T38PCD2091DMOBILE PHONE

1 2091D User Manual 2 YOUR PHONE ................................................................................................................................ 5 STANDBY MODE .............................................................................................................................. 6 GETTING STARTED ....................................................................................................................... 6 INSTALLING THE SIM CARD AND THE BATTERY ................................................................................... 6 INSTALLING A MICROSD CARD ......................................................................................................... 7 CHARGING THE BATTERY ................................................................................................................. 8 SWITCHING THE PHONE ON AND OFF ................................................................................................. 8 CALL FUNCTIONS ......................................................................................................................... 8 MAKING A CALL ............................................................................................................................... 8 ANSWERING OR REJECTING AN INCOMING CALL ................................................................................. 8 CALL WAITING ................................................................................................................................ 8 INPUT METHOD ............................................................................................................................. 9 PHONEBOOK ................................................................................................................................. 9 SEARCH ......................................................................................................................................... 9 ADD NEW CONTACT ........................................................................................................................ 9 CALLER GROUPS .......................................................................................................................... 10 PHONEBOOK SETTINGS ................................................................................................................. 10 STK (SIM TOOLKIT) ..................................................................................................................... 10 CALL CENTER ............................................................................................................................. 10 CALL HISTORY .............................................................................................................................. 11 Missed Calls ............................................................................................................................................. 11 Dialed Calls ............................................................................................................................................. 11 Received Calls.......................................................................................................................................... 11 Delete Call Logs ...................................................................................................................................... 11 Call timers................................................................................................................................................ 11 Call Cost .................................................................................................................................................. 11 Text Message Counter .............................................................................................................................. 11 GPRS Counter.......................................................................................................................................... 11 CALL SETTINGS ............................................................................................................................ 12 Advance Settings ..................................................................................................................................... 12 SETTINGS..................................................................................................................................... 12 PHONE SETTING ........................................................................................................................... 12 Time and Date ......................................................................................................................................... 12 Schedule Power On/Off .......................................................................................................................... 12 Language ................................................................................................................................................ 13 Writing Language: Allows you to predefine your writing Language...................................................... 13 Display .................................................................................................................................................... 13 Themes .................................................................................................................................................... 13 Greeting Text ........................................................................................................................................... 13 Dedicated Key ......................................................................................................................................... 13 Auto Update Of Date and Time ............................................................................................................... 13 Flight Mode.........…

Text truncated - open the document above for the full version.

Cellon (Shenzhen) Co.,Ltd. Date: 25 May, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Cellon Communications Technology (Shenzhen) Co.,Ltd. , the undersigned, hereby authorizes Mr.Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Cellon Communications Technology (Shenzhen) Co.,Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID #T38PCD2091D including the signing of documents in connection with this Application. Necessary acts carried out by Cellon Communications Technology (Shenzhen) Co.,Ltd. on our behalf of the Cellon Communications Technology (Shenzhen) Co.,Ltd. in connection with the Application shall have the same effect as acts of the Cellon Communications Technology (Shenzhen) Co.,Ltd.. The Cellon Communications Technology (Shenzhen) Co.,Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

Cellon (Shenzhen) Co.,Ltd. Date: 25 May, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Cellon Communications Technology (Shenzhen) Co.,Ltd. FCC ID: T38PCD2091D FCC Part 22H&24E& Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Cellon Communications Technology (Shenzhen) Co.,Ltd. requests that the following documents regarding this submission for FCC ID: T38PCD2091D be kept confidential: Exhibit Type File Name Block Diagram CONF APPENDIX T38PCD2091D_Block Diagram.pdf Schematics CONF APPENDIX T38PCD2091D_Schematics.pdf Operational Description CONF APPENDIX T38PCD2091D_Operational Description.pdf Part list CONF APPENDIX T38PCD2091D_BOM.pdf Tune-Up-Procedure CONF APPENDIX T38PCD2091D_Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Cellon Communications Technology (Shenzhen) Co.,Ltd. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Cellon Communications Technology (Shenzhen) Co.,Ltd. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Label Label Location

Cellon (Shenzhen) Co.,Ltd. Date: 25 May, 2010 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: T38PCD2091D Dear Sirs: Cellon Communications Technology (Shenzhen) Co.,Ltd. requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier T38PCD2091D. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22&24 for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, camera, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Cellon Communications Technology (Shenzhen) Co.,Ltd. proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Cellon (Shenzhen) Co.,Ltd. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Cellon Communications Technology (Shenzhen) Co.,Ltd. will add the FCC identifier "T38PCD2091D" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely, David Tian Program director Communications Technology (Shenzhen) Co.,Ltd.

Internal Photos

Report No.: SZ10050046E01 Page 2 of 16 TABLE OF CONTENTS 1. TEST CERTIFICATION ........................................................................................................... 3 2. GENERAL INFORMATION .................................................................................................... 4 2.1 EUT Description ......................................................................................................................... 4 2.2 Test Standards and Results........................................................................................................ 5 2.3 Facilities and Accreditations ..................................................................................................... 6 2.3.1 Facilities ................................................................................................................................... 6 2.3.2 Test Environment Conditions ................................................................................................... 6 2.3.3 Measurement Uncertainty ........................................................................................................ 6 3. TEST CONDITIONS SETTING .............................................................................................. 7 3.1 Test Mode .................................................................................................................................... 7 3.2 Test Setup and Equipments List ............................................................................................... 9 3.2.1 Conducted Emission ................................................................................................................. 9 3.2.2 Radiated Emission .................................................................................................................. 10 4. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 4.1 Conducted Emission................................................................................................................. 11 4.1.1 Requirement ........................................................................................................................... 11 4.1.2 Test Description ...................................................................................................................... 11 4.1.3 Test Result .............................................................................................................................. 11 4.1.3.1 GSM Test Mode ........................................................................................................................ 11 4.1.3.2 USB Test Mode ......................................................................................................................... 13 4.2 Radiated Emission .................................................................................................................... 14 4.2.1 Requirement ........................................................................................................................... 14 4.2.2 Test Description ...................................................................................................................... 14 4.2.3 Test Result .............................................................................................................................. 14 Change History Issue Date Reason for change 1.0 May 25, 2010 First edition Report No.: SZ10050046E01 Page 4 of 16 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ............................. : Cell phone Model Name ......................... : C2091D, DTV1188 Serial No............................... : (n.a, marked #1 by test site) Hardware Version ................. : P1 Software Version .................. : V1.3 temp Modulation Type .................. : GMSK Power Supply ....................... : Battery Model Name: BTR2096 Brand name: PCD Capacitance: 1050mAh Rated voltage: 3.7V Manufacturer: Shenzhen BAK Battery Co.,Ltd Ancillary Equipment 1 ......... : AC Adapter (Charger for Battery) Model Name: DSA-3RNA-05 FUS 050065 Brand Name: PCD Serial No.: (n.a. marked #1 by test site) Rated Input: 110-240V, 50/60Hz, Max48W Rated Output: 5.0V, 650mA, Max 3.25W Manufacturer: DEE VAN Electronics(ShenZhen) CO., LTD Manufacturer Address: 5th industrial District, Gong Ming Town, Baoan county, Shen Zhen, Guang Dong, CHINA Note 1: The EUT is a Cell phone; it supports GSM 850MHz, 1900MHz, GPRS and ISM 2.4GHz Bluetooth module. GSM 850MHz and 1900MHz are tested in this report. Note 2: The EUT is equipped with a T-Flash card slot; equipped with a special port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC Adapter and the USB Adapter Cable. The EUT outfits an inner Camera. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ10050046E01 Page 5 of 16 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-05 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ10050046E01 Page 6 of 16 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Electronic Product Quality Testing Center Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L1659. All measurement facilities used to collect the measurement data are located at Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen 518055 …

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2. RE
