T38PCD1535GSM MOBILE PHONE

Cellon (Shenzhen) Co.,Ltd. Date: May 4, 2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Cellon Communications Technology (Shenzhen) Co.,Ltd. , the undersigned, hereby authorizes Mr.Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Cellon Communications Technology (Shenzhen) Co.,Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID #T38PCD1535 including the signing of documents in connection with this Application. Necessary acts carried out by Cellon Communications Technology (Shenzhen) Co.,Ltd. on our behalf of the Cellon Communications Technology (Shenzhen) Co.,Ltd. in connection with the Application shall have the same effect as acts of the Cellon Communications Technology (Shenzhen) Co.,Ltd. The Cellon Communications Technology (Shenzhen) Co.,Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

Cellon (Shenzhen) Co.,Ltd. Date: May 4, 2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Cellon Communications Technology (Shenzhen) Co.,Ltd. FCC ID: T38PCD1535 FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Cellon Communications Technology (Shenzhen) Co.,Ltd. requests that the following documents regarding this submission for FCC ID: T38PCD1535 be kept confidential: Exhibit Type File Name Block Diagram CONF APPENDIX T38PCD1535_Block Diagram.pdf Schematics CONF APPENDIX T38PCD1535_Schematics.pdf Operational Description CONF APPENDIX T38PCD1535_Operational Description.pdf Part list CONF APPENDIX T38PCD1535_BOM.pdf Tune-Up-Procedure CONF APPENDIX T38PCD1535_Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Cellon Communications Technology (Shenzhen) Co., Ltd. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Cellon Communications Technology (Shenzhen) Co., Ltd. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

External Photos

FCC ID: T38PCD1535 Label Label Location

Date: May 4, 2012 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: T38PCD1535 Dear Sirs: Cellon Communications Technology (Shenzhen) Co.,Ltd. requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier T38PCD1535. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Cellon Communications Technology (Shenzhen) Co.,Ltd. proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Cellon Communications Technology (Shenzhen) Co.,Ltd. will add the FCC identifier " T38PCD1535 " to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

Internal Photos

SZ12040085S01 Page 2 of 75 DIRECTORY TESTING LABORATORY.......................................................................................4 1.1. Identification of the Responsible Testing Laboratory...........................................4 1.2. Identification of the Responsible Testing Location...............................................4 1.3. Accreditation Certificate........................................................................................4 1.4. List of Test Equipments.........................................................................................4 2. TECHNICAL INFORMATION...........................................................................5 2.1. Identification of Applicant.....................................................................................5 2.2. Identification of Manufacturer...............................................................................5 2.3. Equipment Under Test (EUT)...............................................................................5 2.3.1. Photographs of the EUT.....................................................................................5 2.3.2. Identification of all used EUT............................................................................5 2.4. Applied Reference Documents..............................................................................6 2.5. Device Category and SAR Limits.........................................................................6 2.6. Test Environment/Conditions................................................................................7 3. SPECIFIC ABSORPTION RATE (SAR)............................................................8 3.1. Introduction............................................................................................................8 3.2. SAR Definition......................................................................................................8 4. SAR MEASUREMENT SETUP...........................................................................9 4.1. The Measurement System......................................................................................9 4.2. Probe......................................................................................................................9 4.3. Probe Calibration Process....................................................................................11 4.3.1 Dosimetric Assessment Procedure....................................................................11 4.3.2 Free Space Assessment Procedure.................................................................... 11 4.3.2 Temperature Assessment Procedure..................................................................11 4.4. Phantom...............................................................................................................12 4.5. Device Holder......................................................................................................12 5. TISSUE SIMULATING LIQUIDS.....................................................................13 6. UNCERTAINTY ASSESSMENT.......................................................................15 6.1. UNCERTAINTY EVALUATION FOR HANDSET SAR TEST......................15 6.2. UNCERTAINTY FOR SYSTEM PERFORMANCE CHECK..........................16 7. SAR MEASUREMENTEVALUATION...........................................................18 7.1. System Setup........................................................................................................18 SZ12040085S01 Page 3 of 75 7.2. Validation Results................................................................................................19 8. OPERATIONAL CONDITIONS DURING TEST...........................................20 8.1. Informationson the testing..................................................................................20 8.2. Body-worn Configurations..................................................................................21 8.3. Measurement procedure.......................................................................................21 8.4. Description of interpolation/extrapolation scheme............................................. 22 9. Measurement Of Conducted Peak Output Power...................................................23 10. MULTIPLE TRANSMITTERS EVALUATION............................................25 11. TEST RESULTS LIST.......................................................................................26 ANNEX A EUT SETUP PHOTOS.........................................................................27 ANNEX B GRAPH TEST RESULTS.................................................................... 30 Change History IssueDateReason for change 1.0Apr. 25, 2012First edition SZ12040085S01 Page 4 of 75 Testing Laboratory 1.1. Identification of the Responsible Testing Laboratory Company Name:Shenzhen Morlab Communications Technology Co., Ltd. Department:Morlab Laboratory Address:3/F, Electronic Testing Building, Shahe Road, Nanshan District, Shenzhen, 518055 P. R. China Responsible Test Lab Manager:Mr. Shu Luan Telephone:+86 755 86130268 Facsimile:+86 755 86130218 1.2. Identification of the Responsible Testing Location Name:Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory Address:3/F, Electronic Testing Building, Shahe Road, Nanshan District, Shenzhen, 518055 P. R. China 1.3. Accreditation Certificate Accredited Testing Laboratory:No. CNAS L3572 1.4. List of Test Equipments No.InstrumentTypeCal. Date Cal. Due 1PC Dell (Pentium IV 2.4GHz, SN:X10-23533) (n.a)(n.a) 2 Network Emulator Rohde&Schwarz (CMU200, SN:105894) 2011-9-261year 3VoltmeterKeithley (2000, SN:1000572)2011-9-241year 4Synthetizer Rohde&Schwarz (SML_03, SN:101868) 2011-9-241year 5AmplifierNucl udes (ALB216, SN:10800)2011-9-241year 6Power Meter Rohde&Schwarz (NRVD, SN:101066) 2011-9-241year 7ProbeSatimo (SN:SN_3708_EP80)2011-9-241year 8PhantomSatimo (SN:SN_36_08_SAM62)2011-9-241year …

Text truncated - open the document above for the full version.

 Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         1    COMOSAR E-FIELD PROBE CALIBRATION REPORT Prepared By: LUC Jérôme, SATIMO Project Description: SAR TEST BENCH Prepared For (End User): Shenzhen Morlab Communication Technology          This document is issued by SATIMO, in confidence and is not to be reproduced in whole or in part without the prior written permission. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or in part without the prior written permission of SATIMO.  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         2  COMOSAR SEPT ISOTROPIC E-FIELD PROBE CALIBRATION REPORT DATE: 12/02/2009 REFERENCE: SN 37/08 EP80 OBJECT: COMOSAR SEPT ISOTROPIC E-FIELD PROBE MANUFACTURER: SATIMO SERIAL NUMBER: SN 37/08 EP80 CUSTOMER: Shenzhen Morlab Communication Technology CONTRACT: PF2130108b_SAR_Morlab DATE OF CALIBRATION: 24/09/20 WARRANTY: This Calibration certificate may not be reproduced other than in full. Calibration certificates without signature and seal are not valid. This documentation contains property information which is protected by copyright. All right are reserved. No part of this document may be photocopied, reproduced without the prior written agreement of SATIMO. SATIMO shall not be liable for errors contained herein or for incidental or consequential in connection with the furnishing, performance or use of this material. Warranty doesn’t apply to Normal wear, Normal tear, Improper use, Improper maintain, Improper installation. Date SAR TEAM MANAGER Date SAR TEAM MANAGER  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         3  PRODUCT DESCRIPTION Frequency Range 100 MHz - 30 GHz Probe length 330 mm Length of one dipole 4.5 mm Maximum external diameter 8 mm Probe extremity diameter 6.5 mm Distance between dipoles/probe extremity < 2.7 mm Resistance of the three dipole (at the connector) Dipole 1: R1=1.4382 MΩ Dipole 2: R2=1.4894 MΩ Dipole 3: R3=1.4683 MΩ Connector (HIROSE series SR30) 6 wire male (Hirose SR30series) The probe could be checked by measuring the resistance of the three dipoles. CALIBRATION TEST EQUIPMENT TYPE IDENTIFICATION Calibration bench CALISAR Multimeter Keithley 2000  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         4  MEASUREMENT PROCEDURE Probe calibration is realized, in compliance with CENELEC EN 50361 and IEEE 1528 std, with CALISAR, Antennessa proprietary calibration system. The calibration is performed with the EN 50361 annexe technique using reference guide at the five frequencies. Where : P fw = Forward Power P bw = Backward Power a and b = Waveguide dimensions
= Skin depth Keithley configuration: Rate = Medium; Filter =ON; RDGS=10; FILTER TYPE =MOVING AVERAGE; RANGE AUTO After each calibration, a SAR measurement is performed on a validation dipole and compared with a NPL calibrated probe, to verify it.  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         5  PROBE UNCERTAINTIES  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         6  1. Calibration at 450.00 MHz A. Calibration parameters. Label GSM450 Epsilon 43.33 Sigma 0.84 S/m Temperature 21°C Antenna gain 2.03 dB Antenna S11 -10.50 dB Low limit detection (CW)     Calibration curves ei=f(V) (i=1,2,3) allow to obtain E-field value using the formula:   EEEE= The following tables represent the calibration curves linearization by curve segment in CW signal.  Ref: CR-280-1-08-SATB-A COMOSAR E-Field probe Calibration Report         7  Calibration coefficients for the three dipoles in CW: v1 e1 v2 e2 v3 e3 0.584004 419.557857 -0.696059 435.622023 0.541191 412.830715 0.467833 339.207465 -0.556278 351.381991 0.469757 336.297240 0.376994 276.348283 -0.452232 288.647980 0.378826 274.224190 0.302778 224.954643 -0.359005 232.397390 0.305842 224.365698 0.241038 182.154071 -0.286978 188.889931 0.246562 183.825274 0.192549 148.484090 -0.230386 154.650994 0.195712 148.993075 0.154033 121.674762 -0.185412 127.378480 0.157543 122.783107 0.123397 100.276479 -0.147311 104.193802 0.125866 100.956090 0.099878 83.770361 -0.118637 86.660489 0.101471 84.063863 0.081165 70.553219 -0.095250 72.263937 0.082289 70.694342 0.065166 59.152028 -0.076788 60.795323 0.066427 59.538957 0.051916 49.592416 -0.061280 51.041514 0.053353 50.232492 0.041968 42.297602 -0.048746 43.022565 0.042906 42.675214 0.033724 36.126757 -0.039149 36.748110 0.034686 36.605243 0.021855 26.962568 -0.024798 27.024723 0.022272 27.149463 0.018405 23.975145 -0.020856 24.085809 0.018755 24.141334 0.015467 21.515985 -0.017534 21.515985 0.015767 21.615299 0.013018 19.309065 -0.014750 19.398191 0.013276 19.487731 0.010938 17.408496 -0.012392 17.529166 0.011157 17.569575 0.009022 15.586953 -0.010228 15.658899 0.009215 15.676938 0.007353 13.956010 -0.008328 13.988181 0.007484 14.020428 0.005989 12.466979 -0.006801 12.495719 0.006111 12.567858 0.004890 11.214019 -0.005573 11.265779 0.005003 11.330818 0.004019 10.133541 -0.004570 10.121882 0.004099 10.168601 0.003279 9.094132 -0.003739 9.157170 0.003352 9.125596 0.002660 8.095827 -0.003041 8.293946 0.002769 8.265350 0.002126 7.324219 -0.002453 7.366500 0.002188 7.358024 0.001685 6.565400 -0.001947 6.580536 0.001724 6.542765 0.001300 5.784440 -0.001511 5.718225 0.001334 5.757862 0.001123 5.245191 -0.001307 5.269400 0.001174 5.275471 0.000891 4.701768 -0.001057 4.723470 0.000924 4.728912 0.000704 4.209798 -0.000850 4.226839 0.000736 4.243862 0.000574 3.790376 -0.000689 3.791428 0.000603 3.830551 0.000457 3.396200 -0.000570 3.434303 0.000483 3.421852 0.000365 3.050686 -0.000463 3.078014 0.000389 3.079630 0.000292 2.745766 -0.000369 2.726866 0.00031…

Text truncated - open the document above for the full version.

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

 Ref: CR-280-7-08-SATB-A COMOSAR Dipole 2450 MHz Calibration Report                    DIPOLE 2450 MHZ CALIBRATION REPORT   !"# $% &'( ())&*"+#,"#,-. /&0,* 1 "2*32*$&45& *)()&*#(2*&4&             #2) &( *) ) 5"# $%!)*(&*6)*(*) *&&5& ()*72&4&)* 7)2& 2)&7)* ) )&*8#2)*6& )&*(&*)* 2)*) & 5 &*46&2  & 6&72)(2))  5 )*) *&&54 )*72&4&)*7)2& 2)&7)*  ) )&*&6"# $%8  Ref: CR-280-7-08-SATB-A COMOSAR Dipole 2450 MHz Calibration Report          DIPOLE 2450 MHz CALIBRATION REPORT DATE    REFERENCE"- 9 :    OBJECT%$%"+ ,,,+,/,+,-, %,  MANUFACTURER"# $%  SERIALNUMBER"- 9 :    CUSTOMER"2*32*$&45& *)()&*#(2*&4&  CONTRACT/ :5;"+;$&45  DATE OF CALIBRATION    WARRANTY: #2) 4)5)&*()6)( *&5& (&22*)*6 4484)5)&*()6)(  7)2&  )* * 4*&<4)8#2) &( *)&*(&*)* &)*6& )&*72)(2)  &( 5 (&)28 44 )2   <8 -&  &6 2)  &( *  5 2&&(&)! & (7)2& 2)&7)* *&6"# $%8"# $% 244*&54)546&&  (&*)*2)*&6&)*()*4&(&* = *)4)*(&**()&*7)226 *) 2)*!6& *(& &62)  )48>*& *?4&-& 47!-& 4! & ! & )*)*! &)* 44)&*8      "+#,$$-@,+   "+#,$$-@,+  Ref: CR-280-7-08-SATB-A COMOSAR Dipole 2450 MHz Calibration Report         PRODUCT DESCRIPTION  CALIBRATION TEST EQUIPMENT TYPE IDENTIFICATION A(&-7&B*43.:CD    MEASUREMENT PROCEDURE  >4(2)&4 *264&6"$2*& 6)447)2D$.324)= )8  E ! E E D E  ED E ED E ED  ! D!DD Frequency (GHz) S11 (dB)   VSWR at 2450 MHz: -33.09 dB.

Report No.: SZ12040085W01 Page 2 of 48 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 2. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS ........................................................ 6 2.1 Conducted RF Output Power .................................................................................................... 6 2.2 99% Occupied Bandwidth ....................................................................................................... 14 2.3 Frequency Stability ................................................................................................................... 18 2.4 Conducted Out of Band Emissions ......................................................................................... 20 2.5 Band Edge ................................................................................................................................. 27 2.6 Transmitter Radiated Power (EIRP/ERP) ............................................................................. 30 2.7 Radiated Out of Band Emissions ............................................................................................ 35 Change History Issue Date Reason for change 1.0 May 4, 2012 First edition Report No.: SZ12040085W01 Page 3 of 48 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ............................. : GSM mobile phone Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : P3 Software Version .................. : Applicant .............................. : Manufacturer ........................ : V1.1 Cellon Communications Technology(ShenZhen)Co., Ltd. 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen Cellon Communications Tcchnology（shenzhen）Co,.Ltd 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen Frequency Range .................. : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) Modulation Type................... : GPRS/GSM Mode with GMSK Modulation Multislot Class ...................... : GPRS: Multislot Class12,EGPRS: Multislot Class12 Antenna Type ........................ : PIFA Antenna Emission Designators ........... : GSM:249KGXW, Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(n)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.8MHz). Report No.: SZ12040085W01 Page 4 of 48 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 2, Part 22 and Part 24 for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 2 (10-1-09 Edition) Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 47 CFR Part 22 (10-1-09 Edition) Public Mobile Services 3 47 CFR Part 24 (10-1-09 Edition) Personal Communications Services Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 2.1046 Conducted RF Output Power PASS 2 2.1049 99% Occupied Bandwidth PASS 3 2.1055 22.355 24.235 Frequency Stability PASS 4 2.1051 2.1057 22.917 24.238 Conducted Out of Band Emissions PASS 5 2.1051 2.1057 22.917 24.238 Band Edge PASS 6 22.913 24.232 Transmitter Radiated Power (EIPR/ERP) PASS 7 2.1053 2.1057 22.917 24.238 Radiated Out of Band Emissions PASS NOTE：Measurement method according to TIA/EIA 603.D-2010 Report No.: SZ12040085W01 Page 5 of 48 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 Report No.: SZ12040085W01 Page 6 of 48 2. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS 2.1 Conducted RF Output Power 2.1.1 Requirement According to FCC section 2.1046(a), for transmitters other than single sideband, independent sideband and controlled carrier radiotelephone, power output shall be measured at the RF output terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on the circuit elements specified in FCC section 2.1033(c)(8). 2.1.2 Test Description 1. Test Setup: The EUT, which is pow…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CSE 2. RSE
