T9J-RN1022-MBluetooth Scanner

LED and Beep Signals Green LED Beeper Discoverable Blinks two None Mode* times every two seconds Connected* Blinks once None every two seconds Sleeping Does not blink None Good Scan Blinks once Beeps once Bar Code Blinks three Beeps three Memory Full times times Uploading Blinks twice per None second while the data is uploading Upload Blinks once Three beeps Complete that descend in pitch *Cordless Scanner only Setting Up Your Scanner 1. Obtain software from the seller. 2. Install the software. For instructions, see the Software User's Guide. 3. Install the batteries in the scanner. Follow the steps outlined in "Installing and Replacing Batteries." 4. For a cordless scanner install the Bluetooth adapter in the host device. The host device is the PC or PDA that will receive the bar codes from the scanner. For installation instructions, see the documentation provided with the adapter. 5. Configure the software to connect to the scanner. Note for Cordless Scanner: Place the scanner in discoverable mode by pressing the button. The default Bluetooth Passkey is 0000. 6. Verify that the scanner is working correctly, see the Software User's Guide. How to Scan 1. Aim Scanner - Hold the scanner at a slight angle to the bar code you wish to scan. (Fig. 1) 2. Press & Hold the Button on top of the scanner to make the red laser line appear. The laser line should cover the entire bar code symbol. 3. Release the Button after the Beep and the the green light blinks. This indicates that the scanner has successfully scanned the bar code symbol. Try the sample bar code now. Sample Bar Code Scanner Modes The scanner runs in two modes: real-time and store-and-forward. Real-time is when the scanner is connected to a cable or a Bluetooth host device. The scanner uploads the bar codes as you scan them. Batch mode is when the scanner is disconnected or out of range. It stores the bar codes in memory. When you plug in the scanner or move it back into range, the scanner automatically connects to the host device and uploads the stored bar codes. Three beeps indicates the scanner's memory is full. If this occurs, either connect the cable or move the scanner back into range of the Bluetooth host device and wake up the scanner by pushing the button. When connected, the scanner automatically uploads the saved bar codes and clears its memory. Installing and Replacing Batteries Use only AAA Alkaline batteries in your Scanner. Please remove the batteries when you are storing the scanner for more than 30 days. 1. Turn the scanner over so that the back faces up. 2. Remove the battery cover by pressing the button at the top of the cover, and moving the cover down. 3. If there are batteries in the scanner, remove them. 4. Insert the new batteries so that the positive end (+) is up on the outside batteries, and down on the middle battery. 5. Replace the battery cover by inserting the tabs at the top of the cover into the slots in the back of the scanner. Slide the cover up. Battery Life: Scanner - 100,000+ continuous scans or 24,000+ scans over 12 months at 100 scans/day Cordless - 76,000+ continuous scans or 16,000+ scans over 8 months at 100 scans/day Operator's Guide Laser Bar Code Scanner The Scanner is a breakthrough in affordable laser scanning. The scanner has the scanning performance of more expensive laser scanners, the convenience of hand-held portability, and the advantage of optional Bluetooth ® wireless technology. In store-and-forward mode you can capture approximately 500 (optional 4000) UPC bar code symbols, and then automatically upload them when you connect the scanner or move back into range. The Cordless Scanner has a 10 to 15 meter real-time operating range, and an unlimited store-and-forward range with automatic reconnection. Limited Warranty Manufacturer warrants that the scanner product will be free of defects in material and workmanship for one (1) year from the date of shipment. Manufacturer will, at its option, either repair, replace or refund the purchase price paid by buyer for the defective products. Such repair, replacement or refund shall be buyer's sole remedy in the event of Manufacturer's breach of this limited warranty. Repaired or replaced parts or product may include new, reconditioned or re-manufactured parts and equipment at Manufacturer's option. All costs associated with shipment to Manufacturer for warranty service, including but not limited to freight, duties, insurance and customs fees are buyer's responsibility. Manufacturer will pay the freight costs (duties, insurance, customs and any other fees are buyer's responsibility) associated with the return shipment to buyer. The method of shipment will be at Manufacturer's discretion. Repair or replacement of any parts or equipment does not extend the period of warranty provided for herein. THIS LIMITED WARRANTY IS MANUFACTURER'S ONLY WARRANTY. MANUFACTURER DOES NOT GIVE WARRANTIES OF MERCHANTABILITY OR WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE. To take advantage of this warranty, buyer should contact the seller not the Manufacturer. The warranty set forth herein does not cover and Manufacturer will have no obligations hereunder if any non-conformance is caused in whole or in part by; accident, transportation, neglect, misuse, alteration, modification, or enhancement of the products or incorporation, interfacing, attachment of any feature, program, or device to the Products by a person or entity other than Manufacturer, failure to provide a suitable installation environment, use of the products for other than the specific purpose for which the products are designed or any use of the product not in accordance with the Operator's Guide or other misuse or abuse of the product. Legal Notice The Bluetooth word, mark, and logo are owned by the Bluetooth SIG, Inc. and any use of such marks by Manufacturer is under license. This product is covered by one or more pending or issued patents. DOCUMENT NUMBER: DA0116777-001 Rev. A scan window LE…

Text truncated - open the document above for the full version.

May 16, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). [Remove this section if Regulatory Authority is not FCC] In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Michael Conrad Michael Conrad, President Roving Networks 431 Monterey Ave, Suite 5 Los Gatos, CA 95030 408-395-6539 phone 603-843-7550 fax www.rovingnetworks.com [email protected]

Roving Networks 431 Monterey Ave, Suite 5 Los Gatos, CA 95030 408-395-6539 phone 603-843-7550 fax May 23, 2006 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: T9J-RN1022-M, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation . These documents contain detailed system and equipment description and related information about the product that Roving Networks considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Roving Networks considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Michael Conrad Michael Conrad President Roving Networks

MICROVISION, INC.6222 185TH AVENUE N.E.REDMOND, WA. 98052MADE IN XXXXXXXXXPATENTS PENDINGMODEL XXXXXX MODEL BT2141-03 SN XXXXXXXXXXX IC: 6514A-RN22M FRAGILE MANUFACTURED XXXXXXXXX,200X MADE IN INDONESIA FCC ID: T9J-RN1022-M DO NOT TOUCH PROPOSED ID LABEL LOCATION

HIGH FREQUENCY SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 DATA SHEET Product specification – Jul 27, 2004 V.3 Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 2 www.yageo.com QUICK REFERENCE DATA DESCRIPTION VALUE Centre frequency (for different central frequency shifts) 2.45 GHz 02 type/03 type/Default/06 type/07 type Bandwidth ＞100 MHz Gain 4.1 dBi max. (depends on the special environment) VSWR 2.5 max. (depends on the special environment) Polarization Linear Azimuth beamwidth Omni-directional Impedance 50 Ω Power dissipation 1 W Operating temperature −55 to +85 °C Terminations NiSn Resistance to soldering heat 260 °C for 10 seconds (1) Bluetooth is a trademark owned by Telefonieaktiebolaget L M Ericsson, Sweden. The foil making process uses an environment- friendly aqueous-solvent technology that fully complies with today’s green-product design requirements. All terminations are lead-free. Packing materials can be recycled. ENVIRONMENTAL CARE DESCRIPTION This 2.45 GHz ceramic multilayer antenna has been designed to meet the requirements of the Bluetooth TM(1) and IEEE 802.11b/g wireless communications protocol. It consists of a rectangular block of low-dielectric ceramic material and is fabricated in a water-based non-toxic process. The antenna is capable of providing good connectivity using near 50 Ω microstrip directly onto the PC board. FEATURES • Designed for 2.45 GHz ISM-band • Simplifies antenna circuitry • NiSn lead-free terminations • Suitable for wave and reflow soldering • Supplied in tape on reel. APPLICATIONS • Telecommunications • Computing (PCs, printers, PDAs) • Wireless office data communications including WLAN • Consumer electronics (wireless headphones). Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 MECHANICAL DATA Fig.1. Component outline. L W IWA0011 T S 2 F C F C S 1 S 1 S 2 For dimensions see Table 1. Physical dimensions Table 1 antenna dimensions SYMBOL DETAILS DIMENSIONS (mm) L − 7.8 ±0.25 W − 3.6 ±0.20 T − 0.9 ±0.20 F feed termination 1.25 ±0.25 C − 0.4 ±0.20 S1 − 1.25 ±0.25 S2 − 1.25 ±0.25 2004 Jul 27 Rev.3 3 www.yageo.com Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 4 www.yageo.com Fig.2. Recommend dimension of solder lands IWA0012 L C C Antenna W F S 1 C S 2 C S 2 For dimensions see Table 2. FOOTPRINT DIMENSIONS Physical dimensions Table 2 The dimensions of antenna appearance SYMBOL DETAILS DIMENSIONS (mm) L − 9.0 ±0.1 W − 4.4 ±0.2 F feed pad 1.4 ±0.25 C − 0.8 ±0.20 S1 − 1.4 ±0.25 S2 − 1.6 ±0.25 ELECTRICAL CHARACTERISTICS DESCRIPTION VALUE Centre frequency (for different central frequency shifts) 2.45 GHz 02 type/03 type/Default/06 type/07 type Bandwidth ＞100 MHz Gain 4.1 dBi max. (depends on the special environment) VSWR 2.5 max. (depends on the special environment) Polarization Linear Azimuth beamwidth Omni-directional Impedance 50 Ω Power dissipation 1 W Operating temperature −55 to +85 °C Terminations NiSn Resistance to soldering heat 260 °C for 10 s Weight 0.0839 g/piece Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 5 www.yageo.com Physical dimensions Table 3 The dimensions of test board SYMBOL DETAILS DIMENSIONS (mm) L1 − 30 L2 − 10 W − 18 T − 0.8 T1 − 5.0 Fig.3. Typical FR4 test board. IWA0013 50 Ω transmisson line SMA connector Ground areaClear area L 1 L 2 W T Antenna chip T 1 For dimensions see Table 3. ANTENNA CHARACTERISTICS IN STANDRD TEST BOARD Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 6 www.yageo.com Fig.4 The measurements of typical SWR and return loss on standard test board . Pre-tuning reference only,after-tuning performance is depending on customer installation. Marker data: 1: Γ= −10 dB; f= 2.35 GHz 2: Γ= −10 dB; f= 2.56 GHz Marker data: 1: SWR= 2.5; f= 2.31 GHz 2: SWR= 2.5; f= 2.62 GHz 2.02.13.0 f (GHz) SWR 1.0 2.0 3.0 5.0 7.0 6.0 8.0 9.0 10.0 4.0 2.22.32.42.52.62.72.82.9 IWA0016 1 2 2.02.13.0 f (GHz) Γ (dB) −45 −40 −35 −25 −15 −20 −10 − 5 0 −30 2.22.32.42.52.62.72.82.9 IWA0038 1 2 Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 7 www.yageo.com Table 4 Max. and avg. antenna gain value of radiation pattern Plane XY (dBi) XZ(dBi) YZ (dBi) Vertical Pol. (max.) −8.9 −4.3 1.4 Vertical Pol. (avg.) −14.6 −9.8 −2.8 Horizontal Pol. (max.) 2.4 4.1 1.1 Horizontal Pol. (avg.) −3.7 −3.1 −5.2 Total gain (max.) 2.4 4.1 1.6 Total gain (avg.) −3.6 −2.8 −1.6 -10 −20 30 −4050 dBi −20−30−40−50 20304050 XYXZYZ dBi For antenna gain value see Table 4. Fig.6 Radiation pattern measurements Vertical Horizontal 0° −90°−270° −180° IWA0052 0° −270° −180° −180° 0° −90°−270°−90° − −-10 -10−−−− dBi XY plane YZ plane XZ plane − 270° −180° − 90° 0° 0° IWA0046 − 270° −180° − 90° 0° 0° − 270° −180° − 90° 0° 0° Fig.5 The definition of X-Y-Z plane and angle for radiation pattern Phycomp Product specification High Frequency SMD type antennas for BT/802.11b/g application 2.45 GHz size 7.8 × 3.6 2004 Jul 27 Rev.3 8 www.yageo.com 4 3 X X 1 1 5 0 0 2 4 5 Centre frequency Tolerance Size 7.8 x 3.6 x 0.9 mm15 Packing 11 13 reel: ∅180 mm; 7", blister, 1000 pcs bulk, 1000 pcs Material 1high-frequency material Family 43antenna IWA0040 2452.45 GHz Default 00 at 100 MHz Impedance Bandwidth 2252.25 GHz 02type 2302.30 GHz 03type 2602.60 GHz 06type 2702.70 GHz 07type Yageo part number EXAMPLE: CAN4311115002451K DESCRIPTION CODE Family CAN43 = antenna products Packing 11 = 180 mm/7” blister Materials 1 = high frequency materials Size 15 = 7.8 × 3.6 × 0.9 mm Tolerance 00 = large than 100 MHz Working Frequency (1) 245 = 2.45 GHz (Default) 220 = 2.25 GHz (02 type) 2…

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR BLUETOOTH SCANNER MODEL NUMBER: BT2141-03 FCC ID: T9J-RN1022-M REPORT NUMBER: 06U10284-1, REVISION B ISSUE DATE: JUNE 01, 2006 Prepared for ROVING NETWORKS 431 MONTEREY AVE, SUITE 5 LOS GATOS, CA 95030, USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 2 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By - 5/30/06 Initial Issue MH B 6/01/06 Updated EUT description, model number and section 5.1 DZ REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 3 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.4. SOFTWARE AND FIRMWARE .................................................................................................... 6 5.5. WORST-CASE CONFIGURATION AND MODE......................................................................... 6 5.6. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. LIMITS AND RESULTS ................................................................................................................. 10 7.1. ANTENNA PORT CHANNEL TESTS ......................................................................................... 10 7.1.1. 20 dB BANDWIDTH ......................................................................................................... 10 7.1.2. HOPPING FREQUENCY SEPARATION......................................................................... 14 7.1.3. NUMBER OF HOPPING CHANNELS ............................................................................. 16 7.1.4. AVERAGE TIME OF OCCUPANCY ............................................................................... 20 7.1.5. PEAK OUTPUT POWER .................................................................................................. 23 7.1.6. RF EXPOSURE REQUIREMENT..................................................................................... 27 7.1.7. AVERAGE POWER........................................................................................................... 27 7.1.8. CONDUCTED SPURIOUS EMISSIONS.......................................................................... 28 7.2. RADIATED EMISSIONS.............................................................................................................37 7.2.1. TRANSMITTER RADIATED SPURIOUS EMISSIONS ................................................. 37 7.2.2. TRANSMITTER RADIATED EMISSIONS ABOVE 1 GHZ .......................................... 40 7.2.3. WORST-CASE RADIATED EMISSIONS BELOW 1 GHz ............................................. 49 8. SETUP PHOTOS .............................................................................................................................. 51 REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 4 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: ROVING NETWORKS 431 MONTEREY AVE, SUITE 5 LOS GATOS, CA 95030, USA EUT DESCRIPTION: BLUETOOTH SCANNER MODEL: BT2141-03 SERIAL NUMBER: 01746 DATE TESTED: MAY 17- 20, 2006 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the r…

Text truncated - open the document above for the full version.

REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 51 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 52 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION X-AXIS FRONT PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 53 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. X-AXIS BACK PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 54 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS FRONT PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 55 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Y-AXIS BACK PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 56 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Z-AXIS FRONT PHOTO REPORT NO: 06U10284-1B DATE: JUNE 01, 2006 EUT: BLUETOOTH SCANNER FCC ID: T9J-RN1022-M Page 57 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. END OF REPORT Z-AXIS BACK PHOTO
