T4K3208PLUSTwo Way Radio

Model name:3208plus Frequency:400-480MHz FCC ID:T4K3208PLUS TWO WAY RADIO THANK YOU! transceiver introduces innovative DSP digital signal processing technology, high level integration, it is including kinds of professional function, best stability and great reliability as well as exterior smooth lines, novel, fashionable, let it meet the instant communication technology and become a high battery (7.4V 1500mAh), It is best suit for property, building, shopping mall, outdoor work place with noisy surroundings. For your full comprehension of the varous excellent functions and maintenance, please read the user manual before use. NOTE: When programming the transceiver, read the factory initial data first, then rewrite the frequency and signaling etc., otherwise errors may occur because of different frequency band etc. transceiver will provide you with reliable, clear and efficient communication service. The The performance transveiver, It boasts power (5W), long distance, loud and clear timbre, capacity User Manual Applied to: 3208plus SAFETY INFORMATION FOR USER precautions to perform your obligation, prevent personal injury and ensure the safety of transceiver usage. Keep the transceiver and accessories away from children.1 . Please do not try to open or modify the transceiver without permission, non-professionals process 2. may also cause damage. Please use assorted battery and charger to avoid damage.3. Please use assorted antenna to ensure the communication distance.4. Please do not expose the transceiver to long period of direct sunlight, nor place it close to heat 5. appliances. Please do not put the transceiver in excessively dusty or humid areas.6. Do not use harsh chemicals, cleaning solvents to clean the transceiver.7. Do not transmit without antenna.8. When using this transceiver, we recommend transmitting for 1 minute then receiving for 4 minutes. 9. Continuous transmitting for long time or working in high power will heat the back of the transceiver. Do not place the transceiver’s hot back close to any surface of plastic. If any abnormal odor or smoke detected coming from the transceiver, turn off the power and take 10. off the battery pack and its case. Then contact local dealers. ATTENTION: All tips above apply to accessories of your transceiver. If any device can not work normally, please contact local dealers. If you use any accessories made by other companies, our Company does not guarantee the operability and safety of the transceiver. transceiver is excellently designed with advanced technology. Please observe the following the Professional FM Transceiver I UNPACKING .........................................................................................................................................1 Supplied Accessories .........................................................................................................................1 STANDARD ACCESSORIES/OPTIONAL ACCESSORIES .................................................................2 Standard Accessories ................................................................................................................................................2 BATTERY INFORMATION ....................................................................................................................3 How to Charge ...........................................................................................................................................................3 PREPARATION .....................................................................................................................................4 Installing / Removing the Battery ...............................................................................................................................4 Installing / Removing the Antenna .............................................................................................................................5 Installing / Removing the Belt Clip .............................................................................................................................5 Installing the Additional Speaker/ Microphone (Optional) .........................................................................................6 GETTING ACQUAINTED ......................................................................................................................7 Indicator Status and Beep ........................................................................................................................................9 [PF1] & [PF2] Key Default .........................................................................................................................................9 ....................................................................................................................................................10 BASIC OPERATIONS ...........................................................................................................................11 Switch on / off Transceiver ........................................................................................................................................11 Battery Capacity Enquiry ...........................................................................................................................................11 Adjusting Volume .......................................................................................................................................................11 Channel Selection .....................................................................................................................................................12 Receiving ...................................................................................................................................................................12 Monitor ....................................................................................................…

Text truncated - open the document above for the full version.

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian, China Tel: 86-592-22652998 Fax: 86-595-22656927 Jun.17.2014 To: Federal Communication Commission Authorization and Evaluation Division Subject: Attestation statement regarding the Land Mobile Radio frequency TYPE OF QEUIPMENT: Licensed Non-Broadcast Transmitter Held to Face FCC ID: T4K3208PLUS Dear Sir or Madam I attest that the product could program the frequence on computer through interface by manufacturer, is incapable of tuning, or readily being altered, by the end-user. Please contact the undersigned if you have any questions or need any further information. Regards Qixiang Electron Science& Technology Co., Ltd Signature: Name, Job Title and Dept.: Ken Xu / General Manager

Jun.17, 2014 Federal Communication Commission Authorization and Evaluation Division FCC ID: T4K3208PLUS Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List 5.Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Qixiang Electron Science& Technology Co., Ltd Contact person: Ken Xu Title: General manager

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian, China Tel: 86-592-22652998 Fax: 86-595-22656927 Jun.30.2014 To: Federal Communication Commission Authorization and Evaluation Division Subject: Attestation statement regarding the Land Mobile Radio TYPE OF QEUIPMENT: Licensed Non-Broadcast Transmitter Held to Face FCC ID: T4K3208PLUS Dear Sir or Madam I attest that the product has one antenna, one battery capacity and one body- worn and audio accessories. Please contact the undersigned if you have any questions or need any further information. Regards Alinco Incorporated, Electronics Division Signature: Name, Job Title and Dept.: Ken Xu / General Manager

Jun.17, 2014 Federal Communication Commission Authorization and Evaluation Division Subject: FCC ID: T4K3208PLUS Justification Letter for Expanded Frequency Range 400‐480MHz Gentlemen; You have asked Qixiang Electron Science& Technology Co., Ltd for justification to have the freq range 400‐480MHz appears on the face of the FCC Grant of Certification for a FCC Part 90 Certification. This frequency range is regarded as usual & customary by United States Federal Government and its various departments, user organizations and the military to appear on the face of the equipment Grant of Certification. Sincerely, Qixiang Electron Science& Technology Co., Ltd Ken Xu /General Manager

FCC ID Label Location FCC RF Warning Label TWO WAY RADIO Model: 3208plus FCC ID: T4K3208PLUS 518plus,518Turbo, 518G,518,3208 518R,3208R,318P

Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT

Report No.: AGC00589140502FE09 Page 1 of 55 FCC Part 90 Test Report Report No.: AGC00589140502FE09 FCC ID : T4K3208PLUS PRODUCT DESIGNATION : TWO WAY RADIO BRAND NAME : N/A MODEL NAME : 518plus, 3208plus, 518Turbo, 518G, 518, 3208, 518R, 3208R,318P CLIENT : Qixiang Electron Science & Technology Co., Ltd. Quanzhou DATE OF ISSUE : Jun.12, 2014 STANDARD(S) : FCC Part 90 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00589140502FE09 Page 2 of 55 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Jun.12, 2014Valid Original Report Report No.: AGC00589140502FE09 Page 3 of 55 VERIFICATION OF COMPLIANCE Applicant: Qixiang Electron Science & Technology Co., Ltd. Quanzhou Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Manufacturer: Qixiang Electron Science & Technology Co., Ltd. Quanzhou Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Product Designation: TWO WAY RADIO Brand Name: N/A Model Name 3208plus Series Model 518plus, 518Turbo, 518G, 518, 3208, 518R, 3208R,318P Model Difference All the same except for the model name. Date of Test: Jun.09, 2014 to Jun.11, 2014 WE HEREBY CERTIFY THAT: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C 63.4:2009. The sample tested as described in this report is in compliance with the FCC Rules Part 90 requirements The test results of this report relate only to the tested sample identified in this report. Tested by Freddie Duan Jun.12, 2014 Checked By Kidd Yang Jun.12, 2014 Authorized By Solger Zhang Jun.12, 2014 Report No.: AGC00589140502FE09 Page 4 of 55 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................. 6 1.1 PRODUCT DESCRIPTION ............................................................................................................. 6 1.3 TEST METHODOLOGY ................................................................................................................. 7 1.4 TEST FACILITY .............................................................................................................................. 7 1.5 SPECIAL ACCESSORIES .............................................................................................................. 7 1.6 EQUIPMENT MODIFICATIONS ..................................................................................................... 7 2. SYSTEM TEST CONFIGURATION ..................................................................................................... 8 2.1 EUT CONFIGURATION .................................................................................................................. 8 2.2 EUT EXERCISE ............................................................................................................................. 8 2.3 GENERAL TECHNICAL REQUIREMENTS .................................................................................... 8 2.4 CONFIGURATION OF TESTED SYSTEM .................................................................................... 9 3. SUMMARY OF TEST RESULTS ....................................................................................................... 10 4. DESCRIPTION OF TEST MODES ..................................................................................................... 11 5. CONDUCTED LIMITS ........................................................................................................................ 12 5.1 PROVISIONS APPLICABLE ......................................................................................................... 12 5.2 MEASUREMENT PROCEDURE .................................................................................................. 12 5.3 TEST SETUP BLOCK DIAGRAM ................................................................................................. 13 5.4 TEST EQUIPMENT USED ............................................................................................................ 13 5.5 TEST RESULT .............................................................................................................................. 14 6. FREQUENCY TOLERANCE .............................................................................................................. 16 6.1 PROVISIONS APPLICABLE ......................................................................................................... 16 6.2 MEASUREMENT PROCEDURE .................................................................................................. 16 6.3 TEST SETUP BLOCK DIAGRAM ................................................................................................. 17 6.4 TEST EQUIPMENT USED: ........................................................................................................... 17 6.5 TEST RESULT .............................................................................................................................. 18 7. EMISSION BANDWIDTH ................................................................................................................... 18 7.1 PROVISIONS APPLICABLE ......................................................................................................... 21 7.2 MEASUREMENT PROCEDURE .................................................................................................. 21 7.3 TEST SETUP BLOCK DIAGRAM ................................................................................................. 21 7.4 MEASUREMENT EQUIPMENT USED: ...................…

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP RADIATED EMISSION TEST SETUP CONDUCTED EMISSION TEST SETUP
