T38A1033GSM/GPRS + Bluetooth Mobile phone

1 Introduction 1.1 Phone Display We continuously strive to improve our products. Therefore, we reserve the rights to revise this user manual or withdraw it at any time without prior notice. 1.2 Key Key Function Dial / Answer Key Press to answer a call or make a call after you enter a phone number. In idle mode, press to view the call log. End / Power Key Press to end a call. Press and hold to turn the phone on/off. Within a menu, press to return to idle mode. 2 Left Soft Key In idle mode, press to enter the Main Menu. Press to access the option listed directly above it on the display. Right Soft Key In idle mode, press to access the Call ce n ter. Press to access the option listed directly above it on the display. Within a menu, press to return to the previous screen. OK Key In idle mode, press to enter the Internet se rvice. Press to confirm a selection. Numeric key Press to enter the corresponding number, letter or symbol located on the key. Within a menu, press to access the corresponding menu option. *Key Press the * Key twice quickly to enter ‘+’ to make an international call. Press and hold the * Key to toggle between *, +, (pause character) P, and (wait character) W. Press to enter symbol when editing text. #Key In idle mode, press and hold to activate or deactivate the silent mode. Press to switch input modes when entering text. Navigation Key Within a menu, press Up, Down, Left or Right to scroll through menu options. Note: “Press” in this manual, means to press and release the key; “press and hold” means to press and hold the key for at least 2 seconds. 1.3 Icons & Symbols Icon Description Ne t wo r k - The left portion indicates whether your phone is already registered with a network and the right portion indicates signal strength (from no signal to strongest). Battery - Indicates battery level. When charging, a scrolling icon will be displayed. The more bars, the stronger the charge. 3 To log onto GPRS - The icon will be displayed only when you have logged onto GPRS. MMS - Indicates you have one or more unread MMS messages. Message - Indicates you have one or more unread messages. Push Message-Indicates that you have received a ne w push message. Voicemail- Indicates voice messages that have not been heard. Missed Call - Indicates there is a missed call. Call Divert - Indicates that “Divert All Voice Calls” is activated. Alarm-Indicates that the alarm clock is on. Headset-Indicates that headset profile is activated. Alert type is “Ring”. 2 Getting Started Please read the safety instructions in the "Safety Information and Notices" section before use. 2.1 Inserting the SIM Card 2.1.1 Remove the back cover(1), remove the batte r y (2), an d inse rt the SIM car d (3) (1) 4 (2) (3) 2.1.2 Install the batter y (4 ) and back cover (5) (4) (5) 2.2 Turning the phone on To turn the phone on, press and hold the End / Power key. Enter the PIN code if required. 2.3 Charging the Battery 1. To charge the battery, plug in the charger connector at the bottom of your phone (USB interface) and then plug the other end into an AC power socket. 2. The battery symbol indicates the charging status. While charging, the charge indicators will scroll. 3. Disconnect the charger from the phone. 4. Disconnect the charger from the AC power socket. 5 Note: If the battery is powerless, the battery icon will reappear after a few minutes of charging. 2.4 Inserting a T-Flash Card With the metal contacts facing down, gently slide the T-F lash card into the slot. 2.5 Important Password Phone lock password is 1234. 3 Text Entry 3.1 Input Method During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Options] and select Input me thod to select different input modes. 3.1.1 Entering Symbols In any input mode, press the * Key to open the symbols input screen. 3.2 Smar t Input Method 2 to 9 Press to input letters. 1 Press to input symbol. 0 Press to input space. ◀/▶ Press to confirm the letter or word, or move the cursor to the left or right. ▲/▼ Press to browse the last or next available 6 word. Left Soft Key (Select) or the OK Key Press to confirm the letter or word. Right Soft Key (Clear) Press to clear a letter, press and hold to clear all entries. # Switch between input mode. * Press to activate punctuation mode Example: How to enter the word "HOME" 1. Press the # Key to switch toABC; 2. Press 4 6 6 3, the first word “GOOD” appears; 3. Press ▶ to browse and select “HOME”; 4. Press the Left Soft Key [Select] or OK Key to confirm “HOME”. 3.3 Mu lt i-tap Input Using this mode requires you to press a key as many times as needed to enter the desired letter. To enter the word “casa” in Multi-tap input mode “ abc”, pr e ss key 2 (ABC) three times, press 2 (ABC) once, press key 7 (PQRS) four times, press key 2 (ABC) once. 3.4 Numer ic Input Press the # Key to select "123" then you can enter the numbers. 4 Calling 4.1 Mak ing a Call Note: You can make a call only when the network name appears on the screen. 1. In idle mode,enter the phone number. 2. Press the Dial / Answer Key to dial the number. 3. Press the End / Power Key to end the call. Note: During a call, press the Navigation Key Up/Down to adjust the volume. 7 You can press the Left Soft Key [Options] to choose Sound Re corder. Note: In most countries, recording telephone conversations is subject to legislation. We advise you to notify the caller if you intend to record your conversation and only do so if they agree. 4.2 Making an International Call 1. Press the * Key twice quickly until "+" appears on the screen. 2. Enter the country code. 3. Enter the area code (normally without the 0 before it) followed by the phone number. 4. Press the Dial / Answer Key to call directly. 4.3 Answering or Rejecting a incoming Call 1. Press the Dial / Answer Key to answer a call. 2. Press the End / Power key to reject a call. 5 Function Menu 5.1 Main Menu STK Messaging Call center Fun & Games Services Phonebook Organizer Multimedia Settings 5…

Text truncated - open the document above for the full version.

ZTE Corporation Reliability Testing Center, Address: 1/F, B2 Wing, ZTE Plaza, Keji Road South, Hi-Tech industrial park, Shenzhen, Guangdong, 518057, China Company Registration Number ： 373926 Declaration We, ZTE Corporation Reliability Testing Center the undersigned hereby declare, that the test performed by ZTE Corporation Reliability Testing Center to the following Report No(project).: 20120916FCC-B（Test Radiated Emission (9kHz ~ 30MHz)） The Test Results relate only to the samples tested. - Point of contact: Jennie He TEL: 0086-755-2677 7735 FAX: 0086-755-2677 0347 E-mail: [email protected]; (Name, telephone and fax number) shenzhen Date: 2012/9/25 (Place, date of issue) (Signature) Jennie / Manager (Name and title in block letters)

IAC Compliance Laboratory, No.789 Pu Xing Road,Shanghai,PRC Declaration We, IAC Compliance Laboratory the undersigned hereby declare, that the test performed by IAC Compliance Laboratory to the following Report No(project).: 20120916FCC-A 20120916FCC-B 20120916FCC-D 20120916SAR The Test Results relate only to the samples tested. − Point of contact: Jeff Huang TEL: +86-21-5433-6899 FAX: +86-21-5431-5010 [email protected]; (Name, telephone and fax number) Shanghai Date: 2012/9/25 (Place, date of issue) (Signature) Jeff Huang / Manager (Name and title in block letters)

IAC Report No. : 20120916EP1 Page : 1 of 7 Version:1.0 Annex external Photographs IAC Report No. : 20120916EP1 Page : 2 of 7 Version:1.0 IAC Report No. : 20120916EP1 Page : 3 of 7 Version:1.0 IAC Report No. : 20120916EP1 Page : 4 of 7 Version:1.0 IAC Report No. : 20120916EP1 Page : 5 of 7 Version:1.0 IAC Report No. : 20120916EP1 Page : 6 of 7 Version:1.0 IAC Report No. : 20120916EP1 Page : 7 of 7 Version:1.0

IAC Report No. : 20120916EP3 Page : 1 of 2 Version:1.0 Annex Label exhibit IAC Report No. : 20120916EP3 Page : 2 of 2 Version:1.0

IAC Report No. : 20120916EP2 Page : 1 of 5 Version:1.0 Annex internal Photographs IAC Report No. : 20120916EP2 Page : 2 of 5 Version:1.0 IAC Report No. : 20120916EP2 Page : 3 of 5 Version:1.0 IAC Report No. : 20120916EP2 Page : 4 of 5 Version:1.0 IAC Report No. : 20120916EP2 Page : 5 of 5 Version:1.0

IAC Report No.:20120917FCC-A Page 1 of 19 Version:1.0 FCC Test Report FCC 47 CFR FCC Part 15 Subpart B Product Name : GSM 850/900/1800/1900 GPRS Mobile Phone Model No. : A1034 FCC ID : T38A1034 Prepared By: : Inventec Appliances(Pudong) Corporation Address: : No.789 Pu Xing Road,Shanghai,PRC Date of Receipt : 2012.09.17 Date of Test : 2012.09.17-2012.09.24 Report No. : 20120917FCC-A IAC Report No.:20120917FCC-A Page 2 of 19 Version:1.0 Test Report Certification Date of Issue : Sep.25.2012 Report No. : 20120917FCC-A Product Name : GSM 850/900/1800/1900 GPRS Mobile Phone Model No. : A1034 Trade Name : CLARO Applicant : Cellon Communications Technology (Shenzhen) Co.,Ltd. Address : 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, Standard : FCC 47 CFR FCC Part 15 Subpart B Classification : JBP Test Result : Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of IAC regulatory Laboratory Documented By : , Sep.25.2012 Judy Ge/Engineer Tested By : , Sep.25.2012 Alice Lee/Engineer Approved By : , Sep.25.2012 Jeff Huang/Director of Operations IAC Report No.:20120917FCC-A Page 3 of 19 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ................................................................................................ 5 1.1 Applicant ................................................................................................................................ 5 1.2 Manufacture r ......................................................................................................................... 5 1.3 Feature of Equipment Under Test ......................................................................................... 5 1.4 Applied Standards ................................................................................................................. 5 2. Test Configuration of Equipme nt Unde r Test ....................................................................... 6 2.1 Test Modes .............................................................................................................................. 6 2.2 Testing Environme nt .............................................................................................................. 6 3. Test Result .............................................................................................................................. 7 3.1 Test of AC Conducted Emission Measure me nt ..................................................................... 7 3.2 Test of Radiated Emission Measurement ............................................................................. 11 4. List of Measuring Equipme nt .............................................................................................. 17 5 Ancillary Equipment List .................................................................................................... 17 6 Unce rtainty Evaluation ........................................................................................................ 17 IAC Report No.:20120917FCC-A Page 4 of 19 Version:1.0 SUMMARY OF TEST RESULT Report Section FCC Rule IC Rule Description Limi t Result Remark 3.1 15.107 7.2.2 AC Conducted Emission < 15.107 limits < RSS-Gen table 2 limits PASS Under limit 6 dB 3.2 15.109 7.2.3.2 Radiated Emission < 15.109 limits or < RSS-Gen table 1 limits (Section 6) PASS Under limit 6dB IAC Report No.:20120917FCC-A Page 5 of 19 Version:1.0 1. GENERAL INFORMATION 1.1 Applicant Company Name: Cellon Communications Technology (Shenzhen) Co.,Ltd. Address: 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, 1.2 Manufacturer Company Name: Cellon Communications Technology (Shenzhen) Co.,Ltd. Address: 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, 1.3 Feature of Equipment Under Test Product Feature & Specification Equipment GSM 850/900/1800/1900 GPRS Mobile Phone Brand Name CLARO Model Name A1034 FCC ID T38A1034 HW Version P2 SW Version A1034_01.09_61010F_70401_MTK_026 Remark: 1. For other wireless features of this EUT, test report will be issued separately. 2. This test report recorded only product characteristics and test results of JBP. 3. The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. 1.4 Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of thefollowing standards: • FCC 47 CFR FCC Part 15 Subpart B • ANSI C63.4-2003 Remark: All test items were verified and recorded according to the standards and without any deviation during the test. IAC Report No.:20120917FCC-A Page 6 of 19 Version:1.0 2. Test Configuration of Equipment Under Test 2.1 Test Modes The EUT has been associated with peripherals pursuant to ANSI C63.4-2003 and configuration operated in a manner tended to maximize its emission characteristics in a typical application. Frequency range investigated: conduction (150 kHz to 30 MHz), radiation (30MHz to the 5th harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower). Abbreviations:  EMI AC: AC conducted emissions  EMI RE ≥ 1G: EUT radiated emissions ≥ 1GHz  EMI RE < 1G: EUT radiated emissions < 1GHz Test Item Function Type AC Conducted Emission Mode 1: GSM 850 Idle + Battery + LCD monitor+ Notebook+ Adapter Test Item Function Type RadiatedEmissions < 1GHz Mode 1: GSM 850 Idle + Battery + LCD monitor+ Notebook+ Adapter Test Item Function Type RadiatedEmissions > 1GHz Mode 1: GSM 850 Idle + Battery + LCD monitor+ Notebook+ Adapter 2.2 Testing Environment Items Ambient Temperature Relative Humidity Test Distance Normal Condition 22~24°C 35~60% 3m IAC Report No.:20120917FCC-A Page 7 of 19 Version:1.0 3. Test Result 3.1 Test of AC Conducted Emission Measurement 3.1.1 Limits of AC Conducted Emission For e…

Text truncated - open the document above for the full version.

IAC Report No.:20120916FCC-A Page 1 of 19 Version:1.0 FCC Test Report FCC 47 CFR FCC Part 15 Subpart B Product Name : GSM 850/900/1800/1900 GPRS\BT Mobile Phone Model No. : A1033 FCC ID : T38A1033 Prepared By: : Inventec Appliances(Pudong) Corporation Address: : No.789 Pu Xing Road,Shanghai,PRC Date of Receipt : 2012.09.16 Date of Test : 2012.09.17-2012.09.24 Report No. : 20120916FCC-A IAC Report No.:20120916FCC-A Page 2 of 19 Version:1.0 Test Report Certification Date of Issue : Sep.25.2012 Report No. : 20120916FCC-A Product Name : GSM 850/900/1800/1900 GPRS\BT Mobile Phone Model No. : A1033 Trade Name : CLARO Applicant : Cellon Communications Technology (Shenzhen) Co.,Ltd. Address : 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, Standard : FCC 47 CFR FCC Part 15 Subpart B Classification : JBP Test Result : Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of IAC regulatory Laboratory Documented By : , Sep.25.2012 Judy Ge/Engineer Tested By : , Sep.25.2012 Alice Lee/Engineer Approved By : , Sep.25.2012 Jeff Huang/Director of Operations IAC Report No.:20120916FCC-A Page 3 of 19 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..................................................................................................... 5 1.1 Applicant ...................................................................................................................................... 5 1.2 Manufacturer ............................................................................................................................... 5 1.3 Feature of Equipment Under Test .............................................................................................. 5 1.4 Applied Standards ....................................................................................................................... 5 2. Test Configuration of Equipment Under Test ........................................................................... 6 2.1 Test Modes .................................................................................................................................... 6 2.2 Testing Environment ................................................................................................................... 6 3. Test Result .................................................................................................................................... 7 3.1 Test of AC Conducted Emission Measurement ......................................................................... 7 3.2 Test of Radiated Emission Measurement ................................................................................ 11 4. List of Measuring Equipment................................................................................................... 17 5 Ancillary Equipment List ......................................................................................................... 17 6 Uncertainty Evaluation ............................................................................................................. 17 IAC Report No.:20120916FCC-A Page 4 of 19 Version:1.0 SUMMARY OF TEST RESULT Report Section FCC Rule IC Rule Description Limit Result Remark 3.1 15.107 7.2.2 AC Conducted Emission < 15.107 limits < RSS-Gen table 2 limits PASS Under limit 6 dB 3.2 15.109 7.2.3.2 Radiated Emission < 15.109 limits or < RSS-Gen table 1 limits (Section 6) PASS Under limit 6dB IAC Report No.:20120916FCC-A Page 5 of 19 Version:1.0 1. GENERAL INFORMATION 1.1 Applicant Company Name: Cellon Communications Technology (Shenzhen) Co.,Ltd. Address: 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, 1.2 Manufacturer Company Name: Cellon Communications Technology (Shenzhen) Co.,Ltd. Address: 13/F, Skyworth C Building, Gaoxin S.Ave1, Hi-Tech Industrial Park, Nanshan District, 1.3 Feature of Equipment Under Test Product Feature & Specification Equipment GSM 850/900/1800/1900 GPRS\BT Mobile Phone Brand Name CLARO Model Name A1033 FCC ID T38A1033 HW Version P2 SW Version A1033_01.05_65010F_70401_EON_027_026 Remark: 1. For other wireless features of this EUT, test report will be issued separately. 2. This test report recorded only product characteristics and test results of JBP. 3. The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. 1.4 Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of thefollowing standards:  FCC 47 CFR FCC Part 15 Subpart B  ANSI C63.4-2003 Remark: All test items were verified and recorded according to the standards and without any deviation during the test. IAC Report No.:20120916FCC-A Page 6 of 19 Version:1.0 2. Test Configuration of Equipment Under Test 2.1 Test Modes The EUT has been associated with peripherals pursuant to ANSI C63.4-2003 and configuration operated in a manner tended to maximize its emission characteristics in a typical application. Frequency range investigated: conduction (150 kHz to 30 MHz), radiation (30MHz to the 5th harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower). Abbreviations:  EMI AC: AC conducted emissions  EMI RE ≥ 1G: EUT radiated emissions ≥ 1GHz  EMI RE < 1G: EUT radiated emissions < 1GHz Test Item Function Type AC Conducted Emission Mode 1: GSM 850 Idle + Bluetooth Idle + Battery + LCD monitor+ Notebook+ Adapter Test Item Function Type RadiatedEmissions < 1GHz Mode 1: GSM 850 Idle + Bluetooth Idle + Battery + LCD monitor+ Notebook+ Adapter Test Item Function Type RadiatedEmissions > 1GHz Mode 1: GSM 850 Idle + Bluetooth Idle + Battery + LCD monitor+ Notebook+ Adapter 2.2 Testing Environment Items Ambient Temperature Relative Humidity Test Distance Normal Condition 22~24°C 35~60% 3m IAC Report No.:20120916FCC-A Page…

Text truncated - open the document above for the full version.

IAC Report No.:20120916EP4 Page 1 of 3 Version:1.0 APPENDIX A. SETUP PHOTOGRAPHS FCC Part15B Radiated Emission below 1GHz Setup 1- EUT + Battery + Notebook + Adapter+ LCD monitor -Front -Rear IAC Report No.:20120916EP4 Page 2 of 3 Version:1.0 FCC Part15B Radiated Emission above 1GHz Setup 1- EUT + Battery + Notebook + Adapter+ LCD monitor -F ro nt -Rear IAC Report No.:20120916EP4 Page 3 of 3 Version:1.0 AC Conducted Emission Test Setup Setup 1- EUT + Battery + Notebook + Adapter+ LCD monitor

IAC Report No.:20120916EP5 Page 1 of 4 Ve r s i on:1.0 APPENDIX B. SETUP PHOTOGRAPHS FCC Part15C Radiated Emission Plot between 9 kHz ~ 30MHz - Front -Rear IAC Report No.:20120916EP5 Page 2 of 4 Ve r s i on:1.0 FCC Part15C Radiated Emission below 1GHz - Front -Rear IAC Report No.:20120916EP5 Page 3 of 4 Ve r s i on:1.0 FCC Part15C Radiated Emission above 1GHz -F ro nt -Rear IAC Report No.:20120916EP5 Page 4 of 4 Ve r s i on:1.0 AC Conducted Emission Test Setup
