T4K3318UVELand Mobile Radio

User Manual TWO WAY RADIO Model Name:3318UVE FCC ID:T4K3318UVE THANK YOU! including kinds of professional function, best stability and great reliability as well as exterior smooth lines, novel, fashionable, sturdy and durable. are able to realize dual PTT functions. 51 groups of CTCSS encode/decode and 1 group of user-defined CTCSS encode/decode, 1024 groups of DCS encode/decode, 5TONE/2TONE/DTMF encode/decode, built-in radio functions, etc..It is a meticulous build functional and Multi frequency band radio for radio amateur and commercial users. 3318UVE will provide you with reliable, clear and efficient communication service. The 3318UVE introduces innovative DSP digital signal processing technology, high degree integration, it is The 3318UVE includes plenty of TX, RX channels, as well as UU,VV and UV standby modes which CAUTIONS 1. damage. 3.Please use assorted battery and charger to avoid damage. 4.Please use assorted antenna to ensure the communication distance. 5.Please avoid exposing the radio under the sunshine for a long time or storing it in too hot places. High temperature will shorten the life of electronic devices. 6.Please avoid storing the radio in the dusty, dirty and damp areas. 7.Please keep the radio dry. Do not wash radio with ardent chemicals and detergents. 8.Do not transmit without antenna. back close to any plastics. and its case. Then contact local dealers. 3318UVE is excellent designed with advanced technology. The following tips will be helpful for you in Keep the 3318UVE and accessories away from children. 2.Please do not try to open or modify the 3318UVE without permission, non-professionals operation may also cause 9.When using this radio, we recommend transmitting for 1 minute then receiving for 4 minutes. continuously transmitting for long time or working in high power will heat the back of the radio. Do not place the radio's hot performing your obligation under warranty and understanding the safety of radiousage. 10.If any abnormal smell or smoke coming from the radio, please turn off the power instantly and take off the battery UNPACKING table before discarding the packing material. If any items are missing or have been damaged during shipment, please contact with dealers immediately. ItemNumberQuantity AntennaQA09UV2 1 Li-ion Battery QB-26L1 Battery ChargerQBC-26L1 AC AdaptorQPS-01 1 Belt ClipBC01 1 Hand StrapGS01 1 Instruction Manual 1 Certificate 1 Supplied Accessories Please carefully unpack the radio. We recommend that you identify the items listed in the following STANDARD ACCESSORIES/ADDITIONAL ACCESSORIES Standard Accessories Antenna* 1 QA09UV2 Li-ion Battery QB-26L(1500mAh) Instruction Manual Battery Charger QBC-26L AC Adaptor (12V/500mA) QPS-01 Belt Clip BC01 Hand Strap GS01 BATTERY INFORMATION Charging Operation The battery is not charged at the factory, please charge it before use. Charge the battery for the first time after purchase or extended storage (more than 2 months) may not bring the battery to its normal operating capacity. After repeating fully charge/ discharge cycle for two or three times, the operating capacity will reach the best performance. The battery life is over when its operating time decreases even though it is fully and correctly charged. Replace the battery. Battery Charger Type Please use our company's designated charger, other models may cause explosion and injure people. After installing the battery, if the radio red light twinkles and remind changing battery, please charge the battery. Notice for Charging Battery Do not shortcircuit our company designated charger. Never attempt to remove the casing from the battery, ▲ we show no responsibility on the faulty caused by modifying freely without permission of our factory. The ambient temperature should be between 5 ▲°C and 40°C in charging. Charging outside this range may not fully charge the battery. Always switch off the transceiver equipped with a battery before charging. Otherwise, it will interfere ▲ with correct charging. To avoid interfering the charging procedure, please do not cut off the power or take out the battery ▲ during charging. Do not recharge the battery if it is already fully charged. This may shorten the life of the battery or ▲ How to Charge 1.Plug the AC adaptor into the AC outlet, then plug the cable of AC adaptor into the DC jack, the indicator lights orange for 1s and turns into GREEN---waits to charge. charger; make sure the battery terminals are in contact with the charging terminals well. LED turns into twinkling RED---pre-charging begins. 3.Pre-charging for about 5 minutes, LED twinkles stop then charging begins. 4.It takes about 4 hours to fully charge the battery, when LED turns into GREEN— full charged. BATTERY INFORMATION WARNING: When keys or ornamental chains and other electric metals contact with the battery terminals, the battery may cause damage or hurt bodies. If the battery terminal short circuit, it will generate a lot of heat, please be careful when you bring or use the battery, please put battery or radio into insulated container. Do not put it into metal container. damage the battery. ▲ Ac Input 2.Slide the battery orradio with battery into the Do not charge the battery or radio if it is damp. Dry it before charging to avoid danger. has been fully charged, the charger will charge battery in voltage consumption and fail to indicate correctly. BATTERY INFORMATION STATUS self-examine when power on (No battery)Pre-charging Charge normally Full Charged Trouble LED Orange (for 1 second) Green Red light twinkles for 5 minutes RedGreen Red twinkles for a long time 5.Charging Process: 6.LED Indicator: NOTE: Trouble means battery heating, battery short-circuit or charger short-circuit. Status LED Standby (self-examine orange lights 1second when power on) Pre-charging (pre-charging stage) Charging (charge in constant currency) Full charged (charge in constant voltage) Green light Red light twinkles for about 5 minutes RED light lightens…

Text truncated - open the document above for the full version.

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Tel: 86-592-22652998 Fax: 86-595-22656927 Sep.10.2014 To: Federal Communication Commission Authorization and Evaluation Division Subject: Attestation statement regarding the TWO RAY Radio frequency Applicant: Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Ken Xu / General Manager TYPE OF QEUIPMENT: Scanning Receiver FCC ID: T4K3318UVE Dear Sir or Madam I attest that the receiver is incapable of tuning, or readily being altered, by the user to operate with frequency bands allocated to the Domestic Public Cellular Telecommunuications Service in Part 22. Please contact the undersigned if you have any questions or need any further information. Regards Qixiang Electron Science& Technology Co., Ltd Signature: Name, Job Title and Dept.: Ken Xu / General Manager

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Tel: 86-592-22652998 Fax: 86-595-22656927 Sep.10.2014 To: Federal Communication Commission Authorization and Evaluation Division Subject: Attestation statement regarding the TWO RAY Radio frequency Applicant: Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Ken Xu / General Manager TYPE OF QEUIPMENT: Scanning Receiver FCC ID: T4K3318UVE Dear Sir or Madam I attest that the receiver is incapable of tuning, or readily being altered, by the user to operate with frequency bands allocated to the Domestic Public Cellular Telecommunuications Service in Part 22. Please contact the undersigned if you have any questions or need any further information. Regards Qixiang Electron Science& Technology Co., Ltd Signature: Name, Job Title and Dept.: Ken Xu / General Manager

Sep.10, 2013 Federal Communication Commission Authorization and Evaluation Division FCC ID: T4K3318UVE Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Qixiang Electron Science& Technology Co., Ltd Contact person: Ken Xu Title: General manager

External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID LABEL LOCATION FCC ID: T4K3318UVE

FCC ID Label Location FCC ID: T4K3318UVE

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Date: Sep.10, 2014 Statement We, Qixiang Electron Science& Technology Co., Ltd states that our device, FCC ID: T4K3318UVE, has no space to put the label except the battery compartment of this device. It is visible to the users as they purchase the products and install the battery. Regards Company: Qixiang Electron Science& Technology Co., Ltd Contact Person: Ken Xu Title: General Manager

Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT INTERNAL VIEW-6 OF EUT INTERNAL VIEW-7 OF EUT

Page 1 of 30 FCC ID T4K3318UVE TYPE OF AUTHORIZATION : Certification APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : TWO WAY RADIO BRAND NAME : N/A TEST MODEL :3318UVE, 398UVE, 3318UV, 398UV CLIENT : Qixiang Electron Science & Technology Co., Ltd. Quanzhou DATE OF ISSUE : Sep.09, 2014 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. FCC Test Report Report No.: AGC00589140801FE08 Report No.: AGC00589140801FE08 Page 2 of 30 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / Sep.09, 2014Valid Original Report Report No.: AGC00589140801FE08 Page 3 of 30 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ............................................................................................................... 4 2. PRODUCT INFORMATION ........................................................................................................................... 5 3. TEST FACILITY ............................................................................................................................................. 6 4. SUPPORT EQUIPMENT LIST ....................................................................................................................... 7 5. SYSTEM DESCRIPTION ............................................................................................................................... 7 6. SUMMARY OF TEST RESULTS ................................................................................................................... 8 7. FCC LINE CONDUCTED EMISSION TEST .................................................................................................. 9 7.1. TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST .......................................................... 9 7.2 .LIMITS OF LINE CONDUCTED EMISSION TEST .............................................................................. 9 7.3. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ............................................................ 9 7.4. PROCEDURE OF LINE CONDUCTED EMISSION TEST ................................................................. 10 7.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST ................................................................ 11 8. FCC RADIATED EMISSION TEST .............................................................................................................. 13 8.1. TEST EQUIPMENT OF RADIATED EMISSION ................................................................................ 13 8.2. LIMITS OF RADIATED EMISSION TEST .......................................................................................... 13 8.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ......................................................................... 13 8.4 PROCEDURE OF RADIATED EMISSION TEST ................................................................................ 14 8.5 TEST RESULT OF RADIATED EMISSION TEST .............................................................................. 15 9. ANTENNA CONDUCTED POWER FOR RECEIVERS ............................................................................... 19 APPENDIX 1 .................................................................................................................................................... 22 PHOTOGRAPHS OF TEST SETUP ................................................................................................................ 22 APPENDIX 2 .................................................................................................................................................... 23 PHOTOGRAPHS OF EUT ............................................................................................................................... 23 Report No.: AGC00589140801FE08 Page 4 of 30 1. VERIFICATION OF COMPLIANCE Applicant Qixiang Electron Science & Technology Co., Ltd. Quanzhou Address Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Manufacturer Qixiang Electron Science & Technology Co., Ltd. Quanzhou Address Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Product Designation TWO WAY RADIO Brand name N/A Test Model 3318UVE Series Model 398UVE, 3318UV, 398UV Difference description All the same except for the model name. Hardware Version V1.00 Software Version V1.00 Measurement Procedure ANSI C63.4: 2003 Date of test: Sep.01, 2014 to Sep.05, 2014 Deviation: None Condition of Test Sample Normal The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Tested by Freddie Duan Sep.09, 2014 Checked By Kidd Yang Sep.09, 2014 Authorized By Solger Zhang Sep.09, 2014 Report No.: AGC00589140801FE08 Page 5 of 30 2. PRODUCT INFORMATION The EUT is a TWO WAY RADIO designed for voice communication. It is designed by way of utilizing the FM modulation achieves the system operating. A major technical description of EUT is described as following: Communication Type Voice / Tone only Modulation FM RX Frequency Range 220-260MHZ Emission Type 10K5F8E Antenna Designation Detachable Power Supply DC 7.4V by battery Adapter Parameter Input: 100-240V, 50/60HZ, 0.3A Output: 5V, 0.5A I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with DC Input Port 1 1.5m, Unshielded Antenna Connect Port 1 0 1 Hand-Operated Micropho…

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP RADIATED TEST SETUP CONDUCTED EMISSION
