SZQ-T100Wireless charger

4 1 Power-up the VÜ by attaching the charging cord to the charging port located on the underside of the unit. Plug the charger into a wall socket for power. 2 3 Specifications: Input: 12V / 750mA Output: 5W Included: VÜ Pad AC Power Supply Users guid e ©2013 TYLT. All rights reserved. TYLT® and the TYLT® logo are registered trademarks of Foreign Trade Corp. Other marks are the property of their respective owners. IC2094A Charging Platform LED Indicator Light Cord Slot Charging Port AC Power Supply Place your Qi™ compatible device on the VÜ pad to begin charging. While the VÜ pad is charging a device, the Green LED will turn on. Upon completion of charge, the LED will turn off. Under any type of error condition, the Red LED will turn on. In case of an error condition, remove the phone and place it back on the pad. If this does not solve the problem, unplug the VÜ from the AC charger and re-connect it. NOTE: If the Red LED blinks and does not stay solid, the error condition has been automatically resolved Standby Error! Charging LED indicator light VÜ WIRELESS CHARGING PAD User Guide 1. The VÜ is for charging wireless charging enabled and Qi™Charging Standard compatible smartphones only. 2. The charging unit should only be used at normal indoor room conditions. 3. Place charger on a hard flat surface. 4. Never use any power cable and transformer other than those originally supplied with the charging unit. 5. The VÜ may become hot during charging. Avoid direct contact with highly flammable materials. Avoid contact with fine furniture finishes. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. CAUTIONS: - Place charger on a hard flat surface. - When cleaning the charger, use a soft damp cloth only. Do not wet the exposed metal part of the charging unit. Do not use solvents or scouring agents as they may mark the LED and casing. - Do not submerge in water or rinse under faucet. - Keep the device dry. Precipitation, humidity, liquids and moisture can contain minerals that corrode electronic circuits. - If the device gets wet, immediately unplug it and allow it to dry - Do not disassemble or make any repair attempts to the unit. -Do not store the device in high or low temperatures. CARE AND MAINTENANCE: For more information on the VÜ, wireless charging, Qi ™ Charging Standard and a list of compatible smartphones, please visit: www.TYLT.com/VÜ • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules [and with RSS-210 of Industry Canada]. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. To comply with FCC and other RF exposure requirements, please maintain a distance of 20cm between the charger and your body when in use. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Changes or modifications made to this equipment not expressly approved by the manufacturer may void the FCC authorization to operate this equipment. FCC ID: SZQ-T100 2 Sided 6 panel folded User Guide 4/4 (CMYK) 3.5“ inches 21“ inches 2.125” inches FOLDFOLDFOLDFOLD FOLDFOLDFOLDFOLD FOLD FOLD

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 5/3-2013 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name SZQ-T100 VUXX-T For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Vahid Zarie CTO ( Chief Technical Officer)

Federal Communication Commission Equipment Authorization Devision, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 5/3-2013 TO WHOM IT MAY CONCERN FCC ID: SZQ-T100 We the undersigned hereby authorize Salcomp Inc and Cetecom Inc to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Salcomp Inc and Cetecom Inc, on our behalf shall have the same effect as acts of our own. The authorization is valid for 90 days from the date of this letter. Sincerely, Vahid Zarie CTO ( Chief Technical Officer)

Annex 1 to Test Report 6-0333-1-2d, Page 1 of 4 TR6-0333-13-1-2d-A1.docx Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 1: External photographs of EUT to TEST REPORT No.: 6-0333-13-1-2d Wireless Charger VUBK-T FCC-ID: SZQ-T100 According to: FCC Regulations §1.1310 §1.1307(b) § 2.1091 & 2.1093 Salcomp(Shenzhen)Co., Ltd. for Annex 1 to Test Report 6-0333-1-2d, Page 2 of 4 TR6-0333-13-1-2d-A1.docx Table of contents 1. External EUT Photographs Photograph 1: Equipment under test , right side Photograph 2: Equipment under test, left side Annex 1 to Test Report 6-0333-1-2d, Page 3 of 4 TR6-0333-13-1-2d-A1.docx Photograph 3: Equipment under test, under side Photograph 4: Auxiliary equipment under test Annex 1 to Test Report 6-0333-1-2d, Page 4 of 4 TR6-0333-13-1-2d-A1.docx Photograph 5: Auxiliary equipment under test

Version Date/Sign CR No. Material: Colour: Product: Title: Scale Associated Sys CorelDRAW13 Design Draw Check Appd WLS1 PAD Type label_FCC ID 2:1 01.04.13 02.05.13 Dwang Dwang Code: Zz1248 See Note(Material description) See Note(Material description) Draw: 600606 FCC ID: SZQ-T100 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and that may cause undesired (2)this device must accept any interference received, including interference operation. 50.5+/-0.2 mm 55.1+/-0.2 mm 44.6+/-0.2 mm Version Date/Sign CR No. Material: Colour: Product: Title: Scale Associated Sys CorelDRAW13 Design Draw Check Appd WLS1 PAD Type label_SW01A00B_Universal_Black 1:1 01.11.12 02.05.13 Dwang Dwang Code: Zz1241 See Note(Material description) See Note(Material description) Draw: 600600 Scan 1:1 Note: YY = Year,2 digits (12=2012, 13=2013, 14=2014,etc.) MM= Month, 2 digits from 01-12 SS= Series number 6 digits staring from 0...01 every month LL= Production line number , 2 digits ... YYMMSSSSSSLL Material description: 1. Material: 0.05mm matte silver PET film; 2. Surface: 0.025mm matte transparent OPP film; 3. Printing: Black background; 4. Material must fulfill Gwi 4-11 Salcomp Hazardous Substances Management Standard latest version. 41+/-0.2 mm 55.9+/-0.2 mm 31.2+/-0.2 mm Red content print by Salcomp -'VL, M ode':VUB K -T 'nput:DC 12V= 7S0rnA Output:5W ~ FCC ID:SZQ-Tl 00 "'----.J q i C~ ~f.~ ~ 11!l: : I --­-­.. . 1 «{<!»» W IRELES S POWER •••'In

Annex 2 to Test Report 6-0333-13-1-2d, Page 1 of 3 TR6-0333-13-1-2d-A2.docx Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 2: Internal photographs of EUT to TEST REPORT No.: 6-0333-13-1-2d Wireless Charger VUBK-T FCC-ID: SZQ-T100 According to: FCC Regulations §1.1310 §1.1307(b) § 2.1091 & 2.1093 Salcomp(Shenzhen)Co., Ltd. for Annex 2 to Test Report 6-0333-13-1-2d, Page 2 of 3 TR6-0333-13-1-2d-A2.docx Table of contents 1. Internal EUT Photographs Photograph 1: Adapter WLS1_PCB Bottom Photograph 2: Adapter WLS1_PCB Top Annex 2 to Test Report 6-0333-13-1-2d, Page 3 of 3 TR6-0333-13-1-2d-A2.docx Photograph 3: WLS1_PCB bottom Photograph 4: WLS1_PCB top

Annex 1 to Test Report 6-0333-1-2b, Page 1 of 4 TR6-0333-13-1-2b-A1.docx Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 1: External photographs of EUT to TEST REPORT No.: 6-0333-13-1-2b Wireless Charger VUBK-T FCC-ID: SZQ-T100 According to: FCC Regulations Part 15.207, Part 15.209 IC-Regulations RSS-Gen, Issue 3 Salcomp(Shenzhen)Co., Ltd. for Annex 1 to Test Report 6-0333-1-2b, Page 2 of 4 TR6-0333-13-1-2b-A1.docx Table of contents 1. External EUT Photographs Photograph 1: Equipment under test , right side Photograph 2: Equipment under test, left side Annex 1 to Test Report 6-0333-1-2b, Page 3 of 4 TR6-0333-13-1-2b-A1.docx Photograph 3: Equipment under test, under side Photograph 4: Auxiliary equipment under test Annex 1 to Test Report 6-0333-1-2b, Page 4 of 4 TR6-0333-13-1-2b-A1.docx Photograph 5: Auxiliary equipment under test

Annex 2 to Test Report 6-0333-13-1-2b, Page 1 of 3 TR6-0333-13-1-2b-A2.docx Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 2: Internal photographs of EUT to TEST REPORT No.: 6-0333-13-1-2b Wireless Charger VUBK-T FCC-ID: SZQ-T100 According to: FCC Regulations Part 15.207, Part 15.209 IC-Regulations RSS-Gen, Issue 3 Salcomp(Shenzhen)Co., Ltd. for Annex 2 to Test Report 6-0333-13-1-2b, Page 2 of 3 TR6-0333-13-1-2b-A2.docx Table of contents 1. Internal EUT Photographs Photograph 1: Adapter WLS1_PCB Bottom Photograph 2: Adapter WLS1_PCB Top Annex 2 to Test Report 6-0333-13-1-2b, Page 3 of 3 TR6-0333-13-1-2b-A2.docx Photograph 3: WLS1_PCB bottom Photograph 4: WLS1_PCB top

Page 1 of 12 The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Laboratory Accreditation and Listings Reg. No.: 736496 MRA US-EU 0003 Industry Canada Reg. No.: 3462D-1 Reg. No.: 3462D-2 Reg. No.: 3462D-3 Voluntary Controls for Electromagnetic Emissions Reg. No.: R-2665, R-2666 C-2914, T-1967, G-301 accredited according to DIN EN ISO/IEC 17025 CETECOM GmbH Laboratory Radio Communications & Electromagnetic Compatibility Im Teelbruch 116 • 45219 Essen • Germany Registered in Essen, Germany, Reg. No.: HRB Essen 8984 Tel.: + 49 (0) 20 54 / 95 19-954 • Fax: + 49 (0) 20 54 / 95 19-964 E-mail: [email protected] • Internet: www.cetecom.com Annex 4: Measurement diagrams to TEST REPORT No.: 6-0333-13-1-2b Wireless Charger VUBK-T FCC-ID: SZQ-T100 According to: FCC Regulations Part 15.207, Part 15.209 IC-Regulations RSS-Gen, Issue 3 Salcomp(Shenzhen)Co., Ltd. for Annex 4 to Test Report 6-0333-13-1-2b, Page 2 of 12 TR6-0333-13-1-2b-A4.docx Table of contents 1. MEASUREMENT RESULTS ............................................................................................................................. 3 1.1. Emission measurements on AC-mains ............................................................................................................ 3 1.2. Magnetic field strength measurement ( 9kHz < f < 30MHz) ........................................................................... 6 1.3. Electric field measurements ( 30MHz < f < 1GHz) ......................................................................................... 10 1.4. Occupied 99% bandwidth ................................................................................................................................ 12 Annex 4 to Test Report 6-0333-13-1-2b, Page 3 of 12 TR6-0333-13-1-2b-A4.docx 1. Measurement results 1.1. Emission measurements on AC-mains Diagram No. 1.02 Test Description: Date: 04.04.2013 Page 1 of 3 Test Description: Ref.-Nr. 348, Conducted Voltage Measurement Class B Version of Testsoftware: EMC32 V8.52.0 Testspecification: FCC 15.107, FCC 15.207 Technical Data: Please see next page for detailed information Diagram: Shows the peak values as a sum of measured ports (N+L1) in maxhold mode Operator name: Mar Report.- Nr. 6-0333-13-1 EUT: WLS-1 Manufacturer: Salcomp Operating mode: charging mode Measured on line: Mains AC L1 and N Power during test: 110 V AC 60 Hz Comment 1: Comment 2: 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 150 k 30 040 050 0 80 01M2M3M4M5M6 810M20 M30 M Le vel i n dB μV F re q u e n c y in H z 0 1 b _ F C C _ 1 0 7 _ 2 0 7 _ C la ss B _ V o lt a g e _ P K _ Q P A V _ N _ L 1 Cla ss B Vo lt a ge QP Cla ss B Vo lt a ge AV Annex 4 to Test Report 6-0333-13-1-2b, Page 4 of 12 TR6-0333-13-1-2b-A4.docx Date: 04.04.2013 Page 2 of 3 Final Result 1 Frequency (MHz) QuasiPeak (dBμV) Meas. Time (ms) Bandwidth (kHz) PE Line Corr . (dB) Margin (dB) Limit (dBμV) 0.155000 49.6 1000.0 9.000 GND N 0.1 16.2 65.7 0.155000 49.7 1000.0 9.000 GND N 0.1 16.1 65.7 0.232344 42.7 1000.0 9.000 GND L1 0.1 19.6 62.4 0.436563 45.8 1000.0 9.000 GND N 0.1 11.4 57.1 0.569844 42.4 1000.0 9.000 GND N 0.1 13.6 56.0 0.585000 42.1 1000.0 9.000 GND N 0.1 13.9 56.0 0.624688 41.2 1000.0 9.000 GND L1 0.2 14.8 56.0 0.729531 45.0 1000.0 9.000 GND L1 0.2 11.0 56.0 0.875156 40.0 1000.0 9.000 GND L1 0.3 16.0 56.0 1.022500 47.3 1000.0 9.000 GND N 0.3 8.8 56.0 1.167031 41.2 1000.0 9.000 GND N 0.3 14.8 56.0 1.316563 47.9 1000.0 9.000 GND N 0.3 8.1 56.0 1.461094 43.1 1000.0 9.000 GND N 0.3 13.0 56.0 1.609531 48.2 1000.0 9.000 GND N 0.3 7.8 56.0 1.754063 41.3 1000.0 9.000 GND L1 0.3 14.7 56.0 1.902500 48.0 1000.0 9.000 GND N 0.3 8.0 56.0 2.195469 47.1 1000.0 9.000 GND N 0.3 8.9 56.0 2.488438 45.3 1000.0 9.000 GND N 0.2 10.7 56.0 2.781406 43.4 1000.0 9.000 GND N 0.3 12.6 56.0 4.679844 40.4 1000.0 9.000 GND N 0.4 15.6 56.0 Final Result 2 Frequency (MHz) CAverage (dBμV) Meas. Time (ms) Bandwidth (kHz) PE Line Corr . (dB) Margin (dB) Limit (dBμV) 0.155000 31.6 1000.0 9.000 GND N 0.1 24.1 55.7 0.155000 31.5 1000.0 9.000 GND N 0.1 24.2 55.7 0.232344 21.2 1000.0 9.000 GND L1 0.1 31.1 52.4 0.436563 42.4 1000.0 9.000 GND N 0.1 4.7 47.1 0.569844 32.1 1000.0 9.000 GND N 0.1 13.9 46.0 0.585000 32.9 1000.0 9.000 GND N 0.1 13.1 46.0 0.624688 23.7 1000.0 9.000 GND L1 0.2 22.3 46.0 0.729531 40.7 1000.0 9.000 GND L1 0.2 5.3 46.0 0.875156 31.5 1000.0 9.000 GND L1 0.3 14.5 46.0 1.022500 44.0 1000.0 9.000 GND N 0.3 2.0 46.0 1.167031 34.6 1000.0 9.000 GND N 0.3 11.4 46.0 1.316563 44.6 1000.0 9.000 GND N 0.3 1.4 46.0 1.461094 37.5 1000.0 9.000 GND N 0.3 8.5 46.0 1.609531 44.7 1000.0 9.000 GND N 0.3 1.3 46.0 1.754063 35.6 1000.0 9.000 GND L1 0.3 10.4 46.0 1.902500 44.5 1000.0 9.000 GND N 0.3 1.5 46.0 2.195469 43.4 1000.0 9.000 GND N 0.3 2.6 46.0 2.488438 41.5 1000.0 9.000 GND N 0.2 4.5 46.0 2.781406 39.1 1000.0 9.000 GND N 0.3 6.9 46.0 4.679844 34.7 1000.0 9.000 GND N 0.4 11.3 46.0 Technical Data of Measurements with R&S EMC32 V8.52.0 EMI Auto Test Template: 01b_FCC_107_207_Class B_Voltage_PK_QPAV_N_L1 Hardware Setup: ESH2-Z5 Measurement Type: 4 Line LISN Frequency Range: 150 kHz - 30 MHz Graphics Level Range: 0 dBμV - 90 dBμV Preview Measurements: Scan Test Template: 02_Class B pre_PK_fast Subrange Step Size Detectors IF BW Meas. Time Preamp 9 kHz - 150 kHz 61.035 Hz PK+ 200 Hz 0,00005 s 0 dB 150 kHz - 30 MHz 3.906 kHz PK+ 9 kHz 0,00005 s 0 dB Receiver: [ESCS 30] Annex 4 to Test Report 6-0333-13-1-2b, Page 5 of 12 TR6-0333-13-1-2b-A4.docx Data Reduction: Limit Line #1: Class B Voltage QP Limit Line #2: Class B Voltage AV Peak Search: 6 dB , Maximum Results: 10 Subrange Maxima: 25 Subranges , Maxima per Subrange: 1 Acceptance Offset: -13 dB Maximum Number of Results: 30 After Data Reduction: Interactive data reduction Frequency Zoom: Zoom Scan Template: 08_Class B maxZoom_PK100mS Subrange Ste…
