T38PCD1021Mobile Phone

Cellon Communications Technology (Shenzhen) Co.,Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Apr 10, 2011
Application Purpose: Original Equipment
Date of Application: Apr 10, 2011
Equipment Note: Mobile Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Cellon Communications Technology (Shenzhen) Co.,Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1. Introduction 1.1 Phone Display 2 We continuously strive to improve our products. Therefore, we reserve the right to revise this user manual or withdraw it at any time without prior notice. 1.2 Key Key Function Dial/ Answer Key Make or answer a call. View call logs in standby mode. Hang-Up Press and hold to turn the phone on/off. End a call or reject an incoming call. Return to the idle mode. Right Soft Key In idle mode, press to turn the torch on for about 5 seconds. In idle mode, press and hold to turn the torch on all the time, press again and the torch will turn off. Return to the previous menu. Left Soft Key Access the menu in idle mode. When keypad is locked, press Left Soft key and * key to unlock the keypad 3 OK Enter the Main menu in idle mode. Confirm a selection. Numeric Key Enter numbers, letters or characters. Select a submenu item labeled with the corresponding number. * Press twice quickly to enter „+‟ to make an international call. Press to switch input modes when entering text. # Press and hold to activate or deactivate the silent mode in idle mode. Press and hold to enter the pause character (P) or the wait character (W) when entering number. Press to enter a symbol when editing text. Navigation Key Within a menu, press Up, Down, Left or Right to scroll through menu options. Note: “Press” in this manual, means press the key and release; “press and hold” means to press and hold the key for at least two seconds. 1.3 Icons & Symbols Icon Description Network - The left portion indicates whether your phone is already registered with a 4 network and the right portion indicates signal strength (from no signal to strongest signal). Battery - Indicates battery level with 3 battery level indicator bars. When charging, a scrolling icon will be displayed. The more bars, the stronger the charge. SMS - Indicates you have a new SMS. Alert type is “Silent”. Alert type is” vibration” Alert type is “Ring”. Missed call - Indicates there is a missed call. Call Divert - Indicates that the call divert unconditional function is activated. Lock - Indicates that the keypad is locked. Earset is in use Alarm - Indicates that the alarm clock is on. 2. Getting Started 2.1 Inserting the SIM Card 5 2.1.1 Remove the back cover and battery 2.1.2 Insert the SIM card Make sure that the clipped corner of the SIM card is facing the correct direction (clipped corner at down right) and the metallic contacts are facing downwards. Slide the SIM card into the card slot until it stops. 6 . 2.1.3 Install the battery and back cover 7 2.2 Turning on the Phone To turn the phone on, press and hold the Hang-Up Key. 8 2.3 Charging the Battery 1. Make sure the battery is inserted. To charge the battery, plug in the charger connector at the bottom of your phone (Charger port) and then plug the other end into an AC power socket. 2. The battery symbol indicates the charging status. During charging, the charge indicators will scroll. When all the scroll bars are steady, the battery is fully charged. 3. Disconnect the charger from the phone. 4. Disconnect the charger from the AC power socket. 3. Text Entry 3.1 Input Method During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Options] and select Input Method to select different input modes. In any input mode, press the * Key to open the symbols input screen. 3.2 Predictive Text entry “2~9” Press to input letters. 1 Press to input symbols. 0 Press to enter a space. Navigation Key ▲/▼/◀/▶ Press to browse the last or next available word. 9 Left Soft Key [Select] Press to confirm the letter or word. Right Soft Key [Clear] Press to clear a letter, press and hold to clear all entries. # Press to switch the input modes. * Press to activate punctuation mode. Example: How to enter the word " ERROR " 1. Press the # Key to switch to ES. 2. Press 3 7 7 6 7, “ERROR” appears.. 3. Press the OK Key to confirm “ERROR”. 3.3 Multi-tap Input Using this mode requires you to press a key as many times as the order of the letters listed on the key. For example, to enter the word “casa” in basic text input mode “es”, press key 2 (ABC) three times, press 2 (ABC) once, press key 7 (PQRS) four times, press key 2 (ABC) once. 3.4 Numeric Input Press the # Key to select “123” then enter the numbers using the keypad. 4. Calling 4.1 Making a Call 10 1. In idle mode, enter the phone number. 2. Press the Dial Key to dial the number. 3. Press the Hang-up Key to end the call. Note: During a call, press the Navigation Key Up/Down to adjust the volume. 4.1.1 Making an International Call 1. Press * twice quickly to enter "+" appears on the screen. 2. Enter the country code. 3. Enter the area code (normally without the 0 before it) followed by the phone number. 4. Press the Dial Key to call directly. 4.2 Answering a Call Press the Answer Key to answer it. Press the Hang-Up key to reject it. 5. Phonebook 5.1 Search Contact 1. Press Menu > Phonebook, you can enter first few letters of contact name directly. 11 2. Enter the contact name. 5.2 Add New Contact To create a new SIM/phone contact: 1. Select Menu > Phonebook > Add new contact. If you want to change the storage position, press the Left Soft Key [Options] and then select Phonebook settings > Preferred storage to set the storage position. 2. Press the Options > Select > To SIM/To phone to edit the contact information. 3. Press the Options Key > Done to save the contact. . 6. Messaging 6.1 Create Message 1. Select Menu > Messaging>Write message. 2. In content, you are able to add text message into your message. 3. After finished, press the Left Soft Key [Options] and select send to to go to the following options:enter number,Add from Phonebook. 6.2 Broadcast Message 12 1. Select Menu > Messaging > Broadcast message. 2. Press the Left Soft Key [On]/[Off] to Activate /Deactivate this function. 3. Press the Navigation Key Down to select Channel settings to enter the channel number. 7. Call history 7.1 View Call History 1. …

Text truncated - open the document above for the full version.

External Photos

Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 720510 1. External Photograph of EUT Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 5 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 6 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 7 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 List of Accessory: Specification of Accessory AC Adapter Brand Name PCD Model Name ATC002005 Battery Brand Name PCD Model Name BTR1031 Earphone Signal Line Type 1 meter non-shielded cable without ferrite core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 8 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 9 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 10 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 11 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 12 of 22 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 Photographs of EUT Report No.: EP131624 Brand Name: PCD, Movistar Model Name: C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 13 of 22 TEL : …

Text truncated - open the document above for the full version.

ID Label/Location Info

Back of the Device Battery Compartment Label Location

Internal Photos

RF Exposure Info

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 System Check_Head_835MHz_110321 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835_110321 Medium parameters used: f = 835 MHz; σ = 0.901 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.63 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.8 V/m; Power Drift = -0.00114 dB Peak SAR (extrapolated) = 3.62 W/kg SAR(1 g) = 2.44 mW/g; SAR(10 g) = 1.61 mW/g Maximum value of SAR (measured) = 2.62 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-22 System Check_Body_835MHz_110322 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_110322 Medium parameters used: f = 835 MHz; σ = 0.97 mho/m; ε r = 56.5; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.65, 8.65, 8.65); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.57 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51 V/m; Power Drift = 0.00512 dB Peak SAR (extrapolated) = 3.57 W/kg SAR(1 g) = 2.38 mW/g; SAR(10 g) = 1.57 mW/g Maximum value of SAR (measured) = 2.57 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 System Check_Head_1900MHz_110321 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_110321 Medium parameters used: f = 1900 MHz; σ = 1.41 mho/m; ε r = 39.3; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(7.39, 7.39, 7.39); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 11.4 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 88.6 V/m; Power Drift = -0.00515 dB Peak SAR (extrapolated) = 19.5 W/kg SAR(1 g) = 10 mW/g; SAR(10 g) = 5.09 mW/g Maximum value of SAR (measured) = 11.2 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-22 System Check_Body_1900MHz_110322 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_110322 Medium parameters used: f = 1900 MHz; σ = 1.53 mho/m; ε r = 54.7; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.2 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(7.26, 7.26, 7.26); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 11.5 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 85.5 V/m; Power Drift = -0.0045 dB Peak SAR (extrapolated) = 19.8 W/kg SAR(1 g) = 10.1 mW/g; SAR(10 g) = 5.14 mW/g Maximum value of SAR (measured) = 11.3 mW/g

RF Exposure Info

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #16 GSM850_Right Cheek_Ch251 DUT: 131504 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110321 Medium parameters used: f = 849 MHz; σ = 0.916 mho/m; ε r = 41.4; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.03 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 27 V/m; Power Drift = -0.068 dB Peak SAR (extrapolated) = 1.26 W/kg SAR(1 g) = 0.958 mW/g; SAR(10 g) = 0.672 mW/g Maximum value of SAR (measured) = 1.01 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #16 GSM850_Right Cheek_Ch251_2D DUT: 131504 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110321 Medium parameters used: f = 849 MHz; σ = 0.916 mho/m; ε r = 41.4; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.03 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 27 V/m; Power Drift = -0.068 dB Peak SAR (extrapolated) = 1.26 W/kg SAR(1 g) = 0.958 mW/g; SAR(10 g) = 0.672 mW/g Maximum value of SAR (measured) = 1.01 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #12 GSM850_Right Tilted_Ch189 DUT: 131504 Communication System: Generic GSM; Frequency: 836.4 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110321 Medium parameters used: f = 836.4 MHz; σ = 0.903 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch189/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.619 mW/g Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 24.4 V/m; Power Drift = -0.059 dB Peak SAR (extrapolated) = 0.783 W/kg SAR(1 g) = 0.581 mW/g; SAR(10 g) = 0.407 mW/g Maximum value of SAR (measured) = 0.614 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #18 GSM850_Left Cheek_Ch251 DUT: 131504 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110321 Medium parameters used: f = 849 MHz; σ = 0.916 mho/m; ε r = 41.4; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.000 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 27.1 V/m; Power Drift = -0.075 dB Peak SAR (extrapolated) = 1.25 W/kg SAR(1 g) = 0.935 mW/g; SAR(10 g) = 0.652 mW/g Maximum value of SAR (measured) = 0.986 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #14 GSM850_Left Tilted_Ch189 DUT: 131504 Communication System: Generic GSM; Frequency: 836.4 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110321 Medium parameters used: f = 836.4 MHz; σ = 0.903 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(8.67, 8.67, 8.67); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch189/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.600 mW/g Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.5 V/m; Power Drift = -0.025 dB Peak SAR (extrapolated) = 0.770 W/kg SAR(1 g) = 0.556 mW/g; SAR(10 g) = 0.386 mW/g Maximum value of SAR (measured) = 0.590 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-3-21 #06 GSM1900_Right Cheek_Ch810 DUT: 131504 Communication System: Generic GSM; Frequency: 1909.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_1900_110321 Medium parameters used: f = 1910 MHz; σ = 1.42 mho/m; ε r = 39.3; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3697; ConvF(7.39, 7.39, 7.39); Calibrated: 2010-11-23 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY5, V5.2 Build 162; SEMCAD X Version 14.0 Build 57 Ch810/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.912 mW/g Ch810/Zoom Scan (5x5x7)/Cube 0: Measurement …

Text truncated - open the document above for the full version.

RF Exposure Info

SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY

RF Exposure Info

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 31 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 FCC SAR Test Report Report No. : FA131624 FCC SAR Test Report APPLICANT : Cellon Communications Technology (Shenzhen) Co., Ltd. EQUIPMENT : Mobile phone BRAND NAME : PCD, Movistar MODEL NAME : C1021, PCD1201, CL1201, TE1201, PCD1201PE, PCD1201AL, PCD1201CL, PCD1201PO, PCD1201MV, PCD1201OM, PCD1201MX, TE1201PE, AL1201AL, CL1201CL, CL1201PO, MV1201MV, TE1201MX, TE1201GT FCC ID : T38PCD1021 STANDARD : FCC 47 CFR Part 2 (2.1093) IEEE C95.1-1991 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was received on Mar. 16, 2011 and completely tested on Mar. 22, 2011. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (KUNSHAN) INC., the test report shall not be reproduced except in full. Reviewed by: Roy Wu / Manager SPORTON INTERNATIONAL (KUNSHAN) INC. No. 3-2, PingXiang Road, Kunshan, Jiangsu Province, P.R.C. SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 31 TEL : 86-0512-5790-0158 Report Issued Date : Mar. 30, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD1021 FCC SAR Test Report Report No. : FA131624 Table of Contents Revision History ................................................................................................................................................................ 3 1. Statement of Compliance .......................................................................................................................................... 4 2. Administration Data ................................................................................................................................................... 5 2.1 Testing Laboratory ............................................................................................................................................ 5 2.2 Applicant ........................................................................................................................................................... 5 2.3 Manufacturer .................................................................................................................................................... 5 2.4 Application Details ....................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

maggie xu(TA manager)

[email protected]+86-755-86365704Fax: +86-755-86365686

Test Firm

SPORTON INTERNATIONAL(KUN SHAN)INC.Alex Chen

[email protected]886-3-3273456Fax: 886-3-3270973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	690.00 mW	248KGXW	0.03 ppm

Confidentiality

Long Term

Grant Notes
