SWX-UKUDigital Transmission Radio

Ubiquiti Inc.
Digital Transmission Radio - FCC ID SWX-UKU - Ubiquiti Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Dec 14, 2023
Application Purpose
Original Equipment
Date of Application
Dec 05, 2023
Equipment Note
Digital Transmission Radio
Frequency Range
2412.00000000 - 2462.00000000
Company
Ubiquiti Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

E-Label User Information FCC ID: SWX-UKU IC ID: 6545A-UKU Ubiquiti Inc. will be incorporating the E-Label procedures per FCC KDB 784748-D02. The information below is what will be included in the E-Labeling. E-label and warning statements can be found in the device/controller GUI under Device > Settings > About. Detailed compliance information including Declaration of Conformity is available at the following internet address: ui.com/compliance FCC Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures; - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. ISED Canada CAN ICES-3 (A) / NMB-3 (A) This device complies with ISED Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (A) / NMB-3 (A) Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. I’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. RF Exposure Warning The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter. Les antennes utilisées pour ce transmetteur doivent être installé en considérant une distance de séparation de toute personnes d’au moins 20 cm et ne doivent pas être localisé ou utilize en conflit avec tout autre antenne ou transmetteur.

Users Manual

Safety Notices (if applicable) 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specied by the manufacturer. WARNING: Failure to provide proper ventilation may cause re hazard. Keep at least 20 mm of clearance next to the ventilation holes for adequate airow. WARNING: To reduce the risk of re or electric shock, do not expose this product to rain or moisture. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning. Electrical Safety Information (if applicable) 1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a dierent power source than those specied may result in improper operation, damage to the equipment, or pose a re hazard if the limitations are not followed. 2. There are no operator serviceable parts inside this equipment. Service should be provided only by a qualied service technician. 3. This equipment is provided with a detachable power cord which has an integral safety ground wire intended for connection to a grounded safety outlet. a. Do not substitute the power cord with one that is not the provided approved type. Never use an adapter plug to connect to a 2-wire outlet as this will defeat the continuity of the grounding wire. b. The equipment requires the use of the ground wire as a part of the safety certication, modication or misuse can provide a shock hazard that can result in serious injury or death. c. Contact a qualied electrician or the manufacturer if there are questions about the installation prior to connecting the equipment. d. Protective earthing is provided by Listed AC adapter. Building installation shall provide appropriate short-circuit backup protection. e. Protective bonding must be installed in accordance with local national wiring rules and regulations. Radiation Exposure Statement - This equipment should be installed and operated with a minimum distance 20 cm between the radiator and your body. - This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operating Frequency (MHz): Max. RF Output Power: This device is restricted to indoor use only when operating in the 5150 - 5350 MHz frequency range within all member states. Operation in the 5.8 GHz frequency band is prohibited in non-BFWA member states. Declaration of Conformity Hereby, UBIQUITI, declares that this device, UK-Ultra, is in compliance with the essential requirements and other relevant provisions of Directives 2014/53/EU, 2014/30/EU, 2014/35/EU. The device has software that cannot aect the conformity with the RED, even if the software is changed or replaced. The full text of the EU declaration of conformity and detailed compliance information is available at the following internet address: ui.com/compliance Ubiquiti International Holding B.V. Ekkersrijt 3102, Son, Netherlands 5150-5350 ≤ 23 dBm 5470 -5725 ≤ 30 dBm 2400-2483.5 ≤ 20 dBm Indicaciones de seguridad (si corresponde) 1. Lea, siga y conserve estas instrucciones. 2. Preste atención a todas las advertencias. 3. Utilice exclusivamente los dispositivos o accesorios indicados por el fabricante. ADVERTENCIA: La falta de ventilación adecuada puede provocar riesgo de incendio. Mantenga al menos 20 mm de separación junto a los oricios de ventilación para que haya una ventilación adecuada. ADVERTENCIA: Para reducir el riesgo de incendio o descarga eléctrica, no exponga el producto a la lluvia ni a la humedad. ADVERTENCIA: No utilice este producto en un lugar en el que pueda quedar sumergido en agua. ADVERTENCIA: Evite utilizar este producto durante una tormenta eléctrica. Existe la remota posibilidad de se produzca una descarga eléctrica causada por los rayos. Información de seguridad eléctrica (si corresponde) 1. Es obligatorio cumplir los requisitos de corriente, frecuencia y voltaje indicados en la etiqueta del fabricante. La conexión a una fuente de alimentación diferente a las especicadas puede ocasionar un funcionamiento incorrecto, daños en el equipo o riesgo de incendio si no se respetan las limitaciones. 2. Este equipo no contiene piezas que un operador pueda reparar. Solo un técnico de servicio cualicado debe proporcionar servicios. 3. Este equipo se suministra con un cable de alimentación desmontable que dispone de un cable de tierra de seguridad integral diseñado para conectarse a una toma de tierra de seguridad. a. No sustituya el cable de alimentación por otro distinto al tipo aprobado proporcionado. Nunca utilice un enchufe adaptador para conectar a una salida de dos cables, ya que se detendrá la continuidad del cable de tierra. b. El equipo requiere el uso del cable de tierra como parte de la certicación de seguridad. La modicación o el uso indebido puede ocasionar un riesgo de descarga, lo cual podría provocar lesiones graves o la muerte. c. Si tiene alguna duda acerca de la instalación, póngase en contacto con un electricista cualicado o con el fabricante antes de conectar el equipo. d. El adaptador de CA indicado proporciona una puesta a tierra de seguridad. Para la instalación en un edicio deberá proporcionarse una protección de reserva contra cortocircuitos adecuada. e. Debe instalarse una conexión protectora de acuerdo con las normas y reglamentos nacionales de cableado. Declaración de exposición a la radiación - Este equipo se debe instalar y utilizar con una distancia mínima de 20 cm entre el radiador y su cuerpo. - Este transmisor no debe colocarse ni utilizarse junto con ninguna otra antena o transmisor. Las bandas de frecuencias de operación (MHz): Máx. potencia de salida de radiofrecuencia: Este dispositivo está restringido para su uso en interiores solo cuando opera en la banda de frecuencia de 5150 a 5350 MHz dentro de todos los estados miembros. El funcionamiento …

Text truncated - open the document above for the full version.

Attestation Statements

www.ui.com Date: 12 September 2023 Federal Communications Commission (the “Commission” or “FCC”) Authorization and Evaluation Division 7435 Oakland Mills Rd. Columbia, MD 21046 USA RE: Attestation Statements Part 2.911(d)(5)(i) Filing – FCC ID: SWX-UKU Ubiquiti Inc. (“the applicant”) certifies that, as of the date of the application, the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Alex Macon Ubiquiti lnc. Compliance Officer

Attestation Statements

www.ui.com Date: 30 October 2023 Federal Communications Commission (the “Commission” or “FCC”) Authorization and Evaluation Division 7435 Oakland Mills Rd. Columbia, MD 21046 USA RE: Attestation Statements Part 2.911(d)(5)(ii) Filing – FCC ID: SWX-UKU Ubiquiti Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List 1 (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Alex Macon Ubiquiti lnc. Compliance Officer 1 https://www.fcc.gov/supplychain/coveredlist

Attestation Statements

www.ui.com Date: 17 February 2023 Federal Communications Commission (the “Commission” or “FCC”) Authorization and Evaluation Division 7435 Oakland Mills Rd. Columbia, MD 21046 RE: Attestation Statement Part 2.911(d)(7) – FCC: SWX Ubiquiti Inc. (“the Applicant”, FRN: 0012268215) certifies that, as of the date of this letter agreement, C T Corporation System is the Applicant’s designated U.S. agent for service of process for the above referenced grantee code. Applicant agrees to maintain an agent for no less than one year after (i) the Applicant has terminated all marketing and importation or (ii) the conclusion of any Commission-related proceeding involving the equipment certified by the FCC. C T Corporation System accepts, as of the date hereof, the obligation of the designated U.S. agent for service of process for the above referenced grantee code. Designated U.S. Agent Information: Name: C T Corporation System Address: 1015 15th Street N.W., Suite 1000, Washington, D.C., 20005 Email: [email protected] U.S. Agent FRN: The agent for service of process does no other business with the FCC and does not have an FRN. Sincerely, Ubiquiti Inc. C T Corporation System Alex Macon Denise Bell, Assistant Secretary By:

Cover Letter(s)

www.ui.com Date: 11/09/2023 TIMCO Engineering, Inc. 13146 NW 86 th Drive, Suite 400 Alachua, FL 32615 RE: Request for Confidentiality In reference to the application under FCC ID: SWX-UMT, and pursuant to Sections 0.457(d)1(ii) and 0.459 of the Commission’s Rules, Ubiquiti Networks hereby requests permanent confidential treatment of the accompanying information as outlined below: Block Diagram Schematics Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to Ubiquiti Networks and provide unjustified benefits to its competitors. In addition to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the important rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short term confidentiality on the following attachments until 180 days from grant date. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Ubiquiti Networks understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Alex Macon Ubiquiti lnc. Compliance Manager

Cover Letter(s)

685 3 RD AVE. • NEW Y0RK, NY 10071 • www.ui.com Date: 12 September 2023 Federal Communications Commission 7435 Oakland Mills Rd. Columbia, MD 21046 RE: Request for Original Equipment Certification – FCC: SWX-UKU It is hereby requested that Ubiquiti Inc. obtain FCC Original Equipment Certification of a radio apparatus on the Ubiquiti Inc. product UK-Ultra. The associated FCC: number is listed above. The UK-Ultra is a WiFi mesh that provides simultaneous, dual-band, 2x2 MIMO technology. The UK-Ultra is used to expand the coverage of an UniFi system. The UK- Ultra provides 802.11ac technology for ubiquitous WiFi coverage for both indoor and outdoor use. The UK-Ultra is power from a 48 volt PoE adapter. Sincerely, Alex Macon Ubiquiti lnc. Compliance

Cover Letter(s)

www.ui.com Power of Attorney Date: May 8, 2022 Dear Sir or Madam, I hereby have entrusted the following individuals and entity to be an authorized agent regarding application for Type Certification. Ubiquiti Inc. also authorizes the following individuals and entity to be a proxy to handle all certification matters. Clay Allred Joseph W. Jackson Richard L. Winter Tyler Parry Kimberly Rodriguez Tanner Langley Unified Compliance Laboratories Address : 427 W 128000 South Draper Utah 84020 e-mail : [email protected] Applicant : Ubiquiti Inc. Address : 685 Third Avenue, New York NY 10017 United States Of America Sincerely, Alex Macon Ubiquiti, lnc. Compliance Manager

External Photos

427 West 12800 South, Draper, UT 84020 Photograph 1: Front View of DUT Photograph 2: Back View of DUT 427 West 12800 South, Draper, UT 84020 Photograph 3: Back View of DUT With Cover Off Photograph 4: Right View of DUT 427 West 12800 South, Draper, UT 84020 Photograph 5: Left View of DUT Photograph 6: Top View of DUT 427 West 12800 South, Draper, UT 84020 Photograph 7: Top View of DUT With Cover Off Photograph 8: Bottom View of DUT

ID Label/Location Info

M/N UK-Ultra IPX6 IC: 6545A-UKU FCC ID: SWX-UKU Ubiquiti Inc. 685 Third Avenue New York NY 10017 USA Label Location

ID Label/Location Info

M/N UK-Ultra IPX6 IC: 6545A-UKU FCC ID: SWX-UKU Ubiquiti Inc. 685 Third Avenue New York NY 10017 USA Label Location

Internal Photos

427 West 12800 South, Draper, UT 84020 Ethernet Port Photograph 1: Internal View of DUT With Front Cover Off 427 West 12800 South, Draper, UT 84020 2.4 & 5 GHz Ext Antenna 2.4 & 5 GHz Ext Antenna 2.4 & 5 GHz Int. Antenna 2.4 & 5 GHz Int. Antenna 2.4 & 5 GHz Int. Antenna Test Point Only Test Point Only Photograph 2: Internal View of Top PCB 427 West 12800 South, Draper, UT 84020 Photograph 3: Internal View of Bottom PCB 427 West 12800 South, Draper, UT 84020 Photograph 4: Internal View of Bottom PCB With Can Off

RF Exposure Info

Maximum Permissible Exposure FCC Part 2 Sections §2.1091 and §2.1093 Test Requirement(s): §15.407(f): U-NII devices are subject to the radio frequency radiation exposure requirements specified in §1.1307(b), §2.1091 and §2.1093 of this chapter, as appropriate. All equipment shall be considered to operate in a “general population/uncontrolled” environment. RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit: EUT’s operating frequencies @ WiFi 2412 – 2462 MHz; UNII-1 5180 – 5240 MHz; UNII-2a 5260 – 5320 MHZ; UNII-2c 5500 – 5720 MHz; UNII-3 5745 – 5855 MHz; Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √(PG / 4S) where, S = Power Density (mW/cm 2 ) P = Power Input to antenna (mW) G = Antenna Gain (numeric value) R = Distance (cm) Test Results: FCC Frequency (MHz) Con. Pwr. (dBm) Con. Pwr. (mW) Ant. Gain (dBi) Ant. Gain numeric Pwr. Density (mW/cm 2 ) Limit (mW/cm 2 ) Margin Distance (cm) Result 2432* 21.33 135.83 4.7 2.95 0.08 1.0 0.92 20 Pass 5180* 26.77 475.34 6.1 4.07 0.39 1.0 0.61 20 Pass 5320 21.71 148.25 6.1 4.07 0.12 1.0 0.88 20 Pass 5500 21.84 152.76 6.1 4.07 0.12 1.0 0.88 20 Pass 5745 21.51 141.58 6.1 4.07 0.11 1.0 0.89 20 Pass *There is Simultaneous Transmission (worse case) 0.47 1.0 0.53 20 Pass The safe distance for SWX-UKU where Power Density is less than the MPE Limit listed above was found to be 20 cm.

Test Report

PROPRIETARY - INTERNAL USE ONLY [UK Ultra] antenna measurement PROPRIETARY - INTERNAL USE ONLY [WiFi measurement] Peak gain (dBi) 2.4G (Max gain frequency) 4.7 Model 117-04192 117-04193 Antenna type: PIFA PROPRIETARY - INTERNAL USE ONLY [WiFi measurement] Peak gain (dBi) 5G (Max gain frequency) 6.1 Model 117-04192 117-04193 Antenna type: Stamp PROPRIETARY - INTERNAL USE ONLY [WIFI Antenna Photo] 117-04192117-04193 CONFIDENTIAL - INTERNAL USE ONLY

Test Report

Item Page 1.1 2.2 3.3~12 ............... .................. 成品圖 Contents Description ................................. 規格表 ............... 測試報告 .................. Specification 1. Electrical Properties :(單天線) 1.1 Frequency Range.................. 1.2 Impedance ........................ 1.3 VSWR .............................. 1.4 Return Loss........................ 1.5 Radiation........................... 1.6 Gain(peak)......................... 1.74.57 dBi [email protected]~5.825 GHz 1.8 Cable................................. 1.9 Connector........................... 1.10 Polarization........................ Linear ; Vertical 2. Physical Properties : 2.1 Operating Temp. ............... ...-10°C ~ +60°C 2.2 Storage Temp. .....................-10°C ~ +70°C 1.92 :1Max. 10 dB Min. 3.59 dBi Max.@ 2.4~2.5 GHz Omni-directional RG-178 Cable SMA Connector RF Antenna Assembly 2.4~2.5 GHz;4.9~5.825 GHz 50Ω Nominal Antenna Design For NE3-16033 V1.02 Product Development Status Concept Study In Development Production X Document Number NE3-16033 1 st Released Date 04/01/2016 Last Released Date 05/23/2016 Designers Carter Su Testers Carter Su Reviewed by SKY 3 3 Electrical Item Specification Note Test Environment With Housing Frequency Range 2.4GHz~2.5GHz 4.9GHz~5.825GHz VSWR 1.92 : 1 (max) Input Impedance 50 ohm Port to Port Isolation N/A Polarization Linear (Vertical or Horizontal) Gain(Peak gain) ANT 1. 2.4GHz(3.59dBi) / 5GHz(4.57dBi) Efficiency 2.4GHz>80% / 5GHz>70% Half Power Beam Width (HPBW) N/A Mechanical Dimensions N/A Connector SMA Cable Type RG-178 Cable Length N/A Radome Material N/A Ingress Protection N/A Operating Temperature -10 ~ +60 Storage Temperature -10 ~ +70 4 4 Revised History Date Version Revised Record 04/01/16 1.00 z 1 st released 04/26/16 1.01 z Helix 05/23/16 1.02 z Helix 5 5 1 Antenna Introduction 6 6 2 S11 test results 2.1 ANT 1. 7 7 3 Gain & Patterns test results 3.1 Measurement setting XY YZ XZ 0° Right Up Up 90° Back Back Right 180° Left Down Down 270° Front Front Left X Y Z AUT Up(+Z) Left Front Back(+Y) Right(+X) Down AUT 8 8 θ φ To t a l a n g l e 175 ̊ 360 ̊ How many angle scan one point 5 ̊ 5 ̊ Total scan point 36 73 9 9 3.2 ANT 1. 2400 MHz~2500 MHz/4900 MHz~5825 MHz X-Z Plane (E-total) 2400 MHz~2500 MHz/4900 MHz~5825 MHz Y-Z Plane (E-total) X Z Y Z 10 10 2400 MHz~2500 MHz/4900 MHz~5825 MHz X-Y Plane (E-total) Y X 11 11 4 Return Loss Frequency Ant 1. (dB) 2400MHz -24.61 2450MHz -27.63 2500MHz -20.97 4900MHz -22.81 5150MHz -21.00 5350MHz -21.12 5725MHz -20.44 5825MHz -15.75 5 3D total Peak Gain & Efficiency Ant 1. Frequency Peak Gain (dBi) Efficiency (%) 2400MHz 3.59 86.35 2450MHz 3.20 86.64 2500MHz 3.29 85.27 4900MHz 3.94 72.57 5150MHz 4.57 72.46 5350MHz 3.60 73.99 5725MHz 4.19 76.23 5825MHz 4.05 76.58 12 12

Test Report

427 Wes t 12800 South Draper, UT 84020 Test Report Certification FCC ID SWX-UKU IC ID 6545-UKU Equipment Under Test UK-Ultra Test Report Serial Number TR8447_01 Date of Tests 9-10, 11, 14 August 2023 Report Issue Date 25 August 2023 Test Specification Applicant 47 CFR FCC Part 15, Subpart C Ubiquiti Inc. 685 Third Avenue New York, NY 10017 U.S.A. NVLAP LAB CODE 600241-0 427 West 12800 South, Draper, UT 84020 TR8447_UK-Ultra_FCC15.247_2.4WiFi_01 Page 2 of 29 PROPRIETARY Certification of Engineering Report This report has been prepared by Unified Compliance Laboratory (UCL) to document compliance of the device described below with the requirement of Federal Communication Commissions (FCC) Part 15, Subpart C. This report may be reproduced in full. Partial reproduction of this report may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. Applicant Ubiquiti Inc. Manufacturer Ubiquiti Inc. Brand Name UBIQUITI Model Number UK-Ultra FCC ID SWX-UKU IC ID 6545-UKU On this 25 th day of August 2023, I individually and for Unified Compliance Laboratory certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge and are made in good faith. Although NVLAP has accredited the Unified Compliance Laboratory testing facilities, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the U.S. federal government. Unified Compliance Laboratory Written By: Kimberly Rodriguez Reviewed By: Richard L. Winter 427 West 12800 South, Draper, UT 84020 TR8447_UK-Ultra_FCC15.247_2.4WiFi_01 Page 3 of 29 PROPRIETARY Revision History Revision Description Date 01 Original Report Release 25 August 2023 427 West 12800 South, Draper, UT 84020 TR8447_UK-Ultra_FCC15.247_2.4WiFi_01 Page 4 of 29 PROPRIETARY Table of Contents 1 Client Information ................................................................................................................................. 5 1.1 Applicant ....................................................................................................................................... 5 1.2 Manufacturer ................................................................................................................................. 5 2 Equipment Under Test (EUT) ............................................................................................................... 6 2.1 Identification of EUT .................................................................................................................... 6 2.2 Description of EUT ....................................................................................................................... 6 2.3 EUT and Support Equipment ........................................................................................................ 6 2.4 Interface Ports on EUT ................................................................................................................. 7 2.5 Operating Environment ................................................................................................................. 7 2.6 Operating Modes ........................................................................................................................... 7 2.7 EUT Exercise Software ................................................................................................................. 7 2.8 Block Diagram of Test Configuration .......................................................................................... 8 2.9 Modification Incorporated/Special Accessories on EUT .............................................................. 8 2.10 Deviation, Opinions Additional Information or Interpretations from Test Standard .................... 8 3 Test Specification, Method and Procedures .......................................................................................... 9 3.1 Test Specification .......................................................................................................................... 9 3.2 Methods & Procedures .................................................................................................................. 9 3.3 FCC Part 15, Subpart C ................................................................................................................ 9 3.4 Results ......................................................................................................................................... 10 3.5 Test Location .............................................................................................................................. 10 4 Test Equipment ................................................................................................................................... 11 4.1 Conducted Emissions at Mains Ports .......................................................................................... 11 4.2 Direct Connect at the Antenna Port Tests ................................................................................... 11 4.3 Radiated Emissions ..................................................................................................................... 12 4.4 Equipment Calibration ................................................................................................................ 13 4.5 Measurement Uncertainty ........................................................................................................... 13 5 Test Results ......................................................................................................................................... 14 5.1 §15.203 Antenna Requirements .................................................................................................. 14 5.2 Conducted Emissions at Mains Ports Data ................................................................................. 14 5.3 §15.2…

Text truncated - open the document above for the full version.

Test Report

427 West 12800 South Draper, UT 84020 Test Report Attachment FCC ID SWX-UKU ISED ID 6545-UKU Equipment Under Test UK-Ultra Test Report Serial Number TR8447_01 Date of Test(s) 9-10, 11, 14 August 2023 Report Issue Date 25 August 2023 Test Personnel Testing performed by Tyler Parry Test Location Testing was performed at the Unified Compliance Laboratory located at 427 West 12800 South, Draper, UT 84020. Unified Compliance Laboratory is accredited by National Voluntary Laboratory Accreditation Program (NVLAP); NVLAP Code 600241-0 which is effective until 30 June 2023. This site has also been registered with Innovations, Science and Economic Development (ISED) department as was accepted under Appendix B, Phase 1 procedures of the APEC Tel MRA for Canadian recognition. ISED No.: 25346, effective until 30 June 2024. Unified Compliance Laboratory has been assigned Conformity Assessment Number US0223 by ISED and MRA US5037. NVLAP LAB CODE 600241-0 427 West 12800 South, Draper, UT 84020 Document1 Page 2 of 63 PROPRIETARY 1 Table of Contents Test Personnel ....................................................................................................................... 1 Test Location ......................................................................................................................... 1 2 UK-Ultra 2.4GHz WiFi ...................................................................................................... 3 2.1 b mode ...............................................................................................................................3 2.2 g mode.............................................................................................................................. 19 2.3 n mode ............................................................................................................................. 35 427 West 12800 South, Draper, UT 84020 Document1 Page 3 of 63 PROPRIETARY 2 UK-Ultra 2.4GHz WiFi 2.1 b mode Summary Test Frequency (MHz) Nominal Power (dBm) Nominal Bandwidth (MHz) Result RF output power 2412.000 24.0 20.000000 PASS Minimum Emission Bandwidth 6 dB 2412.000 24.0 20.000000 PASS Power Spectral Density 2412.000 24.0 20.000000 PASS Occupied Channel Bandwidth 99% 2412.000 24.0 20.000000 PASS Tx Spurious Emission 2412.000 24.0 20.000000 PASS Minimum Emission Bandwidth 6 dB 2437.000 24.0 20.000000 PASS Occupied Channel Bandwidth 99% 2437.000 24.0 20.000000 PASS Tx Spurious Emission 2437.000 24.0 20.000000 PASS Minimum Emission Bandwidth 6 dB 2462.000 24.0 20.000000 PASS Occupied Channel Bandwidth 99% 2462.000 24.0 20.000000 PASS Tx Spurious Emission 2462.000 24.0 20.000000 PASS RF output power (2412 MHz; 24.000 dBm; 20 MHz) Customized settings. Result DUT Frequency (MHz) Gated RMS (dBm) Limit Max (dBm) Gated EIRP (dBm) DutyCycle (%) Result 2412.000000 21.3 30.0 21.3 95.677 PASS OSP Po…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Alex Macon
[email protected]385-200-1617Fax: 408-904-7556

Test Firm

Unified Compliance LaboratoryClay Allred
[email protected]8015309355

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz136.00 mW
Confidentiality
Long Term
Grant Notes
Output Power listed is the maximum combined conducted output power. The antenna(s) used for this transmitter must be installed and operated so as to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing. End-users must be informed of operating requirements for satisfying RF exposure compliance. This device supports 20 and 40 MHz bandwidth modes.
