Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Apr 10, 2011
Application Purpose: Original Equipment
Date of Application: Apr 10, 2011
Equipment Note: Mobile Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Cellon Communications Technology (Shenzhen) Co.,Ltd.
Country: China
