T4K588V2Land Mobile Radio

Qixiang Electron Science& Technology Co., Ltd

Click to zoom

Application Details

Equipment Class: CSR - Scanning Receiver
Date of Grant: Mar 04, 2014
Application Purpose: Original Equipment
Date of Application: Mar 04, 2014
Equipment Note: Land Mobile Radio
Frequency Range: 220.00000000 - 260.00000000
Company: Qixiang Electron Science& Technology Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

588 Land Mobile Radio FCC ID:T4K588V2 Do not attempt to configure your transceiver while driving,it is dangerous. This transceiver is designed for a 13.8V DC power supply. Don't use a 24V battery to power on the transceiver. Do not place the transceiver in excessively dusty, humid or wet areas, nor unstable surfaces. Please keep it away from interferential devices (such as TV, generator etc.) Do not expose the transceiver to long periods of direct sunlight nor place it close to heating appliances. If an abnormal odor or smoke is detected coming from the transceiver, turn OFF the power immediately. Contact an Anytone service station or your dealer. Do not transmit with high output power for extended periods; the transceiver may overheat. Please observe the following precautions to prevent fire, personal injury, or transceiver damage: Precautions Power CONTENTS New and Innovative Features .............................................. 1 Supplied Accessories/Optional Accessories ..................... 2 Supplied Accessories ....................................................................... 2 Optional Accessories ....................................................................... 2 Initial Installation .................................................................. 3 Mobile Installation ............................................................................ 3 DC Power Cable Connection ........................................................... 4 Power Supply Voltage Display ......................................................... 6 Antenna Connection ........................................................................ 6 Accessories Connections ................................................................. 7 Getting Acquainted .............................................................. 8 Front panel ....................................................................................... 8 Rear panel ....................................................................................... 9 Display ............................................................................................. 9 Microphone ...................................................................................... 10 Working Mode (Amateur Transceiver or Professional Transceiver) ........................................................................ 11 Basic Operations ................................................................. 12 Switching the Power On/Off ............................................................ 12 Adjusting the Volume ...................................................................... 12 Switch between VFO and Channel mode ....................................... 12 Adjusting Frequency/Channel Through Selector Knob .................... 12 Receiving ......................................................................................... 12 Transmitting ..................................................................................... 12 Transmitting Tone-Pulse .................................................................. 13 Transmitting Optional Signaling ...................................................... 13 Channel Edit .................................................................................... 13 Channel Delete ................................................................................ 13 Shortcut Operations ............................................................. 14 Squelch Off/Squelch Off Momentary................................................ 14 Squelch Level Setup ........................................................................ 14 Frequency/Channel Scan ................................................................ 14 Channel Scan .................................................................................. 14 CTCSS/DCS Encode and Decode Setup ........................................ 14 CTCSS Scan .................................................................................... 15 DCS Scan ........................................................................................ 15 ............................................................ 15 Compander (Decrease the background noise and enhance audio clarity .................................................................................................. 15 Offset Direction and Offset Frequency Setup .................................. 16 Keypad Lockout ............................................................................... 16 Current Voltage Enquiry ................................................................... 16 Auto-Dialer Setup ............................................................................. 16 Transmitting Edited DTMF Tones in the Auto-dialer Memory ........... 17 General Setting ..................................................................... 18 Frequency Channel Step Setup ....................................................... 18 DTMF, DTMF ANI, 2Tone or 5Tone Signaling .................................. 18 Sending 2-Tone Call ......................................................................... 19 Sending 5-Tone Call ......................................................................... 19 Sending DTMF call .......................................................................... 19 Signaling Combination Setup ........................................................... 19 CONTENTS TX OFF Setup .................................................................................. 21 Busy Channel Lockout ..................................................................... 21 Editing Channel Name ..................................................................... 21 Reverse TX/RX ................................................................................ 21 Talk Around ...................................................................................... 22 Voice Compander ....................................…

Text truncated - open the document above for the full version.

Attestation Statements

Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Tel: 86-592-22652998 Fax: 86-595-22656927 Mar.06.2014 To: Federal Communication Commission Authorization and Evaluation Division Subject: Attestation statement regarding the Land Mobile Radio frequency Applicant: Qixiang Electron Science& Technology Co., Ltd Qixiang Building, Tangxi Industrial Zone, Luojiang Quanzhou, Fujian China Ken Xu / General Manager TYPE OF QEUIPMENT: Scanning Receiver FCC ID: T4K588V2 Dear Sir or Madam I attest that the receiver is incapable of tuning, or readily being altered, by the user to operate within frequency bands allocated to the Domestic Public Cellular Telecommunuications Service in Part 22. Please contact the undersigned if you have any questions or need any further information. Regards Qixiang Electron Science& Technology Co., Ltd Signature: Name, Job Title and Dept.: Ken Xu / General Manager

Cover Letter(s)

Feb.17, 2014 Federal Communication Commission Authorization and Evaluation Division FCC ID: T4K588V2 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Qixiang Electron Science& Technology Co., Ltd Contact person: Ken Xu Title: General manager

Cover Letter(s)

External Photos

External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

ID Label/Location Info

FCC ID Label Location Land Mobile Radio Model: 588 FCC ID: T4K588V2

Internal Photos

Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT INTERNAL VIEW-6 OF EUT INTERNAL VIEW-7 OF EUT INTERNAL VIEW-8 OF EUT INTERNAL VIEW-9 OF EUT

Test Report

Report No.: AGC00589140202F1 Page 1 of 27 FCC ID : T4K588V2 TYPE OF AUTHORIZATION : Certification APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Land Mobile Radio BRAND NAME : N/A TEST MODEL : 588 CLIENT : Qixiang Electron Science & Technology Co., Ltd. Quanzhou DATE OF ISSUE : Feb.18, 2014 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. FCC Test Report Report No.: AGC00589140202F1 Report No.: AGC00589140202F1 Page 2 of 27 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / Feb.18, 2014Valid Original Report Report No.: AGC00589140202F1 Page 3 of 27 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ............................................................................................................... 4 2. PRODUCT INFORMATION ........................................................................................................................... 5 3. TEST FACILITY ............................................................................................................................................. 6 4. SUPPORT EQUIPMENT LIST ....................................................................................................................... 7 5. SYSTEM DESCRIPTION ............................................................................................................................... 7 6 SUMMARY OF TEST RESULTS .................................................................................................................... 8 7. FCC LINE CONDUCTED EMISSION TEST .................................................................................................. 9 7.1. TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST .......................................................... 9 7.2 .LIMITS OF LINE CONDUCTED EMISSION TEST .............................................................................. 9 7.3. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ............................................................ 9 7.4. PROCEDURE OF LINE CONDUCTED EMISSION TEST ................................................................. 10 7.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST ................................................................ 11 8. FCC RADIATED EMISSION TEST .............................................................................................................. 12 8.1. TEST EQUIPMENT OF RADIATED EMISSION ................................................................................ 12 8.2. LIMITS OF RADIATED EMISSION TEST .......................................................................................... 12 8.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ......................................................................... 12 8.4 PROCEDURE OF RADIATED EMISSION TEST ................................................................................ 13 8.5 TEST RESULT OF RADIATED EMISSION TEST .............................................................................. 14 APPENDIX 1 .................................................................................................................................................... 18 PHOTOGRAPHS OF TEST SETUP ................................................................................................................ 18 APPENDIX 2 .................................................................................................................................................... 19 PHOTOGRAPHS OF EUT ............................................................................................................................... 19 Report No.: AGC00589140202F1 Page 4 of 27 1. VERIFICATION OF COMPLIANCE Applicant Qixiang Electron Science & Technology Co., Ltd. Quanzhou Address Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Manufacturer Qixiang Electron Science & Technology Co., Ltd. Quanzhou Address Qixiang Building, Tangxi Industrial Zone, Luojiang District, Quanzhou, Fujian, China Product Designation Land Mobile Radio Brand name: N/A Test Model 588 Hardware Version: N/A Software Version: N/A Measurement Procedure ANSI C63.4: 2003 Date of test: Feb.13, 2014 to Feb.17, 2014 Deviation: None Condition of Test Sample Normal The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Test By: Wall Huang Feb.18, 2014 Reviewed By: Kidd Yang Feb.18, 2014 Authorized By: Solger Zhang Feb.18, 2014 Report No.: AGC00589140202F1 Page 5 of 27 2. PRODUCT INFORMATION The EUT is a VHF FM MOBILE TRANSCEIVER designed for voice communication. It is designed by way of utilizing the FM modulation achieves the system operating. A major technical description of EUT is described as following: Communication Type Voice / Tone only Modulation FM Emission Type 11KфF3E RX Frequency Range 220-260MHz Antenna Designation Detachable Power Supply DC 13.8V by DC source I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with DC Input Port 1 1.5m, Unshielded 1 Antenna Connect Port 1 0 1 Hand-Operated Microphone Connect Port 1 0.5m, Unshielded 1 Cigar-Plug connect Port 1 0 1 External Speaker connect Port 1 0 1 Report No.: AGC00589140202F1 Page 6 of 27 3. TEST FACILITY Facility Attestation of Global Compliance (Shenzhen) Co., Ltd Location: 2/F., Building 2, No.1-No.4, Chaxi Sanwei…

Text truncated - open the document above for the full version.

Test Setup Photos

APPENDIX IV PHOTOGRAPHS OF TEST SETUP RADIATED TEST SETUP
