page 2 of 3 UNII-1_-40 degrees UNII-1_25 degrees p14a0029_Annex D_UNII-1_Rev 1.0 Page 3 of 3 UNII-1_75 degrees

p14a0029_Annex E_UNII-1_Rev 1.0 Page 1 of 3 Annex E A/C Powerline Conducted Emission p14a0029_Annex E_UNII-1_Rev 1.0 Page 2 of 3 Compliance Testing Conducted Emissions - Class B Line 1 (Neutral) 100.0K1.0M10.0M100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Amplitude dBuV Job #: p14a002815.207_03Nov2014.TIL Operator: ms Points of Interest C orrected Peak D ata C ISPR B _QP C ISPR B _A V Compliance Testing Cond…

Text truncated - open the document above for the full version.
