T38PCD3031GSM850/900/1800/1900 UMTS850/1900 GPRS,EDGE,BT Mobile Phone

Cellon Communications Technology (Shenzhen) Co.,Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Oct 31, 2011
Application Purpose: Original Equipment
Date of Application: Oct 30, 2011
Equipment Note: GSM850/900/1800/1900 UMTS850/1900 GPRS,EDGE,BT Mobile Phone
Frequency Range: 1852.40000000 - 1907.60000000
Company: Cellon Communications Technology (Shenzhen) Co.,Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 1 Preface Thank you for purchasing this cellular phone. To guarantee your cellular phone works properly, please follow the instructions in this manual to prevent any possible incidents or malfunctions. Follow all safety warnings to avoid injury or property damage. Screen displays and illustrations in this user’s manual are designed to help you operate your phone to its optimum performance. We continuously strive to improve our products. Therefore, we reserve the rights to revise this user manual or withdraw it at any time without prior notice. Contents 1 Preface --------------------------------------------------------------------------------------------------------------------- --------- 1 2 Introduction ---------------------------------------------------------------------------------------------------------------- ------- 3 2.1 P HONE D ISPLAY .............................................................................................................................. ........... 3 2.2 K EY F UNCTIONS .............................................................................................................................. ........... 4 2.3 I CONS & S YMBOLS .............................................................................................................................. ........ 5 3 Getting Started ------------------------------------------------------------------------------------------------------------- ------ 7 3.1 I NSERTING THE SIM C ARD AND THE BATTERY ................................................................................................ 7 3.2 I NSERTING A T-F LASH (E XTERNAL M EMORY ) C ARD ...................................................................................... 11 3.3 T URNING THE PHONE ON ............................................................................................................................ 1 2 3.4 C HARGING THE B ATTERY ........................................................................................................................... 12 3.5 I MPORTANT P ASSWORD ............................................................................................................................. 13 3.6 K EYPAD L OCK AND U NLOCK ....................................................................................................................... 13 4 Text Entry ------------------------------------------------------------------------------------------------------------------ ------ 14 4.1 I NPUT M ETHOD .............................................................................................................................. ........... 14 4.2 P REDICTIVE TEXT ENTRY ............................................................................................................................ 1 4 4.3 M ULTI - TAP I NPUT .............................................................................................................................. ........ 15 4.4 N UMERIC I NPUT .............................................................................................................................. .......... 15 5 Calling --------------------------------------------------------------------------------------------------------------------- -------- 16 5.1 M AKING A C ALL .............................................................................................................................. .......... 16 5.2 A NSWERING A C ALL .............................................................................................................................. .... 16 6 Menu Functions -------------------------------------------------------------------------------------------------------------- -- 17 6.1 H OW T O U SE .............................................................................................................................. ............. 17 6.2 M AIN M ENU .............................................................................................................................. ................ 17 2 6.3 C ALL CENTER .............................................................................................................................. ............. 18 6.4 STK ........................................................................................................................... ............................. 18 6.5 F UN & G AMES .............................................................................................................................. ............ 18 6.6 M ULTIMEDIA .............................................................................................................................. ............... 19 6.7 P HONEBOOK ............................................................................................................................... .............. 24 6.8 M ESSAGING ............................................................................................................................... ............... 25 6.9 O RGANIZER .............................................................................................................................. ................ 27 6.10 S ERVICES .............................................................................................................................. ................ 29 6.11 S ETTINGS ............................................................................................................................... ................ 32 8 Troubleshooting ------------------------------------------------------------------------------------------------------------- -- 39 9 Safety Information and Notices------------------------------------------------------------------------------------------- 42 12 MONTH LIMITED WARRANTY ------------------------------------------------------------------------------------------- 50 3 2 Introduction 2.1 Phone Display 4 2.2 Key Functions Key Function Dial/Answer key Answer all call…

Text truncated - open the document above for the full version.

External Photos

Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 1. External Photograph of EUT Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 5 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 6 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 7 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 List of Accessory: Specification of Accessory AC Adapter Brand Name PCD and Movstar Model Name ASTC20-050065 Battery Brand Name PCD and Movstar Model Name BTR380 Earphone Type 1.20m non- shielded without core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 8 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 9 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 10 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 11 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 12 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 13 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 14 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 15 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 16 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031

Internal Photos

Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 17 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 3. Internal Photograph of EUT Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 18 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 19 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 20 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 21 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 22 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 23 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 24 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 25 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 26 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 27 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 28 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 Bluetooth Antenna Photographs of EUT Report No.: EP1O1401 Brand Name: PCD and Movstar / Model Name: C3031 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 29 of 29 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 WWAN Antenna

RF Exposure Info

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 33 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 FCC SAR Test Report Report No. : FA1O1401 FCC SAR Test Report APPLICANT : Cellon Communications Technology Co., Ltd EQUIPMENT : GSM850/900/1800/1900 UMTS850/1900 GPRS、 EDGE、BT mobile phone BRAND NAME : PCD and Movstar MODEL NAME : C3031,PCD1299,CL12299,TE1299, PCD1299ENPCD1299PE,PCD1299AL, PCD1299CL,PCD1299PO,PCD1299MV, PCD1299OM,PCD1299MX,PCD1299CA, TE1299PE,AL1299AL,CL1299CL,CL1299PO, MV1299MV,TE1299MX,C1030 FCC ID : T38PCD3031 STANDARD : FCC 47 CFR Part 2 (2.1093) IEEE C95.1-1991 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was received on Oct. 14, 2011 and completely tested on Oct. 25, 2011. We, SPORTON INTERNATIONAL (KUNSHAN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (KUNSHAN) INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL (KUNSHAN) INC. No. 3-2, PingXiang Road, Kunshan, Jiangsu Province, P.R.C. SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 33 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 FCC SAR Test Report Report No. : FA1O1401 Table of Contents Revision History .................................................................................................................................................................3 1. Statement of Compliance ...........................................................................................................................................4 2 Administration Data ....................................................................................................................................................5 2.1 Testing Laboratory .............................................................................................................................................5 2.2 Applicant ............................................................................................................................................................5 2.3 Manufacturer .....................................................................................................................................................5 2.4 Application Details .............................................................................................................................................5 3 General Information ....................................................................................................................................................6 3.1 Description of Device Under Test (DUT) ............................................................................................................6 3.2 Product Photos ..................................................................................................................................................6 3.3 Applied Standards .............................................................................................................................................7 3.4 Device Category and SAR Limits ......................................................................................................................7 3.5 Test Conditions ..................................................................................................................................................7 3.5.1 Ambient Condition ...................................................................................................................................7 3.5.2 Test Configuration ....................................................................................................................................7 4 Specific Absorption Rate (SAR) .................................................................................................................................8 4.1 Introduction ........................................................................................................................................................8 4.2 SAR Definition ...................................................................................................................................................8 5 SAR Measurement System .........................................................................................................................................9 5.1 E-Field Probe...................................................................................................................................................10 5.1.1 E-Field Probe Specification ...................................................................................................................10 5.1.2 E-Field Probe Calibration .......................................................................................................................10 5.2 Data Acquisition Electronics (DAE) ..................................................................................................................10 5.3 Robot ............................................................................................................................................................... 11 5.4 Measurement Server ....................................................................................................................................... 11 5.5 Phantom ..........................................................................................................................................................12 5.6 Device Holder .......................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : A1 of A1 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 FCC SAR Test Report Report No. : FA1O1401 Appendix A. Plots of System Performance Check The plots are shown as follows. Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 System Check_Head_835MHz_111024 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835_111024 Medium parameters used: f = 835 MHz; σ = 0.92 mho/m; ε r = 41.847; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.602 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 55.387 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 3.356 W/kg SAR(1 g) = 2.4 mW/g; SAR(10 g) = 1.59 mW/g Maximum value of SAR (measured) = 2.593 mW/g 0 dB = 2.590mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-25 System Check_Body_835MHz_111024 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_111025 Medium parameters used: f = 835 MHz; σ = 0.974 mho/m; ε r = 54.204; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.22, 6.22, 6.22); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.593 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.004 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 3.310 W/kg SAR(1 g) = 2.39 mW/g; SAR(10 g) = 1.6 mW/g Maximum value of SAR (measured) = 2.595 mW/g 0 dB = 2.590mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 System Check_Head_1900MHz_111024 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_111024 Medium parameters used: f = 1900 MHz; σ = 1.415 mho/m; ε r = 40.527; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(5.03, 5.03, 5.03); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM2; Type: SAM; Serial: TP-1477 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 10.890 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 90.456 V/m; Power Drift = -0.0015 dB Peak SAR (extrapolated) = 16.558 W/kg SAR(1 g) = 9.36 mW/g; SAR(10 g) = 4.94 mW/g Maximum value of SAR (measured) = 10.593 mW/g 0 dB = 10.590mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-25 System Check_Body_1900MHz_111024 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_111025 Medium parameters used: f = 1900 MHz; σ = 1.525 mho/m; ε r = 54.504; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(4.48, 4.48, 4.48); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM2; Type: SAM; Serial: TP-1477 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 12.615 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 91.374 V/m; Power Drift = 0.0023 dB Peak SAR (extrapolated) = 18.061 W/kg SAR(1 g) = 10.5 mW/g; SAR(10 g) = 5.57 mW/g Maximum value of SAR (measured) = 11.917 mW/g 0 dB = 11.920mW/g

RF Exposure Info

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : B1 of B1 TEL : 86-0512-5790-0158 Report Issued Date : Oct. 28, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : T38PCD3031 FCC SAR Test Report Report No. : FA1O1401 Appendix B. Plots of SAR Measurement The plots are shown as follows. Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 #13 GSM850_Right Cheek_Ch251 DUT: 1O1401 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_111024 Medium parameters used: f = 849 MHz; σ = 0.933 mho/m; ε r = 41.688; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.829 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.147 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 0.968 W/kg SAR(1 g) = 0.750 mW/g; SAR(10 g) = 0.514 mW/g Maximum value of SAR (measured) = 0.797 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 #13 GSM850_Right Cheek_Ch251_2D DUT: 1O1401 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_111024 Medium parameters used: f = 849 MHz; σ = 0.933 mho/m; ε r = 41.688; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.829 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.147 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 0.968 W/kg SAR(1 g) = 0.750 mW/g; SAR(10 g) = 0.514 mW/g Maximum value of SAR (measured) = 0.797 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 #14 GSM850_Right Tilted_Ch251 DUT: 1O1401 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_111024 Medium parameters used: f = 849 MHz; σ = 0.933 mho/m; ε r = 41.688; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.409 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.719 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.470 W/kg SAR(1 g) = 0.381 mW/g; SAR(10 g) = 0.277 mW/g Maximum value of SAR (measured) = 0.401 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 #15 GSM850_Left Cheek_Ch251 DUT: 1O1401 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_111024 Medium parameters used: f = 849 MHz; σ = 0.933 mho/m; ε r = 41.688; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY52, Version 52.6 (2); SEMCAD X Version 14.4.5 (3634) Ch251/Area Scan (41x81x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.796 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.560 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 0.894 W/kg SAR(1 g) = 0.706 mW/g; SAR(10 g) = 0.499 mW/g Maximum value of SAR (measured) = 0.746 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-10-24 #16 GSM850_Left Tilted_Ch251 DUT: 1O1401 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_111024 Medium parameters used: f = 849 MHz; σ = 0.933 mho/m; ε r = 41.688; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.39, 6.39, 6.39); Calibrated: 2011-5-20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18…

Text truncated - open the document above for the full version.

Contact Information

Applicant

maggie xu(TA manager)

[email protected]+86-755-86365704Fax: +86-755-86365686

Test Firm

SPORTON INTERNATIONAL(KUN SHAN)INC.Alex Chen

[email protected]886-3-3273456Fax: 886-3-3270973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	490.00 mW	4M12F9W	0.01 ppm

Confidentiality

Long Term

Grant Notes

Power listed is ERP for part 22 and EIRP for part 24. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. The antenna(s) used for this transmitter must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5cm separation distance between the device and the user�s body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest SAR value for this device as reported to the FCC is: Head: 0.75 W/kg, Body: 0.611 W/kg (GSM850 MHz) and Head: 0.595 W/kg, Body: 0.546 W/kg (GSM 1900 MHz), Head: 0.831 W/kg, Body: 0.475 W/kg (WCDMA V) and Head: 1.49 W/kg, Body: 0.861 W/kg (WCDMA II).
