SZO-RR03Active Timing System

1 Manual RR03 Transponder 2 Imprint HEADQUARTER GERMANY race result AG Joseph-von-Fraunhofer-Str. 11 D-76327 Pfinztal Phone +49 (721) 961 409 00 [email protected] Product Model: RR03 Regulatory FCC 15.21 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation. RSS GEN Issue 5 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences (2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement indésirable de l'appareil. 3 1. Description ...................................................................................................................................... 4 2. Mounting the Transponder ............................................................................................................. 4 2.1 Activation Orientation of the ActiveBasic ............................................................................... 5 3. Modes .............................................................................................................................................. 6 3.1 Tracking Mode ......................................................................................................................... 6 3.1.1 Activating the Tracking Mode ......................................................................................... 6 3.1.2 Deactivating the Tracking Mode ..................................................................................... 7 3.2 Store Mode .............................................................................................................................. 7 3.2.1 Activating the Store Mode .............................................................................................. 7 4. Battery ............................................................................................................................................. 8 4.1 Active Transponder Battery Testing ........................................................................................ 8 4.2 Getting the best Active Transponder Battery Life ................................................................... 9 4.2.1 Transponder Activation ................................................................................................... 9 4.2.2 Temperature .................................................................................................................... 9 4.2.3 Tracking ........................................................................................................................... 9 4.2.4 Deep Sleep Mode .......................................................................................................... 10 4.2.5 Storage of Transponders ............................................................................................... 10 5. Technical Details ............................................................................................................................ 10 4 The RR03 transponder is an active transponder for time keeping in different sports. There are 4 variants of the transponder which are suitable for different sports or different needs. ActiveBasic V3 The AvtiveBasic V3 is designed for clubs and events that appreciate the reliability of active technology but don’t have high accuracy needs. ActivePro V3 (Endurance) The AvtivePro V3 (Endurance) combines high accuracy and speed with long battery life, store mode and tracking. ActivePro V3 Performance The ActivePro V3 Performance is the high end version of the transponder, designed for pro races. It delivers the highest accuracy, most stable data transmission in sprint finishes, additional tracking data and store mode. MotorKart V3 The MotorKart V3 transponder is designed for the timing of go-karts, optimized to avoid electrical interferences at detection heights smaller than 0.5 m. It ensures highest reliability and precision over tens of thousands of rounds of kart racing. For more information, see chapter Technical Details. CAUTION Make sure that the active transponder is at least 5 mm away from the body after it is attached. Active Transponders can be worn in different ways: Active Chip Holder When fixing to a bike or go-kart, we recommend using the Active Chip Holder to separate the transponder and any metal parts which may impact the transponder activation. There are three ways how to attach the holder: • Use one of the O rights to attach it to a pipe. • Feed a cable strap through the holes. • Use a screw. 5 Velcro® Strap The transponder can be worn on a Velcro® Strap, e. g. on the ankle. NOTE: When you are using a Velcro® Strap, make sure the transponder code facing outwards and the strap is not covering the transponder. Shoelaces The transponder can be tied directly in the shoelaces of your shoes. The ActiveBasic transponder has a 1-directional activation field. This means it will only be activated reliably when orientated the correct way. NOTE: This does not apply to the ActivePro or MotorKart transponders. Simple rule of thumb: You must be able to read the transponder code…

Text truncated - open the document above for the full version.

CSA Group - External Date: 2023-04-04 FCC FRN: 0033425919 Date of Filing with TCB: March 13, 2023 FCC FRN: 0024039364

Antenna Report Manufacturer: race result AG Type: Custom PCB Antenna Max. Gain: 0 dBi +/-1 dB RR03 PCB Antenna Gain in dBi Gain in dBi xy-horizontal plane xy-vertical plane Legend: Radiation Patterns of PCB Antenna y x z Gain in dBi Gain in dBi xz-horizontal plane xz-vertical plane Gain in dBi Gain in dBi yz-horizontal plane yz-vertical plane

Nonroutine Long-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 4 April 2023 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: SZO-RR03 IC: 20465-RR03 HVIN: RR03 To Whom it may concerns, Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rule and KDB726920, we hereby request nonroutine long-term confidential treatment of information accompanying this application as outlined below: ☒ Internal Photos of a consumer device where the circuit board is enclosed in epoxy or in a material that would destroy the circuit board if removed, or the device is sealed and disassembly would destroy the product. ☐ Internal Photos of a non-consumer device where the device is not accessible to the general public (for example a device mounted on the top of a large tower or in a fenced enclosure that is only serviceable by the licensee or designated technicians). ☐ Installation Manual is very technical and is not provided to the consumer because the consumer cannot service the device. ☐ Integration Manual is not made available to the public as this module is solely integrated by our company in our own final products and will not be sold to any other integrators. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. If you have any questions, please feel free to contact me. Yours sincerely, Christa Jäger Project Coordinator GMA

/ HVIN: RR03

The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-00 to 80149824-07, page 1 of 6 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 5.0, 2020-02-11 Attachment A Type / Model Name : RR03 Product Description : Active Timing System Applicant : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany Manufacturer : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany according to Test Report No. : 80149824-00 to 80149824-07 13. March 2023 ______________________________________________________________________________________________ Date of issue The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-00 to 80149824-07, page 2 of 6 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 5.0, 2020-02-11 Contents 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 3 1.1 EUT ZZZZZ12 (Radiated, Battery) 3 1.2 EUT ZZZZZ107 (Radiated, External Voltage) 4 1.3 EUT ZZZZZ67 (Conducted, External Voltage) 5 1.4 Companion Device 6 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-00 to 80149824-07, page 3 of 6 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 5.0, 2020-02-11 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 1.1 EUT ZZZZZ12 (Radiated, Battery) The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-00 to 80149824-07, page 4 of 6 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 5.0, 2020-02-11 1.2 EUT ZZZZZ107 (Radiated, External Voltage)

Front* Back Side1* Side2 Side3* Side4 Product Variant RACE RESULT Active Pro Performance Transponder RACE RESULT ActivePro (Endurance) Transponder RACE RESULT ActiveBasic Transponder RACE RESULT MotorKart Transponder RACE RESULT Active Pro Performance Transponder RACE RESULT ActivePro (Endurance) Transponder RACE RESULT Active Pro Performance Transponder RACE RESULT ActivePro (Endurance) Transponder * The unit of measurement of the ruler shown is centimeter.

RR03 – Label The label information on the picture is raised. It may be engraved later. The positioning of the FCC ID, IC ID and model number remains on the top.

The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-05 Rev_2, page 1 of 10 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.3, 2021-11-03 R F − T E S T R E P O R T - Human Exposure - Type / Model Name : RR03 Product Description : Active Timing System Applicant : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany Manufacturer : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany Test Result according to the standards listed in clause 1 test standards: POSITIVE Test Report No. : 80149824-05 Rev_2 15. May 2023 ______________________________________________________________________________________________ Date of issue The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-05 Rev_2, page 2 of 10 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.3, 2021-11-03 Contents 1 T E S T S T A N D A R D S 3 2 E Q U I P M E N T U N D E R T E S T 4 2.1 Information provided by the Client 4 2.2 Sampling 4 2.3 General remarks 4 2.4 Photo documentation of the EUT – Detailed photos see attachment A 4 2.5 Equipment category 4 2.6 Short description of the equipment under test (EUT) 4 2.7 Variants of the EUT 4 2.8 Operation frequency and channel plan 4 2.9 Transmit operating modes 5 2.10 Antenna 5 2.11 Power supply system utilised 5 2.12 Peripheral devices and interface cables 5 2.13 Determination of worst-case conditions for final measurement 5 3 T E S T R E S U L T S U M M A R Y 6 3.1 Revision history of test report 6 3.2 Final assessment 6 4 T E S T E N V I R O N M E N T 7 4.1 Address of the test laboratory 7 4.2 Environmental conditions 7 4.3 Statement of the measurement uncertainty 7 5 H U M A N E X P O S U R E 8 5.1 SAR test exclusion considerations 8 5.2 Exemption limits for routine evaluation - SAR evaluation 9 ATTACHMENT A as separate supplement The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-05 Rev_2, page 3 of 10 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.3, 2021-11-03 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 1, Subpart I - Procedures Implementing the National Environmental Policy Act of 1969 Part 1, Subpart I, Section 1.1310 Radiofrequency radiation exposure limits Part 1, Subpart 2, Section 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. Part 1, Subpart 2, Section 2.1093 Radiofrequency radiation exposure evaluation: portable devices. KDB 447498 D01 RF Exposure procedures and equipment authorisation policies for mobile and portable devices, April 20, 2021. ANSI C95.1: 2005 IEEE Standard for Safety Levels with respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz ETSI TR 100 028 V1.3.1: 2001-03, Electromagnetic Compatibility and Radio Spectrum Matters (ERM); Uncertainties in the Measurement of Mobile Radio Equipment Characteristics—Part 1 and Part 2 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-05 Rev_2, page 4 of 10 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.3, 2021-11-03 2 E Q U I P M E N T U N D E R T E S T 2.1 Information provided by the Client Please note, we do not take any responsibility for information provided by the client or his representative which may have an influence on the validity of the test results. 2.2 Sampling The customer is responsible for the choice of sample. Sample configuration, start-up and operation is carried out by the customer or according his/her instructions. 2.3 General remarks None. 2.4 Photo documentation of the EUT – Detailed photos see attachment A 2.5 Equipment category EUT is a low power 2.4 GHz transceiver. 2.6 Short description of the equipment under test (EUT) The active timing system is used for time measurements in sport events and consists of the RR02 (base station) and the RR03 (transponder). RR02 and a 125 kHz loop antenna is placed on the time measurement position. The RR03 is attached to the participant of the event or their equipment. The 125 kHz signal triggers a 2.4 GHz transmission between the RR02 and the RR03. This message contains the required information and is stored. The functions of the RR03 are controlled by the 125 kHz signal of the RR02. Number of tested samples: 2 Serial number: ZZZZZ107 (Radiated sample, external power supply) ZZZZZ67 (Conducted sample, external power supply) 2.7 Variants of the EUT There are no variants. 2.8 Operation frequency and channel plan The operating frequency band is 2400 MHz to 2483.5 MHz. Main Backup Channel Frequency (MHz) Channel Frequency (MHz) 0 2480 8 2410 1 2405 9 2470 2 2425 10 2465 3 2475 11 2440 4 2415 12 2445 5 2460 13 2430 6 2435 14 2455 7 2450 15 2420 The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-05 Rev_2, page 5 of 10 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.3, 2021-11-03 2.9 Transmit operating modes The EUT allows free selection of main channel and following transmit modes: - TX continuous, unmodulated - Communica…

Text truncated - open the document above for the full version.

The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . CSA Group Bayern GmbH File No. 80149824-04 Rev_2, page 1 of 27 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.5, 202111--05 R F − T E S T R E P O R T - FCC Part 15.249, RSS-210 - Type / Model Name : RR03 Product Description : Active Timing System (HVIN: RR03) Applicant : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany Manufacturer : race result AG Address : Joseph-von-Fraunhofer-Straße 11 76327 Pfinztal, Germany Test Result according to the standards listed in clause 1 test standards: POSITIVE Test Report No. : 80149824-04 Rev_2 17. May 2023 ______________________________________________________________________________________________ Date of issue The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . FCC ID: SZO-RR03 IC ID: 20465-RR03 CSA Group Bayern GmbH File No. 80149824-04 Rev_2, page 2 of 27 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.5, 202111--05 Contents 1 T E S T S T A N D A R D S 3 2 E Q U I P M E N T U N D E R T E S T 4 2.1 Information provided by the Client 4 2.2 Sampling 4 2.3 General remarks 4 2.4 Photo documentation of the EUT – Detailed photos see Attachment A 4 2.5 Equipment category 4 2.6 Short description of the equipment under test (EUT) 4 2.7 Variants of the EUT 4 2.8 Operation frequency and channel plan 4 2.9 Transmit operating modes 5 2.10 Antenna 5 2.11 Power supply system utilised 5 2.12 Peripheral devices and interface cables 5 2.13 Determination of worst-case conditions for final measurement 5 3 T E S T R E S U L T S U M M A R Y 6 3.1 Revision history of test report 6 3.2 Final assessment 6 4 T E S T E N V I R O N M E N T 8 4.1 Address of the test laboratory 8 4.2 Environmental conditions 8 4.3 Statement of the measurement uncertainty 8 4.4 Conformity Decision Rule 9 4.5 Measurement protocol for FCC and ISED 9 5 T E S T C O N D I T I O N S A N D R E S U L T S 12 5.1 AC power line conducted emissions 12 5.2 Field strength of fundamental 12 5.3 Spurious Emissions, radiated 16 5.4 Occupied bandwidth 23 5.5 Antenna application 26 6 U S E D T E S T E Q U I P M E N T A N D A C C E S S O R I E S 27 ATTACHMENT A as separate supplement The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . FCC ID: SZO-RR03 IC ID: 20465-RR03 CSA Group Bayern GmbH File No. 80149824-04 Rev_2, page 3 of 27 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.5, 202111--05 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15, Subpart A - General (February 2023) Part 15, Subpart A, Section 15.31 Measurement standards Part 15, Subpart A, Section 15.33 Frequency range of radiated measurements Part 15, Subpart A, Section 15.35 Measurement detector functions and bandwidths FCC Rules and Regulations Part 15, Subpart C - Intentional Radiators (February 2023) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.205 Restricted bands of operation Part 15, Subpart C, Section 15.207 Conducted limits Part 15, Subpart C, Section 15.209 Radiated emission limits, general requirements Part 15, Subpart C, Section 15.215 Additional provisions to the general radiated emission limitations Part 15, Subpart C, Section 15.249 Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz ANSI C63.10: 2013 Testing Unlicensed Wireless Devices The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permissi on of the test laboratory . FCC ID: SZO-RR03 IC ID: 20465-RR03 CSA Group Bayern GmbH File No. 80149824-04 Rev_2, page 4 of 27 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 6.5, 202111--05 2 E Q U I P M E N T U N D E R T E S T 2.1 Information provided by the Client Please note, we do not take any responsibility for information provided by the client or his representative which may have an influence on the validity of the test results. 2.2 Sampling The customer is responsible for the choice of sample. Sample configuration, start-up and operation is carried out by the customer or according his/her instructions. 2.3 General remarks None. 2.4 Photo documentation of the EUT – Detailed photos see Attachment A 2.5 Equipment category EUT is a low power 2.4 GHz transceiver. 2.6 Short description of the equipment under test (EUT) The active timing system is used for time measurements in sport events and consists of the RR02 (base station) and the RR03 (transponder). RR02 and a 125 kHz loop antenna is placed on the time measurement position. The RR03 is attached to the participant of the event or their equipment. The 125 kHz signal triggers a 2.4 GHz transmission between the RR02 and the RR03. This message contains the required information and is stored. The functions of the RR03 are controlled by the 125 kHz signal of the RR02. Number of tested samples: 2 Serial number: ZZZZZ107 (Radiated sample, external power supply) ZZZZZ67 (Conducted sample, external power supply) 2.7 Variants of the EUT RACE RESULT ActivePro Performance Transponder (red, cyan or orange) RACE RESULT ActivePro Endurance Transponder (red, cyan or orange) RACE RESULT ActiveBasic Transponder (blue) RACE RESULT MotorKart Transponder (grey) 2.8 Operation frequency and channel plan The ope…

Text truncated - open the document above for the full version.

Page 1 of 4 Internal Test Setup Photos (FCC §15.249 / RSS 210) Extract from Test Report 80149824-04 issued by CSA Group Bayern GmbH Field Strength of Fundamental Page 2 of 4 Internal Spurious Emissions, radiated Page 3 of 4 Internal Page 4 of 4 Internal Occupied Bandwidth
