SWX-UBBXGUniFi Network Building Bridge XG

Ubiquiti Inc.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: May 16, 2021
Application Purpose: Original Equipment
Date of Application: May 16, 2021
Equipment Note: UniFi Network Building Bridge XG
Frequency Range: 5745.00000000 - 5825.00000000
Company: Ubiquiti Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Datasheet UBB-XG 2 of 3 Mechanical Hardware Dimensions Ø192 x 59 mm (Ø7.56 x 2.32") Weight Without Mount: 1.7 kg (3.75 lb) With Mount: 2.85 kg (6.28 lb) Enclosure Materials Aluminum Alloy, UV Resistant Polycarbonate Mount Material Stainless Steel (SUS304) Mounting 60G Precision Alignment Pole Mount (Included) Weatherproong IPX6 Processor Quad-Core ARM ® Cortex ® A72 at 1.6 GHz Memory 2 GB DDR4 Management Interface Ethernet Bluetooth Networking Interface (1) 10/100/1000 Mbps RJ45 Ethernet (1) 1/10 Gbps SFP+ Button Factory Reset LED R/G/B Power Method PoE+, Passive PoE (48V) Power Supply UniFi PoE Switch 48V, 0.65A Gigabit PoE Adapter (Included) Supported Voltage Range 48VDC ± 10% Max. Power Consumption 31.2W Maximum Throughput 5 GHz866.6 Mbps 60 GHz3.8 Gbps Maximum Range 500 m (1640 ft) Operating Temperature -40 to 55° C (-40 to 131° F) Operating Humidity 5 - 95% Noncondensing Certications FCC, IC, CE UniFi 10Gbps Building-to-Building Bridge 10Gbps 60Ghz PtP link with an integrated 5Ghz radio for backup redundancy. Ideal for high-throughput connectivity with a range of up to 500 m. UniFi® 10Gbps Building-to-Building Bridge is the ideal solution for short-range, high-throughput connectivity. The UBB-XG is a 60Ghz PtP Bridge supporting blazing-fast speeds at ranges of up to 500m. Both units come pre- paired for simple setup out of the box. Calibration LEDs on every unit allows operators to easily adust angling and postioning in the eld to get the best signal, and integration with the UniFi Controller makes bridging two networks seamless. As a pack of two radios, UniFi Building-to-Building Bridge contains everything you need to get up and running within minutes. Enjoy simple, easy-to-use, 10Gbps connectivity anywhere. Specifications are subject to change. Ubiquiti products are sold with a limited warranty described at: www.ui.com/support/warranty ©2021 Ubiquiti Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, UniFi, and UniFi Network are trademarks or registered trademarks of Ubiquiti Inc. in the United States and in other countries. All other trademarks are the property of their respective owners. Software RF Back-Up RF Wi-Fi Standards 802.11ad/ay 802.11ac (Wi-Fi 5) Wireless Security WPA2 AES (Always On) Operating Modes PtP VLAN Management VLAN Only Operating Frequency* 57 to 66 GHz * Depends on regulatory region. Channel Bandwidth 2160 MHz Operating Channels 58320, 60480, 62640, 64800 MHz Operating Frequency* US/CAU-NII-15150 - 5250 MHz U-NII-35725 - 5850 MHz Worldwide5150 - 5725 MHz * Depends on regulatory region. Channel Bandwidth 20/40/80 MHz FCC Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. The following apply to Class A products This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operations of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. ISED Canada CAN ICES-3(A)/NMB-3(A) This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.CAN ICES-3(A)/NMB-3(A) Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio ex- empts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. l’appareil ne doit pas produire de brouillage; 2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.RF Exposure Warning The antennas used for this transmitter must be installed to provide a separation distance of at least 32/33(FCC/IC) cm from all persons and must not be located or operating in con junction with any other antenna or transmitter. Les antennes utilisées pour ce transmetteur doivent être installé en considérant une dis tance de séparation de toute personnes d’aumoins 32/33(FCC/IC) cm et ne doivent pas être localisé ou utilisé en conflit avec tout autre antenne ou transmetteur.

Cover Letter(s)

685 Third Avenue, New York, New York 10017 USA Date : 2020-12-11 FCC ID : SWX-UBBXG To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

Cover Letter(s)

685 Third Avenue, New York, New York 10017 USA Date : 2020-12-28 FCC ID : SWX- UBBXG To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

Cover Letter(s)

685 Third Avenue, New York, NY 10017, United States TEL: 408-942-3084 Date: 2020-12-29 FCC ID: SWX- UBBXG A U T H O R I Z A T I O N L E T T E R To Whom It May Concern: Ubiquiti Inc. hereby authorizes Amanda Wu, Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu, Senior Specialist of BV CPS Taoyuan on Ubiquiti Inc.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Mark Feil / Compliance manager Ubiquiti Inc. Tel: 408-942-3084 E-mail: [email protected]

External Photos

Reference No.:BFPJ-WTW-P20110897-1 Page 1/6 CONSTRUCTION PHOTOS OF EUT Reference No.:BFPJ-WTW-P20110897-1 Page 2/6 Reference No.:BFPJ-WTW-P20110897-1 Page 3/6 Reference No.:BFPJ-WTW-P20110897-1 Page 4/6 PoE Adapter Reference No.:BFPJ-WTW-P20110897-1 Page 5/6 Reference No.:BFPJ-WTW-P20110897-1 Page 6/6

Internal Photos

Reference No.:BFPJ-WTW-P20110897-2 Page 1/26 CONSTRUCTION PHOTOS OF EUT Reference No.:BFPJ-WTW-P20110897-2 Page 2/26 Reference No.:BFPJ-WTW-P20110897-2 Page 3/26 Reference No.:BFPJ-WTW-P20110897-2 Page 4/26 Reference No.:BFPJ-WTW-P20110897-2 Page 5/26 Reference No.:BFPJ-WTW-P20110897-2 Page 6/26 Reference No.:BFPJ-WTW-P20110897-2 Page 7/26 Reference No.:BFPJ-WTW-P20110897-2 Page 8/26 Reference No.:BFPJ-WTW-P20110897-2 Page 9/26 Reference No.:BFPJ-WTW-P20110897-2 Page 10 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 11 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 12 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 13 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 14 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 15 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 16 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 17 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 18 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 19 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 20 /26 ANT- 5G Reference No.:BFPJ-WTW-P20110897-2 Page 21 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 22 /26 ANT- 60G Reference No.:BFPJ-WTW-P20110897-2 Page 23 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 24 /26 Reference No.:BFPJ-WTW-P20110897-2 Page 25 /26 ANT- BT Reference No.:BFPJ-WTW-P20110897-2 Page 26 /26 ANT- GPS

RF Exposure Info

Report No.: SABFPJ-WTW-P20110897 Page No. 1 / 6 Report Format Version: 6.1.1 Reference No.: RF Exposure Report Report No.: SABFPJ-WTW-P20110897 FCC ID: SWX-UBBXG Test Model: UBB-XG Received Date: Dec. 02, 2020 Test Date: Jan. 15, 2021 Issued Date: Jan. 21, 2021 Applicant: Ubiquiti Inc. Address: 685 Third Avenue, New York, New York 10017 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABFPJ-WTW-P20110897 Page No. 2 / 6 Report Format Version: 6.1.1 Reference No.: Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Calculation Result ............................................................................................................................... 6 Report No.: SABFPJ-WTW-P20110897 Page No. 3 / 6 Report Format Version: 6.1.1 Reference No.: Release Control Record Issue No. Description Date Issued SABFPJ-WTW-P20110897 Original release. Jan. 21, 2021 Report No.: SABFPJ-WTW-P20110897 Page No. 4 / 6 Report Format Version: 6.1.1 Reference No.: 1 Certificate of Conformity Product: UniFi Network Building Bridge XG Brand: UBIQUITI Test Model: UBB-XG Sample Status: Engineering sample Applicant: Ubiquiti Inc. Test Date: Jan. 15, 2021 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: Jan. 21, 2021 Joyce Kuo / Specialist Approved by : , Date: Jan. 21, 2021 Clark Lin / Technical Manager Report No.: SABFPJ-WTW-P20110897 Page No. 5 / 6 Report Format Version: 6.1.1 Reference No.: 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 32 cm away from the body of the user. So, this device is classified as Mobile Device. (客戶要求，客戶說他的產品固定在電線桿上) Report No.: SABFPJ-WTW-P20110897 Page No. 6 / 6 Report Format Version: 6.1.1 Reference No.: 2.4 Calculation Result The maximum power of WLAN 5GHz and Bluetooth was refer to the FCC test reports. (Report No.: TR5712_UBB-XG_15.407_UNII-1_01, TR5712_UBB-XG_15.407_UNII-3_01, TR5694_UBB-XG_FCC_15.247_BLE_01) The Maximum power was refer to the FCC test reports. (Report No.: ) Operation Mode Evaluation Frequency (MHz) Max. Avg. Power (dBm) Max .Avg. Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WLAN 5GHz 5180-5825 22.80 190.546 14.00 32 0.37195 1 Bluetooth 2402-2480 5.80 3.802 2.50 32 0.00053 1 Operation Mode Evaluation Frequency (MHz) Max. Avg. EIRP (dBm) Max. EIRP (mW) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm…

Text truncated - open the document above for the full version.

Test Report

427 West 12800 South Draper, UT 84020 Test Report Certification FCC ID SWX-UBBXG ISED ID 6545A-UBBXG Equipment Under Test UBB-XG Test Report Serial Number TR5712_05 Date of Test(s) 14, 17 December 2020; 5 January 2021 Report Issue Date 14 th January 2021 Test Specification Applicant 47 CFR FCC Part 15, Subpart E Ubiquiti Inc. 685 Third Avenue New York, NY 10019 U.S.A. NVLAP LAB CODE 600241-0 427 West 12800 South, Draper, UT 84020 TR5712_UBB-XG_15.407_UNII-1_045 Page 2 of 28 PROPRIETARY Certification of Engineering Report This report has been prepared by Unified Compliance Laboratory (UCL) to document compliance of the device described below with the requirement of Federal Communication Commissions (FCC) Part 15, Subpart E. This report may be reproduced in full. Partial reproduction of this report may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. Applicant Ubiquiti Inc. Manufacturer Ubiquiti Inc. Brand Name UniFi Model Number UBB-XG FCC ID SWX-UBBXG ISED ID 6545A-UBBXG On this 14th day of January 2021, I individually and for Unified Compliance Laboratory certify that the statements made in this engineering report are true, complete and correct to the best of my knowledge and are made in good faith. Although NVLAP has accredited the Unified Compliance Laboratory testing facilities, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the U.S. federal government. Unified Compliance Laboratory Written By: Noah Vickers Reviewed By: Richard L. Winter 427 West 12800 South, Draper, UT 84020 TR5712_UBB-XG_15.407_UNII-1_045 Page 3 of 28 PROPRIETARY Revision History Revision Description Date 01 Original Report Release 14 th January 2021 02 Add PTP to product description. Added measurements distance to section 5.5 28 th January 2021 03 Corrected Copy and Paste error and updated section 5.5.1 2 nd February 2021 04 Added test data tables in section 5.2 25 th February 2021 05 Updated AC line conducted emissions data 18 th March 2021 427 West 12800 South, Draper, UT 84020 TR5712_UBB-XG_15.407_UNII-1_045 Page 4 of 28 PROPRIETARY Table of Contents 1 Client Information ................................................................................................................................. 5 1.1 Applicant ....................................................................................................................................... 5 1.2 Manufacturer ................................................................................................................................. 5 2 Equipment Under Test (EUT) ............................................................................................................... 6 2.1 Identification of EUT .................................................................................................................... 6 2.2 Description of EUT ....................................................................................................................... 6 2.3 EUT and Support Equipment ........................................................................................................ 6 2.4 Interface Ports on EUT ................................................................................................................. 7 2.5 Operating Environment ................................................................................................................. 7 2.6 Operating Modes ........................................................................................................................... 7 2.7 EUT Exercise Software ................................................................................................................. 7 2.8 Block Diagram of Test Configuration .......................................................................................... 8 2.9 Modification Incorporated/Special Accessories on EUT .............................................................. 8 2.10 Deviation, Opinions Additional Information or Interpretations from Test Standard .................... 8 3 Test Specification, Method and Procedures .......................................................................................... 9 3.1 Test Specification .......................................................................................................................... 9 3.2 Methods & Procedures .................................................................................................................. 9 3.3 FCC Part 15, Subpart E ................................................................................................................. 9 3.4 Results ........................................................................................................................................... 9 3.5 Test Location ................................................................................................................................ 9 4 Test Equipment ................................................................................................................................... 11 4.1 Conducted Emissions at Mains Ports .......................................................................................... 11 4.2 Direct Connect at the Antenna Port Tests ................................................................................... 11 4.3 Radiated Emissions ..................................................................................................................... 12 4.4 Equipment Calibration ................................................................................................................ 13 4.5 Measurement Uncertainty ........................................................................................................... 13 5 Test Results ...........................................................................................................…

Text truncated - open the document above for the full version.

Test Report

TR5712 UBB-XG UNII-1 Annex Summary TestFrequency (MHz) Nominal Power (dBm) Nominal Bandwidth (MHz) Result Emission Bandwidth 26 dB5180.00030.020.000000PASS RF output power5180.00030.020.000000PASS Power Spectral Density5180.00030.020.000000PASS Occupied Channel Bandwidth 99%5180.00030.020.000000PASS Emission Bandwidth 26 dB5210.00030.020.000000PASS Occupied Channel Bandwidth 99%5210.00030.020.000000PASS Emission Bandwidth 26 dB5240.00030.020.000000PASS Occupied Channel Bandwidth 99%5240.00030.020.000000PASS Emission Bandwidth 26 dB5190.00030.040.000000PASS Occupied Channel Bandwidth 99%5190.00030.040.000000PASS Emission Bandwidth 26 dB5230.00030.040.000000PASS Occupied Channel Bandwidth 99%5230.00030.040.000000PASS Emission Bandwidth 26 dB5210.00030.080.000000PASS Occupied Channel Bandwidth 99%5210.00030.080.000000PASS FCC 15.407 2018 2021-01-063 / 293:17:54 PM Emission Bandwidth 26 dB (5180 MHz; 30.000 dBm; 20 MHz) Customized settings. 26 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5180.00000022.300000------5168.8500005191.150000 (continuation of the "26 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 5180.0000007.4PASS -50 -40 -30 -20 -10 0 10 5150 5160 5170 5180 5190 5200 5210 Level in dBm Frequency in MHz 26 dB Bandwidth 22.300 MHz Bandwidth FCC 15.407 2018 2021-01-064 / 293:17:54 PM Measurement SettingInstrument Value Target Value Start Frequency5.15000 GHz5.15000 GHz Stop Frequency5.21000 GHz5.21000 GHz Span60.000 MHz60.000 MHz RBW200.000 kHz~ 200.000 kHz VBW300.000 kHz>= 240.000 kHz SweepPoints600~ 600 Sweeptime37.969 μsAUTO Reference Level-5.000 dBm-5.000 dBm Attenuation15.000 dBAUTO DetectorMaxPeakMaxPeak SweepCount500500 Filter3 dB3 dB Trace ModeMax HoldMax Hold SweeptypeFFTAUTO Preampoffoff FCC 15.407 2018 2021-01-065 / 293:17:54 PM RF output power (5180 MHz; 30.000 dBm; 20 MHz) Result DUT Frequency (MHz) Gated RMS (dBm) Limit Max (dBm) Gated EIRP (dBm) DutyCycle (%) Result 5180.00000022.030.032.095.513PASS OSP PowerMeter settings SettingInstrument Value Target Value Measurement Time1.000 s1.000 s Points10000001000000 Time resolution1.000 μs1.000 μs FCC 15.407 2018 2021-01-066 / 293:17:54 PM Power Spectral Density (5180 MHz; 30.000 dBm; 20 MHz) Customized settings. Result DUT Frequency (MHz) Frequency (MHz) PSD (dBm) Limit Max (dBm) Result 5180.0000005185.3465357.74917.0PASS Ports PortState 1used 2used Measurement SettingInstrument Value Target Value Start Frequency5.17000 GHz5.17000 GHz Stop Frequency5.19000 GHz5.19000 GHz Span20.000 MHz20.000 MHz RBW1.000 MHz<= 1.000 MHz VBW3.000 MHz>= 3.000 MHz SweepPoints101~ 40 Sweeptime2.020 ms2.020 ms Reference Level20.000 dBm20.000 dBm Attenuation40.000 dBAUTO DetectorRMSRMS SweepCount100100 Filter3 dB3 dB Trace ModeMax HoldMax Hold SweeptypeFFTAUTO Preampoffoff FCC 15.407 2018 2021-01-067 / 293:17:54 PM Occupied Channel Bandwidth 99% (5180 MHz; 30.000 dBm; 20 MHz) Customized settings. 99 % Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5180.00000017.800000------5171.0500005188.850000 (continuation of the "99 % Bandwidth" table from column 6 ...) DUT Frequency (MHz) Result 5180.000000PASS -30 -20 -10 0 10 15 5160 5170 5180 5190 5200 Level in dBm Frequency in MHz 99 % Bandwidth 17.800 MHz Bandwidth FCC 15.407 2018 2021-01-068 / 293:17:54 PM Measurement SettingInstrument Value Target Value Start Frequency5.16000 GHz5.16000 GHz Stop Frequency5.20000 GHz5.20000 GHz Span40.000 MHz40.000 MHz RBW200.000 kHz>= 200.000 kHz VBW1.000 MHz>= 600.000 kHz SweepPoints400~ 400 Sweeptime28.477 μsAUTO Reference Level-5.000 dBm-5.000 dBm Attenuation15.000 dBAUTO DetectorMaxPeakMaxPeak SweepCount500500 Filter3 dB3 dB Trace ModeMax HoldMax Hold SweeptypeFFTAUTO Preampoffoff FCC 15.407 2018 2021-01-069 / 293:17:54 PM Emission Bandwidth 26 dB (5210 MHz; 30.000 dBm; 20 MHz) Customized settings. 26 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5210.00000028.400000------5195.7500005224.150000 (continuation of the "26 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 5210.0000008.3PASS -40 -30 -20 -10 0 10 15 5180 5190 5200 5210 5220 5230 5240 Level in dBm Frequency in MHz 26 dB Bandwidth 28.400 MHz Bandwidth FCC 15.407 2018 2021-01-0610 / 293:17:54 PM FCC 15.407 2018 2021-01-0611 / 293:17:54 PM Occupied Channel Bandwidth 99% (5210 MHz; 30.000 dBm; 20 MHz) Customized settings. 99 % Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5210.00000018.000000------5200.9500005218.950000 (continuation of the "99 % Bandwidth" table from column 6 ...) DUT Frequency (MHz) Result 5210.000000PASS -20 -10 0 10 20 5190 5195 5200 5205 5210 5215 5220 5225 5230 Level in dBm Frequency in MHz 99 % Bandwidth 18.000 MHz Bandwidth FCC 15.407 2018 2021-01-0612 / 293:17:54 PM FCC 15.407 2018 2021-01-0613 / 293:17:54 PM Emission Bandwidth 26 dB (5240 MHz; 30.000 dBm; 20 MHz) Customized settings. 26 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5240.00000021.300000------5229.0500005250.350000 (continuation of the "26 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 5240.0000006.2PASS -50 -40 -30 -20 -10 0 10 5210 5220 5230 5240 5250 5260 5270 Level in dBm Frequency in MHz 26 dB Bandwidth 21.300 MHz Bandwidth FCC 15.407 2018 2021-01-0614 / 293:17:54 PM FCC 15.407 2018 2021-01-0615 / 293:17:54 PM Occupied Channel Bandwidth 99% (5240 MHz; 30.000 dBm; 20 MHz) Customized settings. 99 % Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 5240.00000017.700000------5231.0500005248.750000 (continuation of the "99 % Bandwidth" table from column 6 ...) DUT Freque…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Alex Macon

[email protected]385-200-1617Fax: 408-904-7556

Test Firm

Unified Compliance LaboratoryAlex Macon

[email protected]385-200-1617

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15E	5.75 GHz - 5.83 GHz	170.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is maximum conducted output power. This device supports 20, 40 and 80 MHz bandwidth modes. This device must be professionally installed for fixed point-to-point operations such that its antenna(s) can provide a separation distance of at least 32 cm from all persons and must not transmit simultaneously with any other transmitter, except in accordance with FCC multi-transmitter product procedures or as described in this filing. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance.
