SXXKTS-30ABluetooth Speaker

6 49182103 75 3 22 MUSIC 44 General Information Copyright This document is protected by copyright. Any reproduc- tion or reprint, even in parts, and any reproduction of the illustrations, even in a changed state, is strictly prohibi- ted without the written consent of the manufacturer. Information on environmental protection The packaging material used is recyclable. Dispose of packaging material which is no longer needed in accordance with the locally applicable regulations. This product must not be disposed of in the normal household waste within the European Union. Dispose of the device via the communal collecting points. 23 MUSIC 44 Guarantee / Warranty This product has been thoroughly checked for quality and functionality before dispatch. 12 month warranty form the date of purchase for the speaker, 6 months for the integrated battery. We will replace or repair defective products free of charge during the guarantee period. The guarantee is not extended in the course of a repair or an exchange, exchanged parts become our property. Ple- ase contact us before sending a guarantee consignment. The guarantee is excluded in the following cases: ■in the case of faulty installation, ■in the case of changes to the system without our approval, ■in the case of damages due to moisture, damages caused by dropping or damaged cables, ■if there is no proof of purchase. 24 MUSIC 44 Declaration of conformity The CE declaration of conformity for this product can be downloaded from our website: www.mobiset.de Symbols used WARNING Is used for a possible dangerous situation which could lead to serious injuries or death. ►Follow the instructions given here in order to avoid danger. NOTE ►A note marks additional information which facilita- tes the handling of the product. 25 MUSIC 44 Intended use This device is only intended for the reproduction of audio signals of optional Bluetooth audio devices. Additionally, you can connect the device to a Bluetooth telephone and use the device as hands-free equipment. Any other use or use beyond what is specified is regar- ded as not intended. WARNING The device can be dangerous in the case of uninten- ded use and / or different use. ►Only use the device as intended. ►Comply with the procedures described in these operating instructions. 26 MUSIC 44 Claims of any kind due to damages as a result of unin- tended use are excluded. This risk is borne exclusively by the operator. Limitation of liability All technical information, data and notes for connection and operation contained in these operating instructions correspond to the latest status during printing and are carried out to the best of our knowledge, taking into con- sideration our experience and knowledge up to now. No claims can be derived from the data, illustrations and descriptions in these operation instructions. The manufacturer does not assume any liability for da- mages due to non-compliance with the operating instruc- tions, non-intended use, improper repairs, unauthorised changes or use of unauthorised spare parts. 27 MUSIC 44 Safety Handling (storage) batteries WARNING ►The device must not be opened, thrown into fire, dipped in fluids or be short-circuited. ►Charge the device only with the delivered rechar- ger cable. Using a wrong charger can lead to fire, explosion and acid burns. ►In the case of damage and improper use of the storage battery, vapours can escape. Supply fresh air and consult a doctor in case of complaints. The vapours can irritate the airways. 28 MUSIC 44 WARNING ►In the case of a damaged storage battery, battery fluid can leak. If one of the storage batteries has leaked, please avoid contact of the skin, the eyes and the mucous membranes with the battery fluid. In the case of contact with the battery fluid, imme- diately rinse the corresponding spots with plenty of clear water and consult a doctor promptly. Basic safety information ■Check the device for any visible external damage before use. Do not put into operation a damaged or fallen device. ■Persons, who are not in a position to safely operate the product due to their physical, mental or motor skills, may only use the device under supervision or instruction by a responsible person. 29 MUSIC 44 ■Children are only allowed to use the device under supervision. ■The device may only be repaired by authorised specialised companies or the customer service. Im- proper repairs can lead to significant dangers for the user, and to the expiry of the warranty claim. ■Protect the device from moisture and the penetration of fluids. ■Avoid direct sun radiation. Requirements concerning the installation site For a safe and faultless operation of the device, the ins- tallation site has to meet the following requirements: ■The device has to be placed on a firm, flat and hori- zontal base. ■Do not place the device in a hot, wet or very wet environment or near flammable material. 30 MUSIC 44 Before first use Unpacking ‹Take the device and the operating instructions out of the cardboard box. ‹Remove all packaging materials and protective films from the device before first use, especially the pro- tective film at the bottom side of the device. NOTE ►Keep the original packaging during the warranty and / or guarantee period of the device so that you can dispatch the device in case of warranty and / or guarantee properly packed. Transport damages will cause the warranty and / or guarantee claim to expire. 31 MUSIC 44 Checking the scope of delivery ‹Check the content for completeness and visible damages. ‹Immediately inform your supplier about any incom- plete or damaged delivery. Device description (Illustrations see front cover page) 1 Micro USB charging port 2 AUX IN port 3 ON/OFF switch 4 Skip forward/Increa- se volume 5 Green LED, cable- connected operation 6 Play/Pause; accept/end call hands-free operation; change of operating mode 7 Blue LED, Bluetooth ope- rating mode 8 Skip back/Decrease volume 9 Microphone 10 Red charging indicator lamp 32 MUSIC 44…

Text truncated - open the document above for the full version.

Shenzhen KingBoard Technology Co.,LTD Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China TEL: +86-755-28026161 FAX: +86-755-28029040 AGENCY AUTHORIZATION LETTER FCC ID: SXXKTS-30A Date: Dec.10, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen CTL Testing Technology Co., Ltd. (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on Dec. 09, 2015. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Shenzhen KingBoard Technology Co.,LTD are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Qin Hong Huang /Manager

Shenzhen KingBoard Technology Co.,LTD Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China TEL: +86-755-28026161 FAX: +86-755-28029040 Rev 11/20/07 Confidentiality Letter Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: SXXKTS-30A. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operation Description Operation Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Qin Hong Huang /Manager

Shenzhen KingBoard Technology Co.,LTD Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China TEL: +86-755-28026161 FAX: +86-755-28029040 Series Models Description FCC ID: SXXKTS-30A Date: Dec.10, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name: Bluetooth Speaker) Models Name:: KTS-30A, KTS-30B, CSBT-304 have same electrical, PCB and BOM, only the model’s name and color are different for marketing requirements. Sincerely, Qin Hong Huang /Manager

Shenzhen KingBoard Technology Co., Ltd. Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China TEL: +86-755-28026161 FAX: +86-755-28029040 USB Port Statement FCC ID: SXXKTS-61A Date: Nov. 20, 2014 To whom it may concern: We, the undersigned, state that the device's (Model: KTS-61A, KTS-61, BT-1004, SM-3929, SM-3929BK, SM-3929RYL, SM-3929SL, CUBE) USB port only used for charge, no any data transfer to PC. Sincerely, Qin Hong Huang /Manager

FCC ID Label Information 1. Label location: 2. FCC ID Label: Bluetooth Speaker KTS-30A FCC ID: SXXKTS-30A

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No......................: CTL1412052939-WF Compiled by ( position+printed name+signature)..: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Tracy Qi Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Dec. 15, 2014 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: Shenzhen KingBoard Technology Co., Ltd. Address.............................................: Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description.................... : Bluetooth Speaker Trade Mark .......................................: N/A Models/Type reference.....................: KTS-30A, KTS-30B, CSBT-304 Modulation .......................................: GFSK, Pi/4 DQPSK, 8DPSK Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: SXXKTS-30A Result................................................: Positive V1.0 Page 2 of 51 Report No.: CTL1412052939-WF T E S T R E P O R T Test Report No. : CTL1412052939-WF Dec. 15, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Bluetooth Speaker Model /Type : KTS-30A Listed Modes : KTS-30B, CSBT-304 Difference Description : Only the color and model's name is different Applicant : Shenzhen KingBoard Technology Co., Ltd. Address : Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China Manufacturer Shenzhen KingBoard Technology Co., Ltd. Address Bldg. A, Dakanglong Industry Zone, Dabuxiang, Guanlan, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 51 Report No.: CTL1412052939-WF Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 6 2.5. EUT configuration 6 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Fundamental Emissions 14 4.3. Transmitter Radiated Unwanted Emissions 15 4.4. Band Edge Measurement 31 4.5. Occupied Bandwidth Measurement 40 5. ANTENNA REQUIREMENT ....................................................... 44 6. TEST SETUP PHOTOS OF THE EUT .......................................... 45 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 47 V1.0 Page 4 of 51 Report No.: CTL1412052939-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 V1.0 Page 5 of 51 Report No.: CTL1412052939-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Dec. 05, 2014 Testing commenced on : Dec. 05, 2014 Testing concluded on : Dec. 15, 2014 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.7V from battery 2.3. Short description of the Equipment under Test (EUT) The EUT is a Bluetooth Speaker work at 2402~2480 MHz support Bluetooth 2.1+EDR. Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 77 2479 24 2426 51 2453 78 2480 25 2427 52 2454 26 2428 53 2455 Modulation: 1Mbps(GFSK), 2Mbps(Pi/4 DQPSK), 3Mbps(8DPSK) For more details, refer to th…
