T54AD312RECEIVERAD312RECEIVER

Notices 1. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. 2. This device complies with Part 15 of the FCC Rules. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Attestation for FCC Declaration of Conformity FCC ID: T54AD312RECEIVER Data: Aug 24, 2010 Please be notified that we, the undersigned, AnJieLun Electronic Techology Limited. declare that the product bears the above FCC ID is also complying with the requirements of FCC DoC. The test report is issued by an accredited lab, Interocean EMC Technology Corporation, address No. 5-2, Lin 1,Tin-Fu Tsun, Lin-Kou Hsiang,Taipei County 244,Taiwan, R.O.C. Which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827. Sincerely, Wang Gang Manager AnJieLun Electronic Techology Limited Phone: 86-755-84196309 Fax: 86-755-84193006 E-mail: [email protected]

External Photos of the EUT

Label and Label Location Label: Label location: AD312RECEIVER Model: SW322-YDW-RECEIVER FCC ID: T54AD312RECEIVER INPUT:5V 0.15A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos of the EUT

FCC PART 15 SUBPART C TEST REPORT FCC Part 15.249 Report Reference No......................: FCC ID..............................................: WE10080005 T54AD312RECEIVER Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Xiankun Ding Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Sep 10, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: AnJieLun Electronic Techology Limited Address.............................................: 2F, 12st, LONGBI INDUSTRIAL PARK BANTIAN VILLAGE, BUJI TOWN Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : AD312RECEIVER Trade Mark .......................................: / Model/Type reference.......................: SW322-YDW-RECEIVER Listed Models ..................................: / Modulation .......................................: GFSK Result................................................: Positive V1.0 Page 2 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER T E S T R E P O R T Test Report No. : WE10080005 Sep 10, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : AD312RECEIVER Model /Type : SW322-YDW-RECEIVER Listed Models : / Applicant : AnJieLun Electronic Techology Limited Address : 2F, 12st, LONGBI INDUSTRIAL PARK BANTIAN VILLAGE, BUJI TOWN Manufacturer : SHENZHEN ANJIELUN ELECTRONIC TECHNOLOGY LTD Address : 12ST LONGBI INDUSTRIAL PARK BUJI TOWN BANTIAN VILLAGE SHENZHEN CHINA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 16 4.3. Band Edge Measurement 24 4.4. 20dB Bandwidth Measurement 41 4.5. Antenna Requirement 45 5. TEST SETUP PHOTOS OF THE EUT .......................................... 46 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 48 V1.0 Page 4 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. V1.0 Page 5 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Aug 11, 2010 Testing commenced on : Aug 11, 2010 Testing concluded on : Aug 20, 2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) 2.3. Short description of the Equipment under Test (EUT) 2.4GHz device contains transmit and receive functions. For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ○ - supplied by the manufacturer ● - supplied by the lab ○ AC ADAPTER Manufacturer: Nalin Model No.: NLA10050W1A Power Cable: 150cm ○ USB Cable Length: 100cm Shield: shielded ○ A/V Cable Length: 120cm Shield : Unshielded V1.0 Page 6 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER ● TV Manufacturer: Hisense Model No.: TLM19V68 ● Notebook PC Manufacturer: DELL Model No.: PP11L ● Printer Manufacturer: HP Model No.: Laserjet 6L C3990A ● Gigabit Switch Manufacturer: D-Link Model No.: DGS-1005D 2.6. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: T54AD312RECEIVER filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. 2.7. Modifications No modifications were implemented to meet testing criteria. V1.0 Page 7 of 52 Report No.: WE10080005 FCC ID: T54AD312RECEIVER 3. TEST…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
